2005 MERCEDES-BENZ SL600 Owner's Manual

143 Controls in detail
Control system
Distronic activated
When Distronic is activated the DTR sym-
bol and the set speed are seen in the left
display.
1Symbol for activated Distronic
2Set speed
Vehicle status message memory menu
Use the vehicle status message memory
menu to scan malfunction and warning
messages that may be stored in the sys-
tem. Such messages appear in the multi-
function display and are based on
conditions or system status the vehicle’s
system has recorded.

Press button è or ÿ repeatedly
until the vehicle status message mem-
ory appears in the multifunction dis-
play.
No vehicle status messages
If no conditions have been recorded, the
message in the right display is:
Malfunction memory, no malfunctions
.
Vehicle status messages have been
recorded
If conditions have occurred causing status
messages to be recorded, the number of
messages appears in the right multifunc-
tion display:
1Number of recorded status messages
Warning!
G
Malfunction and warning messages are only
indicated for certain systems and are inten-
tionally not very detailed. The malfunction
and warning messages are simply a remind-
er with respect to the operation of certain
systems and do not replace the owner’s
and/or driver’s responsibility to maintain
the vehicle’s operating safety by having all
required maintenance and safety checks
performed on the vehicle and by bringing
the vehicle to an authorized Mercedes-Benz
Center to address the malfunction and
warning messages (
page 335).

144 Controls in detailControl system
Press button k or j.
The stored messages will now be dis-
played in the order in which they have
occurred. For malfunction and warning
messages, see “Vehicle status messag-
es in the multifunction display”
(page 335).
Should the vehicle’s system record any
conditions while driving, the number of
messages will reappear in the multifunc-
tion display


when the SmartKey in the starter
switch is turned to position0 or re-
moved from the starter switch
or


when you turn off the engine by press-
ing the KEYLESS-GO* start/stop but-
ton on the gear selector lever once and open the driver’s door (this puts the
starter switch in position 0, same as
with the SmartKey removed from the
starter switch)
Settings menu
In the
Settings
menu there are two func-
tions:


The function
Reset
, with which you can
reset all the settings to those set at the
factory.


A collection of submenus with which
you can make individual settings for
your vehicle.

Press button è or ÿ repeatedly
until the
Settings...
menu appears in
the left display.
iAfter you have scrolled through all re-
corded status messages, the first re-
corded message appears again.
iThe vehicle status message memory
will be cleared when you then turn the
SmartKey in the starter switch to posi-
tion 1 or 2, or when you press the
KEYLESS-GO* start/stop button once
or twice without depressing the brake
pedal. You will then only see high prior-
ity messages in the multifunction dis-
play (
page 335).

145 Controls in detail
Control system
The following settings and submenus are
available:Resetting all settings
You can reset all the functions of all sub-
menus to the factory settings.

Press the reset button in the instru-
ment cluster for approximately three
seconds.
In the right display you will see the re-
quest to press the reset button again to
confirm.

Press the reset button again.
The functions of all the submenus will
reset to factory settings.Submenus in the Settings menu

Press button k or j.
In the right display you see the collec-
tion of submenus.

Press button ç.
The selection marker moves to the next
submenu.
The submenus are arranged by hierarchy.
Scroll down with the ç button, scroll up
with the æ button.
Move within the submenus with the k
or j button to the individual functions.
The settings themselves are made with
button æ or ç.
Function
Page
Resetting all settings
145
Submenus in the Settings menu
145
Resetting the functions of a sub-
menu
146
Instrument cluster submenu
148
Time submenuLighting submenu
152
Vehicle submenu
156
Convenience submenu
157
iThe settings you have changed will not
be reset unless you confirm the action
by pressing the reset button a second
time.

146 Controls in detailControl systemResetting the functions of a submenu
For each submenu you can reset all the
functions to the factory settings.
Move to a function in the submenu.

Press the reset button in the instru-
ment cluster for approximately three
seconds.
In the right display you will see the re-
quest to press the reset button again to
confirm.

Press the reset button again.
All functions of the submenu will reset
to factory settings.

147 Controls in detail
Control system
The table below shows what settings can
be changed within the various menus. De-
tailed instructions on making individual
settings can be found on the following pag-
es.Instrument cluster
Time
Lighting
Vehicle
Convenience
Selecting temperature
display mode
Synchronizing time with
head unit
Setting daytime running
lamp mode (USA only)
Setting station selection
mode (radio)
Activating
easy-entry/exit feature
Selecting speedometer
display mode
Setting the time (hours)
Setting locator lighting
Setting automatic locking
Setting key-dependency
Selecting language
Setting the time
(minutes)
Setting night security
illumination
Tire inflation pressure
display
Setting parking position
for exterior rear view
mirror
Selecting time display
mode
Setting interior lighting
delayed switch-off

148 Controls in detailControl systemInstrument cluster submenu
Access the
Inst. cluster
subenu via the
Settings
menu. Use the
Inst. cluster

submenu to change the instrument cluster
display settings. The following functions
are available:Selecting temperature display mode

Move the selection marker with button
æ or ç to the
Inst. cluster

submenu.

Press button j or k repeatedly
until you see this message in the left
display:
Temp. indicator
.
The selection marker is on the current
setting.

Press æ or ç to set temperature
unit to degrees Celsius (
°C) or degrees
Fahrenheit (
°F).Selecting speedometer display mode

Move the selection marker with button
æ or ç to the
Inst. cluster

submenu.

Press button j or k repeatedly
until you see this message in the left
display:
Digital speedometer
.
The selection marker is on the current
setting.

Press æ or ç to set the speed-
ometer units to
Kilometres
or
Miles
.
Function
Page
Selecting temperature display
mode
148
Selecting speedometer display
mode
148
Selecting language
149

149 Controls in detail
Control system
Selecting language
Move the selection marker with button
æ or ç to the
Inst. cluster

submenu.

Press button j or k repeatedly
until the message
Text
appears in the
multifunction display.
The selection marker is on the current
setting.

Press æ or ç to select the
language to be used for the
multifunction display messages. Available languages:


German


English


Italian


French


SpanishTime submenu
Access the
Time
submenu via the
Settings

menu. Use the
Time
submenu to change
the time and date settings. The following
functions are available:
Synchronizing time with head unit

Move the selection marker with the
æ or ç button to the
Time

submenu.

Press button j or k repeatedly
until the message
Time sync. with
head unit
appears in the multifunction
display.
The selection marker is on the current
setting.
Function
Page
Synchronizing time with head
unit
149
Setting the time (hours)
150
Setting the time (minutes)
151
Selecting time display mode
151

150 Controls in detailControl system
Press æ or ç enable or disable
this feature.
When you set this feature to
On, the time
displayed in the multifunction display is
automatically synchronized with the time
of the COMAND systemSetting the time (hours)
This function is only available if the func-
tion
Time sync. with head unit

(
page 149) has been set to
Off
. The time
is then not set automatically by the
COMAND and must be set manually if re-
quired.

Move the selection marker with the
æ or ç button to the
Time

submenu.

Press button j or k repeatedly
until the message
Set time Hours

appears in the multifunction display.
The selection marker is on the hour
setting.

Press button æ or ç to set the
hour.

Press the reset button in the instru-
ment cluster (
page 25) to confirm
the setting.
iFor information on setting the time, re-
fer to the separate COMAND operating
instructions.
