2009 HONDA PILOT Owners Manual

To open the sunglasses holder, push
on the f ront edge. Make sure the
holder is closed while you are driving.
Some larger styles of sunglasses
may not f it in the holder.
Each rear door has an integrated
sunshade. To use a sunshade, hold
the tab on the top, and pull the
sunshade all the way up. Insert the
holes on the sunshade into the hooks
on the window f rame.
Open the glove box by pulling up on
thehandle.Closeitwithafirmpush.
Lock or unlock the glove box with
the master key.
The glove box light comes on when
the parking lights are on.
CONT INUED
On Touring models
Interior Convenience Items
Sunglasses Holder
Integrated Sunshades
Glove Box
Inst rument s and Cont rols
181
TAB
HOOK
SUNGLASSES HOLDER
Push
An open glove box can cause
serious injury to your passenger
inacrash,evenifthe
passenger is wearing the seat
belt.
Always keep the glove box
closed while driving.
——
y

y
(/y
y
2009 Pilot

To use the sun visor, pull it down.
Whenusingthesunvisorforthe
side window, remove the support rod
f rom the clip, and swing it out.
In this position, the sun visor can be
adjusted by moving it on its slider.
Do not use the extended sun visor
over the inside mirror.
Make sure you put the sun visor
back in place when you are getting
into or out of the vehicle.
You may also store small items in
thisholder.Makesuretheyare
small enough to let the holder close
and latch, and that they are not
heavy enough to cause the holder to
pop open while driving.
The sunglasses holder uses a convex
mirror f or its bottom panel. You can
see all the vehicle passengers in this
mirror. To use the mirror, open the
sunglasses holder f ully, push it to the
f irst detent, and release it.On EX-L and Touring models
Interior Convenience Items
Sun Visor
Conversation Mirror
182
Slide
SUN VISOR
——
y
y
(/y
y
2009 Pilot

These hooks are not designed f or
large or heavy items.
Touseacoathook,slideitout
slightly, then pull it down.
Make sure the coat hook is f olded up
when you are not using it. This hook
is not designed f or large or heavy
items.
Tousethevanitymirrorontheback
of the sun visor, pull up the cover.
Interior Convenience Items
Coat Hooks
Vanity Mirror
Inst rument s and Cont rols
183
——
y

y
(/y
y
2009 Pilot

To use an accessory power socket,
the ignition switch must be in the
ACCESSORY (I) or ON (II) position.
Each socket is intended to supply
power f or 12 volt DC accessories
that are rated 120 watts or less (10
amps).
Your vehicle has a seat under tray
located under the f ront passenger
seat. Use the tray by pulling on the
f ront center edge of the tray.
Your vehicle has four accessory
power sockets. These are located on
the instrument panel, in the console
compartment, back of the center
console box, or behind the third row
seat on the passenger’s side.On Touring models
Interior Convenience Items
A ccessory Power Sockets
Seat Under T ray
184
——
y
y
(/y
y
2009 Pilot

CONT INUED
There is a 115 volt AC power outlet
inside the f ront console
compartment. To use the AC power
outlet, open the lids and open the
outlet cover. Insert the plug into the
receptacle slightly, turn it 90°
clockwise, then push in the plug all
the way.
None of the sockets will power an
automotive type cigarette lighter
element. Always run the engine when you use
the AC power outlet.
The maximum capacity f or this
power outlet is 115 volt AC at 100
watts or less. If you use an appliance
which requires more than 100 watts,
it automatically stops supplying the
power. If this happens, turn the
ignition switch of f and turn it on
again.
On vehicles with rear entertainment
system and on Touring models
Interior Convenience Items
AC Power Outlet
Inst rument s and Cont rols
185
REAR
——
y
y
(/y
y
2009 Pilot

The AC power outlet is not
designed f or electric appliances
which require high initial peak
wattage such as cathode-ray tube
type televisions, ref rigerators,
electric pumps, etc. It is also not
suitable f or devices that process
precise data such as medical
equipment or measuring instruments.
Any appliances that require an
extremely stable power supply such
as microcomputer-controlled electric
blankets, touch sensor lamps, etc.,
should not be connected to this
outlet. The hooks on the f loor of the cargo
area enable you to tie down items
stored in the back. Make sure all
stored items are secured bef ore
driving. The cargo net will separate the
storage area into two storage areas.
On the upper area, you can store
small and light items. You should
place heavy items in the lower
storage area. You can remove the
cargo net and store it under the
cargo f loor to make a larger cargo
area.
Interior Convenience Items
Cargo Hooks
Cargo Net
186
NOTE:
HOOK
——
y
y
(/y

y
2009 Pilot

Make sure to use the cargo net
securely hooked.The maximum load on the cargo net
is 22 lbs on U.S. models, and 10 kg
on Canadian models. This is shown
on a label back of the cargo area
f loor (see page ). To prevent
damage to the cargo net, do not
exceed the maximum load.
Make sure all items in the cargo area
are secured. Loose items can f ly
f orward and cause injury if you have
to brake hard (See
on page ).
When any of the third row seats are
f olded down, do not place any
objects on the cargo net. Make sure
to store the cargo net under the
cargo area f loor. It could be
unlatched during a crash. 188
408
Interior Convenience Items
Carrying Cargo
Inst rument s and Cont rols
187
Do not use this cargo net if the
third row seats are folded down.
Objects placed on the cargo net
could be thrown forward during
a crash or sudden stop and hurt
someone.
——
y
y
(/y
y
2009 Pilot

To prevent damage, do not place
more than 22 lbs (10 kg) on this
cargo net.
To prevent damage, do not place
more than 10 kg on this cargo net.
On U.S. modelsOn Canadian models
Interior Convenience Items
188
——
y
y
(/y
y
2009 Pilot
