NISSAN TEANA 2003 Service Manual LT-20
HEADLAMP - XENON TYPE -

NOTE:
This item is displayed, but cannot be monitored.
ACTIVE TEST
Operation Procedure
1. Touch “HEAD LAMP” on “SELECT TEST ITEM” screen.
2. Touch “ACTIVE TES

LT-20
HEADLAMP - XENON TYPE -

NOTE:
This item is displayed, but cannot be monitored.
ACTIVE TEST
Operation Procedure
1. Touch “HEAD LAMP” on “SELECT TEST ITEM” screen.
2. Touch “ACTIVE TEST” on “SELECT DIAG MODE” screen.
3. Touch item to be tested and check operation of the selected item.
4. During the operation check, touching “OFF” deactivates the operation.
Display Item List
NOTE:
This item is displayed, but cannot be monitored.
CONSULT-II Functions (IPDM E/R)BKS001N5
CONSULT-II can display each diagnostic item using the diagnostic test mode shown following.
CONSULT-II OPERATION
Refer to GI-34, "CONSULT-II Start Procedure" .
DOOR SW - DR “ON/OFF”Displays status of the driver door as judged from the driver door switch signal. (Door is open:
ON/door is closed: OFF)
DOOR SW - AS “ON/OFF”Displays status of the passenger door as judged from the passenger door switch signal. (Door
is open: ON/door is closed: OFF)
DOOR SW - RR “ON/OFF”Displays status of the rear door as judged from the rear door switch (RH) signal. (Door is open:
ON/door is closed: OFF)
DOOR SW - RL “ON/OFF”Displays status of the rear door as judged from the rear door switch (LH) signal. (Door is open:
ON/door is closed: OFF)
BACK DOOR SW
NOTE “OFF” —
TURN SIGNAL R “ON/OFF” Displays status (Turn right: ON/others: OFF) as judged from lighting switch signal.
TURN SIGNAL L “ON/OFF” Displays status (Turn left: ON/others: OFF) as judged from lighting switch signal.
OPTICAL SENSOR “0 - 5V ”Displays “outside brightness (close to 5V when light/close to 0V when dark)” judged from opti-
cal sensor signal.
VEHICLE SPEED “km/h” Displays vehicle speed as judged from vehicle speed signal.Monitor item Contents
CONSULT-II screen
displayTest item Description
TAIL LAMPParking, license plate and tail
lamps operationTail lamp relay is operated by switching operation ON-OFF.
HEAD LAMP High beam headlamp and low
beam headlamp operationHeadlamp high relay and headlamp low relay are operated by switching
operation (OFF: OFF, HI: high beam, LO: low beam).
RR FOG LAMP Rear fog lamp operation Rear fog lamp is operated by switching operation ON-OFF.
FR FOG LAMP Front fog lamp operation Front fog lamp relay is operated by switching operation ON-OFF.
CORNERING LAMP
Cornering lamp operation
NOTE—
ILL DIM SIGNALCombination meter and dis-
play dimming operationDimming function by MR output signal from BCM, it is operated by switch-
ing operation ON-OFF.
Diagnosis Mode Description
SELF-DIAGNOSTIC RESULTS Refer to PG-19, "
SELF-DIAG RESULTS" .
DATA MONITOR The input/output data of the IPDM E/R is displayed in real time.
CAN DIAG SUPPORT MNTR The result of transmit/receive diagnosis of CAN communication can be read.
ACTIVE TEST IPDM E/R sends a drive signal to electronic components to check their operation.
