2005 TOYOTA AVENSIS diagram

D30688
ECM
MPX2
MPX1 29
18 E10 11
B8
22 SNOWI14
Integration Relay
8 14
DA B E8
ECT Pattern Select SW
*1: RHD
*2: LHD 4 1 W−B
CH
CF
CA 8
11
6
W−B
IPE10 MPX1
MPX2
*1
*2
B8
(*3) Pattern Select Switch (ECT SNOW Switch)
When the ECT SNOW switch is pushed, the switch contact is made and the ECT SNOW mode is selected.
To cancel the ECT SNOW mode, push the ECT SNOW switch once again. The ECT SNOW mode is automatical-
ly cancelledout when the ignition switch is turned ”OFF”.
*3
Instrument Panel J/B 05−630
− DIAGNOSTICSELECTRONIC CONTROLLED AUTOMATIC
TRANSAXLE [ECT] (U151E)
AVENSIS Supplement (RM1045E)
PATTERN SELECT SWITCH CIRCUIT
CIRCUIT DESCRIPTION
Integration relay receives pattern select switch information, and sends it through the multiplex communica-
tion system to the ECM.
ECT SNOW is the system that operates the throttle motor to control engine output to reduce skidding of the
driving wheels, guarantee takeoff acceleration, driving straightness and turning stability.
WIRING DIAGRAM
05JLL−01

D30750
ECM
SPT1
SFTD
SFTU L
B
R20
21
22 E10
7
1
2
5J17
J/C
W−B(*1)
(*2) A
A S
SFTD
SFTU
E IG 3 R−WT7
Transmission Control SW
Center J/B
Driver Side J/B
I13
Ignition SW
Engine Room J/B No.4
FL MAIN
Battery
*1: LHD
*2 RHDIJIK IPJ15
J/C A AM1IG1 R−W
W−B B−G
G−Y7
1
CA
7
DB
9
DA
1
DH AM1 GAUGE1 IG1Relay
5
13
2 DN
31
1
4D1
4B ALT
21E10
E10
W−B
W−B
CG
R−W 1
5
DH
G−R
G−Y
W−B
B−G R−W
B−G 05−626
− DIAGNOSTICSELECTRONIC CONTROLLED AUTOMATIC
TRANSAXLE [ECT] (U151E)
AVENSIS Supplement (RM1045E)
WIRING DIAGRAM

G31165
E1
Electronically Controlled
Transmission SolenoidECM
9
E12 SR
9
V
BR
−W
SR +B
CPU
−
DIAGNOSTICS ELECTRONIC CONTROLLED AUTOMATIC
TRANSAXLE [ECT] (U151E)05−619
AVENSIS Supplement (RM1045E)
DTC P0985 SHIFT SOLENOID ”E” CONTROL CIRCUIT
LOW (SHIFT SOLENOID VALVE SR)
DTC P0986 SHIFT SOLENOID ”E” CONTROL CIRCUIT HIGH (SHIFT SOLENOID VALVE SR)
CIRCUIT DESCRIPTION
Shifting from 1st to 5th is performed in combination with ”ON” and ”OFF” operation of the shift solenoid valves
SL1, SL2, SL3, S4 and SR which is controlled by the ECM. If an open or short circuit occurs in either of the
shift solenoid valves, the ECM controls the remaining normal shift solenoid valve to allow the vehicle to be
operated smoothly (Fail safe function).
DTC No.DTC Detection ConditionTrouble Area
P0985ECM detects short in solenoid valve SR circuit 2 times when
solenoid valve SR is operated (1 −trip detection logic)S Short in shift solenoid valve SR circuit
S Shift solenoid valve SR
S ECM
P0986ECM detects open in solenoid valve SR circuit 2 times when
solenoid valve SR is not operated (1 −trip detection logic)S Open in shift solenoid valve SR circuit
S Shift solenoid valve SR
S ECM
MONITOR DESCRIPTION
The ECM commands gear shifts by turning the shift solenoid valves ”ON/OFF”. When there is an open or
short circuit in any shift solenoid valve circuit, the ECM detects the problem and illuminates the MIL and
stores the DTC. And the ECM performs the fail −safe function and turns the other shift solenoid valves in good
condition ”ON/OFF” (In case of an open or short circuit, the ECM stops sending current to the circuit.)
(see page 05 −560).
WIRING DIAGRAM
05CW5 −03

