2005 MERCEDES-BENZ ML500 Owner's Manual

95 Controls in detail
Seats
Seats
For information on seat adjustment, see
the “Getting started” section (
page 35).
Removing and installing front seat
head restraints
For more information on head restraint ad-
justment, see the “Getting started” section
(page 35).Front seat head restraints
1Release button
Removing front seat head restraints

Pull head restraint to its highest
position.

Push release button1 and pull out
head restraint.
iAdjust the head restraint in such a way
that it is as close to the head as possi-
ble.
Warning!
G
For your protection, drive only with properly
positioned head restraints.
Adjust head restraint so that the center of
the head restraint supports the back of the
head at eye level. This will reduce the poten-
tial for injury to the head and neck in the
event of an accident or similar situation.
Do not drive the vehicle without the seat
head restraints. Head restraints are intend-
ed to help reduce injuries during an acci-
dent.
Do not interchange head restraints from
front and rear seat.

96 Controls in detailSeatsInstalling front seat head restraint
Insert head restraint and push it down
to the stop.

Push release button1 and adjust
head restraint to the desired position
(page 37).
Rear seat head restraints
Head restraint height
1Release buttonRaising:

Manually adjust the height of the head
restraint by pulling it upward.
Lowering:

To lower the head restraint, push
release button1 and press down on
the head restraint.iAdjust the head restraint in such a way
that it is as close to the head as possi-
ble.
Warning!
G
For your protection, drive only with properly
positioned head restraints.
Adjust head restraint so that the center of
the head restraint supports the back of the
head at eye level. This will reduce the poten-
tial for injury to the head and neck in the
event of an accident or similar situation.
Do not drive the vehicle without the seat
head restraints. Head restraints are
intended to help reduce injuries during an
accident.
Do not interchange head restraints from
front and rear seat.

97 Controls in detail
Seats
Head restraint tilt
Manually adjust the angle of the head
restraint.
Push or pull on the upper edge of the
head restraint cushion.
For more information on seats, see the
“Getting started” section (
page 35).Removing and installing rear seat head
restraints
1Release button
Removing rear seat head restraints

Pull head restraint to its highest
position.

Push release button1 and pull out
head restraint.
Warning!
G
For your protection, drive only with properly
positioned head restraints.
Adjust head restraint so that the center of
the head restraint supports the back of the
head at eye level. This will reduce the poten-
tial for injury to the head and neck in the
event of an accident or similar situation.
Do not drive the vehicle without the seat
head restraints. Head restraints are intend-
ed to help reduce injuries during an acci-
dent.
Do not interchange head restraints from
front and rear seat.
iFor a better view toward the rear, you
can store the rear center head restraint
underneath the rear seat (
page 98).

98 Controls in detailSeatsInstalling rear seat head restraints
Insert head restraint and push it down
to the stop.

Push release button1 and adjust
head restraint to the desired position
(page 37).
Stowing rear center head restraint
1Rear center head restraint
2Bar
3Clip

Remove rear center head restraint
(page 97).

If necessary, remove cargo floor plates,
see “Removing cargo floor plates”
(page 165).

Slide rear seats forward, see “Adjusting
rear seat fore and aft” (
page 100).

Fold rear seat backrests down, see
“Folding down the backrest”
(page 100).

From cargo compartment, attach rear
center head restraint1 to underside
of rear center seat.
Make sure front side of head
restraint1 is facing upward.

Press bar2 on both sides into
clips3.
Heated seats*
Both switches for the front seats are loca-
ted in the center console.
1Normal heating
2Rapid heating
Start the engine.
Switching on seat heating

Press upper switch position1.
A red indicator lamp on the switch
lights up.

