2005 TOYOTA AVENSIS gas type

141NB−01
−
ENGINE MECHANICAL CYLINDER HEAD GASKET (2AZ −FSE)
14 −79
AVENSIS Supplement (RM1045E)
REPLACEMENT
1. DISCHARGE FUEL SYSTEM PRESSURE (See page 11 −4)
2. REMOVE FRONT WHEEL RH
3. REMOVE RADIATOR SUPPORT OPENING COVER (See page 14 −23)
4. REMOVE ENGINE ROOM COVER SIDE (See page 14 −23)
5. REMOVE ENGINE UNDER COVER LH (See page 14 −23)
6. REMOVE ENGINE UNDER COVER NO.4 RH (See page 14 −23)
7. REMOVE ENGINE UNDER COVER RH (See page 14 −23)
8. DRAIN COOLANT (See page 16 −7)
9. DRAIN ENGINE OIL (See page 17 −6)
10. REMOVE ENGINE COVER SUB −ASSY NO.1 (See page 14 −45)
11. REMOVE FUEL PRESSURE PULSATION DAMPER ASSY
12. SEPARATE FUEL TUBE SUB −ASSY (See page 11 −4)
13. REMOVE FUEL PIPE SUB −ASSY NO.1 (See page 11 −24)
SST 09023 −12900
14. REMOVE FUEL PUMP ASSY (See page 11 −24)
15. REMOVE FAN AND GENERATOR V BELT (See page 14 −5)
SST 09249 −63010
16. REMOVE GENERATOR ASSY (See page 19 −8)
17. REMOVE EXHAUST PIPE ASSY FRONT (See page 15 −2)
18. SEPARATE VANE PUMP ASSY (See page 14 −45)
19. REMOVE IGNITION COIL ASSY (See page 14 −45)
20. SEPARATE RETURN TUBE SUB −ASSY (See page 14 −45)
21. SEPARATE COOLER REFRIGERANT SUCTION HOSE NO.1 (LHD STEERING POSITION TYPE) (See page 14 −45)
22. REMOVE VANE PUMP OIL RESERVOIR ASSY (See page 14 −45)
23. REMOVE OIL RESERVOIR BRACKET NO.1 (See page 14 −45)
24. SEPARATE ENGINE WIRE (See page 14 −23)
25. REMOVE COOLER BRACKET (LHD STEERING POSITION TYPE) (See page 14 −45)
26. REMOVE ENGINE SERVICE COVER BRACKET RH (RHD STEERING POSITION TYPE)
(See page 14 −45)
27. REMOVE CYLINDER HEAD COVER SUB −ASSY (See page 14 −45)
28. SET NO. 1 CYLINDER TO TDC/COMPRESSION (See page 14 −45)
29. REMOVE ENGINE MOUNTING BRACKET NO.2 RH (See page 14 −45)
30. REMOVE TRANSVERSE ENGINE ENGINE MOUNTING INSULATOR (See page 14 −45)
31. REMOVE CRANKSHAFT PULLEY (See page 14 −45)
SST 09213 −54015 (91651 −60855), 09330 −00021, 09950 −50013 (09951 −05010, 09952 −05010,
09953 −05020, 09954 −05021)
32. REMOVE CHAIN TENSIONER ASSY NO.1 (See page 14 −45)
33. REMOVE CRANKSHAFT POSITION SENSOR (See page 14 −45)
34. REMOVE OIL PAN SUB −ASSY (See page 14 −45)
SST 09032 −00100
35. REMOVE V −RIBBED BELT TENSIONER ASSY (See page 14 −45)
36. REMOVE TIMING CHAIN OR BELT COVER SUB −ASSY (See page 14 −45)
37. REMOVE CRANKSHAFT POSITION SENSOR PLATE NO.1 (See page 14 −45)
38. REMOVE CHAIN TENSIONER SLIPPER (See page 14 −45)
39. REMOVE CHAIN VIBRATION DAMPER NO.1 (See page 14 −45)
40. REMOVE TIMING CHAIN GUIDE (See page 14 −45)
41. REMOVE CHAIN SUB −ASSY (See page 14 −45)

