FRONT DOOR GLASS AND REGULATOR
GW-69
C
D
E
F
G
H
J
K
L
MA
B
GW
Revision: August 20072004 QX56
FRONT DOOR GLASS AND REGULATORPFP:80300
Removal and InstallationEIS00623
FRONT DOOR GLASS
Removal
1. Remove the front door speaker. Refer to AV-45, "Removal and Installation of Front Door Speaker" .
2. Remove the hole cover over rear door glass bolt.
3. Temporarily reconnect the power window switch to the door harness.
4. Operate the power window main switch to raise/lower the door glass until the door glass bolts can be
seen.
5. Remove the inside seal.
6. Remove the door glass bolts.
7. While holding the front door glass, raise it at the rear end and
pull the door glass out of the sash toward the outside of the
door.
Installation
Installation is in the reverse order of removal.
LIIA0959E
LIIA1687E
Door glass bolts : 6.1 N·m (0.62 kg-m, 54 in-lb)

REAR DOOR GLASS AND REGULATOR
GW-73
C
D
E
F
G
H
J
K
L
MA
B
GW
Revision: August 20072004 QX56
7. Remove door glass bolts and door glass.
8. Remove door glass.
Installation
Installation is in the reverse order of removal.
REAR DOOR GLASS REGULATOR
Removal
1. Remove the rear door finisher. Refer to EI-32, "Rear Door" .
2. Operate the power window switch to raise/lower the door glass
until the door glass bolts can be seen.
3. Remove the inside seal.
4. Remove the door glass bolts.
5. Raise the rear door glass and hold it in place with suitable tool
(A).
6. Remove the bolts, and the regulator and guide channel.
7. Disconnect the connector from the regulator assembly.
SIIA0290E
Door glass bolts : 6.1 N·m (0.62 Kg-m, 54 in-lb)
SIIA0290E
WIIA0765E
SIIA0291E

INSIDE MIRROR
GW-77
C
D
E
F
G
H
J
K
L
MA
B
GW
Revision: August 20072004 QX56
Removal and InstallationEIS002VL
INSIDE MIRROR
1. Remove inside mirror finisher.
2. Slide the mirror upward to remove.
3. Disconnect the connector.
Installation is in the reverse order of removal.
1. Inside mirror 2. Inside mirror finisher
SIIA0828E

GW-100
DOOR MIRROR
Revision: August 20072004 QX56
Door Mirror AssemblyEIS002WA
REMOVAL
NOTE:
Be careful not to damage the mirror bodies.
1. Remove the front door sash cover. Refer to AV- 4 6 , "
Removal and Installation of Front Tweeter" .
2. Remove the door mirror harness connector.
3. Remove the door mirror mounting nuts and the mirror assembly.
