2005 MERCEDES-BENZ ML500 Owner's Manual

127 Controls in detail
Transmission control – LOW RANGE mode
Transmission control – LOW RANGE mode
In the following situations you should
switch to LOW RANGE mode:

during off-road driving


when crossing water


when towing up or down on steep
gradients
Switching on LOW RANGE modeLOW RANGE mode switch
Stop the vehicle.

Move the gear selector lever to
positionN.

Press on the upper part of the switch.
During the changeover the indicator
lamp (
page 25) flashes three times.
Once the changeover is complete, the
indicator lamp comes on continuously.
Switching off LOW RANGE mode
Stop the vehicle.

Move the gear selector lever to
positionN.

Press on the upper part of the switch.
During the changeover the indicator
lamp (
page 25) flashes three times.
Once the changeover is complete, the
indicator lamp goes out.
For information on driving safety systems
during LOW RANGE mode, see the “Safety
and Security” section (
page 76).
!Only switch the LOW RANGE mode on
or off, when the vehicle is

at a complete standstill


the engine speed is less than
1500 rpm
Failure to do so may result in transmis-
sion or engine damage which is not
covered by the Mercedes-Benz Limited
Warranty.
!You should only operate the vehicle on
a single axle dynamometer for briefly
testing the brakes.
The key must be in steering lock
position1 (
page 33).

128 Controls in detailGood visibilityFor more information, see “Windshield
wipers” (
page 51) and “Mirrors”
(
page 41).
Rear view mirrors
Interior rear view mirror, antiglare
position
1Lever

Tilt the mirror to the antiglare night po-
sition by moving lever1 towards the
windshield.
The interior rear view mirror is dimmed.
Automatic antiglare rear view mirrors*
The reflection brightness of the exterior
rear view mirror on the driver’s side and
the interior rear view mirror will respond
automatically to glare when:


the automatic antiglare function is acti-
vated (
page 129)


the ignition is switched on


incoming light from headlamps falls on
the sensor in the interior rear view
mirror
The rear view mirror will not react if


reverse gear is engaged


the interior light is turned on
Warning!
G
The automatic antiglare function does not
react if incoming light is not aimed directly
at sensors in the interior rear view mirror.
The interior rear view mirror and the exterior
rear view mirror on the driver’s side do not
react, for example, if the cargo compart-
ment is fully loaded.
Glare can endanger you and others.Warning!
G
In the case of an accident, liquid electrolyte
may escape from the mirror housing if the
mirror glass breaks.
Electrolyte has an irritating effect. Do not al-
low the liquid to come into contact with
eyes, skin, clothing, or respiratory system.
In case it does, immediately flush affected
area with water, and seek medical help if
necessary.

129 Controls in detail
Good visibility
Activating
1Button
2Indicator lamp
Press button1.
Indicator lamp2 comes on.
Deactivating

Press button1 again.
Indicator lamp2 goes out.Activating exterior rear view mirror
parking position
The buttons are located on the lower part
of the center console.
1Deactivating parking position
2Activating parking position
3Adjustment button

Make sure you have stored a parking
position for the passenger-side exterior
rear view mirror (
page 106).

Switch on ignition (
page 33).

Press button2 for the passenger-side
exterior rear view mirror.
Warning!
G
Exercise care when using the passen-
ger-side exterior rear view mirror. The mirror
surface is convex (outwardly curved surface
for a wider field of view). Objects in mirror
are closer than they appear. Check your in-
terior rear view mirror or glance over your
shoulder before changing lanes.!Electrolyte drops coming into contact
with the vehicle paint finish can be
completely removed only while in the
liquid state and by applying plenty of
water.


130 Controls in detailGood visibility
Place the gear selector lever in reverse
gearR.
The passenger-side exterior rear view
mirror will be turned downward to the
stored position.
The exterior rear view mirror returns to its
previously stored driving position:


ten seconds after you put the gear
selector lever in positionD


immediately once you exceed a vehicle
speed of approx. 6 mph (10 km / h)


immediately when you press the
button1 for driver’s side mirrorElectrically folding exterior rear view
mirrors
Folding exterior mirrors in and out
manually*
The exterior rear view mirrors can vibrate if
they are not completely folded out.The buttons are located on the lower part
of the center console.
1Folds the exterior mirrors in
2Folds the exterior mirrors out

Switch on ignition (
page 33).
iIf the button1 is pressed, the auto-
matic passenger-side exterior rear view
parking position is deactivated.
!Before driving the vehicle through an
automatic car wash, fold the exterior
mirrors in. Otherwise they may get
damaged.
iWith the front doors closed, the exteri-
or mirrors can still be folded in and out
approximately 30 minutes after the ig-
nition has been turned off.


