2002.5 PEUGEOT 807 Owners Manual

YOUR 807 IN DETAIL
134
MANUAL GEARBOX
Reverse
*
To change to reverse gear, lift the
ring under the gear lever knob and
push the gear lever to the left then to
the front.
Reverse gear can only be
engaged when the vehicle is sta
tionary with the engine idling.
* According to engine. AIR BAGS
The air bags have been designed to
maximise the safety of the occu
pants in the event of serious colli
sions. They work in conjunction with
the forcelimiting seat belts. The
electronic detectors register and
analyse any abrupt deceleration of
the vehicle : if the triggering thresh
old is reached, the air bags inflate
instantly and protect the occupants
of the vehicle.
Immediately after the impact, the air
bags deflate rapidly so that they do
not hinder the visibility of the occu
pants nor their exit if necessary from
the vehicle.
The air bags are not deployed in the
case of collisions which are not seri
ous, for which the seat belt is suffi
cient to ensure maximum protection.
The seriousness of a collision
depends on the nature of the obsta
cle and the speed of the vehicle at
the moment of the collision.
Air bags only operate when the
ignition is switched on.
Note:
the gas escaping from the air
bags can be a minor irritant. FRONT AIR BAGS
These are folded in the centre of the
steering wheel for the driver and in
the fascia for the front passenger.
They are deployed simultaneously,
except in cases where the passen
ger air bag is disarmed.
Front air bag fault
If this warning light comeson, accompanied by an
audible signal and the mes
sage "Air bag fault" on the
multi–function display, con
tact a PEUGEOT dealer to
have the system checked.
18-11-2002

YOUR 807 IN DETAIL135
Disarming the passenger
air bag*
To ensure the safety of your child,
it is essential to disarm the pas
senger air bag when you install a
rearfacing child seat on the front
passenger seat.
With the ignition switched off,
insert the key into the passenger
air bag disarming switch 1, turn it
to the "OFF" position, then
remove the key keeping the slot
in this position.
The air bag warning light on the
instrument panel is lit throughout the
disarming process. In the
"OFF" position, the passenger
air bag will not be triggered in the
event of an impact.
As soon as the child seat is
removed, turn the air bag slot to the
"ON" position to reactivate the air
bag and thus ensure the safety of
your passenger in the event of an
impact.
Operating check
This is confirmed by an indicator
light, accompanied by an audible
signal and a message on the multi
function display.
With the ignition on (2nd
notch), illumination of this
warning light accompanied
by an audible signal and the
message "Passenger air
bag disarmed" on the
multifunction display, indicates that
the passenger air bag is disarmed
(switch in the "OFF" position). SIDE AIR BAGS AND
CURTAIN AIR BAGS
The side air bags are incorporated
into the front seat backs on the door
side.
The curtain air bags are incorporated
into the door pillars and the upper
part of the passenger compartment.
They are deployed independently of
each other depending on which side
the collision occurs.
Operating check
This is confirmed by an indi
cator light, accompanied by
an audible signal and a
message on the multi–func
tion display.
If this indicator light comes on,
accompanied by an audible signal
and the message "Air bag fault" on
the multi–function display, contact a
PEUGEOT dealer to have the sys
tem checked.
* According to destination. If
the two "Air bag fault" and "Passenger air bag disarmed" warning
lights come on permanently, do not install a rearward facing child seat
and consult a PEUGEOT dealer.
18-11-2002

18-11-2002
YOUR 807 IN DETAIL
136
For the front, side and curtain air bags to be fully effec tive, observe the following safety rules:
• W ear a correctly adjusted seat belt.
• Sit in a normal upright position.
• Do not leave anything between the occupants of the front seats and the air bags (a child, pet, object).
This could hamper the operation of the air bags or injure th e occupants.
• All work on the air bag system is strictly forbidden unless it is ca rried out by qualified personnel of the PEUGEOT net
work.
• After an accident or if the vehicle has been stolen or broken into, have the air bag systems checked.
• The air bag systems have been designed to be fully operation al for 10 years after the vehicle has been registered.
For greater safety, have them checked by a PEUGEOT dealer within 10 years of purchase of the vehicle.
Front air bags
• Do not drive holding the steering wheel by its spokes or resti ng your hands on the centre part of the wheel.
• Passengers must not place their feet on the fascia.
• Smoke as little as possible; deployment of the air bags can cau se burns or the risk of injury from a cigarette or pipe.
• Never remove or pierce the steering wheel or hit it violently.
Side air bags
• Only put approved covers on the front seats. Contact your PEUGEOT dealer.
• Do not fix or glue anything to the front seat backs. This co uld cause injury to the chest or arms when the side air bag
inflates.
• Do not sit with the upper part of the body any nearer to the door than necessary.
Curtain air bags
• Do not fix or glue anything to the pillars or the roof. T his could cause injury to the head when the curtain air bag
inflates.
• Do not remove the bolts from the grab handles installed on the roof, they play a part in securing the curtain air bags.

