2005 MERCEDES-BENZ SL600 Owner's Manual

103 Controls in detail
Locking and unlocking
Selective setting
If you frequently travel alone, you may wish
to reprogram the SmartKey with
KEYLESS-GO so that grasping a door han-
dle only unlocks the driver’s door, interior
lockable storage compartments and the
fuel filler flap.
Press and hold buttons Œ and ‹
simultaneously for about six seconds
until battery check lamp5
(page 94) flashes twice.
The SmartKey with KEYLESS-GO will
then function as follows:Unlocking the driver’s door and fuel fill-
er flap

Grasp the driver’s door handle.
All turn signals flash once. The locking
knob in the driver’s door moves up. The
anti-theft alarm system is disarmed.
Global unlocking

Grasp the door handle on the passen-
ger side.
All turn signals flash once. The locking
knobs in the doors move up. The
anti-theft alarm system is disarmed.
Global locking

Press lock button at door handle or
trunk lid.
All turn signals flash three times. The
locking knobs in the doors move down.
The anti-theft alarm system is armed.Restoring to factory setting

Press and hold buttons Œ and ‹
simultaneously for about six seconds
until battery check lamp5
(page 98) flashes twice.
!If you can no longer lock or unlock the
vehicle with the SmartKey with
KEYLESS-GO, then the battery in the
SmartKey is discharged, the SmartKey
with KEYLESS-GO is malfunctioning or
the vehicle battery is drained.

Check the battery in the SmartKey
with KEYLESS-GO (
page 97) and
replace it if necessary
(
page 377).

104 Controls in detailLocking and unlocking
Global locking using the lock button at
trunk lid
1Lock button at trunk lid

Press lock button 1 at trunk lid.
All turn signals flash three times. The
locking knobs in the doors move down.
The anti-theft alarm system is armed.


Use the mechanical key to unlock
the driver’s door (
page 374).


Have the vehicle batteries and their
connections checked
(page 401).


Use the mechanical key to lock or
unlock the doors (
page 376).
If the SmartKey with KEYLESS-GO is
malfunctioning, contact an authorized
Mercedes-Benz Center.
iVehicles with KEYLESS-GO*: To pre-
vent a possible inadvertent lockout, the
trunk lid will open automatically if a
SmartKey with KEYLESS-GO is recog-
nized inside the trunk.
When the hardtop is retracted, it must
be completely lowered in the trunk be-
fore the trunk lid can be closed
(page 235).
iYou can also lock the vehicle using the
lock button at the outside door handle
(page 60).

105 Controls in detail
Locking and unlocking
Checking the battery
Press button ‹ or Œ.
Battery check lamp5 (
page 98)
comes on briefly to indicate that the
SmartKey batteries are in order.Unlocking the trunk
You can unlock the trunk separately.
A minimum height clearance of
6.2 ft (1.88 m) is required to open the
trunk lid.
The handle is located above the rear li-
cense plate recess.
1Handle

Pull on handle 1.
The vehicle unlocks the trunk lid only.
!If battery check lamp5 (
page 98)
does not come on briefly during check,
then the SmartKey battery is dis-
charged.


Replace the battery (
page 377).
You can obtain the required battery at
any authorized Mercedes-Benz Center.
iIf the vehicle was previously centrally
locked, the trunk lid will lock automati-
cally when closed (
page 109). The
turn signals will flash three times to
confirm locking.
To prevent a possible inadvertent lock-
out, the trunk lid will open automatical-
ly if a SmartKey with KEYLESS-GO is
recognized inside the trunk.

106 Controls in detailLocking and unlockingLoss of SmartKey with KEYLESS-GO
If you lose your SmartKey with
KEYLESS-GO, you should do the following:
Have the SmartKey with KEYLESS-GO
deactivated by an authorized
Mercedes-Benz Center.

Report the loss of the SmartKey with
KEYLESS-GO or the mechanical key to
your car insurance company immedi-
ately.

Have the mechanical lock replaced if
necessary.
Your authorized Mercedes-Benz Center
will be glad to supply you with a replace-
ment.
Opening the doors from the inside
You can open a locked door from the in-
side. Open door only when conditions are
safe to do so.
1Locking knob
2Inside door handle
Pull on door handle2.
If door was locked, locking knob1 will
move up.
iIf the vehicle has previously been
locked from the outside with the
SmartKey, opening a door from the in-
side will trigger the anti-theft alarm sys-
tem.
To cancel the alarm, do one of the fol-
lowing:
With the SmartKey

Insert the SmartKey in the starter
switch.


Press button Œ or ‹on the
SmartKey.
With KEYLESS-GO*


Press the KEYLESS-GO* start/stop
button (
page 49).


