Always use Honda Heavy Duty
Brake Fluid DOT 3. If it is not
available, you should use only DOT 3
or DOT 4 f luid, f rom a sealed
container, as a temporary
replacement.
Using any non-Honda brake f luid can
cause corrosion and decrease the lif e
of the system. Have the brake
system f lushed and ref illed with
Honda Heavy Duty Brake Fluid
DOT 3 as soon as possible.
Brake f luid marked DOT 5 is not
compatible with your vehicle’s
braking system and can cause
extensive damage.The f luid level should be between
theMINandMAXmarksontheside
of the reservoir. If the level is at or
below the MIN mark, your brake
system needs attention. Have the
brake system inspected f or leaks or
worn brake pads.
Replace the brake f luid when this
service is indicated on a maintenance
message on the inf ormation display
or multi-inf ormation display
(depending on models).
Check the f luid level in the brake
f luid reservoir monthly.
Brake Fluid
Maint enance
485
MAX
MIN
——
y
y
(/yy
2009 Pilot

µµ
Check the level on the side of the
reservoir when the engine is cold.
The f luid should be between the
UPPER LEVEL and LOWER LEVEL.
If not add power steering f luid to the
UPPER LEVEL mark. Always use Honda Power Steering
Fluid. You may use another power
steering f luid as an emergency
replacement, but have the power
steering system f lushed and ref illed
with Honda PSF as soon as possible.
The timing belt should be replaced
at the intervals shown in the
maintenance minder schedule.
A low power steering f luid level can
indicate a leak in the system. Check
the f luid level f requently, and have
the system inspected as soon as
possible.
If you are not sure how to add
f luid, contact your dealer.
Pour the f luid slowly and caref ully so
you do not spill any. Clean up any
spills immediately; it could damage
components in the engine
compartment. Replace the timing belt every 60,000
miles (U.S.) or every 100,000 km
(Canada) if you regularly drive your
vehicle in any of the f ollowing
conditions:
In very high temperatures
(over 110°F, 43°C).
In very low temperatures
(under 20°F, 29°C).
Frequently tow a trailer.
Timing Belt
Power Steering Fluid
Power Steering Fluid, Timing Belt
486
UPPER LEVEL
LOWER LEVEL
Turning the steering wheel to f ull lef t
or right lock and holding it there can
damage the power steering pump.
——
y
y
(/y
y
2009 Pilot

CONT INUED
Your vehicle has halogen headlight
bulbs. When replacing a bulb, handle
it by its base, and protect the glass
f rom contact with your skin or hard
objects. If you touch the glass, clean
it with denatured alcohol and a clean
cloth.Open the hood.
If you need to change the
headlight bulb on the driver’s side,
remove the f ront end of the air
intake duct by pulling it out.
Theheadlightswereproperlyaimed
when your vehicle was new. If you
regularly carry heavy items in the
cargo area or pull a trailer,
readjustment may be required.
Adjustmentsshouldbedonebyyour
dealer or other qualif ied technician.
The high beam headlight bulb, the
low beam headlight bulb, and
daytime running light bulb are
replaced the same way.
1.
Headlight A iming
Replacing a Headlight/Daytime
Running L ight Bulb
Lights
Maint enance
487
CONNECTOR BULBHalogen headlight bulbs get very hot
when lit. Oil, perspiration, or a scratch
on the glass can cause the bulb to
overheat and shatter.
——
y
y
(/yy
2009 Pilot

Open the hood.
Remove the electrical connector
f rom the bulb by pushing on the
tab and pulling the connector
down.
Remove the bulb by turning it
about one-quarter turn
counterclockwise. Insert the new bulb into the hole,
and turn it one-quarter turn
clockwise to lock it in place.
Push the electrical connector onto
the new bulb.
Turn on the headlights to test the
new bulb.
Remove the socket by turning it
one-quarter turn counterclockwise.
Pull the bulb straight out of its
socket.
1.
2.
3.
2.
3.
4.
5.
6.
Lights
Replacing Front Turn Signal/
Parking and Side Marker L ight
Bulbs
488
SOCKET
BULB
CONNECTOR
BULB
CONNECTOR BULB
FRONT TURN SIGNAL/PARKING LIGHT
—
—
y

y
(/yy
2009 Pilot

Push the new bulb straight into
the socket until it bottoms.
Insert the socket back into the
headlight assembly. Turn it
clockwise to lock it in place.
Turn on the lights to make sure
the new bulb is working.Your vehicle uses halogen light
bulbs. When replacing a bulb, handle
it by its plastic case, and protect the
glass from contact with your skin or
hard objects. If you touch the glass,
clean it with denatured alcohol and a
clean cloth.
Place a cloth on the edge of the
cover. Remove the covers by
caref ully prying on the edge with a
small f lat-tipped screwdriver.
1.
4.
5.
6.
CONT INUED
Except LX models
Replacing a Front Fog L ight Bulb
Lights
Maint enance
489
BULB
SOCKET
SIDE MARKER LIGHT
Halogen bulbs get very hot when lit. Oil,
perspiration, or a scratch on the glass
can cause the bulb to overheat and
shatter.
—
—
y


y
(/yy
2009 Pilot

Remove the bulb f rom the f og
light assembly by turning it one-
quarter turn counterclockwise. Remove the electrical connector
f rom the bulb by pushing on the
tab and pulling the connector
down. Remove the f ront f og light
assembly f rom the bumper.Open the tailgate.
Remove the two mounting bolts
with an 8 mm wrench.
Remove the assembly f rom the
mounting holes by pulling it out. Place a cloth on the inner edge of
the assembly. Loosen the
assembly by caref ully prying on
thetopandsideedgeswithasmall
f lat-tipped screwdriver. Use your
fingers to further pull it loose.
1.
3.
3.
4. 2.
2.
4.
Lights
Replacing Rear Bulbs
(in Rear Pillar)
490
CONNECTOR
—
—
y

y
(/yy
2009 Pilot

Push the new bulb straight into
the socket until it bottoms.
Turn on the lights to make sure
the new bulb is working.
Put the socket back into the light
assembly, and turn it clockwise to
lock it in place.Each outside mirror has side turn
signal lights. The lights should be
replaced by your dealer.
Align the two tabs on the light
assembly with the mounting holes
and install the rear light assembly
in the rear pillar. Tighten the two
bolts securely.
Pull the bulb straight out of its
socket. Remove the socket by turning it
one-quarter turn counterclockwise. Determine which of the f our bulbs
is burned out: stop/taillight,
back-up light, side marker light, or
turn signal light.
6.
7. 8.
9.
10.
11.
5.
On Touring models
Lights
Side T urn Signal L ights
Maint enance
491
BULB
TABS
SOCKET
—
—
y

y
(/yy
2009 Pilot

Place a cloth on the edge of the
lens segment. Remove each lens
segment by caref ully prying on its
edge with a small f lat-tipped
screwdriver.
Remove the screw under each lens.
Pull the high-mount brake light
assembly out of the vehicle.Remove the lens f rom the light
assembly.
Pull the bulb straight out of its
socket. Push the new bulb straight
into the socket until it bottoms.Turn on the lights to make sure
the new bulb is working. Put the lens back on the light
assembly, and tighten the
mounting bolts securely.
Put the light assembly back into
the vehicle. Install the screws and
tighten them securely.
Reinstall the lens segments.
Remove the two mounting screws
f rom the light assembly.
1.
2.
3. 4.
5.7.
8.
9.
6.
Lights
Replacing a High-mount Brake
Light Bulb
492
LENS SEGMENT
—
—
y

y
(/yy
