DI-22
COMBINATION METERS

2. CHECK UNIFIED METER AND A/C AMP. INPUT SIGNAL
1. Select “ENGINE” on CONSULT-II.
2. Using “COOLAN TEMP/S” on “DATA MONITOR”, print out the
CONSULT-II screen.
3. Select “METER A/C AMP” on CONSULT-II.
4. Using “W TEMP METER” on “DATA MONITOR”, compare the
value of “DATA MONITOR” with that of the “COOLAN TEMP/S”.
OK or NG
OK >> Perform ECM self-diagnosis. Refer to EC-425, "CON-
SULT-II Function (ENGINE)" . Check applicable parts,
and repair or replace corresponding parts
NG >> Replace unified meter and A/C amp. Refer to DI-34,
"Removal and Installation of Unified Meter and A/C
Amp." .
Fuel Level Sensor Signal InspectionBKS001SB
NOTE:
The following symptoms are not malfunction.

Fuel gage
–Depending on vehicle position or driving circumstance, the fuel level in the tank various, and the pointer
may fluctuate.
–If the vehicle is fueled with the ignition switch ON, the pointer will move slowly.

Low-fuel warning lamp
–Depending on vehicle position or driving circumstance, the fuel in the tank flows and the warning lamp ON
timing may change.
1. CHECK UNIFIED METER AND A/C AMP. INPUT SIGNAL
1. Select “METER A/C AMP” on CONSULT-II.
2. Using “FUEL METER” on “DATA MONIOR”, compare the value
of “DATA MONITOR” with fuel gauge pointer of combination
meter.
OK or NG
OK >> GO TO 2.
NG >> Replace combination meter.
2. CHECK FUEL LEVEL SENSOR UNIT
1. Turn ignition switch OFF.
2. Check fuel level sensor unit. Refer to DI-24, "
CHECK FUEL LEVEL SENSOR UNIT" .
OK or NG
OK >> GO TO 3.
NG >> Replace the corresponding parts.
SKIA4368E
Fuel gauge pointer Reference value of data monitor [lit.]
Full Approx. 66
Three quarters Approx. 53
Half Approx. 36
A quarter Approx. 18
Empty Approx. 8
PKIA2088E

UNIFIED METER AND A/C AMP
DI-27
C
D
E
F
G
H
I
J
L
MA
B
DI

UNIFIED METER AND A/C AMPPFP:27760
System DescriptionBKS001SK

For the unified meter and A/C amp., the signal required for con-
trolling the combination meter are integrated in the A/C auto
amp.

Unified meter and A/C amp. controls each operation for A/C
auto amp. For information regarding A/C control, refer to AT C -
24, "AIR CONDITIONER CONTROL" .

Unified meter and A/C amp. inputs necessary information for
combination meter from each unit by CAN communication and
so on.

And unified meter and A/C amp. outputs these signals using
communication line (TX, RX) between unified meter and A/C
amp. and combination meter.

The signals required for the distance to empty (DTE) display are centralized in the unified meter and A/C
amp., converted into data, and sent to the display unit (with display unit) using CAN communication.

Other input signals are also sent to the ECM, TCM, BCM and display unit (with display unit) using CAN
communication.

The unified meter and A/C amp. correspond a CONSULT-II function (self-diagnostic results, CAN diag-
nostic support monitor and data monitor).
INPUT/OUTPUT SIGNALS
Between Unified Meter and A/C amp. and Combination Meter
SKIB0778E
Unit Input Output
Unified meter and A/C amp.

