2002.5 Peugeot 307 Break Owner's Manual

09-09-2002
YOUR 307 IN DETAIL
56
RADIO
Notes on radio reception
Car radio/telephone receivers are subject to phenomena which do not affect domestic radio sets. Both MW/LW and FM are
subject to various forms of interference. This is not a reflection on the quality of the equipment, but is due to the nature of the
signals and the way in which they are transmitted.
On MW/LW interference may be noticed when passing under high voltage power lines or bridges, or in tunnels.
On FM, interference may be the result of the increasing distance from the transmitter, deflection of the signals by obstacles
(mountains, hills, buildings etc.) or of being in an area wh ich is not covered by a transmitter.
Selecting the radio Press "SOURCE" several times.
Selecting a waveband Briefly press button "BND/AST"to select the FM1, FM2, FMast and AM wavebands.
Automatic station search Briefly press button M or Nto search for the station immediately above or below.
The search stops at the first station found.
If the TAtraffic programme is selected, only stations broadcasting this type of programme are
selected.
Searching for a station occurs first in 'LO'(selection of the most powerful transmitters) for scanning of the waveband, then
in 'DX' sensitivity (selection of the weaker and more distant transmitters).
To make a direct search in 'DX'sensitivity, briefly press button Mor N twice.

09-09-2002
YOUR 307 IN DETAIL57
Manual station search Briefly press button Hor Ito increase or decrease the frequency displayed.
By continuing to press the button in the direction selected, you will obtain continuous scrolling of the frequency.
The search stops at the first station found as soon as the but ton is released.
Manual station search
Select the station required.
Press one of the buttons "1"to "6" for more than two seconds.
An audible signal is emitted, confirming that the station h as been stored in memory.
Automatic storing of FM stations in the memory
Press button''BNDAST'' for more than two seconds.
Your audio/telephone automatically stores the 6 stations wit h the strongest signal in FM. These stations are stored in the
FMast waveband.
If it is not possible to find 6 stations, the remaining memo ries are empty.
Recalling stations stored in the memory
For each waveband, briefly pressing the buttons "1"to "6" recalls the corresponding stored station.

09-09-2002
YOUR 307 IN DETAIL
58
RDS SYSTEM
Using the RDS (Radio Data System) function on FM
Radio Data System allows you to continue listening to the sa me station, whatever frequency it is using for the region you a re
going through.
Briefly press the "RDS"button to switch the function on or off.
The multi–function screen will show:
RDS if the function is active
"(RDS)" if the function is active but not available.
RDS station following
This display indicates the name of the station selected. The audio/telephone is continuously searching for the station which
has the best reception and which is transmitting the same progra mme.
Traffic information programme Press the''TA/PTY'' button to switch the function on or off.
The multi–function screen will show:
TA if the function is selected
"(TA)" if the function is selected but not available.
Any traffic information flash will be given priority, whatever source you are listening to (radio, CD or CD changer).
If you wish to interrupt the broadcasting of a message, press th e ''TA/PTY'' button to switch the function off.
Note: the volume of the traffic information is independent of th e volume of normal radio/telephone listening.You can
adjust it by using the volume button. The setting will be stored and will be used when the next messages are broadcast.
Regional following mode (REG)
When they are part of a network, certain stations broadcast regi onal programmes in the various areas they serve. With
regional following mode you can keep listening to the same programme.
Press the "RDS"button to switch the function on or off.

09-09-2002
YOUR 307 IN DETAIL59
PTY function
This allows you to listen to stations broadcasting a specific t ype of programme (news, culture, sport, rock etc.)
When FM is selected, press button "TA/PTY"for more than two seconds to switch the function or or off.
To find a PTYprogramme:
select the PTYbutton,
turn button Gto scroll down the different types of programmes offered,
when the programme of your choice is displayed press button Mor Nto carry out an automatic search
(after an automatic search the PTYfunction is switched off if no station has been found).
In PTY mode the different types of programmes can be stored in the memory . To do this, press the preselection buttons "1"
to " 6" for more than two seconds. To recall the type of programme stored in the memory, briefly press the corrresponding
button.
EON system
This system connects stations which are part of the same network. It enables the broadcast of traffic information or a PTY
programme, by a station that is part of the same network as the station to which you are listening.
The service is available when you have selected the TAtraffic information programme or the PTYfunction.
Contextual menu The contextual menu allows you to access the following functi ons:
'Inputting a frequency'
'Display Radio text' to display information connected with the station being listened to.

