Preview Function warning light........2-17
Push starting .................. .6-9
Push-button ignition switch ..........5-9
R
Radio ..................... .4-46
Radio Car phone or CB radio ..........4-103
FM-AM-SAT radio with Compact Disc (CD)
player .................... 4-61
Rain-sensing auto wiper system .......2-33
Rapid air pressure loss .............5-6
Readiness for inspection/maintenance (I/M)
test ...................... .9-30
Rear Active Steer system ...........5-79
Rear Active Steer warning light ........2-17
Rear center seat belt ............. .1-19
Rear door lock, Child safety rear door lock . .3-6
Rear seats ................... .1-5
Rear window and outside mirror defroster
switch ..................... .2-35
Rear window wiper blades ..........8-21
Rearview monitor ............... .4-22
Recorders, Event data .............9-31
Registering your vehicle in another
country .................... .9-10
Remote controller (DVD) ...........4-102
Remote keyless entry system .........3-13
Reporting safety defects (US only) ......9-29
Roadside assistance program .........6-2
Rollover ..................... .5-5
Roof Moonroof ................. .2-56Roof rack
.................. 2-53
Safety
Child seat belts .............. .1-15
Reporting safety defects (US only) . . . 9-29
Towing safety ............... 9-23
S
Satellite radio operation ...........4-62
Seat adjustment Front power seat adjustment ........1-2
Front seats ..................1-2
Seat belt(s)
Child safety ................ .1-15
Infants .................... 1-15
Injured persons ............... 1-16
Larger
children ............... 1-15
Pre-crash seat belts with comfort
function ................... 1-16
Precautions on seat belt usage ......1-12
Pregnant women .............. 1-16
Rear center seat belt ...........1-19
Seat belt cleaning ..............7-5
Seat belt extenders ............1-19
Seat belt maintenance ..........1-20
Seat belt warning light and chime ....2-17
Seat belts .................. 1-12
Seat belts with pretensioners ......1-52
Shoulder belt height adjustment .....1-19
Small children ............... 1-15
Three-point type .............. 1-17
Seat synchronization function ........3-26
Seat(s) Climate controlled seats ..........2-41
Driver-side memory ............3-25Seats
.....................1-2
Security system (INFINITI Vehicle Immobilizer
System), Engine start .............2-31
Security system, Vehicle security system . .2-29
Selector lever Shift lock release ............. .5-16
Servicing air conditioner
(See automatic climate control) . . . .4-40 , 4-42
Servicing climate control ...........4-46
SETTING button ................ .4-13
Shift lock release Transmission ............... .5-16
Shifting, Automatic transmission .......5-13
Shoulder belt height adjustment, For front
seats ...................... .1-19
Small light indicator light ...........2-20
Snow mode switch .............. .2-43
Spare tire .................... .9-9
Spark plugs .................. .8-18
Speedometer .................. .2-6
Starting Before starting the engine .........5-12
Precautions when starting and driving . . 5-2
Starting
the engine ............ 5-12
STATUS button ................. .4-7
Status light, Front passenger air bag . . . .1-47
Steering Power steering fluid ............8-13
Power steering system ..........5-72
Rear Active Steer system .........5-79
Steering lock release malfunction
indicator .................. 2-23
Steering-wheel-mounted controls for
audio .................... 4-89
Tilt/telescopic steering ..........3-19
Storage .................... .2-46
10-6
—
—
10/19/09—tbrooks


Sun visors................... .3-21
Sunglasses holder .............. .2-47
Supplemental air bag warning labels . . . .1-53
Supplemental air bag warning light . .1-53 , 2-17
Supplemental restraint system ........1-40
Supplemental restraint system, Precautions
on supplemental restraint system ......1-40
Switch Autolight switch ............. .2-36
Continuous Damping Control mode
select switch ................ 2-44
Fog light switch .............. 2-40
Forward Collision Warning (FCW)
switch ................... 2-43
Hazard warning flasher switch ......2-40
Headlight switch .............. 2-36
Ignition switch automatic transmission
models ................... 5-13
Intelligent Brake Assist (IBA) OFF
switch ................... 2-44
Lane departure warning (LDW)
system ................... 2-42
Power door lock switch ...........3-5
Rear window and outside mirror
defroster switch .............. 2-35
Snow mode switch ............2-43
Turn signal switch ............. 2-39
Vehicle dynamic control (VDC) off
switch .................... 2-45
T
Tachometer ................... .2-7
Temperature gauge, Engine coolant
temperature gauge .............. .2-7Theft (INFINITI Vehicle Immobilizer System),
Engine start
.................. .2-31
Thigh extension ................ .1-4
Three-way catalyst ............... .5-2
Tilt/telescopic steering .............3-19
Tire pressure, Low tire pressure warning
light ...................... .2-15
Tire, Tire replacement indicator ........2-25
Tires Flat tire ................... .6-2
Low tire pressure warning system ....5-3
Spare tire ................. 8-38
Tire and Loading information label . . . 8-30
Tire chains ................. 8-35
Tire dressing ................7-4
Tire pressure ................ 8-28
Tire pressure monitoring system
(TPMS) ....................
5-3
Tire rotation ................ 8-36
Types of tires ............... 8-34
Uniform tire quality grading .......9-28
Wheel/tire size ...............9-9
Wheels and tires ............. 8-28
Tonneau cover (see cargo cover) .......2-51
Top tether strap child restraints .......1-24
Touch screen system ..............4-4
Towing Flat towing ................ .9-27
Tow truck towing .............. 6-11
Towing a trailer .............. 9-19
Towing safety ............... 9-23
TPMS, Tire pressure monitoring system . . . .5-3
TPMS, Tire pressure warning system .....6-2
Trailer towing ................. .9-19Transceiver, HomeLink
Universal
Transceiver .................. .2-60
Transmission Automatic transmission fluid (ATF) . . . .8-13
Driving with automatic transmission . . . 5-13
Transmission selector lever lock
release ................... 5-16
Transmitter
(See remote keyless entry system) ......3-13
Traveling or registering your vehicle in
another country ................ .9-10
Trip computer ................. .2-27
Trip odometer ................. .2-27
Turn signal switch .............. .2-39
U
Underbody cleaning .............. .7-3
Uniform tire quality grading .........9-28
V
Vanity mirror ................. .3-24
Vanity mirror lights ............. .2-59
Variable voltage control system . . .....8-17
Vehicle Dimensions ................ .9-10
Recovery (freeing a stuck vehicle) . . . . 6-14
Vehicle dynamic control (VDC) off
switch .................... 2-45
Vehicle dynamic control (VDC)
system ................... 5-77
Vehicle information and settings
(display) ...................