A83481
−
ENGINE MECHANICAL CYLINDER HEAD GASKET (2AZ −FSE)
14 −83
AVENSIS Supplement (RM1045E)
(i) Install the water by −pass pipe with a bolt.
Torque: 9.0 N
m (92 kgf
cm, 80 in.
lbf)
64. INSTALL CAMSHAFT TIMING OIL CONTROL VALVE ASSY
65. INSTALL CAMSHAFT (See page 14 −64)
66. INSTALL NO.2 CAMSHAFT (See page 14 −64)
67. INSTALL EXHAUST MANIFOLD CONVERTER SUB −ASSY (See page 14 −23)
68. INSTALL EXHAUST MANIFOLD HEAT INSULATOR NO.1 (See page 14 −23)
69. INSTALL INTAKE MANIFOLD (See page 11 −13)
70. INSTALL THROTTLE BODY ASSY (See page 10 −8)
71. INSTALL AIR CLEANER ASSEMBLY WITH HOSE (See page 14 −23)
72. INSTALL BATTERY
Torque:
5.0 N
m (51 kgf
cm, 44 in.
lbf) for Bolt
3.5 N
m (36 kgf
cm, 31 in.
lbf) for Nut
73. INSTALL CHAIN VIBRATION DAMPER NO.1 (See page 14 −45)
74. INSTALL CHAIN SUB −ASSY (See page 14 −45)
75. INSTALL TIMING CHAIN GUIDE (See page 14 −45)
76. INSTALL CHAIN TENSIONER SLIPPER (See page 14 −45)
77. INSTALL CRANKSHAFT POSITION SENSOR PLATE NO.1 (See page 14 −45)
78. INSTALL TIMING CHAIN OR BELT COVER SUB −ASSY (See page 14 −45)
79. INSTALL V −RIBBED BELT TENSIONER ASSY (See page 14 −45)
80. INSTALL OIL PAN SUB −ASSY (See page 14 −45)
81. INSTALL CRANKSHAFT POSITION SENSOR (See page 14 −45)
82. INSTALL CRANKSHAFT PULLEY (See page 14 −45)
SST 09213 −54015 (91651 −60855), 09330 −00021
83. INSTALL CHAIN TENSIONER ASSY NO.1 (See page 14 −45)
84. INSTALL TRANSVERSE ENGINE ENGINE MOUNTING INSULATOR
Torque: 52 N
m (530 kgf
cm, 38 ft
lbf)
85. INSTALL ENGINE MOUNTING BRACKET NO.2 RH (See page 14 −45)
86. INSTALL CYLINDER HEAD COVER SUB −ASSY (See page 14 −45)
87. INSTALL COOLER BRACKET (LHD STEERING POSITION TYPE)
Torque: 9.0 N
m (92 kgf
cm, 80 in.
lbf)
88. INSTALL ENGINE SERVICE COVER BRACKET RH (RHD STEERING POSITION TYPE) Torque: 9.0 N
m (92 kgf
cm, 80 in.
lbf)
89. INSTALL OIL RESERVOIR BRACKET NO.1 Torque: 8.0 N
m (82 kgf
cm, 71 in.
lbf)
90. INSTALL COOLER REFRIGERANT SUCTION HOSE NO.1 (LHD STEERING POSITION TYPE)
91. INSTALL RETURN TUBE SUB −ASSY
Torque: 8.0 N
m (82 kgf
cm, 71 in.
lbf)
92. INSTALL IGNITION COIL ASSY
Torque: 9.0 N
m (92 kgf
cm, 80 in.
lbf)
93. INSTALL FUEL PUMP ASSY (See page 11 −24)

A89212
N·m (kgf·cm, ft·lbf)
: Specified torque
zNon−reusable partzGasketCooler Bracket
(LHD Steering Position Type)
113 (1,152, 83)
Cooler Refrigerant Suction Hose No. 1
(LHD Steering Position Type)
8.0 (82, 44 in.
lbf)
8.0 (82, 44 in.
lbf)
52 (530, 38)
Transverse Engine Engine
Mounting Insulator
Vane Pump Oil Reservoir Assy
Return Tube Sub−assy
52 (530, 38)
21 (214, 16)
9.8 (100, 7.2)
Generator Assy
Exhaust Pipe Assy Front
43 (440, 32)
43 (440, 32)
7.0 (71, 62 in.
lbf)
7.0 (71, 62 in.
lbf)
Oil Reservoir Bracket No. 1
52 (530, 38)
52 (530, 38)
Engine Mounting Bracket No. 2 RH
7.0 (71, 62 in.
lbf)
8.0 (82, 71 in.
lbf)
8.0 (82, 71 in.
lbf)
52 (530, 38)
Exhaust Pipe Assy Center
52 (530, 38)
52 (530, 38)
Vane Pump Assy
zGasket
8.0 (82, 44 in.
lbf)
37 (377, 27)
14−70
− ENGINE MECHANICALCYLINDER HEAD GASKET (2AZ−FSE)
AVENSIS Supplement (RM1045E)

