2002.5 PEUGEOT 807 Owners Manual

YOUR 807 IN DETAIL
58
RADIO
Notes on radio reception
Car radio/telephone receivers are subject to phenomena which do not affect domestic radio sets. Both MW/LW and FM are
subject to various forms of interference. This is not a reflection on the quality of the equipment, but is due to the nature of
the signals and the way in which they are transmitted.
On MW/LW interference may be noticed when passing under high voltage power lines or bridges, or in tunnels.
On FM, interference may be the result of increasing distance from the transmitter, deflection of the signals by obstacles
(mountains, hills, buildings etc.) or of being in an area wh ich is not covered by a transmitter.
Selecting radio mode Press "SOURCE" several times.
Selecting a waveband Briefly press the "BND/AST"button to select the FM1, FM2, FMast and AM wavebands.
Automatic station search Briefly press button M or Nto search for the station immediately above or below.
The search stops at the first station found.
If the TAtraffic information programme is selected, only stations broadcastin g this type of programme
are selected.
Searching for a station occurs first in "LO"(selection of the most powerful transmitters) during scanning of t he waveband,
then in "DX"sensitivity (selection of the weaker and more distant transmitters).
To make a direct search in "DX"sensitivity, briefly press button Mor N twice.
18-11-2002

YOUR 807 IN DETAIL59
Manual station search Briefly press button Hor Ito increase or decrease the frequency displayed.
By continuing to press the button in the direction selected, you will obtain continuous scrolling of the frequency.
Scrolling stops at the first station found as soon as the butt on is released.
Manual station search
Select the station required.
Press one of the buttons "1"to "6" for more than two seconds.
An audible signal is emitted, confirming that the station h as been stored in the memory.
Automatic storing of FM stations in the memory
Press the''BNDAST'' button for more than two seconds.
Your audio/telephone automatically stores the 6 stations wit h the strongest signal in FM. These stations are stored in the
FMast waveband.
If it is not possible to find 6 stations, the remaining memo ries are empty.
Recalling stations stored in the memory
For each waveband, briefly press the buttons "1"to "6" to recall the corresponding stored station.
18-11-2002

YOUR 807 IN DETAIL
60
RDS SYSTEM
Using the RDS (Radio Data System) function on FM
Radio Data System allows you to continue listening to the sa me station, whatever frequency it is using for the region you a re
going through.
Briefly press the "RDS"button to switch the function on or off.
The multifunction screen wil show:
RDS if the function is active
"(RDS )" if the function is active but not available.
RDS station following
This display indicates the name of the station selected. The audio/telephone is continuously searching for the station which
has the best reception and which is transmitting the same progra mme.
Traffic information pprogramme Press the''TA/PTY'' button to switch the function on or off.
The multifunction screen will show:
TA if the function is selected
"(TA)" if the function is selected but not available.
Any traffic information flash will be given priority, whatever source you are listening to (radio, CD or CD
changer).
If you wish to interrupt the broadcasting of a message, press th e ''TA/PTY'' button to switch the function off.
Note: the volume of traffic information is independent of the v olume of normal radio/telephone listening.You can
adjust it by using the volume button. The setting will be stored and will be used when the next messages are broadcast.
Regional following mode (REG)
When they are part of a network, certain stations broadcast regi onal programmes in the various areas they serve. With
regional following mode you can keep listening to the same programme.
Press the "RDS"button to switch the function on or off.
18-11-2002

YOUR 807 IN DETAIL61
PTY function
This allows you to listen to stations broadcasting a specific t ype of programme (news, culture, sport, rock etc.)
When FM is selected, press the "TA/PTY"button for more than two seconds to switch the function or or off.
To find a PTYprogramme:
select the PTYbutton,
turn button Gto scroll down the different types of programmes offered,
when the programme of your choice is displayed, press button Mor Nto carry out an automatic
search (after an automatic search the PTYfunction is switched off if no station has been found).
In PTY mode the different types of programmes can be stored in the memory . To do this, press the preselection buttons
" 1 " to " 6'' for more than two seconds. To recall the type of programme sto red in the memory, briefly press the corrresponding
button.
EON system
This system connects stations which are part of the same network. It enables the broadcast of traffic information or a PTY
programme, by a station that is part of the same network as the station to which you are listening.
The service is available when you have selected the TAtraffic information programme or the PTYfunction.
Contextual menu The contextual menu allows you to access the following functi ons:
"Inputting a frequency"
"Display Radio text" to display information connected with th e station being listened to.
18-11-2002