09-09-2002
YOUR 307 IN DETAIL
60
COMPACT DISC
Selecting CD mode After inserting a disc, printed face upwards, the CD drive starts automatically.
If a disc has already been inserted, press the "SOURCE"button to select CD mode.
Ejecting a disc Press button Ato eject the disc from the drive.
Selecting a track Press button Mto select the following track.
Press button Nto return to the start of the current track or to select the previ ous track.
Accelerated play
Press and hold button M or Nfor forwards or backwards accelerated play.
Accelerated play stops as soon as the button is released.
Contextual menu
The contextual menu permits you to to switch on or switch off t he shuffle, track repeat,
track programme or play the start of a track functions.
Do not use copied CDs as these could damage your player.
Insert circular compact discs only.

09-09-2002
YOUR 307 IN DETAIL61
COMPACT DISC CHANGER
Selecting CD changer mode Press the ''SOURCE'' button several times.
Selecting a disc
Press press one of the buttons ''1''to''5'' on the CD changer or on the audio/telephone to select th e appropriate disc.
Buttons H and Iallow you to select respectively the previous or following track o f the changer.
Selecting a track Press button Mto select the following track.
Press button Nto return to the start of the current track or to select the previ ous track.
Accelerated play
Press and hold button M or Npressed for forwards or backwards accelerated play.
Accelerated play stops as soon as the button is released.
Contextual menu The contextual menu permits you to switch on or switch off the shuffle, playing the start
of a track or repeat a track functions.

09-09-2002
YOUR 307 IN DETAIL
62
TELEPHONE
This function is a GSM dualband telephone (800 and 1 800 MHz) incorporated in the RT3 audio system.
It is a ''hands free'' telephone. This function is provided by a microphone located next to the front courtesy light, the speak
ers and a steering column control which allows access to most of th e functions (the audio/telephone control panel buttons
allow access to all the functions).
Display of the principal "mobile" type functions, as well as consultation of the indexes, is pro vided by the multi–function dis
play.
This function is active, whatever position the ignition key is in.
Note: when the key is in the accessories (1st notch) or ignition on (2nd notch) position, this function will be interrupted after
thirty minutes, when the message "Economy mode active"appears on the multi–function display. If you are using the tele
phone at that time, you will be able to finish your call.
Using the menus
Press the ''MENU'' button to display the general menu. Select thetelematicsapplication, validiate Telephone functions to
access the principal telephone functions, then the various menu s, in order to reach the one required.
This menu allows you to access the following functions:
Network: allows you to select the network search mode and to see the ne tworks avail
able.
Duration of calls: allows you to consult the duration recorder of calls made and ze ro
reset.
SIM card security: allows you to use or modify the PIN code and to erase the list of
calls and minimessages (SMS).
Telephone options: allows you to configure the calls with entering of my number,
automatic answering after X rings and specification of ring opt ions.
Within each menu:
Move around and select a function by turning the Gbutton then validate by pressing the button.
Cancel an operation using the "ESC"button.

09-09-2002
YOUR 307 IN DETAIL63
Using the alphanumeric keypad
For a given button, to input a character in the second or sub sequent rows press until you obtain the character required.
Installing the SIM card Open flap Lby pressing the point of a pencil on the circular opening ab ove the flap.
Insert your MicroSIM card as indicated in the graphics, then close th e flap.
Note: removal or insertion of the SIM card must only be carried out after the RT3 audio/telephone has been switched
off. Buttons Associated characters
[1] 1 or space
[2] 2 orA B C 2 o ra b c 2
[3] 3 orD E F 3 or d e f 3
[4] 4 orG H I 4 o rg h i 4
[5] 5 orJ K L 5 o rj k l 5
[6] 6 orM N O 6 o rm n o 6
[7] 7 orP Q R S 7 o rp q r s 7
[8] 8 orT U V 8 o rt u v 8
[9] 9 orW X Y Z 9 o rw x y z 9
[0] 0 or+ (long press)
[#] # orP (long press)
[*] * or erasing of last character input (long press)