Grasp the outside door handle

107 Controls in detail
Locking and unlocking
Opening the trunk
A minimum height clearance of
6.2 ft (1.88 m) is required to open the
trunk lid.Opening the trunk from the outside
The handle is located above the rear li-
cense plate recess.
1Handle

Pull on handle 1 and lift the trunk lid.
iIf you open a door, the side windows on
that side of the vehicle will lower slight-
ly. The windows close again when you
close the door.!Always make sure that there is suffi-
cient overhead clearance.
iVehicles without KEYLESS-GO*:
The vehicle must be unlocked.
iTo facilitate trunk loading and unload-
ing when the hardtop is retracted, you
can raise the hardtop from its storage
position in the trunk using the load as-
sist feature (
page 235). You may also
unhook the luggage cover.
Remember to resecure the luggage
cover after loading/unloading the
trunk. Otherwise you will not be able to
lower the retractable hardtop.
Vehicles without KEYLESS-GO*:
If the trunk lid does not open, the en-
tire vehicle is still locked globally
(
page 94).

108 Controls in detailLocking and unlockingThe trunk can also be opened using

the SmartKey, see “Locking and un-
locking” (
page 94)


the remote trunk lid release switch, see
“Opening the trunk from the inside”
(page 108)


the trunk lid emergency release button,
see “Trunk lid emergency release”
(page 109)Opening the trunk from the inside
You can open the trunk from the inside if
the vehicle is stationary and the retract-
able hardtop is fully opened or closed.
The switch is located on the driver’s door.
1Remote trunk lid release switch
2Indicator lamp

Pull remote trunk lid release switch1.
The trunk lid unlocks. Indicator
lamp2 comes on and remains lit until
the trunk is closed again.

Lift the trunk lid.The trunk can also be opened using


the SmartKey, see “Locking and un-
locking” (
page 94)


the remote trunk lid release switch, see
“Opening the trunk from the inside”
(page 108)


the trunk lid emergency release button,
see “Trunk lid emergency release”
(page 109)
iTo facilitate trunk loading and unload-
ing when the hardtop is retracted, you
can raise the hardtop from its storage
position in the trunk using the loading
aid feature (
page 235). You may also
unhook the luggage cover.
Remember to resecure the luggage
cover after loading/unloading the
trunk. Otherwise you will not be able to
lower the retractable hardtop.

109 Controls in detail
Locking and unlocking
Closing the trunk
1Handle
Lower trunk lid by firmly pulling on
handle1.

Close trunk lid with hands placed flat
on trunk lid.
Trunk lid emergency release
The emergency release button is located
on the left side of the trunk.
1Emergency release button
Briefly press emergency release
button1.
The trunk unlocks and the trunk lid
opens slightly.

Push up the trunk lid to fully open.
Warning!
G
To prevent possible personal injury, always
keep hands and fingers away from the trunk
opening when closing the trunk lid. Be espe-
cially careful when small children are
around.
Warning!
G
Only drive with the trunk closed. Among oth-
er dangers, such as your view being blocked,
exhaust fumes may enter the vehicle interi-
or.iTo prevent an inadvertent lockout, do
not place the SmartKey in the trunk.
Vehicles with KEYLESS-GO*: To pre-
vent a possible inadvertent lockout, the
trunk lid will open automatically if a
SmartKey with KEYLESS-GO is recog-
nized inside the trunk.
When the hardtop is retracted, it must
be completely lowered in the trunk be-
fore the trunk lid can be closed
(page 235).


110 Controls in detailLocking and unlockingIllumination of the emergency release but-
ton:

The button flashes for 30 minutes after
opening the trunk.


The button flashes for 60 minutes after
closing the trunk.
Automatic central locking
The doors and the trunk lid lock automati-
cally when the vehicle is set into motion.
You can open a locked door from the in-
side. Open door only when conditions are
safe to do so.
You can deactivate the automatic locking
using the control system (
page 156).
iThe emergency release button unlocks
the trunk while the vehicle is standing
still or in motion.iThe emergency release button does
not open the trunk lid if the vehicle bat-
tery is discharged or disconnected.
iIf the emergency release button is
pressed and the vehicle was centrally
locked, the exterior lamps will flash and
the alarm will sound as the trunk lid
opens.
To cancel the alarm, do one of the fol-
lowing:
With the SmartKey

Insert the SmartKey in the starter
switch.


Press buttonŒ or‹ on the
SmartKey.
With KEYLESS-GO*


Grasp the outside door handle.


Press the KEYLESS-GO* start/stop
button.
iThe doors unlock automatically after an
accident if the force of the impact ex-
ceeds a preset threshold.
The vehicle locks automatically when
the ignition is switched on and the
wheels are turning at vehicle speeds of
approximately 9 mph (15 km/h) or
more. You could therefore lock yourself
out when the vehicle

is pushed


is on a test stand