Seat belt buckle switch signal (Driver's side)

Parking brake signal

Illumination control nighttime required signal

Refuel status signal

Low-fuel warning lamp condition signal

Combination meter receive error signal

Delivery destination data signal

Combination meter specifications signal

Vehicle speed signal (8-pulse)

Engine speed signal

Engine coolant temperature signal

Fuel level sensor signal (resistance value)

Malfunction indicator lamp signal

ABS warning lamp signal

Brake warning lamp signal

KEY warning lamp signal (With Intelligent Key)

LOCK warning lamp signal (With Intelligent Key)

High-beam request signal

Turn indicator signal

VDC OFF indicator lamp signal (With VDC)

SLIP indicator lamp signal (With VDC)

ASCD CRUISE indicator lamp signal

ASCD SET indicator lamp signal

A/T position indicator signal

A/T CHECK warning lamp signal

CVT indicator lamp signal

CVT position indicator signal

Door switch signal

Oil pressure switch signal

Position lights request signal

Front fog light request signal

Rear fog light request signal

Buzzer output signal

DI-32
UNIFIED METER AND A/C AMP

DTC [U1000] CAN Communication CircuitBKS002B1
1. CHECK CAN COMMUNICATION
1. Select “CAN DIAG SUPPORT MNTR” mode for “METER A/C AMP” with CONSULT-II.
2. Print out CONSULT-II screen.
>> Go to “LAN SYSTEM”. Refer to LAN-49, "
CAN System Specification Chart" .
DTC [B2202] Meter Communication CircuitBKS002B2
1. CHECK CONNECTOR
Check combination meter, unified meter and A/C amp. and terminals (combination meter side, unified meter
and A/C amp. side and harness side) for looseness or bent terminals.
OK or NG
OK >> GO TO 2.
NG >> Repair terminal or connector.
2. CHECK METER/GAUGES VISUALLY
Does the pointer on the meter/gauge fluctuate at the engine start?
Is the fluctuation acceptable?
YES >> GO TO 3.
NO >> GO TO 6.
3. CHECK CONTINUITY COMMUNICATION CIRCUIT (TX: COMBINATION METER)
1. Turn ignition switch OFF.
2. Disconnect combination meter connector and unified meter and A/C amp. connector.
3. Check continuity between combination meter harness connector
M70 terminal 18 and unified meter and A/C amp. harness con-
nector M41 terminal 19.
4. Check continuity between combination meter harness connector
M70 terminal 18 and ground.
OK or NG
OK >> GO TO 4.
NG >> Repair harness or connector.
4. CHECK VOLTAGE OF UNIFIED METER AND A/C AMP.
1. Connect unified meter and A/C amp. connector.
2. Turn ignition switch ON.
3. Check voltage between combination meter harness connector
M70 terminal 18 and ground.
OK or NG
OK >> GO TO 5.
NG >> Replace unified meter and A/C amp. Refer to DI-34,
"Removal and Installation of Unified Meter and A/C
Amp." . 18 – 19 : Continuity should exist.
18 – Ground : Continuity should not exist.
SKIA8726E
18 – Ground : Approx. 5 V
SKIB1049E

WARNING LAMPS
DI-45
C
D
E
F
G
H
I
J
L
MA
B
DI

Oil Pressure Warning Lamp Stays Off (Ignition Switch ON)BKS001SS
1. CHECK IPDM E/R OUTPUT SIGNAL
Activate IPDM E/R auto active test. Refer to PG-21, "
Auto Active Test" .
Is oil pressure warning lamp blinking?
No malfunction detected>> GO TO 5.
Malfunction detected>> Go to 2.
2. CHECK SELF-DIAGNOSTIC RESULTS OF IPDM E/R
Select “IPDM E/R” on CONSULT-II, and perform self diagnosis of IPDM E/R. Refer to PG-19, "
CONSULT-II
Function (IPDM E/R)"
Self-diagnosis result content?
YES >> GO TO 3.
NO >> GO TO PG-19, "
SELF-DIAG RESULTS" in “IPDM E/R”.
3. CHECK UNIFIED METER AND A/C AMP. INPUT SIGNAL
Select “METER A/C AMP” on CONSULT-II. Operate ignition switch
with “OIL W/L” of “DATA MONITOR” and check operation status.
OK or NG
OK >> Replace combination meter.
NG >> GO TO 4.
4. CHECK BCM INPUT SIGNAL
Select “DATA MONITOR” of “SIGNAL BUFFER”. Refer to BCS-13,
"CONSULT-II Function (BCM)" . Operate ignition switch with “OIL
PRESS SW” of “DATA MONITOR” and check operate status.
OK or NG
OK >> Replace combination meter .
NG >> Replace IPDM E/R.“OIL W/L”
When ignition switch is in ON
position (Engine stopped.): ON
When engine running : OFF
PKIA2064E
“OIL PRESS SW”
When ignition switch is in ON
position (Engine stopped.): ON
When engine running : OFF
SKIA8709E

