2002.5 Peugeot 307 Break navigation

09-09-2002
YOUR 307 IN DETAIL 35
MULTI–FUNCTION
SCREENS
Presentation
Monochrome screen B
This enables the following informa
tion to be displayed:
the time,
the date,
the outside temperature (the
°C
symbol flashes when there is a risk
of ice),
the radio displays,
the status of the openings (doors,
bonnet...),
the warning (e.g. “Battery charge
fault”) or information (e.g.
“Passenger air bag disarmed”)
messages displayed temporarily
can be cleared by pressing button
1 or 2,
the trip computer (see correspond
ing section).
Monochrome screen CT and
colour screen DT
These two systems are controlled by
the RT3 audio/telephone keypad.
They enable the following informa
tion to be displayed:
–the time,–the date,–the outside temperature (a mes
sage warns you when there is a
risk of ice),
–the audio source displays (radio,
CD, ...),
–the telematic system displays (tele
phone, services, ...),
–the status of the openings (doors,
bonnet, ...),
–the warning (e.g. “Fuel level low”)
and vehicle functions status (e.g.
“Passenger air bag disarmed”)
messages displayed temporarily,
–the trip computer display (see cor
responding section),
–the satellite navigation system dis plays (see corresponding section).
Note: to enable you to use all of your
system’s functions, you have two
CD ROMs: one, “Configuration”, con
tains the software and the various
display and spoken information lan
guages, the other, “Navigation”, con
tains the satellite navigation system
map data. Monochrome screen CT
General menu
Press the
“MENU” button to access
the general menu and select one of
the following applications:–navigation guidance (see section
“Satellite navigation system”),
–trip computer (see corresponding section),
–directory (see “RT3 audio/telephone” section),
–telematics (see “RT3 audio/telephone” section),
–configuration (see correspondingsection).

YOUR 307 IN DETAIL
36
Parameter configuration
Monochrome screen B
Press button
1for two seconds to
gain access to the settings .
Then, each press of this button per
mits scrolling of the various parame
ters.
language of the information dis played,
speed unit (km or miles),
temperature unit (degrees Celcius or Fahrenheit),
time format (12 or 24 hours),
hour,
minute,
year,
month,
day.
Pressing button 2enables you to
change the parameter selected.
Continue pressing the button for
rapid scrolling.
After ten seconds without action, the
screen returns to the usual display,
the modified data are recorded.configuration (see corresponding
section).
map (see section “Satellite naviga
tion system”)
A few definitions
Superimposed display:
a window appears over the current
application for a short while, to
announce a change of status of
another application.
Permanent application:
main application currently in use, dis
played in the main screen window.
Contextual menu:
limited menu associated with the
main application currently in use, dis
played in the main screen window.
Colour screen DT
General menu
Press the
“MENU” button to access
the general menu and select one of
the following applications:
navigation guidance (see section
“Satellite navigation system”),
trip computer (see corresponding
section),
directory (see “RT3 audio/tele
phone” section),
telematics (see “RT3 audio/tele
phone” section),
09-09-2002

YOUR 307 IN DETAIL
36
Parameter configuration
Monochrome screen B
Press button
1for two seconds to
gain access to the settings .
Then, each press of this button per
mits scrolling of the various parame
ters.
language of the information dis played,
speed unit (km or miles),
temperature unit (degrees Celcius or Fahrenheit),
time format (12 or 24 hours),
hour,
minute,
year,
month,
day.
Pressing button 2enables you to
change the parameter selected.
Continue pressing the button for
rapid scrolling.
After ten seconds without action, the
screen returns to the usual display,
the modified data are recorded.configuration (see corresponding
section).
map (see section “Satellite naviga
tion system”)
A few definitions
Superimposed display:
a window appears over the current
application for a short while, to
announce a change of status of
another application.
Permanent application:
main application currently in use, dis
played in the main screen window.
Contextual menu:
limited menu associated with the
main application currently in use, dis
played in the main screen window.
Colour screen DT
General menu
Press the
“MENU” button to access
the general menu and select one of
the following applications:
navigation guidance (see section
“Satellite navigation system”),
trip computer (see corresponding
section),
directory (see “RT3 audio/tele
phone” section),
telematics (see “RT3 audio/tele
phone” section),
09-09-2002

09-09-2002
YOUR 307 IN DETAIL67
The Directory
General
The "Directory" application gives access to 400 files divided into 4 indepen dent subdirectories ("Professional", "Work",
"Personal", "Guest"). It enables you to manage these files, make cal ls and send SMS messages using the SIM card.
Main menu
From the main menu , select the "directory" function to access the "Directory"main
menu and select one of the following functions:
• "Call", to call a number stored in a file
• "Activcate guidance to", to initiate guidance to a locatio n stored in a file
• "Management of directory files", to add, delete, modify and consult directory files or exchange them with the SIM card
• "Directory configuration", to select the working directory and de fine the directory when the system is switched on
• "Mini message (SMS)", to send SMS messages.
Creation / Modification of a file
To create a file, from the "Directory" menu, select the function "Management of directo
ry files" then "Add".
On the file select the section to be filled in, validate then enter the informaton. You can
also associate a voice description with a file in order to use the voice commands.
To modify an existing file, select it using the "Consult" fun ction of the "Management of
directory files" menu then make the modifications.
Note: when the address is entered, the navigation CD ROM must be p resent in order to obtain guidance to this destination.

