2007 SUZUKI XL7 Owners Manual

6-15 MAINTENANCE SCHEDULE
78J00-03E
Automatic Transaxle Shift Lock Control
System Check
1) Before you start, be sure you have
enough room around the vehicle. It
should be parked on a level surface.
2) Firmly apply the parking brake. Refer to
“Parking Brake” in “Starting and Oper-
ating Your Vehicle” in the “Features
and Controls” section.
Be ready to apply the regular brake
immediately if the vehicle begins to
move.
3) With the engine off, turn the ignition to
RUN, but do not start the engine. With-
out applying the regular brake, try to
move the shift lever out of PARK (P)
with normal effort. If the shift lever
moves out of PARK (P), contact your
dealer for service.Ignition Transaxle Lock Check
While parked, and with the parking brake
set, try to turn the ignition to LOCK in each
shift lever position.
 The ignition should turn to LOCK only
when the shift lever is in PARK (P).
 The ignition key should come out only in
LOCK.
Contact your dealer if service is required.
Parking Brake and Automatic Transaxle
Park (P) Mechanism Check
Park on a fairly steep hill, with the vehicle
facing downhill. Keeping your foot on the
regular brake, set the parking brake.
 To check the parking brake’s holding
ability: With the engine running and tran-
saxle in NEUTRAL (N), slowly remove
foot pressure from the regular brake
pedal. Do this until the vehicle is held by
the parking brake only. To check the PARK (P) mechanism’s
holding ability: With the engine running,
shift to PARK (P). Then release the
parking brake followed by the regular
brake.
Contact your dealer if service is required.
Underbody Flushing Service
At least every spring, use plain water to
flush any corrosive materials such as win-
ter road salt from the underbody. Take
care to clean thoroughly any areas where
mud and other debris can collect.
WARNING
When you are doing this inspection,
the vehicle could move suddenly. If
the vehicle moves, you or others
could be injured.
WARNING
When you are doing this check, your
vehicle could begin to move. You or
others could be injured and property
could be damaged. Make sure there
is room in front of your vehicle in
case it begins to roll. Be ready to
apply the regular brake at once
should the vehicle begin to move.

6-16 MAINTENANCE SCHEDULE
78J00-03E
Recommended Fluids and LubricantsFluids and lubricants identified below by name, part number, or specification can be obtained from your dealer.
Usage Fluid/Lubricant
Engine OilEngine oil which meets Standard GM6094M and displays the American Petroleum Institute Certi-
fied for Gasoline Engines starburst symbol. The proper viscosity for your vehicle’s engine is an
SAE 5W-30 synthetic oil or an SAE 0W-30 oil.
Engine Coolant 50/50 mixture of clean, drinkable water and use only DEX-COOL
® Coolant.
Hydraulic Brake System Delco
® Supreme 11 Brake Fluid or equivalent DOT-3 brake fluid.
Automatic Transaxle Use only T-IV Automatic Transmission Fluid (Part No. SUZUKI ATF 3317 or Mobil ATF 3309).
Hood Latch Assembly,
Secondary Latch, Pivots, Spring
Anchor, and Release PawlLubricate Aerosol type lubricant meeting requirements of NLGI #2, Category LB or GC-LB.
Key Lock Cylinders, Hood and
Door Hinges,
Rear Folding SeatMulti-Purpose Lubricant, Superlube.
Weatherstrip Conditioning Weatherstrip Lubricant or Dielectric Silicone Grease.

6-17 MAINTENANCE SCHEDULE
78J00-03E
Normal Maintenance Replacement PartsReplacement parts identified below by name, part number, or specification can be obtained from your dealer.Engine Drive Belt Routing3.6L V6 Engine
1686383Part SUZUKI Part No.
Engine Air Cleaner/Filter13780–78J00
Engine Oil Filter16510–78J00
Passenger Compartment Air Filter Element 95861–78J00
Replacement Battery33610–78J00
Spark Plugs1119A–78J00
Windshield Wiper Blades Driver’s Side – 24 inches (60.0 cm) 38340–78J00
Passenger’s Side – 19 inches (47.5 cm) 38340–78J10
Rear – 13.0 inches (33.0 cm) 38820–78J00

6-18 MAINTENANCE SCHEDULE
78J00-03E
Maintenance Record except CANADAAfter the scheduled services are performed, record the date, odometer reading, who performed the service, and the type of services per-
formed in the boxes provided. Refer to “Maintenance Requirements” in this section. Any additional information from “Owner Checks and
Services” in this section can be added on the following record pages. You should retain all maintenance receipts.
Maintenance record
DateOdometer
ReadingServiced ByMaintenance I or
Maintenance IIServices Performed

6-19 MAINTENANCE SCHEDULE
78J00-03E
MEMO

GENERAL INFORMATION
7
78J00-03E
GENERAL INFORMATIONIdentification Numbers ....................................................... 7-1
Safety Certification Label ................................................... 7-1
Emission Compliance Label (for U.S.A.) ........................... 7-2
Warranties ............................................................................ 7-2
On-Board Vehicle Computers and Event Data
Recorders ............................................................................ 7-2
Reporting Safety Defects ................................................... 7-3

7-1 GENERAL INFORMATION
78J00-03E
Identification NumbersVehicle Identification Number
60G152
The Vehicle Identification Number (VIN)
may be found in the location shown in the
above illustrations. This number is used to
register the vehicle. It is also used to assist
your dealer when ordering parts or refer-
ring to special service information.
Engine Serial Number
60G128
The engine serial number is stamped on
the cylinder block as shown in the above
illustration.
Safety Certification Label
52D059
This label contains important safety-
related information about your vehicle. The
label is located on the driver’s door lock pil-
lar.
EXAMPLE
(for some vehicles)

7-2 GENERAL INFORMATION
78J00-03E
Emission Compliance Label
(for U.S.A.)
60A412
The EPA emission compliance label is
located under the hood. It provides much
of the information needed to perform an
engine tune-up on your vehicle.
WarrantiesThe warranties covering your vehicle are
explained in a separate New Vehicle War-
ranty Information booklet given to you at
the time of sale. Please read this booklet
carefully so you can understand your rights
and responsibilities.For U.S.A.The following warranties are provided with
your vehicle:
 New Vehicle Limited Warranty
 Limited Warranty For SUZUKI Parts or
Accessories
 Emission Components Defect Warranty
 Emission Performance Warranty
On-Board Vehicle Computers
and Event Data RecordersYour vehicle, like other modern motor
vehicles, has a number of sophisti-
cated computer systems that monitor
and control several aspects of the
vehicle’s performance. Your vehicle
uses on-board vehicle computers to
monitor emission control components
to optimize fuel economy, to monitor
conditions for airbag deployment and,
if so equipped, to provide anti-lock
braking and to help the driver control
the vehicle in difficult driving situa-
tions. Some information may be stored
during regular operations to facilitate
repair of detected malfunctions; other
information is stored only in a crash
event by computer systems, such as
those commonly called event data
recorders (EDR).
In a crash event, computer systems,
such as the Airbag Sensing and Diag-
nostic Module (SDM) in your vehicle
may record information about the con-
dition of the vehicle and how it was
operated, such as data related to
engine speed, brake application, throt-
tle position, vehicle speed, safety belt
usage, airbag readiness, airbag per-
formance, and the severity of a colli-
sion. This information has been used
to improve vehicle crash performance
