2007 SUZUKI XL7 Owners Manual

1-29 SEATS AND RESTRAINT SYSTEMS
78J00-03E
the child restraint with the top tether
and the safety belts. Refer to your child
restraint manufacturer instructions and
the instructions in this manual.
1. Find the lower anchors for the
desired seating position.
2. Put the child restraint on the seat.
3. Attach and tighten the lower attach-
ments on the child restraint to the
lower anchors.
2) If the child restraint manufacturer rec-
ommends that the top tether be
attached, attach and tighten the top
tether to the top tether anchor, if your
vehicle has one. Refer to the child
restraint instructions and the following
steps:
1. Find the top tether anchor.
2. Route, attach and tighten the top
tether according to your child
restraint instructions and the follow-
ing instructions:
1549926
If the position you are using has an adjust-
able head restraint and you are using a
dual tether, route the tether around the
head restraint.
1549824
If the position you are using has an adjust-
able head restraint and you are using a
single tether, raise the head restraint and
route the tether under the head restraint
and in between the head restraint posts.
3) Push and pull the child restraint in dif-
ferent directions to be sure it is secure.Securing a Child Restraint in a Rear
Seat PositionThere is limited space in the third row rear
seating area. If you want to secure a child
restraint in a rear seating position in the
third row, be sure to study the instructions
that came with your child restraint to see if
there is enough room to secure your seat
properly. If the length of the seat cushion is
too short for your child restraint and you
cannot install it in accordance with the
child restraint manufacturers instructions,
secure it in the second row.
If your child restraint has the LATCH sys-
tem, refer to “Lower Anchors and Tethers
for Children (LATCH)” in this section.There are no top tether anchors in the third
row seating positions. Do not secure a
child restraint in the third row if a national
or local law requires that a top tether be
anchored or if the instructions that come
with the restraint say that the top tether
must be anchored.
If your child restraint does not have the
LATCH system, you will be using the lap-
shoulder belt to secure the child restraint in
this position. Be sure to follow the instruc-
tions that came with the child restraint.
Secure the child in the child restraint when
and as the instructions say.
If you are using a rear-facing child restraint
in the second row center position, install
the armrest retention strap.
1) Put the child restraint on the seat.
2) Pick up the latch plate, and run the lap
and shoulder portions of the vehicle’s
safety belt through or around the
restraint. The child restraint instructions
will show you how.

1-30 SEATS AND RESTRAINT SYSTEMS
78J00-03E
1379321
3) Buckle the belt. Make sure the release
button is positioned so you would be
able to unbuckle the safety belt quickly
if you ever had to.
1379324
4) Pull the rest of the shoulder belt all the
way out of the retractor to set the lock.
1379355
5) To tighten the belt, push down on the
child restraint, pull the shoulder portion
of the belt to tighten the lap portion ofthe belt, and feed the shoulder belt
back into the retractor. If you are using
a forward-facing child restraint, you
may find it helpful to use your knee to
push down on the child restraint as you
tighten the belt.
6) If your child restraint has a top tether,
and the position that you are using has
a top tether anchor, attach and tighten
the top tether to the top tether anchor.
Refer to the instructions that came with
the child restraint and to “Lower
Anchors and Tethers for Children
(LATCH)” in this section.
7) Push and pull the child restraint in dif-
ferent directions to be sure it is secure.
To remove the child restraint, just unbuckle
the vehicle's safety belt and let it go back
all the way. The safety belt will move freely
again and be ready to work for an adult or
larger child passenger.