G31765
Electronically Controlled
Transmission SolenoidE12ECM
E12
L
− W
L − R 15
14
SL3+
SL3 −
4
11
R
L
E1
SL3+
SL3 − +B
CPU
−
DIAGNOSTICS ELECTRONIC CONTROLLED AUTOMATIC
TRANSAXLE [ECT] (U151E)05−613
AVENSIS Supplement (RM1045E)
DTC P0798 PRESSURE CONTROL SOLENOID ”C”
ELECTRICAL (SHIFT SOLENOID VALVE
SL3)
CIRCUIT DESCRIPTION
Shifting from 1st to 5th is performed in combination with ”ON” and ”OFF” operation of the shift solenoid valves
SL1, SL2, SL3, S4 and SR which is controlled by the ECM. If an open or short circuit occurs in either of the
shift solenoid valves, the ECM controls the remaining normal shift solenoid valve to allow the vehicle to be
operated smoothly (Fail safe function).
DTC No.DTC Detection ConditionTrouble Area
P0798
ECM checks for an open or short circuit in shift solenoid valves
SL3 (1−trip detection logic)
S Output signal duty equals to 100%S Open or short in shift solenoid valve SL3 circuit
S Shift solenoid valve SL3
S ECM
MONITOR DESCRIPTION
The ECM commands gear shifts by turning the shift solenoid valves ”ON/OFF”. When there is an open or
short circuit in any shift solenoid valve circuit, the ECM detects the problem and illuminates the MIL and
stores the DTC. And the ECM performs the fail −safe function and turns the other shift solenoid valves in good
condition ”ON/OFF” (In case of an open or short circuit, the ECM stops sending current to the circuit.)
(see page 05 −560).
WIRING DIAGRAM
05CW3 −03

GND
C93866
1 V/DIV
1 ms/DIV
G31763
ECM
NC+
NC−
E1234 26
LG
LG−B 2 1 C5
Counter Gear Speed Sensor
E12
5V
E1
− DIAGNOSTICSELECTRONIC CONTROLLED AUTOMATIC
TRANSAXLE [ECT] (U151E)05−607
AVENSIS Supplement (RM1045E)
DTC P0793 INTERMEDIATE SHAFT SPEED SENSOR
”A”
CIRCUIT DESCRIPTION
This sensor detects the rotation speed of the counter gear. By comparing the counter gear speed signal (NC)
with the direct clutch speed sensor signal (NT), the ECM detects the shift timing of the gears and appropriate-
ly controls the engine torque and hydraulic pressure according to various conditions. Thus smooth gear shift-
ing is performed.
DTC No.DTC Detection ConditionTrouble Area
P0793
ECM detects conditions (a), (b) and (c) continuity for 5 sec. or
more: (1−trip detection logic)
(a) Vehicle speed: 50 km/h (31 mph) or more
(b) Park/neutral position switch (NSW) is OFF
(c) Speed sensor (NC): less than 300 rpmSOpen or short in transmission revolution sensor NC (speed
sensor NC) circuit
STransmission revolution sensor NC (speed sensor NC)
SECM
Reference (Using an oscilloscope):
Check the waveform between the terminals NC+ and
NC−of the ECM connector.
Standard: Refer to the illustration.
TerminalNC+−NC−
Tool setting1V/DIV, 1ms/DIV
Vehicle conditionVehicle speed 30 km/h (19 mph): (3rd gear)
Engine speed 1,400 rpm
MONITOR DESCRIPTION
The NC terminal of ECM detects a revolution signal from the speed sensor (NC) (counter gear rpm). The
ECM calculates a gearshift comparing the speed sensor (NT) with the speed sensor (NC).
While the vehicle is operating in 2nd, 3rd, 4th or 5th gear in the shift position of D, if the counter gear revolu-
tion is less than 300 rpm
*1although the output shaft revolution is more than 1,000 rpm*2, the ECM detects
the trouble, illuminates the MIL and stores the DTC.
*1: Pulse is not output or is irregularly output.
*2: The vehicle speed is 50 km/h (31 mph) or more.
WIRING DIAGRAM
05JLK−01

