Page 137 of 160
Final driveFinal drive, typeShaft drive with bevel gears
Final drive gear ratio 2.91 : 1Running gearFront suspensionDouble leading link
Front suspension - total suspension travel 115 mm, Static 125 mm, Dynamic
Rear suspension type Central spring strut pivoted to lever system
with coil spring and single-tube gas-filled
shock absorber; spring preload steplessly
hydraulically adjustable, rebound stage
damping steplessly adjustable.
with OE Electronic Suspension Adjust-
ment (ESA): Central spring strut pivoted to lever system
with coil spring and single-tube gas-filled
shock absorber; spring basic setting three-
way adjustable, compression and rebound
stages each three-way adjustable
Rear suspension, total suspension travel 135 mm, at wheel
9135zTechnical data
Page 138 of 160
BrakesFront brake, typehydraulically operated twin disc brake with 4-
piston fixed calipers and floating brake discs
Front brake pads, material Sintered metal
Rear brake, type Hydraulically operated disc brake with 2-pis-
ton floating caliper and fixed disc
Rear brake pads, material Organic materialWheels and tyresFront wheel, typeCast aluminium, MT H2
Front wheel, rim size 3.50" x 17"
Front wheel, tyre designation 120/70 ZR17
Rear wheel, type Cast aluminium, MT H2
Rear wheel, rim size 5.50" x 17"
with OE Sports wheel: 6.00" x 17"
Rear wheel, tyre designation 180/55 ZR17
with OE Sports wheel: 190/50 ZR17
9136zTechnical data
Page 139 of 160
Tyre pressures
Tyre pressure, front2.5 bar, One-up, tyre cold
2.5 bar, Two-up and/or with luggage, tyre
cold
Tyre pressure, rear 2.9 bar, One-up, tyre cold
2.9 bar, Two-up and/or with luggage, tyre
coldElectricsOn-board socket, rating 5 A
Fuses All circuits are electronically protected, so
plug-in fuses are no longer necessary. If an
electronic fuse trips and de-energises a cir-
cuit, the circuit is active as soon as the igni-
tion is switched on after the fault has been
rectified.
Type
Type, battery AGM (Absorptive Glass Mat) battery
Technical data
Battery rated voltage 12 V
Battery rated capacity 14 Ah
9137zTechnical data
Page 140 of 160
Technical data
Spark plug manufacturer and designation NGK KR9CI
Spark plug electrode gap0.8 mm, When new
Spark plug electrode gap (Wear limit) No wear limit; spark-plug replacement as per
maintenance schedule
Lighting
High-beam headlight bulb H7 / 12 V / 55 W
Low-beam headlight bulb H7 / 12 V / 55 W
Parking-light bulb W5W / 12 V / 5 W
Bulb of tail light/brake light P21W / 12 V / 21 W
Front flashing turn indicator bulbs R10W / 12 V / 10 W
with OE White turn indicators: RY10W / 12 V / 10 W
Rear flashing turn indicator bulbs R10W / 12 V / 10 W
with OE White turn indicators: RY10W / 12 V / 10 W
9138zTechnical data
Page 141 of 160
FrameFrame typeLight alloy weldment with bolt-on tubular
steel rear frame
Type plate location Frame cross-tube, rear
VIN location Frame side section, front rightDimensionsLength of motorcycle2288 mm
Height of motorcycle 1230 mm, At DIN unladen weight, measured
across mirrors
Width of motorcycle 856 mm, Across mirrors
Front-seat height 820 mm, At unladen weight
with OE Double seat, low: 790 mm, At unladen weight
9139zTechnical data
Page 142 of 160
WeightsUnladen weight237 kg, DIN unladen weight, ready for road
90 % load of fuel, without optional extras
Permissible gross weight 450 kg
Maximum payload 213 kg
9140zTechnical data
Page 143 of 160
Service
BMW Motorrad service . . . . . . . 142
BMW Motorrad service
quality . . . . . . . . . . . . . . . . . . . . . . . 142
BMW Motorrad Service Card -
On-the-spot breakdown
assistance . . . . . . . . . . . . . . . . . . . 143
BMW Motorrad service
network . . . . . . . . . . . . . . . . . . . . . . 143
Maintenance work . . . . . . . . . . . . 143
Maintenance schedules . . . . . . . 144
Confirmation of maintenance
work . . . . . . . . . . . . . . . . . . . . . . . . . 145
Confirmation of service . . . . . . . 150
10141zService
Page 144 of 160

BMW Motorrad
serviceAdvanced technology
requires specially adapted
methods of maintenance and
repair.If maintenance and re-
pair work is performed
inexpertly, it could result in
consequential damage and
thus constitute a safety risk.
BMW Motorrad recommends
you to have all the associated
work on your motorcycle car-
ried out by a specialist work-
shop, preferably an author-
ised BMW Motorrad dealer.
Your authorised BMW Motor-
rad dealer can provide inform-
ation on the specified Ser-
vice, Inspection and Annual
Inspection work needed.
Have all maintenance and
repair work carried out confirmed in the "Service"
chapter in this manual.
Authorised BMW Motorrad
dealers are supplied with the
latest technical information
and have the necessary tech-
nical know-how. BMW Mo-
torrad recommends that you
contact your authorised BMW
Motorrad dealer if you have
questions regarding your mo-
torcycle.
BMW Motorrad service
qualityAlong with its reputation for
engineering quality and high
reliability, BMW Motorrad is a
byword for excellent quality of
service.
To ensure that your BMW
is always in optimum condi-
tion, we recommend that you
have the maintenance work
required for your motorcycle
carried out regularly, prefer-ably by your authorised BMW
Motorrad dealer. Evidence of
regular maintenance is essen-
tial for generous treatment of
goodwill claims.
Certain signs of wear,
moreover, may otherwise not
be noticed until it is too late
to put them right at moderate
cost. Your authorised BMW
Motorrad dealer's mechanics
know every detail of your
motorcycle and can take
remedial action if necessary
before minor faults develop
into serious problems. By
having the necessary repairs
done properly and in good
time, you save time and
money in the long run.
10142zService
