2002.5 PEUGEOT 807 Owners Manual

YOUR 807 IN DETAIL
120
MIRRORS
Electric rear view mirrors
Move switch Ato the right or to
the left to select the correspond
ing mirror.
 Move knob Bin all four directions
to adjust.
 Return switch Ato the centre
position.
When parked, the mirrors can be
folded back manually or electrically
by pulling switch Arearwards or
automatically when locking the
vehicle.
Electric unfolding of the mirrors is
possible with the key from the On
postion (2 nd
notch).
Note: the folding back function on
locking the vehicle can be activated
or disarmed by pulling switch Arear
wards for approximately three sec
onds. Manual interior mirror
The interior mirror has two positions :
– day (normal),
– night (antidazzle).
To change from one to the other,
push or pull the lever on the lower
edge of the mirror.
Areas for toll cards /
car park tickets
The athermic windscreen has two
nonreflective zones located either
side of the base of the interior mirror.
They are intended for affixing toll
cards and/or car park tickets.
Child monitoring mirror
This mirror enables the driver or front
passenger to observe all the rear
seats.
Fitted on its own ball joint and able to
retract into its housing in the roof, it
provides a panoramic view of the
rear interior of the vehicle.
18-11-2002

YOUR 807 IN DETAIL121
Automatic day/night interior mirror
This automatically and gradually changes between the day and
night positions.
To prevent dazzling, the glass of the mirror darkens automatically depending on
the intensity of the light from behind. It clears as the li ght (headlamps of follow
ing vehicles, sunlight) decreases, ensuring maximum visibility.
Operation
Switch on the ignition and press switch 1:
– Indicator light 2lit (switch pressed): automatic operation.
– Indicator light 2off: automatic system off. The mirror remains at its most clear.
Special feature
T o ensure maximum visibility during manoeuvres, the mirror clears automatical
ly when reverse gear is engaged. Sun visor with illuminated
courtesy mirror
With the ignition on, the mirror is
automatically lit up when the flap is
opened.
Rear screen sun blind
Pull the blind by the central tab, and
then position its attachments on the
corresponding hooks.
Side blinds
Side blinds are available in the rear
2
nd
and/or 3 rd
rows.
Pull the side blind by the centre tab.
Position the blind's attachment(s) on
the corresponding hook(s).
18-11-2002

YOUR 807 IN DETAIL121
Automatic day/night interior mirror
This automatically and gradually changes between the day and
night positions.
To prevent dazzling, the glass of the mirror darkens automatically depending on
the intensity of the light from behind. It clears as the li ght (headlamps of follow
ing vehicles, sunlight) decreases, ensuring maximum visibility.
Operation
Switch on the ignition and press switch 1:
– Indicator light 2lit (switch pressed): automatic operation.
– Indicator light 2off: automatic system off. The mirror remains at its most clear.
Special feature
T o ensure maximum visibility during manoeuvres, the mirror clears automatical
ly when reverse gear is engaged. Sun visor with illuminated
courtesy mirror
With the ignition on, the mirror is
automatically lit up when the flap is
opened.
Rear screen sun blind
Pull the blind by the central tab, and
then position its attachments on the
corresponding hooks.
Side blinds
Side blinds are available in the rear
2
nd
and/or 3 rd
rows.
Pull the side blind by the centre tab.
Position the blind's attachment(s) on
the corresponding hook(s).
18-11-2002

Horn
Press one of the spokes or
the centre of the steering
wheel.
YOUR 807 IN DETAIL
122
Manual adjustment of the
headlamps
Depending on the load in your vehi
cle, adjusting the beam of your head
lamps is recommended.
0 1 or 2 people in the front seats.
1 5 people.
2 6 to 8 people.
3 Driver + maximum authorised
loads.
Initial setting is position 0.
Automatic adjustment of
headlamps
Refer to the paragraph on Lighting
under the section entitled 'Towing a
trailer...'. Hazard warning lights
Press the button, the direction indi
cators flash.
They can operate with the ignition
off.
Steering wheel height and
depth adjustment
When the vehicle is stationary,
unlock the steering wheel by lower
ing the lever
A.
Adjust the height and depth of the
steering wheel, then lock by pushing
lever Afully upwards.
Automatic lighting of hazard
warning lights*
When braking in an emergency,
depending on the force of decelera
tion, the hazard warning lights come
on automatically. They switch off
automatically the first time you accel
erate.
It is also possible to switch them off
by pressing the button on the fascia.
*According to destination.
18-11-2002

YOUR 807 IN DETAIL123
COURTESY LIGHTS
Off.
Comes on on opening one of the doors.
Permanently on, with the key in the accessories position or the i gnition on.
1 Front courtesy light
2 2nd row rear courtesy light
3 3rd row rear courtesy light
4 Front map reading lights
5 2nd row rear map reading lights
6 3rd row rear map reading lights The front and rear courtesy lights
come on when the ignition key is
removed, on unlocking the vehicle or
on opening one of the doors.
They gradually go off after the igni
tion has been switched on
, after the
vehicle is locked or after the last door
is closed.  With the ignition off, pressing
switch 1turns on the front
and rear courtesy lights for ten
minutes.
 With the ignition off, pressing
switch 2 or 3 turns on the corre
sponding rear courtesy light for
ten minutes.
The front and rear map reading lights
are switched on by operating the cor
responding switch. These are active
when the key is in the accessories
position (1st notch) or the ignition is
on.
18-11-2002

YOUR 807 IN DETAIL
124
18-11-2002

YOUR 807 IN DETAIL125
INTERIOR LAYOUT
1. Spectacles holder
2. Glove box To open the glove box, press the
button.
To close it, press the lid.
It has dedicated compartments
for storing a pen, a mobile tele
phone, a pair of spectacles,
coins or tokens and credit cards.
3. Audio equipment concealing flap
Lower the flap fully to lock it.
Press the flap to raise it.
4. Central storage compartment
5. Passenger upper glove box To open the glove box, press the
button.
To close it, press the lid.
It has dedicated compartments
for storing a pair of spectacles,
keys, five audio CDs and four
audio cassettes or nine audio
CDs. 6. Passenger lower glove box
This is fitted with a lock.
To open the glove box, lift the
handle.
The glove box lights when the lid
is opened.
It contains three sockets for
connecting video equipment.
It has dedicated compartments
for storing maps, a packet of
cigarettes, an A4 format docu
ment, etc.
7. Lighter or 12 volt accessories socket
8. Cooled compartment This can hold up to three cans.
Turn the closer, at the top, to
open or close the air feed.
9. Can holder and ashtray This retractable support, with
light, contains up to two can
holders, a removable ashtray
and a location for the lighter
when it is used as a 12V socket. 10. Storage compartment or
remote control keypad
The storage compartment must
not be used as an ashtray.
11. Storage
12. Door tray with storage compartment for a bottle
of water
13. Instrument panel fuse box
18-11-2002

YOUR 807 IN DETAIL
126
