LT-220
INTERIOR ROOM LAMP

Power is supplied at all times (with Intelligent Key system)

through 15A fuse [No. 18, located in fuse block (J/B)]

to ignition knob switch, key switch and key lock solenoid terminals 3 and 7,

through 15A fuse [No. 17, located in fuse block (J/B)]

to BCM terminal 42,

through 50A fusible link (letter M, located in fuse and fusible link block)

to BCM terminal 55.
With the ignition switch in the ON or START position, power is supplied

through 10A fuse [No. 1, located in fuse block (J/B)]

to BCM terminal 38.
Ground is supplied

to BCM terminal 52

through grounds M71 and M72.
SWITCH OPERATION
When the key switch and key lock solenoid (key switch) is ON (key is inserted), power is supplied (without
Intelligent Key system)

through the key switch and key lock solenoid terminal 4

to BCM terminal 37.
With power is supplied, BCM detects that the key is inserted.
When the ignition knob switch, key switch and key lock solenoid (key switch) is ON (key is inserted), power is
supplied (with Intelligent Key system)

through ignition knob switch, key switch and key lock solenoid terminal 8

to BCM terminal 37.
With power is supplied, BCM detects that the key is inserted.
When the ignition knob switch, key switch and key lock solenoid (ignition knob switch) is ON (ignition knob
switch is pushed), power is supplied (with Intelligent Key system)

through ignition knob switch key switch and key lock solenoid terminal 2

to Intelligent Key unit terminal 27.
With power is supplied, Intelligent Key unit detects that the ignition knob switch is pushed. Intelligent Key unit
sends ignition knob switch signal (ON) to BCM through CAN communication.
When the front door switch (driver side) is ON (door is opened), ground is supplied

to BCM terminal 62

through front door switch (driver side) terminal 2

through case ground of front door switch (driver side).
When the front door switch (passenger side) is ON (door is opened), ground is supplied

to BCM terminal 12

through front door switch (passenger side) terminal 2

through case ground of front door switch (passenger side).
When the rear door switch RH is ON (door is opened), ground is supplied

to BCM terminal 13

through rear door switch RH terminal 2

through case ground of rear door switch RH.
When the rear door RH is opened, ground is supplied

to BCM terminal 63

through rear door switch LH terminal 2

through case ground of rear door switch LH.
With ground is supplied, BCM detects that each door is opened.
When the front door lock assembly (driver side) (door unlock sensor) is ON (driver side door is unlocked),
ground is supplied

to BCM terminal 7

INTERIOR ROOM LAMP
LT-221
C
D
E
F
G
H
I
J
L
MA
B
LT


through front door lock assembly (driver side) (door unlock sensor) terminal 4

through front door lock assembly (driver side) (door unlock sensor) terminal 5

through grounds M71 and M72.
With ground is supplied, BCM detects that the driver side door is unlocked.
When the front door lock assembly (driver side) (door unlock sensor) is OFF (door is locked), ground is not
supplied. And BCM detects that the driver side door is locked.
When the trunk lid lock assembly (trunk room lamp switch) is ON (trunk lid is opened), ground is supplied

to BCM terminal 57

through trunk lid lock assembly (trunk room lamp switch) terminal 3

through trunk lid lock assembly (trunk room lamp switch) terminal 1

through grounds B214 and B217.
With ground is supplied, BCM detects that the trunk lid is opened.
STEP LAMP OPERATION
When front door switch (driver side) or front door switch (passenger switch) is turned ON, front step lamp
(driver side) and front step lamp (passenger side) turns ON. Power is supplied

through 10A fuse [No. 21, located in fuse block (J/B)]

