Page 129 of 160
Technical data
Troubleshooting chart . . . . . . . . 128
Threaded fasteners . . . . . . . . . . . 129
Engine . . . . . . . . . . . . . . . . . . . . . . . 130
Riding specifications . . . . . . . . . 133
Clutch . . . . . . . . . . . . . . . . . . . . . . . 133
Transmission . . . . . . . . . . . . . . . . . 133
Final drive . . . . . . . . . . . . . . . . . . . . 135
Running gear . . . . . . . . . . . . . . . . . 135
Brakes . . . . . . . . . . . . . . . . . . . . . . . 136
Wheels and tyres . . . . . . . . . . . . . 136
Electrics . . . . . . . . . . . . . . . . . . . . . 137
Frame . . . . . . . . . . . . . . . . . . . . . . . 139
Dimensions . . . . . . . . . . . . . . . . . . 139
Weights . . . . . . . . . . . . . . . . . . . . . . 140
9127zTechnical data
Page 130 of 160
Troubleshooting chartEngine does not start at all or is difficult to start.Possible causeRemedyKill switch activated. Kill switch in operating position (run).
Side stand extended and gear engaged. Retract the side stand ( 66).
Gear engaged and clutch not disengaged Select neutral or pull clutch lever ( 66).
Clutch pulled when ignition was OFF Switch on the ignition, then pull the clutch
lever.
No fuel in tank. Refuelling ( 71)
Battery not adequately charged. Charging battery when connected ( 116)
9128zTechnical data
Page 131 of 160
Threaded fastenersFront wheelValue ValidFront brake caliper to wheel
carrier
M8 x 32 -10.9 30 Nm
Clamping screw for quick-re-
lease axle in wheel carrier
M8 x 30 19 Nm
Quick-release axle in threaded
bush
M24 x 1.5 50 NmRear wheelValue ValidRear wheel to wheel flange
M10 x 40 x 1.25Tighten in diagonally opposite
sequence
60 Nm
Silencer to rear footrest, right
M8 x 30 16 Nm
Silencer to manifold
9129zTechnical data
Page 132 of 160
Rear wheelValue ValidM8 x 60 - 10.935 NmMirrorsValue ValidMirror to clamping piece
M10 18 Nm
Clamping piece to clamping
block
10 NmEngineEngine, type Transversely mounted, four-cylinder four-
stroke in-line engine tilted 55° forward, with
four valves per cylinder, two overhead cam-
shafts with cam followers; liquid cooled, with
electronic fuel injection, integrated six-speed
cassette gearbox, dry-sump lubrication.
Effective displacement 1157 cm
3
Cylinder bore79 mm
Piston stroke 59 mm
Compression ratio 13:1
9130zTechnical data
Page 133 of 160
Nominal output120 kW, At: 10250 min
-1
with OE Reduced power output, 74 kW: 74 kW, At: 7000 min
-1
with OE Reduced power output, 79 kW: 79 kW, At: 8750 min
-1
Max. torque127 Nm, At: 8250 min
-1
with OE Reduced power output, 74 kW: 110 Nm, At: 5250 min
-1
with OE Reduced power output, 79 kW: 103 Nm, At: 4500 min
-1
Maximum permissible engine speed11000 min
-1
Idle speed1150
±50
min
-1
Fuel
Recommended fuel grade 98 ROZ/RON, Premium plus unleaded
95 ROZ/RON, Premium unleaded (fuel grade,
usable with power- and consumption-related
restrictions)
Fuel tank capacity 19 l, Usable 4 l, Including reserve of
9131zTechnical data
Page 134 of 160
Engine oil
Engine oil capacity, total3.5 l, With filter change
0.5 l, Difference between MIN / MAX marks
Lubricant Castrol GPS 10W-40 (SAE 10W40; API SG;
JASO MA)
Oil grades Mineral oils of API classification SF through
SH. BMW Motorrad recommends not using
oil additives, because they can have a detri-
mental effect on clutch operation. Please do
not hesitate to contact your authorised BMW
Motorrad dealer if you have any questions re-
lating the choice of a suitable engine oil for
your motorcycle.
Permissible viscosity classes
SAE 10 W-40 -20 °C, Operation at low temperatures
SAE 15 W-40 -10 °C
9132zTechnical data
Page 135 of 160
Riding specificationsTop speed>200 km/hClutchClutch typeMultiplate clutch running in oil bathTransmissionGearbox typeClaw-shift 6-speed cassette gearbox, integ-
rated into engine block
9133zTechnical data
Page 136 of 160
Gear ratios
Gearbox transmission ratios
9134zTechnical data
1.559 (92:59 teeth), Primary transmission ra-
tio
2.294 (39:17 teeth), 1st gear
1.789 (34:19 teeth), 2nd gear
1.458 (35:24 teeth), 3rd gear
1.240 (31:25 teeth), 4th gear
1.094 (35:32 teeth), 5th gear
0.971 (33:34 teeth), 6th gear
1.045 (23:22 teeth), Angular drive