1-31 SEATS AND RESTRAINT SYSTEMS
78J00-03E
Securing a Child Restraint in the
Right Front Seat PositionYour vehicle has a right front passenger's
airbag. A rear seat is a safer place to
secure a forward-facing child restraint.
Refer to “Where to Put the Restraint” in
this section.
In addition, your vehicle has a passenger
sensing system. The passenger sensing
system is designed to turn off the right
front passenger’s frontal airbag when an
infant in a rear-facing infant seat or a small
child in a forward-facing child restraint or
booster seat is detected. Refer to “Passen-
ger Sensing System” in this section and
“Passenger Airbag Status Indicator” in
“Warning Lights, Gages, and Indicators” in
the “Instrument Panel” section for more
information on this including important
safety information.
A label on your sun visor says, “Never put
a rear-facing child seat in the front.” This is
because the risk to the rear-facing child is
so great, if the airbag deploys.
If your vehicle does not have a rear seat
that will accommodate a rear-facing child
restraint, never put a child in a rear-facing
child restraint in the right front passenger
seat unless the passenger airbag status
indicator shows off and the airbag is off.
Here is why:If you need to secure a forward-facing
child restraint in the right front seat posi-
tion, move the seat as far back as it will go
before securing the forward-facing child
WARNING
A child in a rear-facing child restraint
can be seriously injured or killed if
the right front passenger's airbag
inflates. This is because the back of
the rear-facing child restraint would
be very close to the inflating airbag.
Even though the passenger sensing
system is designed to turn off the
right front passenger's frontal airbag
if the system detects a rear-facing
child restraint, no system is fail-safe,
and no one can guarantee that an air-
bag will not deploy under some
unusual circumstance, even though it
is turned off. We recommend that
rear-facing child restraints be
secured in the rear seat, even if the
airbag is off.
If you need to secure a forward-fac-
ing child restraint in the right front
seat, always move the front passen-
ger seat as far back as it will go. It is
better to secure the child restraint in
a rear seat.
WARNING
A child in a rear-facing child restraint
can be seriously injured or killed if
the right front passenger's airbag
inflates. This is because the back of
the rear-facing child restraint would
be very close to the inflating airbag.
Be sure the airbag is off before using
a rear-facing child restraint in the
right front seat position.
Even though the passenger sensing
system is designed to turn off the
passenger's frontal airbag if the sys-
tem detects a rear-facing child
restraint, no system is fail-safe, and
no one can guarantee that an airbag
will not deploy under some unusual
circumstance, even though it is
turned off. We recommend that rear-
facing child restraints be transported
in vehicles with a rear seat that will
accommodate a rear-facing child
restraint, whenever possible.
If you need to secure a forward-fac-
ing child restraint in the right front
seat, always move the front passen-
ger seat as far back as it will go. It is
better to secure the child restraint in
a rear seat.

1-32 SEATS AND RESTRAINT SYSTEMS
78J00-03E
restraint. Refer to “Manual Seats” in this
section.
If your child restraint has the LATCH sys-
tem, refer to “Lower Anchors and Tethers
for Children (LATCH)” in this section.
There is no top tether anchor at the right
front seating position. Do not secure a
child seat in this position if a national or
local law requires that the top tether be
anchored or if the instructions that come
with the child restraint say that the top
tether must be anchored. Refer to “Lower
Anchors and Tethers for Children
(LATCH)” in this section if the child
restraint has a top tether.
You will be using the lap-shoulder belt to
secure the child restraint in this position.
Be sure to follow the instructions that came
with the child restraint. Secure the child in
the child restraint when and as the instruc-
tions say.
1) Your vehicle has a right front passen-
ger’s frontal airbag. Refer to “Passen-
ger Sensing System” in this section. We
recommend that rear-facing child
restraints be secured in a rear seat,
even if the airbag is off. If your child
restraint is for ward-facing, move the
seat as far back as it will go before
securing the child restraint in this seat.
Refer to “Manual Seats” in this section.
When the passenger sensing system
has turned off the right front passen-ger’s frontal airbag, the off indicator in
the passenger airbag status indicator
should light and stay lit when you turn
the ignition to RUN or START. Refer to
“Passenger Airbag Status Indicator” in
“Warning Lights, Gages, and Indica-
tors” in the “Instrument Panel” section.
2) Put the child restraint on the seat.
3) Pick up the latch plate, and run the lap
and shoulder portions of the vehicle’s
safety belt through or around the
restraint. The child restraint instructions
will show you how.
1379321
4) Buckle the belt. Make sure the release
button is positioned so you would be
able to unbuckle the safety belt quickly
if you ever had to.
1379324
5) Pull the rest of the shoulder belt all the
way out of the retractor to set the lock.
1379355
6) To tighten the belt, push down on the
child restraint, pull the shoulder portion
of the belt to tighten the lap portion of