to front step lamp (driver side) terminal 1 and

to front step lamp (passenger side) terminal 1.
Ground is supplied

to front step lamp (driver side) terminal 2 and

to front step lamp (passenger side) terminal 2

through BCM terminal 47.
With power and ground supplied, front step lamp (driver side) and front step lamp (passenger side) illuminate.
And, front step lamp (driver side) and front step lamp (passenger side) turns OFF when front door switch
(driver side) and front door switch (passenger switch) are turned OFF.
TRUNK ROOM LAMP OPERATION
When trunk lid lock assembly (trunk room lamp switch) is turned ON (trunk lid is opened), trunk room lamp turn
ON. Power is supplied

through 10A fuse [No. 21, located in fuse block (J/B)]

to trunk room lamp terminal 1.
Ground is supplied

to trunk room lamp terminal 2

through BCM terminal 64.
With power and ground supplied, trunk room lamp illuminate.
And, trunk room lamp turns OFF when trunk lid lock assembly (trunk room lamp switch) is turned OFF.
INTERIOR ROOM LAMP TIMER OPERATION
The interior room lamp timer controls to turn ON/OFF of the map lamp, personal lamps and ignition keyhole
illumination when map lamp switch and personal lamp switch are in DOOR position.
BCM controls the interior room lamp timer according to the following signals.

Key switch signal

Door lock status signal (from front door lock assembly)

Front door switch (driver side) signal

Front door switch (passenger side) signal

Rear door switch RH signal

Rear door switch LH signal

Keyless lock/unlock signal (from remote keyless receiver)

Intelligent Key lock/unlock signal (from Intelligent Key unit through CAN communication)
And when those lamps are turned ON/OFF, the interior room lamp timer executes brightening/dimming control
for maximum 5 seconds. Brightening/dimming control time can be changed with CONSULT-II. Refer to LT- 2 3 3 ,
"WORK SUPPORT (INT LAMP)" .

LT-230
INTERIOR ROOM LAMP

Terminals and Reference Values for BCMBKS001R8
Te r -
minal
No.Wire
colorSignal nameMeasuring condition
Reference value
Ignition
switchOperation or condition
7 LG/R Door lock status signal OFF Door unlock sensorUNLOCK posi-
tionApprox. 0 V
Other
Approx. 8.5 - 9.0
12 R/LFront door switch (pas-
senger side) signalOFFFront door switch
(passenger side)ON (open) Approx. 0 V
OFF (closed)
Approx. 7.5 - 8.0
13 R/BRear door switch RH sig-
nalOFF Rear door switch RHON (open) Approx. 0 V
OFF (closed)
Approx. 7.5 - 8.0
37B/R
*1
BR*2Key switch signal OFFVehicle key is removed. Approx. 0 V
Vehicle key is inserted. Battery voltage
38 R Ignition switch (ON) ON — Battery voltage
39 L CAN−H— — —
40 P CAN−L— — —
42 Y/RBattery power
supplyOFF — Battery voltage
47 R/W Step lamp output signal OFFFront door switch (driver side)
or front door switch (passenger
side)ON
(open)Battery voltage
OFF
(close)Approx. 0 V
48 Y Room lamp output signalOFF
Interior
room lamp
switch:
DOOR
positionVehicle
key is
insertedAny
door
switchON
(open)Approx. 0 V
OFF
(closed)Battery voltage
—Vehicle
key is
removedAfter the
inserted key is
removedApprox. 0 V
Ignition key is
ONBattery voltage
PKIC4868J
PKIB4960J
PKIB4960J

MA-8
PERIODIC MAINTENANCE

PERIODIC MAINTENANCEPFP:00026
Periodic MaintenanceBLS0008Z
The following tables show the normal maintenance schedule. Depending upon weather and atmospheric con-
ditions, varying road surfaces, individual driving habits and vehicle usage, additional or more frequent mainte-
nance may be required.
Periodic maintenance beyond the last period shown on the tables requires similar maintenance.
ENGINE AND EMISSION CONTROL MAINTENANCE
(Annual Mileage <30,000 Km [18,000 miles]/year)
QR and VQ ENGINE
Abbreviations: I = Inspect and correct or replace as necessary, R = Replace
[ ] = At the specified distance only
NOTE:

(1) Periodic maintenance is not required. However, if valve noise increases, check valve clearance.

