P0703 STOP LAMP SWITCH
TM-45
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace damaged parts.
3.CHECK HARNESS BETWEEN STOP LAMP SWITCH AND BCM (PART 2)
Check continuity between BCM vehicle side harness connector terminal and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace damaged parts.
4.CHECK STOP LAMP SWITCH
Check stop lamp switch. Refer to TM-45, "
Component Inspection (Stop Lamp Switch)".
Is the inspection result normal?
YES >> Check the following.
 Harness for short or open between battery and stop lamp switch
 10A fuse (No. 7, located in fuse block)
NO >> Repair or replace stop lamp switch.
5.CHECK BCM
With CONSULT-III
1. Turn ignition switch OFF.
2. Connect BCM connector.
3. Turn ignition switch ON.
4. Select “BRAKE SW 1” in “Data Monitor” of “BCM” and verify the proper operation of ON/OFF. Refer to
BCS-42, "
Reference Value".
Is the inspection result normal?
YES >> GO TO 6.
NO >> Replace BCM. Refer to BCS-78, "
Removal and Installation".
6.DETECT MALFUNCTIONING ITEMS
Check TCM connector pin terminals for damage or loose connection with harness connector.
Is the inspection result normal?
YES >> Replace TCM. Refer to TM-153, "Exploded View".
NO >> Repair or replace damaged parts.
Component Inspection (Stop Lamp Switch)INFOID:0000000003848955
1.CHECK STOP LAMP SWITCH
Check continuity between stop lamp switch connector terminals.
Is the inspection result normal?
YES >> INSPECTION END
Stop lamp switch vehicle side harness connector BCM vehicle side harness connector
Continuity
Connector Terminal Connector Terminal
E115 2 M123 118 Existed
BCM vehicle side harness connector
GroundContinuity
Connector Terminal
M123 118 Not existed
Stop lamp switch connector terminal
Condition Continuity
Connector Terminal
E115 1 2Depressed brake pedal Existed
Released brake pedal Not existed

P0720 VEHICLE SPEED SENSOR CVT (SECONDARY SPEED SENSOR)
TM-57
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace damaged parts.
5.CHECK HARNESS BETWEEN TCM AND OUTPUT SPEED SENSOR (SECONDARY SPEED SENSOR)
(PART 2)
Check continuity between TCM vehicle side harness connector terminal and ground.
Is the inspection result normal?
YES >> GO TO 10.
NO >> Repair or replace damaged parts.
6.CHECK HARNESS BETWEEN IPDM E/R AND OUTPUT SPEED SENSOR (SECONDARY SPEED SEN-
SOR) (POWER) (PART 1)
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R connector.
3. Check continuity between IPDM E/R vehicle side harness connector terminal and output speed sensor
(secondary speed sensor) vehicle side harness connector terminal.
Is the inspection result normal?
YES >> GO TO 7.
NO >> Repair or replace damaged parts.
7.CHECK HARNESS BETWEEN IPDM E/R AND OUTPUT SPEED SENSOR (SECONDARY SPEED SEN-
SOR) (POWER) (PART 2)
Check continuity between IPDM E/R vehicle side harness connector terminal and ground.
Is the inspection result normal?
YES >> Check the following.
 Harness for short or open between ignition switch and IPDM E/R
 10 A fuse (No. 43, located in IPDM E/R)
 Ignition switch
NO >> Repair or replace damaged parts.
8.CHECK HARNESS BETWEEN TCM AND OUTPUT SPEED SENSOR (SECONDARY SPEED SENSOR)
(SENSOR GROUND) (PART 1)
1. Turn ignition switch OFF.
2. Disconnect TCM connector.
3. Check continuity between TCM vehicle side harness connector terminal and output speed sensor (sec-
ondary speed sensor) vehicle side harness connector terminal.
TCM vehicle side harness connectorOutput speed sensor (secondary speed sensor) ve-
hicle side harness connector
Continuity
Connector Terminal Connector Terminal
F2334F19 2Existed
TCM vehicle side harness connector
GroundContinuity
Connector Terminal
F23 34 Not existed
IPDM E/R vehicle side harness connectorOutput speed sensor (secondary speed sensor) ve-
hicle side harness connector
Continuity
Connector Terminal Connector Terminal
F1258F19 3Existed
IPDM E/R vehicle side harness connector
GroundContinuity
Connector Terminal
F12 58 Not existed