YOUR 807 IN DETAIL
62
COMPACT DISC
Selecting CD mode After inserting a disc, printed face upwards, the CD drive starts automatically.
If a disc has already been inserted, press the ''SOURCE''button to select CD mode.
Ejecting a disc Press button Ato eject the disc from the drive.
Selecting a track Press button Mto select the following track.
Press button Nto return to the start of the current track or to select the previ ous track.
Accelerated play
Press and hold button M or Nfor forwards or backwards accelerated play.
Accelerated play stops as soon as the button is released.
Contextual menu
The contextual menu permits you to to switch the shuffle funct ions on or off, to play the
start of a track or to repeat a track or programme the tracks.
The use of copied compact discs may cause faults.
Insert circular compact discs only.
18-11-2002

YOUR 807 IN DETAIL63
COMPACT DISC CHANGER
Selecting CD changer mode Press the ''SOURCE'' button several times.
Selecting a disc
Press press one of the buttons ''1''to''6'' of the audio/telephone to select the apropriate disc.
Buttons H and Iallow you to select the previous or following track of the cha nger respectively.
Selecting a track Press button Mto select the following track.
Press button Nto return to the start of the current track or to select the previ ous track.
Accelerated play
Press and hold button M or Nfor forwards or backwards accelerated play.
Accelerated play stops as soon as the button is released.
Contextual menu
The contextual menu permits you to switch the shuffle function s on or off, to play the
start of a track or to repeat a track.
18-11-2002

YOUR 807 IN DETAIL
64
TELEPHONE MODE
This function is a GSM dualband telephone (800 and 1 800 MHz) incorporated in the RT3 audio system.
It is a ''hands free'' telephone. This function is provided by a microphone located next to the front courtesy light, the
speakers and a steering column control which allows access to most of the functions (because the audio/telephone control
panel buttons allow access to all the functions).
Display of the principal ''mobile'' type functions, as well as consultation of the indexes, is pro vided by the multi–function
display.
This function is active whatever position the ignition key is in.
Note: when the key is in the accessories position (1st notch), this funct ion will be interrupted after thirty minutes, when the
message ''Economy mode active'' appears on the multi–function display. If you are using the telephone at that time, you
will be able to finish your call.
Using the menus
Press the ''MENU'' button to display the general menu. Select thetelematicsapplication, validiate Telephone functions
to access the principal telephone functions, then the various menus, in order to reach the one required.
This menu allows you to access the following functions:
Network: allows you to select the network search mode and to see the ne tworks
available.
Duration of calls: allows you to consult the duration recorder of calls made and ze ro
reset.
SIM card security: allows you to use or modify the PIN code and to erase the list of
calls and minimessages (SMS).
Telephone options: allows you to configure the calls with entering of my number,
automatic answering after X rings and specification of ring opt ions.
Within each menu:
Move around and select a function by turning knob Gthen validate by pressing the knob.
Cancel an operation by means of the ''ESC''button.
18-11-2002

YOUR 807 IN DETAIL65
Using the alphanumeric keypad
For a given button, to input a character in the second or sub sequent rows press until you obtain the character required.
Installing the SIM card Open flap Lby pressing the point of a pencil on the circular opening ab ove the flap.
Insert your MicroSIM card as indicated in the graphics, then close th e flap.
Note: removal or insertion of the SIM card must only be carried out after the RT3 audio/telephone has been
switched off. Buttons Associated characters
[1] 1 or space
[2] 2 or A B C 2 or a b c 2
[3] 3 or D E F 3 or d e f 3
[4] 4 or G H I 4 or g h i 4
[5] 5 or J K L 5 or j k l 5
[6] 6 or M N O 6 or m n o 6
[7] 7 or P Q R S 7 or p q r s 7
[8] 8 or T U V 8 or t u v 8
[9] 9 or W X Y Z 9 or w x y z 9
[0] 0 or + (long press)
[#] # or P (long press)
[*] * or erasing of last character input (long press)
18-11-2002