(2) Replace the drive belt if found damaged or if the auto tensioner reading (for QR20DE engine) reaches the maximum
limit.

(3) First replace at 100,000 km (60,000 miles)/60 months, then every 60,000 km (36,000 miles)/48 months. Perform “I”
(Checking the mixture ratio and correcting the mixture ratio if necessary) at the middle of replacement interval.

(4) Fuel filter is maintenance-free. For service procedures, refer to FL section.

(5) Perform only according to “Maintenance Under Severe Driving Conditions” for models without Euro-OBD system.

Maintenance items with “ ” should be performed more frequently according to “Maintenance Under Severe Driving
Conditions”. MAINTENANCE OPERATIONMAINTENANCE INTERVAL Reference page
Perform either at number of kilometers
(miles) or months, whichever comes first.km x
1,000
(Miles x
1,000)
Months15
(9)
1230
(18)
2445
(27)
3660
(36)
4875
(45)
6090
(54)
72105
(63)
84120
(72)
96QR20DEVQ23DE
VQ35DE
Engine compartment and under vehicle
Intake and exhaust valve clearanceSee
NOTE
(1)EM-50
EM-202
Drive beltsSee
NOTE
(2)I IIIIIIIMA-16MA-24
Engine oil (Use recommended oil.)RR RRRRRRMA-20MA-30
Engine oil filter (Use genuine NISSAN part
or equivalent)RR RRRRRRMA-21MA-31
Engine anti-freeze coolant (Use Genuine
NISSAN Anti-freeze Coolant or equivalent
in its quality.)See
NOTE
(3)IMA-16
MA-25
Cooling system I IIIIIIIMA-18MA-28
Positive crankcase ventilation (PCV) sys-
tem (VQ engine only)IIII—MA-33
Fuel and EVAP vapor lines I I I IMA-23MA-34
Air cleaner filterRRMA-20MA-30
Fuel filter (In-tank type)See
NOTE
(4)——
Spark plugs (Platinum-tipped type) [R] [R] [R] [R]MA-22
MA-32
Heated oxygen sensorSee
NOTE
(5)EC-150,
EC-143EC-496,
EC-486

MA-10
PERIODIC MAINTENANCE

MAINTENANCE UNDER SEVERE DRIVING CONDITIONS
(Annual Mileage <30,000 Km [18,000 miles]/year)
The maintenance intervals shown on the preceding pages are for normal operating conditions. If the vehicle is
mainly operated under severe driving conditions as shown below, more frequent maintenance must be per-
formed on the following items as shown in the table.
Severe driving conditions
A — Driving in dusty conditions
B — Repeatedly driving short distances
C — Towing a trailer or caravan
D — Extensive idling
E — Driving in extremely adverse weather conditions or in areas where ambient temperatures are either
extremely low or extremely high
F — Driving in high humidity or mountainous areas
G — Driving in areas using salt or other corrosive materials
H — Driving on rough and/or muddy roads or in the desert
I — Driving with frequent use of braking or in mountainous areas
J — For models without EURO-OBD system
Driving condition Maintenance itemMainte-
nance
operationMaintenance intervalReference
page
A.........Air cleaner filter ReplaceEvery 30,000 km (18,000 miles)
or 24 monthsMA-20
,
MA-30
ABCD......Engine oil & engine oil
filter ReplaceEvery 7,500 km (4,500 miles) or
6 monthsMA-20
, MA-
21 , MA-30 ,
MA-31
......... JHeated oxygen sensor InspectEvery 30,000 km (18,000 miles)
or 24 monthsEC-150
, EC-
143 , EC-496
, EC-486
.....F....Brake fluid ReplaceEvery 15,000 km (9,000 miles)
or 12 monthsMA-40
. . C . . . . H . . Automatic transaxle fluid ReplaceEvery 30,000 km (18,000 miles)
or 24 monthsMA-36
......GH..Steering gear & linkage,
axle & suspension parts,
propeller shaft, front
drive shafts & exhaust
systemInspectEvery 15,000 km (9,000 miles)
or 12 monthsMA-41
, MA-
42 , MA-43
,MA-35
A.C...GHI.Brake pads, rotors &
other brake componentsInspectEvery 7,500 km (4,500 miles) or
6 monthsMA-41, MA-
41 , MA-41
A.........Air conditioner filter ReplaceEvery 15,000 km (9,000 miles)
or 12monthsAT C - 11 8