DI-46
WARNING LAMPS

5. CHECK OIL PRESSURE SWITCH CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R connector.
3. Check continuity between IPDM E/R harness connector E9 ter-
minal 57 and ground.
OK or NG
OK >> Replace IPDM E/R. Refer to PG-28, "Removal and
Installation of IPDM E/R" .
NG >> GO TO 6.
6. CHECK OIL PRESSURE SWITCH
Check oil pressure switch. Refer to DI-47, "
Electrical Component Inspection"
OK or NG
OK >> GO TO 7.
NG >> Replace oil pressure switch.
7. CHECK OIL PRESSURE SWITCH CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R connector and oil pressure switch connector.
3. Check continuity between IPDM E/R harness connector E9 ter-
minal 57 and oil pressure switch harness connector F257 termi-
nal 1 (VQ engine), F11 terminal 1 ( QR engine ).
OK or NG
OK >> Replace IPDM E/R.
NG >> Repair harness or connector.
Oil Pressure Warning Lamp Does Not Turn Off (Oil Pressure Is Normal)BKS001ST
NOTE:
For oil pressure inspection, refer to LU-20, "
OIL PRESSURE CHECK" .
1. CHECK IPDM E/R OUTPUT SIGNAL
Activate IPDM E/R auto active test. Refer to PG-21, "
Auto Active Test" .
Is oil pressure warning lamp blinking?
No malfunction detected>> GO TO 3.
Malfunction detected>> Go to 2.
2. CHECK SELF-DIAGNOSTIC RESULTS OF IPDM E/R
Select “IPDM E/R” on CONSULT-II, and perform self diagnosis of IPDM E/R. Refer to PG-19, "
CONSULT-II
Function (IPDM E/R)"
Self-diagnosis result content?
YES >> Replace combination meter.
NO >> GO TO PG-19, "
SELF-DIAG RESULTS" in “IPDM E/R”. 57 – Ground : Continuity should not exist.
SKIA5013E
57 – 1 : Continuity should exist.
PKIC9837E

WARNING LAMPS
DI-47
C
D
E
F
G
H
I
J
L
MA
B
DI

3. CHECK IPDM E/R OUTPUT SIGNAL
1. Turn ignition switch OFF.
2. Disconnect oil pressure switch connector.
3. Turn ignition switch ON.
4. Check voltage between oil pressure switch harness connector
F257 terminal 1 ( VQ engine ) or F11 terminal 1 ( QR engine )
and ground.
OK or NG
OK >> GO TO 4.
NG >> GO TO 5.
4. CHECK OIL PRESSURE SWITCH
1. Turn ignition switch OFF.
2. Check oil pressure switch. Refer to DI-47, "
OIL PRESSURE SWITCH" .
OK or NG
OK >> Replace IPDM E/R. Refer to PG-28, "Removal and Installation of IPDM E/R" .
NG >> Replace oil pressure switch.
5. CHECK OIL PRESSURE SWITCH CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R connector.
3. Check continuity between IPDM E/R harness connector E9 ter-
minal 57 and ground.
OK or NG
OK >> Replace IPDM E/R. Refer to PG-28, "Removal and
Installation of IPDM E/R" .
NG >> Repair harness or connector.
Electrical Component InspectionBKS001SU
OIL PRESSURE SWITCH
Check continuity between oil pressure switch and ground.1 – Ground : Battery voltage
PKIC9838E
57 – Ground : Continuity should not exist.
SKIA5013E
Condition
Oil pressure kPa (bar, kg/cm2 , psi) Continuity
Engine stopped Less than 29 (0.3, 0.3, 4) Yes
Engine running More than 29 (0.3, 0.3, 4) No
ELF0044D

