2005 TOYOTA TUNDRA Owners Manual

’05 TUNDRA_U (L/O 0408)
150
2005 TUNDRA from Aug. ’04 Prod. (OM34427U)
Standard and access cab models
Double cab models
To block out glare, move the sun visor.
To block out glare from the front—Swing
down the sun visor (position 1).
To block out glare from the side—Swing
down the sun visor, remove it from the
hook and swing it to the lateral side (posi-
tion 2).
If glare comes from obliquely behind you,
extend the plate at the end of the visor
(to position 3).
Standard and access cab models
Double cab models
Su n viso rs—

’05 TUNDRA_U (L/O 0408)
151
2005 TUNDRA from Aug. ’04 Prod. (OM34427U)
To block the glare from the front when the
main sun visor is swung to the lateral
side (position 2), swing down the sub vi-
sor.
CAUTION
Do not extend the plate at the end of
the sun visor when the visor is in the
position 1. It can cover the anti −glare
inside rear view mirror and obstruct
the rear view.
Standard and access cab models
Double cab models
To use the vanity mirrors, swing down
the sun visor and open the cover.
The vanity light(s) comes on when you
open the cover.
—Vanity mirrors

’05 TUNDRA_U (L/O 0408)
152
2005 TUNDRA from Aug. ’04 Prod. (OM34427U)

’05 TUNDRA_U (L/O 0408)
153
2005 TUNDRA from Aug. ’04 Prod. (OM34427U)
OPERATION OF INSTRUMENTS AND
CONTROLS
Lights and Wipers
Headlights and turn signals 154
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Emergency flashers 155
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . .
Instrument panel light control 156
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front fog lights 156
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . .
Interior light 157
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . .
Personal lights 157
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . .
Center interior and personal lights 158
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ignition switch and step lights 159
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cargo lamp 160
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . .
Windshield wipers and washer 161
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Outside rear view mirror heaters 162
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Back window and outside rear view mirror defoggers 163
. . . . . . . . . . .
SECTION 1− 5

’05 TUNDRA_U (L/O 0408)
154
2005 TUNDRA from Aug. ’04 Prod. (OM34427U)
HEADLIGHTS
To turn on the following lights: Twist
the headlight/turn signal lever knob.
Position 1—Parking, tail, license plate and
instrument panel lights
Position 2—Headlights and all of the
above
The lights automatically turn off when the
driver ’s door is opened with the ignition
turned off. To turn them on again, turn the
key to the “ON” position or actuate the
headlight switch. If you are going to park
for over one week, make sure the head-
light switch is off.
NOTICE
To prevent the battery from being dis-
charged, do not leave the lights on
for a long period when the engine is
not running.
Daytime running light system (on some
models)
The headlights turn on at reduced intensi-
ty when the parking brake is released with
the engine started, even with the light
switch in the “OFF” position. They will not
go off until the ignition switch is turned
off.
To turn on the other exterior lights and
instrument panel lights, twist the knob to
the position 1.
Twist the knob to the position 2 to turn
the headlights to full intensity for driving
at night.
High−Low beams— For high beams, turn
the headlights on and push the lever away
from you (position 1). Pull the lever to-
ward you (position 2) for low beams.
The headlight high beam indicator light
(blue light) on the instrument panel will
tell you that the high beams are on.
Flashing the high beam headlights
(position 3)—Pull the lever all the way
back. The high beam headlights turn off
when you release the lever.
You can flash the high beam headlights
with the knob turned to “OFF”.

Headlights and turn signals

’05 TUNDRA_U (L/O 0408)
155
2005 TUNDRA from Aug. ’04 Prod. (OM34427U)
TURN SIGNALS
To signal a turn, push the headlight/
turn signal lever up or down to position
1.
The key must be in the “ON” position.
The lever automatically returns after you
make a turn, but you may have to return
it by hand after you change lanes.
To signal a lane change, move the lever
up or down to the pressure point (position
2) and hold it.
If the turn signal indicator lights (green
lights) on the instrument panel flash faster
than normal, a front or rear turn signal
bulb is burned out.To turn on the emergency flashers,
push the switch.
All the turn signal lights will flash. To turn
them off, push the switch once again.
Turn on the emergency flashers to warn
other drivers if your vehicle must be
stopped where it might be a traffic hazard.
Always pull as far off the road as pos-
sible.
The turn signal light switch will not work
when the emergency flashers are operat-
ing.
NOTICE
To prevent the battery from being dis-
charged, do not leave the switch on
longer than necessary when the en-
gine is not running.
Emergency flashers

’05 TUNDRA_U (L/O 0408)
156
2005 TUNDRA from Aug. ’04 Prod. (OM34427U)
Standard and access cab models
Double cab models
To adjust the brightness of the instru-
ment panel lights, turn the knob.
To turn on the front fog lights, twist
the band of the headlight/turn signal
lever. They will come on only when the
headlights are on low beam.
Instrument panel light control Front fog lights

’05 TUNDRA_U (L/O 0408)
157
2005 TUNDRA from Aug. ’04 Prod. (OM34427U)
To turn on the interior light, slide the
switch.
The interior light switch has the following
positions:
“ON”—Keeps the light on all the time.
“OFF”—Turns the light off.
“DOOR”—Turns the light on when any
door is opened. The light goes off when
all the doors are closed. Standard cab and access cab models only
(with wireless remote control)—When the
switch is in the “DOOR” position and all
the door are unlocked using the wireless
remote control transmitter simultaneously,
the lights will come on and remain for
about 30 seconds unless any door is
opened or closed.Standard and access cab models
Double cab models
Interior light
Personal lights