PERIODIC MAINTENANCE
MA-11
C
D
E
F
G
H
I
J
K
MA
B
MA

ENGINE AND EMISSION CONTROL MAINTENANCE
(Annual Mileage >30,000 Km [18,000 miles]/year)
QR and VQ ENGINE
Abbreviations: I = Inspect and correct or replace as necessary, R = Replace,.
NOTE:

(1)Periodic maintenance is not required. However, if valve noise increases, check valve clearance.

(2) Replace the drive belt if found damaged or if the auto tensioner reading (for QR20DE engine) reaches the maximum
limit.

(3) First replace at 100,000 Km (60,000 miles), then every 60,000 km (36,000 miles). Perform “I” (Checking the mixture ratio
and correcting the mixture ratio if necessary) at the middle of replacement interval.

(4) Fuel filter is maintenance-free. For service procedures, refer to FL section.

(5) Perform only according to “Maintenance Under Severe Driving Conditions” for models without EURO-OBD system.

Maintenance items with “ ” should be performed more frequently according to “Maintenance Under Severe Driving
Conditions”. MAINTENANCE OPERATIONMAINTENANCE INTERVAL Reference page
Perform at number of kilometers (miles)
basis only.km x
1,000
(Miles x
1,000)15
(9)30
(18)45
(27)60
(36)75
(45)90
(54)105
(63)120
(72)QR20DEVQ23DE
VQ35DE
Engine compartment and under vehicle
Intake and exhaust valve clearanceSee
NOTE
(1)EM-50
EM-202
Drive beltsSee
NOTE
(2)IIIIIIIIMA-16MA-24
Engine oil (Use recommended oil.)RR RRRRRRMA-20MA-30
Engine oil filter (Use genuine NISSAN part
or equivalent)RR RRRRRRMA-21MA-31
Engine anti-freeze coolant (Use Genuine
NISSAN Anti-freeze Coolant or equivalent
in its quality.)See
NOTE
(3)IMA-16
MA-25
Cooling system I I I IMA-18MA-28
Positive crankcase ventilation (PCV) sys-
tem (VQ engine only)IIII—MA-33
Fuel and EVAP vapor lines I IMA-23MA-34
Air cleaner filterRRMA-20MA-30
Fuel filter (In-tank type)See
NOTE
(4)——
Spark plugs (Platinum-tipped type) R R R RMA-22
MA-32
Heated oxygen sensorSee
NOTE
(5)EC-150EC-
143
EC-
496EC-
486