131 Controls in detail
Good visibility
Folding in
Briefly press button1 (
page 130).
The mirrors fold in.Folding out

Briefly press button2.
The mirrors fold out.
Windshield wipers
For more information on the windshield
wipers, see the “Getting started” section
(page 51).
!Before you drive the vehicle through an
automatic car wash, fold the exterior
mirrors in, otherwise they may get
damaged.iIf you are driving at more than approxi-
mately 9 mph (15 km / h), you will not
able to fold the exterior mirrors in.
!If an exterior rear view mirror housing
is forcibly pushed forward (hit from the
rear), reposition it manually by applying
firm pressure until it snaps back into
place.
If an exterior rear view mirror is forcibly
pushed rearward (hit from the front)
press button1 to fold mirrors in, then
press button2 to fold mirrors out. Do
not force mirrors by hand as this may
damage the adjustment mechanism.
The mirror housing is now properly po-
sitioned and you can adjust the mirror
normally.
!If leaves, snow, etc. block the wind-
shield wipers, the wiper motor turns
off.

For safety reasons, withdraw key
from steering lock. Remove block-
age.


Turn the windshield wipers on
again.
If windshield wipers fail to function at
all in switch position1,


set the wiper switch to the next
highest wiper speed.


have the windshield wipers
checked at the nearest authorized
Mercedes-Benz Light Truck Center.

132 Controls in detailGood visibilityIntermittent wiping
Windshield wipers without rain sensor*
At speeds of approximately 105 mph
(170 km / h) the wiper switches automati-
cally to continuous wiping. Always obey lo-
cal speed limits.Windshield wipers with rain sensor*
A rain sensor automatically controls the
windshield wipers depending on how wet
the windshield is.

Switch on ignition.

Set the wiper switch to position1
(page 51).
After the initial wipe, pauses between
wipes are automatically controlled by the
rain sensor which monitors the wetness of
windshield.
iIntermittent wiping is interrupted when
the vehicle is at a standstill and a front
door is opened.
iWhen intermittent wiping is on and the
key is turned from position1 to
position2 in the steering lock
(page 33), and kept in that position
for longer than two seconds, the wipe
interval will be set to approximately
five seconds.
!Do not leave windshield wipers in inter-
mittent setting when the vehicle is tak-
en to an automatic car wash or during
windshield cleaning. Wipers will oper-
ate in the presence of water sprayed on
the windshield, and wipers may be
damaged as a result.
The switch should not be left in inter-
mittent setting as the wipers will wipe
the windshield once every time the en-
gine is started. Dust that accumulates
on the windshield might scratch the
glass and / or damage the wiper blades
when wiping occurs on a dry wind-
shield.

133 Controls in detail
Good visibility
Headlamp cleaning system*
The button is located on the right side of
the dashboard.Headlamp washer button
Switch on ignition.

Briefly press the upper part of button.
The headlamps will be cleaned with a
high-pressure water jet.For information on filling up the washer
reservoir, see the “Operation” section
(
page 230).
Rear window wiper
For more information on Rear window wip-
er, see the “Getting started” section
(page 52).
The rear window wiper will also automati-
cally engage if the windshield wiper is en-
gaged and the gear selector lever is placed
in reverse.Rear window wiper with rain sensor*
Rear window wiper intervals are controlled
automatically according to the amount of
water on the windshield and the speed of
the vehicle, if:


rear window wiper is switched on


front windshield wipers are switched to
intermittent wiping
The interval for the rear window wiper re-
mains constant when the windshield wiper
interval is ten seconds or more.

134 Controls in detailGood visibilitySun visors
The sun visors protect you from sun glare
while driving.
1Mirror cover
2Mounting

Swing sun visors down when you expe-
rience glare.

To use mirror, lift cover1 up.Illuminated vanity mirrors

Turn the key in steering lock to
position1 (
page 33).

Lift cover up.
The lamp switches on.
Warning!
G
Do not use the vanity mirror while driving.
Keep the mirrors in the sun visors closed
while vehicle is in motion. Reflected glare
can endanger you and others.
iIf sunlight enters through a side win-
dow, disengage sun visor from
mounting2 and pivot to the side.