YOUR 807 IN DETAIL135
Disarming the passenger
air bag*
To ensure the safety of your child,
it is essential to disarm the pas
senger air bag when you install a
rearfacing child seat on the front
passenger seat.
With the ignition switched off,
insert the key into the passenger
air bag disarming switch 1, turn it
to the "OFF" position, then
remove the key keeping the slot
in this position.
The air bag warning light on the
instrument panel is lit throughout the
disarming process. In the
"OFF" position, the passenger
air bag will not be triggered in the
event of an impact.
As soon as the child seat is
removed, turn the air bag slot to the
"ON" position to reactivate the air
bag and thus ensure the safety of
your passenger in the event of an
impact.
Operating check
This is confirmed by an indicator
light, accompanied by an audible
signal and a message on the multi
function display.
With the ignition on (2nd
notch), illumination of this
warning light accompanied
by an audible signal and the
message "Passenger air
bag disarmed" on the
multifunction display, indicates that
the passenger air bag is disarmed
(switch in the "OFF" position). SIDE AIR BAGS AND
CURTAIN AIR BAGS
The side air bags are incorporated
into the front seat backs on the door
side.
The curtain air bags are incorporated
into the door pillars and the upper
part of the passenger compartment.
They are deployed independently of
each other depending on which side
the collision occurs.
Operating check
This is confirmed by an indi
cator light, accompanied by
an audible signal and a
message on the multi–func
tion display.
If this indicator light comes on,
accompanied by an audible signal
and the message "Air bag fault" on
the multi–function display, contact a
PEUGEOT dealer to have the sys
tem checked.
* According to destination. If
the two "Air bag fault" and "Passenger air bag disarmed" warning
lights come on permanently, do not install a rearward facing child seat
and consult a PEUGEOT dealer.
18-11-2002

18-11-2002
YOUR 807 IN DETAIL
136
For the front, side and curtain air bags to be fully effec tive, observe the following safety rules:
• W ear a correctly adjusted seat belt.
• Sit in a normal upright position.
• Do not leave anything between the occupants of the front seats and the air bags (a child, pet, object).
This could hamper the operation of the air bags or injure th e occupants.
• All work on the air bag system is strictly forbidden unless it is ca rried out by qualified personnel of the PEUGEOT net
work.
• After an accident or if the vehicle has been stolen or broken into, have the air bag systems checked.
• The air bag systems have been designed to be fully operation al for 10 years after the vehicle has been registered.
For greater safety, have them checked by a PEUGEOT dealer within 10 years of purchase of the vehicle.
Front air bags
• Do not drive holding the steering wheel by its spokes or resti ng your hands on the centre part of the wheel.
• Passengers must not place their feet on the fascia.
• Smoke as little as possible; deployment of the air bags can cau se burns or the risk of injury from a cigarette or pipe.
• Never remove or pierce the steering wheel or hit it violently.
Side air bags
• Only put approved covers on the front seats. Contact your PEUGEOT dealer.
• Do not fix or glue anything to the front seat backs. This co uld cause injury to the chest or arms when the side air bag
inflates.
• Do not sit with the upper part of the body any nearer to the door than necessary.
Curtain air bags
• Do not fix or glue anything to the pillars or the roof. T his could cause injury to the head when the curtain air bag
inflates.
• Do not remove the bolts from the grab handles installed on the roof, they play a part in securing the curtain air bags.

2 LITRE AND 2.2 LITRE 16V
PETROL ENGINES
1 Windscreen/headlamp wash
reservoir.
2 Fuse box.
3 Power steering reservoir. 4
Coolant reservoir.
5 Engine oil filler cap.
6 Dipstick.
7 Air filter. 8
Brake and clutch fluid reservoir.
9 Removable towing eye.
10 Wheelbrace.
11 Jack.
PRACTICAL INFORMATION
137
18-11-2002

PRACTICAL INFORMATION
138
2 LITRE AND 2.2 LITRE 16V
HDI DIESEL ENGINES
1
Windscreen/headlamp wash
reservoir.
2 Fuse box.
3 Power steering reservoir. 4
Coolant reservoir.
5 Engine oil filler cap.
6 Dipstick ( a:2.2 litre HDI;
b: 2 litre HDI).
7 Air filter. 8
Brake and clutch fluid reservoir.
9 Removable towing eye.
10 Wheelbrace.
11 Jack.
18-11-2002

PRACTICAL INFORMATION139
CHECKING THE LEVELS
Oil level
Check the level regularly and top
up between changes (maximum
consumption is 0.5 l per 600 miles
(1000 km).
Checking is carried out with the
vehicle level, engine cold, using
the oil level gauge on the check
module or the dipstick.
Dipstick There are two marks
on the dipstick:
A= maximum
Never fill past this
mark.
B = minimum
To maintain the reliabil
ity of engines and
emission control sys
tems, the use of addi
tives in engine oil is
prohibited.
Oil change
According to the information given in
"PEUGEOT SERVICING".
NOTE: Prevent used oil from coming
into prolonged contact with the skin. Viscosity selection
In all cases, the oil selected must
meet the manufacturer's require
ments.
Brake and clutch fluid level:
The level must always be between
the DANGER and MAXIMUM
marks in the reservoir.
If the level drops substantially, con tact a PEUGEOT dealer immedi
ately.
Fluid change:
must be carried out according to the manufacturer's schedule
use fluids approved by the manu facturer, which fulfil DOT4 stan
dards.
WARNING: brake and clutch fluid is
harmful to health and very corrosive.
Coolant level
Use fluid recommended by the man
ufacturer.
When the engine is warm, the tem
perature of the coolant is controlled
by the engine fan. As this fan can
operate with the ignition off and
because the cooling system is pres
surised, wait for at least one hour
after the engine has stopped before
carrying out any work. Unscrew the cap two turns to allow
the pressure to drop to prevent any
risk of scalding. When the pressure
has dropped, remove the cap and
top up the level.
Note:
The coolant does not need to
be changed.
Used oil
Do not dispose of used oil, brake
fluid or coolant into drains or onto the
ground.
Power steering reservoir  Open the reservoir, with the
engine at ambient temperature.
The level should always be above
the MINI mark and close to the
MAXI mark.
Windscreen and headlamp
wash reservoir
For best quality cleaning and for your
safety, we recommend that you use
products approved by PEUGEOT
(reservoir capacity 4.5 litres or
6.5 litres with headlamp wash).
Measure the fluid level using the dip
stick incorporated in the reservoir
cap.
Close the air hole on the cap and
remove it, then check the level.
18-11-2002