HARNESS
PG-63
C
D
E
F
G
H
I
J
L
MA
B
PG

Wiring Diagram Codes (Cell Codes) BKS002FS
Use the chart below to find out what each wiring diagram code stands for.
Refer to the wiring diagram code in the alphabetical index to find the location (page number) of each wiring
diagram.
Code Section Wiring Diagram Name
A/C ATC Air Conditioner
ABS BRC Anti-Lock Brake System
AFS LT Adaptive Front Lighting System
APPS1 EC Accelerator Pedal Position Sensor
APPS2 EC Accelerator Pedal Position Sensor
APPS3 EC Accelerator Pedal Position Sensor
ASC/BS EC Automatic Speed Control Device (ASCD) Brake Switch
ASC/SW EC Automatic Speed Control Device (ASCD) Steering Switch
ASCBOF EC Automatic Speed Control Device (ASCD) Brake Switch
ASCIND EC Automatic Speed Control Device (ASCD) Indicator
AT/IND DI A/T Indicator Lamp
AUDIO AV Audio
AUT/DP SE Automatic Drive Positioner
AUTO/L LT Auto Light Control
BA/FTS AT A/T Fluid Temperature Sensor and TCM Power Supply
BACK/L LT Back-Up Lamp
BRK/SW EC Brake Switch
CAN AT CAN Communication Line
CAN CVT CAN Communication Line
CAN EC CAN Communication Line
CAN LAN CAN System
CHARGE SC Charging System
CHIME DI Warning Chime
CIGAR WW Cigarette Lighter
COMBSW LT Combination Switch
COMM AV Audio Visual Communication Line
COOL/F EC Cooling Fan Control
CVTIND DI CVT Indicator Lamp
D/LOCK BL Power Door Lock
DEF GW Rear Window Defogger
ECM/PW EC ECM Power Supply for Back-Up
ECTS EC Engine Coolant Temperature Sensor
EMNT EC Electronic Controlled Engine Mount
ENGSS AT Engine Speed Signal
ETC1 EC Electric Throttle Control Function
ETC2 EC Electric Throttle Control Motor Relay
ETC3 EC Electric Throttle Control Motor
F/FOG LT Front Fog Lamp
F/LID BL Fuel Lid Opener
F/PUMP EC Fuel Pump
FRO2 EC Heated Oxygen Sensor 1 Heater

PG-64
HARNESS

FRO2B1 EC Heated Oxygen Sensor 1 Heater Bank 1
FRO2B2 EC Heated Oxygen Sensor 1 Heater Bank 2
FTS CVT CVT Fluid Temperature Sensor Circuit
H/AIM LT Headlamp Aiming Control System
H/LAMP LT Headlamp
HLC WW Headlamp Washer
HORN WW Horn
HO2S1 EC Heated Oxygen Sensor 1
HSEAT SE Heated Seat
I/KEY BL Intelligent Key System
IATSEN EC Intake Air Temperature Sensor
IGNSYS EC Ignition System
ILL LT Illumination
INF/D AV Vehicle Information and Integrated Switch System
INJECT EC Injector
INT/L LT Vanity Mirror Lamp
IVC EC Intake Valve Timing Control Solenoid Valve
IVCB1 EC Intake Valve Timing Control Solenoid Valve Bank 1
IVCB2 EC Intake Valve Timing Control Solenoid Valve Bank 2
KEYLES BL Remote Keyless Entry System
KS EC Knock Sensor
L/USSV CVT Lock-Up Select Solenoid Valve
LPSV AT Line Pressure Solenoid Valve
LPSV CVT Line Pressure Solenoid Valve
M/SEAT SE Air Massage Seat
MAFS EC Mass Air Flow Sensor
MAIN AT Main Power Supply and Ground Circuit
MAIN EC Main Power Supply and Ground Circuit
METER DI Speedometer, Tachometer, Temp. and Fuel Gauges
MIL/DL EC MIL & Data Link Connector
MIRROR GW Power Door Mirror
MMSW CVT Manual Mode Switch
NATS BL Nissan Anti-Theft System
NONDTC AT Non-Detective Items
NONDTC CVT Non-Detective Items
O2S1B1 EC Heated Oxygen Sensor 1 Bank 1
O2S1B2 EC Heated Oxygen Sensor 1 Bank 2
OVRCSV AT Overrun Clutch Solenoid Valve
PHASE EC Camshaft Position Sensor (PHASE)
PHSB1 EC Camshaft Position Sensor (PHASE) (Bank1)
PHSB2 EC Camshaft Position Sensor (PHASE) (Bank2)
PNP/SW CVT Park/Neutral Position Switch
PNP/SW EC Park/Neutral Position Switch
POS EC Crankshaft Position Sensor (CKPS) (POS) Code Section Wiring Diagram Name