G31765
Electronically Controlled
Transmission SolenoidE12ECM
E12
Y
Y −B 19
18
SL1+
SL1 −
6
13
B W
E1
SL1+
SL1− +B
CPU
05
−592−
DIAGNOSTICS ELECTRONIC CONTROLLED AUTOMATIC
TRANSAXLE [ECT] (U151E)
AVENSIS Supplement (RM1045E)
DTC P0748 PRESSURE CONTROL SOLENOID ”A” ELECTRICAL (SHIFT SOLENOID VALVE
SL1)
CIRCUIT DESCRIPTION
Shifting from 1st to 5th is performed in combination with ”ON” and ”OFF” operation of the shift solenoid valves
SL1, SL2, SL3, S4 and SR which is controlled by the ECM. If an open or short circuit occurs in either of the
shift solenoid valves, the ECM controls the remaining normal shift solenoid valve to allow the vehicle to be
operated smoothly (Fail safe function).
DTC No.DTC Detection ConditionTrouble Area
P0748
ECM checks for an open or short circuit in shift solenoid valves
SL1 (1 −trip detection logic)
S Output signal duty equals to 100%S Open or short in shift solenoid valve SL1 circuit
S Shift solenoid valve SL1
S ECM
MONITOR DESCRIPTION
The ECM commands gear shifts by turning the shift solenoid valves ”ON/OFF”. When there is an open or
short circuit in any shift solenoid valve circuit, the ECM detects the problem and illuminates the MIL and
stores the DTC. And the ECM performs the fail −safe function and turns the other shift solenoid valves in good
condition ”ON/OFF” (In case of an open or short circuit, the ECM stops sending current to the circuit.)
(see page 05 −560).
WIRING DIAGRAM
05CVW −03

G31165
E1
Electronically Controlled
Transmission Solenoid
L−B
E12DSLECM
11
SB
10
DSL+B
CPU
05−586− DIAGNOSTICSELECTRONIC CONTROLLED AUTOMATIC
TRANSAXLE [ECT] (U151E)
AVENSIS Supplement (RM1045E)
DTC P0743 TORQUE CONVERTER CLUTCH CIRCUIT
ELECTRICAL (SHIFT SOLENOID VALVE
DSL)
CIRCUIT DESCRIPTION
The shift solenoid valve DSL is turned ”ON” and ”OFF” by signals from the ECM in order to control the hydrau-
lic pressure operation, the lock−up relay valve, which then the controls operation of the lock−up clutch.
DTC No.DTC Detection ConditionTrouble Area
P0743
Either (a) or (b) is detected at 1 time:
(2 trip detection logic)
(a) Solenoid resistance is 8
or less short circuit when sole-
noid is energized
(b) Solenoid resistance is 100 k
or more open circuit when
solenoid is not energized
SOpen or short in shift solenoid valve DSL circuit
SShift solenoid valve DSL
SECM
MONITOR DESCRIPTION
Torque converter lock−up is controlled by the ECM based on engine rpm, engine load, engine temperature,
vehicle speed, transmission temperature, and shift range selection. The ECM determines the lock−up status
of the torque converter by comparing the engine rpm (NE) to the input turbine rpm (NT). The ECM calculates
the actual transmission gear by comparing input turbine rpm (NT) to counter gear rpm (NC). When conditions
are appropriate, the ECM requests ”lock−up” by applying control voltage to shift solenoid DSL. When the
DSL is opened, solenoid DSL applies pressure to the lock−up relay valve and locks the torque converter
clutch. If the ECM detects an open or short in the DSL solenoid circuit, the ECM interprets this as a fault in
the DSL solenoid or circuit. The ECM will turn on the MIL and store the DTC.
WIRING DIAGRAM
05CW7−02

05−580−
DIAGNOSTICS ELECTRONIC CONTROLLED AUTOMATIC
TRANSAXLE [ECT] (U 151E)
AVENSIS Supplement (RM 1045E)
DTC P0724 BRAKE SWITCH ”B” CIRCUIT HIGH
CIRCUIT DESCRIPTION
The purpose of this circuit is to prevent the engine from stalling while driving in lock −up condition, when
brakes are suddenly applied.
When the brake pedal is depressed, this switch sends a signals to the ECM. Then the ECM cancels the op-
eration of the lock −up clutch while braking is in progress.
DTC No.DTC Detecting ConditionTrouble Area
P0724
The stop light switch remains ON even when the vehicle is
driven in a GO (30 km/h) and STOP (3 km/h) fashion 10 times.
(2 −trip detection logic).S Short in stop light switch signal circuit
S Stop light switch
S ECM
MONITOR DESCRIPTION
This DTC indicates that the stop light switch remains on. When the stop light switch remains ON during ”stop
and go” driving, the ECM interprets this as a fault in the stop light switch and the MIL comes on and the ECM
stores the DTC. The vehicle must stop (less than 3 km/h (2 mph)) and go (30 km/h ( 19 mph) or more) ten
times for two driving cycles in order to detect malfunction.
WIRING DIAGRAM
See page 05 −1 85.
05JLI −01