TM-86
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
P1701 TRANSMISSION CONTROL MODULE (POWER SUPPLY)
YES >> GO TO 6.
NO >> GO TO 2.
2.CHECK TCM GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Check continuity between TCM vehicle side harness connector terminals and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace damaged parts.
3.CHECK TCM POWER CIRCUIT
Check voltage between TCM vehicle side harness connector terminals and ground.
Is the inspection result normal?
YES >> GO TO 6.
NO >> GO TO 4.
4.CHECK HARNESS BETWEEN TCM AND IPDM E/R AND BETWEEN TCM AND BATTERY (PART 1)
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R connector.
3. Check continuity between TCM vehicle side harness connector terminals and IPDM E/R vehicle side har-
ness connector terminal.
4. Disconnect fuse block J/B connector.
5. Check continuity between TCM vehicle side harness connector terminals and fuse block J/B vehicle side
harness connector terminal.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace damaged parts.
TCM vehicle side harness connector
GroundContinuity
Connector Terminal
F235
Existed
42
TCM vehicle side harness connector
GroundCondition Voltage (Approx.)
Connector Terminal
F2346Ignition switch ON Battery voltage
Ignition switch OFF 0 V
48Ignition switch ON Battery voltage
Ignition switch OFF 0 V
45
Always Battery voltage
47
TCM vehicle side harness connector IPDM E/R vehicle side harness connector
Continuity
Connector Terminal Connector Terminal
F2346
F12 58 Existed
48
TCM vehicle side harness connector Fuse block J/B vehicle side harness connector
Continuity
Connector Terminal Connector Terminal
F2345
E103 12F Existed
47

P1701 TRANSMISSION CONTROL MODULE (POWER SUPPLY)
TM-87
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
5.CHECK HARNESS BETWEEN TCM AND IPDM E/R AND BETWEEN TCM AND BATTERY (PART 2)
Check continuity between TCM vehicle side harness connector terminals and ground.
Is the inspection result normal?
YES >> Check the following. If NG, repair or replace damaged parts.
 10A fuse (No. 43, located in IPDM E/R)
 10A fuse (No. 11, located in fuse block J/B)
 Ignition switch. Refer to PG-55, "
Wiring Diagram - IGNITION POWER SUPPLY -".
NO >> Repair or replace damaged parts.
6.DETECT MALFUNCTIONING ITEMS
Check TCM connector pin terminals for damage or loose connection with harness connector.
Is the inspection result normal?
YES >> Replace TCM. Refer to TM-153, "Exploded View".
NO >> Repair or replace damaged parts.
TCM vehicle side harness connector
GroundContinuity
Connector Terminal
F2345
Not existed 46
47
48

