2006 BMW MOTORRAD K 1200 R Rider's Manual (in English)

Underneath the seat1Filler neck, engine oil
( 88)
2 Toolkit ( 86)
3 Helmet holder ( 56)
215zGeneral views

Handlebar fitting, left1INFO button for odomet-
er ( 43), INFO button
for on-board computer
OE
( 46)
2 Pushbutton, ESA
OE
( 60)
3 Pushbutton, horn
4 Pushbutton, left flashing
turn indicators ( 53),
Pushbutton, hazard
warning flashers ( 42)
5 Switch, high-beam head-
light and headlight flash-
er ( 52)
216zGeneral views

Handlebar fitting, right1Emergency off switch (kill
switch) ( 50)
2 Pushbutton, starter
( 66)
3 Grip heating switch
OE
( 50)
4 Pushbutton, right flashing
turn indicators ( 54),
Pushbutton, hazard
warning flashers ( 42)
5 Cancel button, flashing
turn indicators ( 54),
Pushbutton, cancel
hazard warning flashers
( 43)
217zGeneral views

Instrument cluster1Speedometer
2 Rev. counter
3 Warning and telltale
lights ( 22)
4 Multifunction display
( 22)
5 Telltale light, anti-theft
alarm (OE) and sensor for
instrument lighting
6 Control, odometer
( 43)
The instrument-cluster
lighting has automatic
day and night switchover.
218zGeneral views

Headlight1High-beam headlights
2 Low-beam headlight
3 Parking light
219zGeneral views

220zGeneral views

Status indicators
Multifunction display . . . . . . . . . . . 22
Warning and telltale lights . . . . . . 22
ABS warning light
OE
........... 22
Function indicators . . . . . . . . . . . . 22
Warnings, general . . . . . . . . . . . . . 23
Warnings issued by the tyre
pressure monitoring system
(RDC)
OE
....................... 31
ABS warnings
OE
............... 35
321zStatus indicators

Multifunction display1Clock ( 44), Panel for
RDC status indicators
OE
( 46), Panel for oil-level
information
OE
( 49)
2 Panel for warnings
( 23)
3 Panel for the on-board
computer's status indic-
ators
OE
( 46)
4 Gear indicator ( 22)
5 Coolant temperature
readout ( 23)
6 Panel for ESA status in-
dicatorsOE
( 60) 7
Odometer reading
( 43)
8 Fuel gauge ( 22)
Warning and telltale
lights1Telltale light, left turn in-
dicator
2 Telltale light, high-beam
headlight
3 Warning light, general
4 Telltale light, neutral
5 Warning light, ABS (OE)
6 Telltale light, right turn
indicator
ABS warning light
OE
The way in which the ABS
warning light indicates status
can differ in some countries.
Possible national variant.
Function indicatorsFuel capacity
The horizontal bars be-
low the fuel-pump sym-
bol indicate the remaining
quantity of fuel.
Gear
Shows which gear is en-
gaged.
If no gear is engaged, the
gear indicator shows N and
the 'neutral' telltale light also
lights up.
322zStatus indicators