4-7
10-7
—
—
10/19/09—tbrooks


Vehicle identification number (VIN)......9-11
Vehicle loading information ..........9-15
Vehicle security system ............2-29
Ventilators .................. .4-39
Voice command (See Bluetooth Hands-Free
Phone System) ............4-105 , 4-121
Voice recognition system ..........4-129
Voice recognition, Alternate command
mode ..................... .4-142
Warning Dot matrix display .............2-21
Hazard warning flasher switch ......2-40
Lane departure warning (LDW)
system ................... 5-19
Tire pressure monitoring system
(TPMS) ....................5-3
Warning/indicator lights and audible
reminders .................. 2-12
W
Warning labels, Air bag warning labels . . .1-53
Warning light Air bag warning light ............1-53
All-wheel drive (AWD) warning light . . . 2-13
Anti-lock braking system (ABS) warning
light ..................... 2-13
Brake warning light ............2-13
Intelligent Key warning light .......2-15
Lane departure warning light .......2-15
Low tire pressure warning light .....2-15
Rear Active Steer warning light ......2-17
Seat belt warning light and chime ....2-17
Warning lights ................ .2-13Warranty, Emission control system
warranty
.................... .9-29
Washer switch, Windshield wiper and
washer switch ................ .2-32
Washing .................... .7-2
Waxing ..................... .7-2
Welcome light ................ .2-57
Wheel/tire size ................ .9-9
Wheels and tires ............... .8-28
Wheels and tires Care of wheels ............... .7-3
Cleaning aluminum alloy wheels .....7-3
Wheels, Rear Active Steer system ......5-79
Window washer fluid ............. .8-14
Window(s) Cleaning .................. .7-3
Power

windows .............. 2-53
Windshield wiper and washer switch . . . .2-32
Wiper Rain-sensing auto wiper system .....2-33
Windshield wiper and washer switch . . 2-32
Wiper blades ................ 8-19
X
Xenon headlights ............... .2-35
10-8
—
—
10/19/09—tbrooks


FUEL RECOMMENDATION:
VK50VE engine
Use unleaded premium gasoline with an octane
rating of at least 91 AKI (Anti-Knock Index)
number (Research octane number 96).
If premium gasoline is not available, unleaded
regular gasoline with an octane rating of 87 AKI
number (Research octane number 91) may be
temporarily used, but only under the following
precautions:
●Have the fuel tank filled only partially with
unleaded regular gasoline, and fill up with
unleaded premium gasoline as soon as pos-
sible.
● Avoid full throttle driving and abrupt accel-
eration.
However, for maximum vehicle performance, the
use of unleaded premium gasoline is recom-
mended.
VQ35HR engine
INFINITI recommends the use of unleaded pre-
mium gasoline with an octane rating of at least
91 AKI (Anti-Knock Index) number (Research
octane number 96).
If unleaded premium gasoline is not available,
you may use unleaded regular gasoline with an octane rating of at least 87 AKI number (Re-
search octane number 91), but you may notice a
decrease in performance.
CAUTION
●
Using a fuel other than that specified could
adversely affect the emission control sys-
tems, and may also affect warranty
coverage.
● Under no circumstances should a leaded
gasoline be used, since this will damage the
three way catalyst.
● Do not use E-85 fuel in your vehicle. Your
vehicle is not designed to run on E-85 fuel.
Using E-85 fuel can damage the fuel system
components and is not covered by the
INFINITI vehicle limited warranty.
ENGINE OIL RECOMMENDATION:
● Engine oil with API Certification Mark
● Viscosity SAE 5W-30
See “CAPACITIES AND RECOMMENDED
FUEL/LUBRICANTS” in the “9. Technical and
consumer information” section for engine oil
and oil filter recommendation.
COLD TIRE PRESSURES:
The label is typically located on the driver side
center pillar or on the driver’s door. For addi-
tional information, see “WHEELS AND TIRES” in
the “8. Maintenance and do-it-yourself” sec-
tion.
NEW VEHICLE BREAK-IN PROCEDURES
RECOMMENDATION:
During the first 1,200 miles (2,000 km) of
vehicle use, follow the recommendations out-
lined in the “BREAK-IN SCHEDULE” in the “5.
Starting and driving” section of this Owner’s
Manual. Follow these recommendations for the
future reliability and economy of your new
vehicle.
GAS STATION INFORMATION
—
—
10/19/09—tbrooks


2010 Infiniti FX35/FX50 Owner’s Manual
Printing: April 2010 (05) / OM0E 0S51U0 / Printed in U.S.A.
For your safety, read carefully and keep in this vehicle.2010 Infiniti FX35/FX50