40188−01
C91925
D30865
AT0103
C91927
− AUTOMATIC TRANSMISSION / TRANSTRANSMISSION VALVE BODY ASSY (U151E)
40−19
AVENSIS Supplement (RM1045E)
TRANSMISSION VALVE BODY ASSY (U151E)
REPLACEMENT
1. REMOVE ENGINE UNDER COVER LH
2. DRAIN AUTOMATIC TRANSAXLE FLUID
(a) Remove the drain plug and gasket, and drain ATF.
(b) Install a new gasket and the drain plug.
Torque: 47 N
m (479 kgf
cm, 35 ft
lbf)
3. REMOVE AUTOMATIC TRANSAXLE OIL PAN
SUB−ASSY
(a) Remove the 18 bolts, oil pan and gasket.
NOTICE:
Some fluid will remain in the oil pan. Remove all of the oil
pan bolts, and carefully remove the oil pan assembly.
(b) Remove the 2 magnets from the oil pan.
(c) Examine the particles in the oil pan.
(1) Collect any steel chips with the removed magnets.
Look at the chips and particles in the pan and on the
magnets carefully to see the type of wear which
might be found in the transaxle.
Steel (magnetic): bearing, gear and plate wear
Brass (non−magnetic): bearing wear
4. DISCONNECT TRANSMISSION WIRE
(a) Disconnect the 7 shift solenoid valve connectors.
(b) Remove the bolt and lock plate, and disconnect the ATF
temperature sensor.

40187−01
C91925
D30865
AT0103
C91927
40−16
− AUTOMATIC TRANSMISSION / TRANSTRANSMISSION WIRE (U151E)
AVENSIS Supplement (RM1045E)
TRANSMISSION WIRE (U151E)
REPLACEMENT
1. REMOVE ENGINE UNDER COVER LH
2. DRAIN AUTOMATIC TRANSAXLE FLUID
(a) Remove the drain plug and gasket, and drain ATF.
(b) Install a new gasket and the drain plug.
Torque: 47 N
m (479 kgf
cm, 35 ft
lbf)
3. REMOVE AUTOMATIC TRANSAXLE OIL PAN
SUB−ASSY
(a) Remove the 18 bolts, oil pan and gasket.
NOTICE:
Some fluid will remain in the oil pan. Remove all of the oil
pan bolts, and carefully remove the oil pan assembly.
(b) Remove the 2 magnets from the oil pan.
(c) Examine the particles in the oil pan.
(1) Collect any steel chips with the removed magnets.
Look at the chips and particles in the pan and on the
magnets carefully to see the type of wear which
might be found in the transaxle.
Steel (magnetic): bearing, gear and plate wear
Brass (non−magnetic): bearing wear
4. DISCONNECT TRANSMISSION WIRE
(a) Disconnect the 7 shift solenoid valve connectors.
(b) Remove the bolt and lock plate, and disconnect the ATF
temperature sensor.

C91925
C86316
Magnet
AT0103
Magnet
C91927
Temperature
Sensor
D03547
Transmission Wire
40−20
− AUTOMATIC TRANSMISSION / TRANSAUTOMATIC TRANSAXLE ASSY (U151E/U151F)
U151E, U151F A/T REPAIR MANUAL (RM1021U)
9. REMOVE AUTOMATIC TRANSAXLE OIL PAN
SUB−ASSY
(a) Remove the 18 bolts, oil pan and gasket.
(b) Remove the 2 magnets from the oil pan.
10. INSPECT TRANSMISSION OIL CLEANER MAGNET
(a) Remove the magnets and use them to collect any steel
chips. Examine the chips and particles in the pan and on
the magnet to determine what type of wear has occurred
in the transaxle:
Steel (magnetic).... bearing, gear and plate wear
Brass (non−magnetic).... bushing wear
11. DISCONNECT TRANSMISSION WIRE
(a) Remove the 7 connectors from the shift solenoid valves.
(b) Remove the bolt, lock plate and ATF temperature sensor.
12. REMOVE TRANSMISSION WIRE
(a) Remove the bolt and transmission wire from the transaxle
case.

A64825
A95449
Axial Direction
A
B10 mm (0.394 in.) Thrust Direction
A95733
13.0 mm
(0.512 in.) 14–62
– ENGINE MECHANICALCYLINDER BLOCK ASSY (1ZZ–FE/3ZZ–FE)
1ZZ–FE,3ZZ–FE ENGINE REPAIR MANUAL
(RM1099E)
13. INSPECT CYLINDER BLOCK FOR FLATNESS
(a) Using a precision straight edge and feeler gauge, mea-
sure the warpage on the surface which comes into con-
tact with the cylinder head gasket.
Maximum warpage: 0.05 mm (0.0020 in.)
If the warpage is greater than maximum, replace the cylinder
block.
14. INSPECT CYLINDER BORE
(a) Using a cylinder gauge, measure the cylinder bore diame-
ter at positions A and B in the thrust and axial directions.
Standard diameter:
79.000 to 79.013 mm (3.1102 to 3.1107 in.)
Maximum diameter: 79.133 mm (3.1155 in.)
If the average diameter of 4 positions is greater than maximum,
replace the cylinder block.
15. INSPECT W/PIN PISTON SUB–ASSY
(a) For engine type 1ZZ–FE.
(1) Using a micrometer, measure the diameter of the
piston. Align the micrometer so it is 13.0 mm (0.512
in.) from the bottom of the piston and at right angles
(90) to the piston pin holes as illustrated.
Piston diameter:
78.955 to 78.965 mm (3.1085 to 3.1089 in.)
If the diameter is not as specified, replace the piston.