TM-106
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
SHIFT LOCK SYSTEM
YES >> Go to TM-106, "Diagnosis Procedure".
NO >> GO TO 2.
2. CHECK CVT SHIFT LOCK OPERATION
Attempt to shift the selector lever to any other position with the brake pedal depressed.
Can the selector lever be shifted to any other position?
YES >> INSPECTION END
NO >> Go to TM-106, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000003862439
1. CHECK POWER SOURCE
1. Turn ignition switch ON.
2. Check voltage between stop lamp switch vehicle side harness connector and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Check the following.
 Harness for short or open between fuse block J/B connector terminal 4F and stop lamp switch
harness connector terminal 3
 10 A fuse [No. 3, located in the fuse block J/B]
 Ignition switch
2.CHECK STOP LAMP SWITCH
Check stop lamp switch. Refer to TM-107, "
Component Inspection (Stop Lamp Switch)".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace stop lamp switch. Refer to BR-17, "
Exploded View".
3.CHECK HARNESS BETWEEN STOP LAMP SWITCH AND CONTROL DEVICE (PART 1)
1. Turn ignition switch OFF.
2. Disconnect stop lamp switch vehicle side harness connector and control device vehicle side harness con-
nector.
3. Check continuity between stop lamp switch vehicle side harness connector terminal and control device
vehicle side harness connector terminal.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace damaged parts
4.CHECK HARNESS BETWEEN STOP LAMP SWITCH AND CONTROL DEVICE (PART 2)
Check continuity between stop lamp switch vehicle side harness connector terminal and ground.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace damaged parts
Stop lamp switch vehicle side harness connector
GroundVoltage (Approx.)
Connector Terminal
E115 3 Battery Voltage
Stop lamp switch vehicle side harness connector Control device vehicle side harness connector
Continuity
Connector Terminal Connector Terminal
E115 4 M57 6 Existed
Stop lamp switch vehicle side harness connector
GroundContinuity
Connector Terminal
E115 4 Not existed

P0703 STOP LAMP SWITCH
TM-211
< COMPONENT DIAGNOSIS >[CVT: RE0F10A]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace damaged parts.
3.CHECK HARNESS BETWEEN STOP LAMP SWITCH AND BCM (PART 2)
Check continuity between BCM vehicle side harness connector terminal and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace damaged parts.
4.CHECK STOP LAMP SWITCH
Check stop lamp switch. Refer to TM-211, "
Component Inspection (Stop Lamp Switch)".
Is the inspection result normal?
YES >> Check the following.
 Harness for short or open between battery and stop lamp switch
 10 A fuse (No. 7, located in the fuse and fusible link block)
NO >> Repair or replace damaged parts.
5.CHECK BCM
With CONSULT-III
1. Turn ignition switch OFF.
2. Connect BCM connector.
3. Turn ignition switch ON.
4. Select “BRAKE SW 1” in “Data Monitor” mode for “BCM” and verify the proper operation of ON/OFF. Refer
to BCS-42, "
Reference Value".
Is the inspection result normal?
YES >> GO TO 6.
NO >> Replace BCM. Refer to BCS-78, "
Exploded View".
6.DETECT MALFUNCTIONING ITEMS
Check TCM connector pin terminals for damage or loose connection with harness connector.
Is the inspection result normal?
YES >> Replace TCM. Refer to TM-315, "Exploded View".
NO >> Repair or replace damaged parts.
Component Inspection (Stop Lamp Switch)INFOID:0000000003806385
1.CHECK STOP LAMP SWITCH
Check continuity between stop lamp switch connector terminals.
Is the inspection result normal?
YES >> INSPECTION END
Stop lamp switch vehicle side harness connector BCM vehicle side harness connector
Continuity
Connector Terminal Connector Terminal
E115 2 M123 118 Existed
BCM vehicle side harness connector
GroundContinuity
Connector Terminal
M123 118 Not existed
Stop lamp switch connector
Condition Continuity
Connector Terminal
E115 1 2Depressed brake pedal Existed
Released brake pedal Not existed

