2009 HONDA PILOT Owners Manual

µ
µ
µ Press and hold this
button for about 1 second to attract
attention; the horn will sound, and
the exterior lights will f lash f or about
30 seconds. To cancel panic mode,
press any other button on the remote
transmitter, or turn the ignition
switch to the ON (II) position. Panic
mode does not work when the key is
in the ignition switch.
Avoid dropping or throwing the
transmitter.
Protect the transmitter from
extreme temperature.
Do not immerse the transmitter in
any liquid.
If you lose a transmitter, the
replacement needs to be
reprogrammed by your dealer.
When you press the UNLOCK
button, the f ront and rear individual
map lights and the cargo area light,
depending on their switch positions,
will come on (see page ). If you
do not open any door or the tailgate,
the lights stay on for about 30
seconds, then go out. If you relock
thedoorsandthetailgatewiththe
remote transmitter before 30
seconds have elapsed, the lights will
go of f immediately.
If you push the same button again
while the tailgate is opening or
closing, three beeps sound, the
tailgate stops moving, reverses
direction and stops in the f ully
opened or f ully closed position.Press and hold the
TAILGATE button to open or close
the power tailgate. When the tailgate
begins to move, you will hear a beep,
and some f ront and rear lights will
flash.
Press this button f or about 1 second
to open the glass hatch. Even if the
glass hatch is open, the tailgate can
be locked with the remote
transmitter. 174
Except Touring models
On Touring models
Remote Transmitter
PA NIC
TAILGATE
GLASS HATCH RELEASE
Remote Transmitter Care
Inst rument s and Cont rols
149
——
y
y
(/y
y
2009 Pilot

Inside the transmitter, separate
the inner cover f rom the keypad
by releasing the two tabs on the
cover.
If it takes several pushes on the
button to lock or unlock the doors
and the tailgate, replace the battery
as soon as possible.
Battery type: CR1616
To replace the battery:Remove the screw at the base of
the transmitter with a small
Phillips-head screwdriver.
Separate the transmitter by prying
its middle seam with your
f ingernail. 3.
1.
2.
Remote Transmitter
Replacing the Transmitter
Battery
150
BATTERY
SCREW
——
y
y
(/y
y
2009 Pilot

´
As required by the FCC:This device complies with Part 15 of theFCC rules. Operation is subject to thef ollowing two conditions: (1) This devicemay not cause harmf ul interf erence, and(2) this device must accept anyinterf erence received, includinginterf erence that may cause undesiredoperation.
Changes or modif ications not expresslyapproved by the party responsible f orcompliance could void the user’sauthority to operate the equipment.
This device complies with IndustryCanada Standard RSS-210.Operation is subject to the f ollowing twoconditions: (1) this device may not causeinterf erence, and (2) this device mustaccept any interf erence that may causeundesired operation of the device. On Touring modelsRemove the old battery, and insert
a new battery into the back of the
cover with the side f acing down.
Install the parts in reverse order. An improperly disposed of battery
can hurt the environment.
Always conf irm local regulations
for battery disposal.
When you unlock the door with your
remote, each remote activates the
keyless memory settings related to
that remote. The driver’s ID (Driver
1orDriver2)isshownontheback
of each remote.
4.
5.
CONT INUED
Remote Transmitter
K eyless Memory Settings
Inst rument s and Cont rols
151
TM
——
y
y
(/y
y
2009 Pilot

µ
See pages f or important saf ety
inf ormation and warnings about how toproperly position the seats and seat-backs.
Except LX models
On EX-L and Touring modelsExcept EX-L and Touring models1413
The controls f or the power
adjustable front seats are on the
outside edge of each seat bottom.
You can adjust the seats with the
ignition switch in any position. Make
all seat adjustments bef ore you start
driving.
The passenger seat has the same
adjustments as the driver’s seat but
without any height and lumbar
adjustments.
The f ront passenger’s seat adjusts
manually.
Here are the settings activated with
the remote;
Driving position memory
(see page ). Customized settings
(see page ). When you unlock and open the
driver’s door with the remote
transmitter, the driver’s seat (except
the power lumbar feature) and
outside mirrors start to move to the
positions stored in memory. The
indicator in the related memory
button to the remote comes on.
95
171 Front Seat Power A djustments
Remote Transmitter, Seats
152
——
y
y
(/y
y
2009 Pilot

µ
See pages f or important saf ety
inf ormation and warnings about how toproperly position the seats and seat-backs.
Except EX-L and Touring models
13 14
Make all seat adjustments bef ore
you start driving.
Moves the seat forward
and backward. Moves the whole seat up
and f orward, or down
and backward. The front
of the seat also tilts up or
down at the same time.
Moves the f ront of the
seat up or down.
Raises or lowers the seat. Adjusts the seat-back
angle f orward or
backward.
Increases or decreases
the lumbar support.
(Driver’s seat only)
CONT INUED
Seats
FrontSeatManualAdjustments
Inst rument s and Cont rols
153
——
y

y
(/y
y
2009 Pilot

The height of your driver’s seat is
adjustable. To raise the seat,
repeatedly pull up the lever on the
outside of the seat cushion. To lower
the seat, push the lever down
repeatedly.
Once a seat is adjusted correctly,
rock it back and f orth to make sure it
is locked in position.
To adjust the seat f orward or
backward, pull up on the bar under
the seat cushion’s f ront edge. Move
the seat to the desired position, and
releasethebar.Trytomovetheseat
to make sure it is locked in position.
To change the seat-back angle, pull
up on the lever on the outside of the
seat bottom.
On LX models
Seats
Driver’s Seat Manual Height
Adjustment
154
——
y

y
(/y
y
2009 Pilot

CONT INUED
The head restraints adjust f or height.
You need both hands to adjust the
restraint.Donotattempttoadjustit
while driving. To raise it, pull upward.
To lower the restraint, push the
release button sideways, and push
the restraint down.
Your vehicle is equipped with head
restraints in all seating positions to
help protect you and your
passengers f rom whiplash and other
injuries.
They are most ef f ective when you
adjust them so the center of the back
of the occupant’s head rests against
the center of the restraint.
See page f or important saf etyinf ormation and a warning aboutimproperly positioning head restraints. 14
Seats
A djust ing t he Head Rest raint
Head Restraints
Inst rument s and Cont rols
155
RELEASE BUTTON
FRONT
SEAT-
BACK
LEGS CUSHION
——
y
y
(/y
y
2009 Pilot

The driver’s and f ront passenger’s
seats have active head restraints. If
the vehicle is struck severely f rom
the rear, the occupant properly
secured with the seat belt will be
pushed against the seat-back and the
head restraint will automatically
move forward.
To remove a head restraint f or
cleaning or repair, pull it up as f ar as
it will go. Push the release button,
then pull the restraint out of the seat-
back. When reinstalling a head restraint,
put the legs back in place. Then
adjust it to the appropriate height
while pressing the release button.
Make sure the head restraint locks
in position when you reinstall it.
Seats
A ct ive Head Rest raint s
Removing t he Head Rest raint
156
SECOND CENTER AND THIRD ROW
CUSHION
RELEASE BUTTON
LEGS
Failure to reinstall the head
restraints can result in severe
injury during a crash.
Always replace the head
restraints before driving.
——
y
y
(/y

y
2009 Pilot