1-33 SEATS AND RESTRAINT SYSTEMS
78J00-03E
the belt, and feed the shoulder belt
back into the retractor. If you are using
a forward-facing child restraint, you
may find it helpful to use your knee to
push down on the child restraint as you
tighten the belt. You should not be able
to pull more of the belt from the retrac-
tor once the lock has been set.
7) Push and pull the child restraint in dif-
ferent directions to be sure it is secure.
8) If the airbag is off, the off indicator on
the instrument panel will be lit and stay
lit when the key is turned to RUN or
START.
If a child restraint has been installed and
the on indicator is lit, turn the vehicle off.
Remove the child restraint from the vehicle
and reinstall the child restraint.
If, after reinstalling the child restraint and
restarting the vehicle, the on indicator is
still lit, check to make sure that the vehi-
cle’s seatback is not pressing the child
restraint into the seat cushion. If this hap-
pens, slightly recline the vehicle’s seatback
and adjust the seat cushion if possible.
Also make sure the child restraint is not
trapped under the vehicle head restraint. If
this happens, adjust the head restraint.
If the on indicator is still lit, secure the child
in the child restraint in a rear seat position
in the vehicle if one is available and check
with your dealer.To remove the child restraint, if the top
tether is attached to the top tether anchor,
disconnect it. Unbuckle the vehicle’s safety
belt and let it go back all the way. The
safety belt will move freely again and be
ready to work for an adult or larger child
passenger.
Airbag SystemYour vehicle has a frontal airbag for the
driver and a frontal airbag for the right front
passenger. Your vehicle also has roof-
mounted rollover airbags designed for
either side impact or rollover deployment.
Roof-mounted rollover airbags are avail-
able for the driver and the passenger
seated directly behind the driver and for
the right front passenger and the passen-
ger seated directly behind that passenger.
For roof-mounted rollover airbags, the
word AIRBAG will appear along the head-
liner or trim.
Also, if your vehicle has a third row pas-
senger seat, your vehicle will have third
row roof-mounted rollover airbags.
Airbags are designed to supplement the
protection provided by safety belts. Even
though today’s airbags are also designed
to help reduce the risk of injury from the
force of an inflating bag, all airbags must
inflate very quickly to do their job.
Here are the most important things to
know about the airbag system:

1-34 SEATS AND RESTRAINT SYSTEMS
78J00-03E
WARNING
You can be severely injured or killed
in a crash if you are not wearing your
safety belt – even if you have airbags.
Wearing your safety belt during a
crash helps reduce your chance of
hitting things inside the vehicle or
being ejected from it. Airbags are
“supplemental restraints” to the
safety belts. All airbags are designed
to work with safety belts but do not
replace them.
Frontal airbags for the driver and
right front passenger are designed to
deploy in moderate to severe frontal
and near frontal crashes. They are
not designed to inflate in rollover,
rear crashes, or in many side
crashes. And, for some unrestrained
occupants, frontal airbags may pro-
vide less protection in frontal
crashes than more forceful airbags
have provided in the past.
(Continued)
WARNING
(Continued)
Roof-mounted rollover airbags are
designed to inflate in moderate to
severe crashes where something hits
the side of your vehicle, during a
vehicle rollover, or in a severe frontal
impact. They are not designed to
inflate in rear crashes. If your vehicle
has roof-mounted airbags, they are
designed to provide both side impact
protection and rollover protection.
Everyone in your vehicle should wear
a safety belt properly – whether or
not there is an airbag for that person.
WARNING
Both frontal and roof-mounted roll-
over airbags inflate with great force,
faster than the blink of an eye. If you
are too close to an inflating airbag, as
you would be if you were leaning for-
ward, it could seriously injure you.
Safety belts help keep you in position
for airbag inflation before and during
a crash. Always wear your safety belt
even with frontal airbags. The driver
should sit as far back as possible
while still maintaining control of the
vehicle. Occupants should not lean
on or sleep against the door in the
first or second row seats, or the rear
windows in the third row seat, if your
vehicle has roof-mounted rollover air-
bags.

1-35 SEATS AND RESTRAINT SYSTEMS
78J00-03E
808302
There is an airbag readiness light on the
instrument panel cluster, which shows the
airbag symbol.
The system checks the airbag electrical
system for malfunctions. The light tells you
if there is an electrical problem. Refer to
“Airbag Readiness Light” in “Warning
Lights, Gages, and Indicators” in the
“Instrument Panel” section for more infor-
mation.
Where Are the Airbags?
1177656
The driver’s airbag is in the middle of the
steering wheel.
809967
The right front passenger’s airbag is in the
instrument panel on the passenger’s side.
WARNING
Anyone who is up against, or very
close to, any airbag when it inflates
can be seriously injured or killed. Air-
bags plus lap-shoulder belts offer the
best protection for adults, but not for
young children and infants. Neither
the vehicle’s safety belt system nor
its airbag system is designed for
them. Young children and infants
need the protection that a child
restraint system can provide. Always
secure children properly in your vehi-
cle. To read how, refer to “Older Chil-
dren” or “Infants and Young
Children” in this section.
Occupants should not lean on or
sleep against the door in the first or
second row seats, or the rear win-
dows in the third row seat, if your
vehicle has roof-mounted rollover
airbags.

1-36 SEATS AND RESTRAINT SYSTEMS
78J00-03E
1177533
The roof-mounted rollover airbag for the
driver and the person seated directly
behind the driver is located in the ceiling
above the side windows.
1197154
The roof-mounted rollover airbag for the
right front passenger and the person
directly behind that passenger is located in
the ceiling above the side windows.
1700418
If your vehicle has a third row seat, the
roof-mounted rollover airbag is located in
the ceiling above the rear windows for the
outside passenger positions.