YOUR 307 IN DETAIL69
Voice commands
The voice commands make it possible to use prerecorded words or phrases to control a certain number of functions of the
RT3 audio/telephone.
Activation of the voice commands
Press the button on the end of the lights stalk to activate this function.
Example: to recall the radio station stored on button 3, the key words are: "Radio" "Memory" "3" .
To use these key words, you must say the word "Radio", wait for the audible confirmation signal, then say the w ord
"Memory" , wait for the audible confirmation signal, then end wit h the word"3", wait for the audible confirmaton signal which
will carry out the action requested.
Notes:
in the absence of any voice commands, this function will be sw itched off after approximately ten seconds,
if a command is not understood, a double audible signal i s emitted.
Saying the word "Help"displays all of the commands available on the screen.
List of
commands available
To change the source (Radio, CD, CD changer, telephone) : "RADIO" / "CD" / "CHANGER" / "CALL"
For the radio: "LISTEN" / "PREVIOUS" / "FOLLOWING" / "MEMORY" + N° / "AUTOSTORE"
For the CD: "LISTEN" / "PLAY" / " PREVIOUS TRACK" / "FOLLOWING TRACK" / "TRACK NUMBER" + N° / "SHUFFLE" / "SCAN" /
"LOOP"
for the CD changer: "LISTEN"/ "PLAY" / " PREVIOUS TRACK" / "FOLLOWING TRACK" / "TRACK NUMBER" + N° / "PREVIOUS DISC" / "FOL
LOWING DISC" / "DISC NUMBER" + N° / "SHUFFLE" / "SCAN" / "LOOP"
For the telephone: "CALL" / "REPEAT" / " PEUGEOT SERVICE"
For the navigation/card: "STOP GUIDANCE" / "RESTART GUIDANCE" / "REDUCE ZOOM " / "INCREASE ZOOM "
Various: "CANCEL" / "HELP"
09-09-2002

09-09-2002
YOUR 307 IN DETAIL
72
SATELLITE NAVIGATION SYS
TEM
Introduction
The satellite navigation system
guides you, by means of vocal and
visual instructions (graphics), to
your chosen destination.
The heart of the system lies in the
use of a map data base and GPS
(Global Positioning System). With
this system you can fix the position of
your vehicle by means of a satellite
network.
The system uses the following ele
ments:
– the CDROM drive,
– the configuration CDROM
– the navigation CDROM,
– the last voice message recall control,
– the control keypad
– the CT monochrome screen or the DT colour screen. The CDROM drive
This is part of the RT3 radio/telephone.
1.
Ejection button on CDROM.
2. CDROM housing.
The navigation CD ROM
This contains all the map data.
It must be inserted in the drive, printed face upwards.
Use only CDRoms approved by PEUGEOT.
The last voice message recall control.
Pressing for more than two seconds on the button at the end o f the lights stalk
repeats the last voice information.
Certain functions or services
described may vary depending on
the version of CDROM or the coun try where the vehicle is sold.
For safety reasons, the
inputting of navigation
information by the driver
must be carried out when
the vehicle is stationary.

09-09-2002
YOUR 307 IN DETAIL
74
Select the Navigation/Guidance icon
using the dial, then validate by press
ing the dial to access the main “Nav
igation Guidance” menu.
General menu
Switch on the RT3 audio/telephone
and insert the navigation CD ROM.
Press the "MENU"button to access
the general menu .
During guidance, if the navigation CDROM is present, the scre en displays
different information depending on the manoeuvres to be carri ed out.
1 . Current manoeuvre or compass.
2 . Next manoeuvre to be carried out.
3 . Next road to be taken.
4. Current road.
5. Estimated time of arrival at destination.
6. Distance to final destination.
7. Distance to next manoeuvre.
Notes:
depending on the situation of the vehicle and on the reception of the GPS
information, this information may disappear from the screen tempora rily,
during guidance, it is only possible to listen to a CD if the vehicle is fitted with
a CD changer.
General notes on the display
12
765
123
7654
4
3
Monochrome screen CT Colour screen DT

09-09-2002
YOUR 307 IN DETAIL75
The main "Navigation Guidance"
menu offers various options for acti
vation or management of guidance:
– choice of the type of destination address (entering of address, ser
vice, GPS coordinates, stored
address),
– modification to the initial route (entering of a diversion)
– displaying of the details of the itin erary (displaying of the chosen
destination)
– management of the guidance options (setting of the guidance
tool parameters),
– stop or resume guidance (display ing of the message which changes
depending on the previous status).
Navigation Guidance
The
"Select a destination" menu
offers various options for reaching a
destination:
– entering a postal address,
– selecting a service available in a town (town hall, hotel, cinema,
airport...),
– entering GPS details,
– selecting a destination stored in the directory,
– selecting one of the last ten desti nations.
Selecting a destinationThe last guidance address is dis
played.
Select and validate in succession the
entry zones
"Town","Street" , then
"N" to fill them in.
The "OK" function permits validation
of the address and access to the
guidance activation function.
The "Archive" function permits
recording of the address in a directo
ry file.
The "Current location" function
permits display of the current
address.
Entering an address