P0705 PARK/NEUTRAL POSITION SWITCH
TM-213
< COMPONENT DIAGNOSIS >[CVT: RE0F10A]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
P0705 PARK/NEUTRAL POSITION SWITCH
DescriptionINFOID:0000000003806386
The PNP switch detects the selector lever position and sends a signal to the TCM.
DTC LogicINFOID:0000000003806387
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
If “DTC CONFIRMATION PROCEDURE” has been previously performed, always turn ignition switch
OFF. Then wait at least 10 seconds before performing the next test.
Perform the following procedure to confirm the malfunction is eliminated after the repair.
1.CHECK DTC DETECTION
With CONSULT-III
1. Turn ignition switch ON.
2. Select “Data Monitor” mode for “TRANSMISSION”.
3. Start engine.
4. Drive vehicle and maintain the following conditions for at least 2 consecutive seconds.
With GST
Follow the procedure “With CONSULT-III”.
Is
“P0705 PNP SW/CIRC” detected?
YES >> Go to TM-213, "Diagnosis Procedure".
NO >> Check intermittent incident. Refer to GI-35, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000003806388
1.CHECK POWER SOURCE
1. Turn ignition switch OFF.
2. Disconnect PNP switch connector.
3. Turn ignition switch ON.
4. Check voltage between PNP switch vehicle side harness connector terminal and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Check the following. If NG, repair or replace damaged parts.
 Harness for short or open between ignition switch and PNP switch
 10 A fuse (No. 4, located in the fuse block J/B)
DTCItem
(CONSULT-III screen term)Malfunction is detected when... Possible cause
P0705 PNP SW/CIRCTCM does not receive the cor-
rect voltage signal (based on
the gear position) from the
switch. Harness or connectors
(PNP switches circuit is open
or shorted.)
 PNP switch
VEHICLE SPEED : More than 10 km/h (6 MPH)
ENG SPEED : More than 450 rpm
ACC PEDAL OPEN : More than 1.0/8
PNP switch vehicle side harness connector
GroundVoltage (Approx.)
Connector Terminal
Battery voltage
F57 3

TM-220
< COMPONENT DIAGNOSIS >[CVT: RE0F10A]
P0715 INPUT SPEED SENSOR (PRI SPEED SENSOR)
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace damaged parts.
5.CHECK HARNESS BETWEEN TCM AND INPUT SPEED SENSOR (PRIMARY SPEED SENSOR) (PART
2)
Check continuity between TCM vehicle side harness connector terminal and ground.
Is the inspection result normal?
YES >> GO TO 10.
NO >> Repair or replace damaged parts.
6.CHECK HARNESS BETWEEN IPDM E/R AND INPUT SPEED SENSOR (PRIMARY SPEED SENSOR)
(POWER) (PART 1)
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R connector.
3. Check continuity between IPDM E/R vehicle side harness connector terminal and input speed sensor (pri-
mary speed sensor) vehicle side harness connector terminal.
Is the inspection result normal?
YES >> GO TO 7.
NO >> Repair or replace damaged parts.
7.CHECK HARNESS BETWEEN IPDM E/R AND INPUT SPEED SENSOR (PRIMARY SPEED SENSOR)
(POWER) (PART 2)
Check continuity between IPDM E/R vehicle side harness connector terminal and ground.
Is the inspection result normal?
YES >> Check the following.
 Harness for short or open between ignition switch and IPDM E/R
 10 A fuse (No. 43, located in the IPDM E/R)
 Ignition switch
NO >> Repair or replace damaged parts.
8.CHECK HARNESS BETWEEN TCM AND INPUT SPEED SENSOR (PRIMARY SPEED SENSOR) (SEN-
SOR GROUND) (PART 1)
1. Turn ignition switch OFF.
2. Disconnect TCM connector.
3. Check continuity between TCM vehicle side harness connector terminal and input speed sensor (primary
speed sensor) vehicle side harness connector terminal.
TCM vehicle side harness connectorInput speed sensor (primary speed sensor) vehicle
side harness connector
Continuity
Connector Terminal Connector Terminal
F2333F55 2Existed
TCM vehicle side harness connector
GroundContinuity
Connector Terminal
F23 33 Not existed
IPDM E/R vehicle side harness connectorInput speed sensor (primary speed sensor) vehicle
side harness connector
Continuity
Connector Terminal Connector Terminal
F1258F55 3Existed
IPDM E/R vehicle side harness connector
GroundContinuity
Connector Terminal
F12 58 Not existed
