DOOR FINISHER

FRONT AND REAR DOOR FINISHER
Removal
1. Fully open door window.
2. Remove inside handle escutcheon cap.
3. Remove inside handle escutcheon screw.
4. Insert a remover tool A into power window switch finisher (front)
(1), lift up front end and disengage metal clip. Pull out finisher
toward front of vehicle.
CAUTION:
Lift up rear end of power window switch finisher (rear) and
disengage metal clips, and then pull out finisher toward
rear of vehicle.
5. Disconnect power window switch harness connector after pulling out, and then remove power window
switch finisher.
6. Remove power window switch screws.
7. Insert a clip clamp remover into clips on back of door trim, and
disengage clips.
CAUTION:
Insert a clip clamp remover into the part shown by the
arrow (between the clips and the body side panel). Remove
door trim.
8. Disconnect harness connector for trunk lid opener after disengaging.
9. Disconnect harness connector for seat memory switch (1) and
indirect lighting (2).
10. Disconnect harness connector for step lamp.
11. Pull up door trim and pull out toward vehicle inside, and then dis-
connect inside handle cable (3) and lock knob cable (2) from
inside handle (1).
PIIB8685E
SIIA0810E
PIIB8687E
PIIB8686E

BODY SIDE TRIM
EI-41
C
D
E
F
G
H
J
K
L
MA
B
EI

2. Remove kicking plate inner mounting clips using a clip clamp
remover, and then remove kicking plate inner.
Installation
Install in the reverse order of removal.
REAR BODY SIDE WELT
Removal
1. Remove center pillar lower garnish.
2. Remove rear seat cushion. Refer to SE-112, "
REAR SEAT" .
3. Remove rear kicking plate inner.
4. Remove rear body side welt.
Installation
Install in the reverse order of removal.
REAR SEATBACK FINISHER
Removal
1. Remove rear seat cushion and rear seatback. Refer to SE-112,
"REAR SEAT" .
2. Remove rear seat belt floor anchor bolt. Refer to SB-5,
"Removal and Installation of Rear Seat Belt" .
3. Remove rear kicking plate inner.
4. Remove rear seatback finisher.
Installation
Install in the reverse order of removal.
NOTE:
To install, check if all clips are matched over holes of panel on vehicle, then push on.
REAR PILLAR FINISHER
Removal
1. Remove rear seat cushion and rear seatback. Refer to SE-112,
"REAR SEAT" .
2. Remove rear seat belt floor anchor bolt. Refer to SB-5,
"Removal and Installation of Rear Seat Belt" .
3. Remove rear kicking plate inner.
4. Remove rear seatback finisher.
5. Remove pillar finisher mounting clips using a screwdriver, and
then remove pillar finisher.
PIIA7074E
PIIA7075E
PIIA7076E

EI-44
REAR PARCEL SHELF FINISHER

REMOVAL
1. Remove rear seatback and rear seat cushion. Refer to SE-112, "REAR SEAT" .
2. Remove rear seat belt floor anchor bolt and rear seat belt shoulder anchor bolt. Refer to SB-5, "
Removal
and Installation of Rear Seat Belt" .
3. Disengage child anchor cover front pawls, and then pull out child
anchor cover (LH/RH center) toward front of vehicle.(Models
with rear window sunshade)
4. Remove rear kicking plate inner, rear seatback finisher, rear pillar finisher. Refer to EI-38, "
BODY SIDE
TRIM" .
5. Disconnect high-mounted stop lamp harness connector from
trunk room side. (Models without rear window sunshade)
6. Disconnect high-mounted stop lamp harness connector from
front side of rear parcel shelf finisher. (Models with rear window
sunshade)
7. Remove rear parcel shelf finisher mounting clip using a clip clamp remover.
8. Remove rear parcel shelf finisher while disengaging dual-lock fastener on back of rear parcel shelf fin-
isher. (Models with rear window sunshade)
9. Remove the following parts after removing rear parcel shelf finisher.

Rear speaker grille (for woofer)

High-mounted stop lamp
INSTALLATION
Install in the reverse order of removal.
7. Screw 8.Rear parcel shelf finisher (with sun-
shade)9. Child anchor cover (LH/RH center)
10. Rear window sunshade 11. Bolt 12. Locating pin
PIIA9530E
PIIA9531E
PIIA9535E

HEADLINING
EI-55
C
D
E
F
G
H
J
K
L
MA
B
EI

REMOVAL
1. Remove front seat belt floor anchor bolt and rear seat belt floor ancher bolt. Refer to SB-3, "SEAT BELTS"
and SB-5, "Removal and Installation of Rear Seat Belt" .
2. Remove rear seat. Refer to SE-112, "
REAR SEAT" .
3. Remove front pillar garnish (LH/RH). Refer to EI-38, "
BODY SIDE TRIM" .
4. Remove roof harness securing clip using a clip clamp remover
after removing, and then disconnect roof harness connector.
5. Remove front kicking plate inner, center pillar lower garnish, center pillar upper garnish, front body side
welt, rear kicking plate inner, rear seatback finisher, rear pillar finisher, and rear body side welt. Refer to
EI-38, "
BODY SIDE TRIM" .
6. Remove mounting clips of front assist grip (RH) and rear assist
grip (LH/RH).
7. Remove sun-visor (LH/RH) mounting screws.
NOTE:
Disconnect vanity mirror illumination harness connector when removing sun-visor.
1. Clip (C101) 2. Headlining (standard model) 3. Rear assist grip (RH)
4. Personal lamp (RH) 5. Roof harness securing clip 6. Roof harness connector
7. Sun-visor (RH) 8. Sun-visor holder (RH) 9. Screw
10. Cap (RH) 11. Spot lamp (map lamp) 12. Sun-visor holder (LH)
13. Cap (LH) 14.Vanity mirror illumination harness con-
nector15. Sun-visor (LH)
16.Spot lamp(map lamp) harness
connector (standardmodel)17. Metal clip 18. Dual lock fastener (with sunroof model)
19.Harness connector for hands-
free phone microphone
(model with car wings unit)20.Roof harness securing tape (standard
model)21. Front assist grip (RH)
22. Personal lamp (LH) 23. Rear assist grip (LH) 24. Clip holder
25.Headlining (model with sun-
roof)26.Sunroof motor harness connector
(model with sunroof)27. Front roof finisher (model with sunroof)
28.Roof hook (model with sun-
roof)
PIIA7118E
PIIA6267E

EI-56
HEADLINING

8. Remove sun-visor holder (LH/RH).
NOTE:
Insert a screwdriver into the cutout and rotate 90 degrees to
remove.
9. Remove clips from back of front roof finisher, and then pull out
front roof finisher toward front of vehicle to remove it. (with sun-
roof model)
10. Pull out sunroof motor harness connector from front roof finisher
mounting hole to disconnect. (with sunroof model)
11. Pull out spot lamp (map lamp) toward lower side of vehicle and disconnect harness connector.
12. Disconnect harness connector for hands-free phone microphone. (Only for models with Car wings unit)
13. Pull spot lamp holder assembly toward vehicle lower, and disen-
gage dual-lock fastener and metal clips.
SIIA0224J
PIIA9621E
PIIA9622E
PIIA6272E
