DTC P1706 PNP SWITCH

Specification data are reference values and are measured between each terminal and ground.
CAUTION:
Do not use ECM ground terminals when measuring input/output voltage. Doing so may result in dam-
age to the ECM's transistor. Use a ground other than ECM terminals, such as the ground.
Diagnostic ProcedureBBS005GY
1. CHECK PNP SWITCH INPUT SIGNAL CIRCUIT FOR OPEN AND SHORT-I
1. Turn ignition switch OFF.
2. Disconnect “unified meter and A/C amp.” harness connector M42.
3. Turn ignition switch ON.
4. Check voltage between “unified meter and A/C amp.” terminals
32, 33 and ground with CONSULT-II or tester under the follow-
ing conditions.
OK or NG
OK >> GO TO 8.
NG >> GO TO 2.
2. CHECK PNP SWITCH POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect PNP switch harness connector.
3. Turn ignition switch ON.
4. Check voltage between PNP switch terminal 3 and ground with
CONSULT-II or tester.
OK or NG
OK >> GO TO 4.
NG >> GO TO 3.
TERMI-
NAL
NO.WIRE
COLORITEM CONDITION DATA (DC Voltage)
102 G/W PNP switch[Ignition switch: ON]

Shift lever: P or NApproximately 0V
[Ignition switch: ON]

Except above positionBATTERY VOLTAGE
(11 - 14V)
Condition (Shift position)Voltage
Te r m i n a l 3 2 Te r m i n a l 3 3
P positionBATTERY VOLTAGE
(11 - 14V)Approximately 0 V
N position Approximately 0 VBATTERY VOLTAGE
(11 - 14V)
Except the above position Approximately 0 V Approximately 0 V
PBIB1675E
Voltage: Battery voltage
PBIB1881E

DTC P1706 PNP SWITCH
EC-241
[QR]
C
D
E
F
G
H
I
J
K
L
MA
EC

3. DETECT MALFUNCTIONING PART
Check the following.

Harness connectors M55, F102

Fuse block (J/B) connector M1

10A fuse

Harness for open or short between PNP switch and fuse
>> Repair open circuit or short to ground or short to power in harness or connectors.
4. CHECK PNP SWITCH INPUT SIGNAL CIRCUIT FOR OPEN AND SHORT-I
1. Turn ignition switch OFF.
2. Check harness continuity between PNP switch terminal 7 and “unified meter and A/C amp.” terminal 32,
PNP switch terminal 9 and “unified meter and A/C amp.” terminal 33.
Refer to Wiring Diagram.
3. Also check harness for short to ground and short to power.
OK or NG
OK >> GO TO 6.
NG >> GO TO 5.
5. DETECT MALFUNCTIONING PART
Check the following.

Harness connectors F102, M55

Harness for open or short between PNP switch and “unified meter and A/C amp.”
>> Repair open circuit or short to ground or short to power in harness or connectors.
6. CHECK PNP SWITCH
Refer to AT- 1 6 6 , "
Component Inspection" .
OK or NG
OK >> GO TO 7.
NG >> Replace PNP switch.
7. CHECK INTERMITTENT INCIDENT
Refer to EC-105, "
TROUBLE DIAGNOSIS FOR INTERMITTENT INCIDENT" .
>>INSPECTION END
8. CHECK PNP SWITCH INPUT SIGNAL CIRCUIT FOR OPEN AND SHORT-II
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check harness continuity between ECM terminal 102 and “unified meter and A/C amp.” terminal 25.
Refer to Wiring Diagram.
4. Also check harness for short to ground and short to power.
OK or NG
OK >> GO TO 9.
NG >> Repair open circuit or short to ground or short to power in harness or connectors.Continuity should exist.
Continuity should exist.

EC-242
[QR]
DTC P1706 PNP SWITCH

9. CHECK INTERMITTENT INCIDENT
Refer to EC-105, "
TROUBLE DIAGNOSIS FOR INTERMITTENT INCIDENT" .
OK or NG
OK >> GO TO 10.
NG >> Repair or replace.
10. REPLACE UNIFIED METER AND A/C AMP.
Refer to DI-27, "
UNIFIED METER AND A/C AMP" .
>>INSPECTION END