DI-50
A/T INDICATOR

A/T Indicator Is MalfunctionBKS001SW
1. CHECK SELF-DIAGNOSIS OF COMBINATION METER
Perform combination meter self-diagnosis. Refer to DI-13, "
OPERA-
TION PROCEDURE"
Are all segments displayed?
YES >> GO TO 2.
NO >> Replace combination meter.
2. CHECK SELF-DIAGNOSIS RESULTS OF UNIFIED AND METER AND A/C AMP.
Select “METER A/C AMP” on CONSULT-II, and then perform self-diagnosis of unified meter and A/C amp.
Refer to DI-29, "
CONSULT-II Function (METER A/C AMP)"
Self-diagnosis result content
No malfunction detected >>SO TO 3
Malfunction detected >>GO TO DI-17, "
SYMPTOM CHART 2"
3. CHECK UNIFIED METER AND A/C AMP. INPUT SIGNAL
1. Connect CONSULT-II and start engine.
2. Use “DATA MONITOR” of “METER A/C AMP” on CONSULT-II.
Confirm each indication on the monitor when operating the shift
lever.
OK or NG
OK >> Replace combination meter.
NG >> GO TO 4.
SKIB0783E
CONSULT-II display Switch operation Operation status
P RANGE INDP range position ON
Except for P range position OFF
R RANGE INDR range position ON
Except for R range position OFF
N RANGE INDN range position ON
Except for N range position OFF
D RANGE INDD range position ON
Except for D range position OFF
3 RANGE IND3 range position ON
Except for 3 range position OFF
2 RANGE IND2 range position ON
Except for 2 range position OFF
1 RANGE IND1 range position ON
Except for 1 range position OFF
SKIB0784E

DI-54
CVT INDICATOR

CVT Indicator Is MalfunctionBKS002B6
1. CHECK SELF-DIAGNOSIS OF COMBINATION METER
Perform combination meter self-diagnosis. Refer to DI-13, "
OPERA-
TION PROCEDURE" .
Are all segments displayed?
YES >> GO TO 2.
NO >> Replace combination meter.
2. CHECK SELF-DIAGNOSTIC RESULTS OF UNIFIED METER AND A/C AMP.
Select “METER A/C AMP” on CONSULT-II, and perform self-diagnosis of unified meter and A/C amp. Refer
toDI-29, "
CONSULT-II Function (METER A/C AMP)" .
Self
-diagnostic results content
No malfunction detected>>GO TO 3.
Malfunction detected>>Check applicable parts, and repair or replace corresponding parts.
3. CHECK UNIFIED METER AND A/C AMP. INPUT SIGNAL
1. Connect CONSULT-II and start engine.
2. Use “DATA MONITOR” of “METER A/C AMP” on CONSULT-II.
Confirm each indication on the monitor when operating the shift
lever.
OK or NG
OK >> Replace combination meter.
NG >> GO TO 4.
EL-3828D
CONSULT-II display Switch operationOperation
status
AT - M I N DManual mode range ON
Except for manual mode range OFF
AT - M G E A RManual mode range (shift-up or down) 5-1
Except for manual mode range 1
P RANGE INDP range position ON
Except for P range position OFF
R RANGE INDR range position ON
Except for R range position OFF
N RANGE INDN range position ON
Except for N range position OFF
D RANGE INDD range position ON
Except for D range position OFF
L RANGE INDL range position ON
Except for L range position OFF
PKID0249E