99 Controls in detail
Seats
Switching off seat heating
Press upper switch position1 again.
The indicator lamp on the switch turns
off.
Switching on rapid seat heating

Press lower switch position2.
Both red indicator lamps on the switch
turn on.Switching off rapid seat heating

Press lower switch position2 again.
Both red indicator lamps on the switch
turn off.
Rear seats
iThe seat heater will be automatically
switched off after approximately
20 minutes.iThe system switches over to normal
heating mode after approximately five
minutes. Only one red indicator lamp
remains on.
!If one or both of the lamps on the seat
heater switch are flashing, there is in-
sufficient voltage available since too
many electrical consumers are turned
on. The seat heater switches off auto-
matically.
The seat heater will switch back on
again automatically as soon as suffi-
cient voltage is available.
Warning!
G
Do not adjust the rear seats while driving.
When using the rear seats, always make
sure the seats are folded up and in the
locked position, and the seat belts are prop-
erly positioned on the body. Your seat must
be adjusted so that you can correctly fasten
your seat belt.
Adjust head restraint so that the center of
the head restraint supports the back of the
head at eye level. This will reduce the poten-
tial for injury to the head and neck in the
event of an accident or similar situation.
Never place hands under the seat or near
any moving parts while a seat is being ad-
justed.

100 Controls in detailSeatsThe rear seats are divided asymmetrically.
To enlarge the cargo compartment you can
adjust the left and right part separately.
The following changes are possible:

moving the seat fore and aft


folding down the backrest


lowering the seat
Adjusting rear seat fore and aft
1Release lever

Pull release lever1 in direction of
arrow.

Slide seat to the desired position until
it locks in place.
Folding down the backrest
1Lock button

Close cup holder (
page 170) and
ashtray (
page 172) in rear center
console (page 170).

Move front seats forward. Manual seat
(page 36) or power seat (
page 38).

Slide seat forward.

Remove head restraint(s) (
page 95).

Pull lock button1 up and fold back-
rest forward until it locks in place.
The red backrest lock indicator at lock
button1 is not visible in the locked
position.
Folding up the backrest

Close cup holder (
page 170) and
ashtray (
page 172) in rear center
console.

Pull lock button1 up and unfold back-
rest until it locks in place.
Make sure the seat belt is not caught in
the seat.

Check for secure locking by pulling and
pushing on the backrest.
Warning!
G
Failure to assure that seats are locked into
place could result in an increased chance of
injury in an accident.

101 Controls in detailSeats
The red backrest lock indicator at lock
button1 is not visible in the locked
position.

Install head restraint (
page 96).

Slide seat rearward to desired position
(page 100).

Adjust front seats to desired position.
Manual seats (
page 36) or power
seats (
page 38).
Lowering the rear seat
1Release button
2Lever
3Release lever

Close cup holder in rear center console
(page 170).

Move front seats forward. Manual seat
(page 36) or power seat (
page 38).

Press and hold release button1 to un-
lock lever2.

Pull lever2 in direction of arrow.

Pull release lever3 and push down
rear seat until it locks in place.

Fold down the backrest (
page 100).

Adjust front seats to desired position.
Manual seats (
page 36) or power
seats (
page 38).Folding up the rear seat

Move front seats forward. Manual seat
(page 36) or power seat (
page 38).

Pull release lever3 and raise rear seat
until it locks in place.
Easy entry / exit feature*
The easy entry / exit feature allows access
to the third row seats*. The right cargo
floor plate must be removed (
page 165).
Warning!
G
Failure to assure that seats are locked into
place could result in an increased chance of
injury in an accident.Warning!
G
Never drive with the second row right seat
folded forward (easy entry / exit feature). It
could open and fold back unintentionally.

102 Controls in detailSeatsFolding rear seat forward
1Lever
Move right seat forward. Manual seats
(page 36) or power seats
(page 38).

Move rear seat forward (
page 100).

Push head restraint fully down and tilt
it forward.

Fold backrest forward (
page 100).

Pull lever1 up and fold the rear seat
forward.Resetting rear seat

Pull down on seat bench until it locks
into place.

Pull lock button1 (
page 100) up
and unfold backrest until it locks into
place.
The red backrest lock indicator at lock
button1 (
page 100) is not visible in
the locked position.

Check for secure locking by pulling and
pushing on the backrest.

Move the rear and front seats in de-
sired position.

Pull up and adjust head restraint
(page 37).
Third row seats*Warning!
G
For your protection, drive only with properly
positioned head restraints.
Adjust head restraint so that the center of
the head restraint supports the back of the
head at eye level. This will reduce the poten-
tial for injury to the head and neck in the
event of an accident or similar situation.
Failure to assure that seats are locked into
place could result in an increased chance of
injury in an accident.
Never place hands under seat or near any
moving parts while a seat is being adjusted.
