PEUGEOT SERVICING
The maintenance cycle of your 307 is based on level A(including the replacement of the engine oil, the oil fi lter and a set
of checks) and level Cservices [ level Aservice + workshop operations carried out every 60 000 km] in accordance with the
tables on the following pages.
So that the driving conditions and your style of driving may be taken into account, your 307 is fitted with a service indicator
which modulates the intervals for level A service:
• every 20,000 miles (30 000 km) maximum or 2 years for petrol engines,
• every 12,000 miles (20 000 km) maximum or 2 years for direct injection diesel engines,
The frequency of level Aservices specific to your vehicle will be determined by three paramet ers:
• the number of engine revolutions,
• the engine oil temperature,
• periods when the vehicle is not in use.
Depending on these three elements, the service indicator will suggest a service interval which is more or less the same
as the initial programme. Depending on the conditions of u se, one or more level Aservices may be carried out between
two level C services.
Depending on the distance recorded, your dealer may offer to ca rry out the level Cservice to avoid the visits being too close
together.
PEUGEOT SERVICING
18

09-09-2002
SERVICE INDICATOR
Located on the instrument panel with
the total distance recorder (total and
trip distances), this programmes ser
vice intervals depending on the use
of the vehicle.
Operation
A few moments after the ignition has
been switched on, the spanner sym
bolising services lights up; the dis
play for the total distance recorder
tells you (in round figures) the dis
tance remaining before your next
service.
Example: 4,800 miles remain before
the next service is due. When the
ignition is switched on and for a few
seconds, the display shows: A few seconds after the ignition is
switched on, the total distance
recorder resumes normal operation
and the display shows the total and
trip distances.
The distance remaining before the
next service is less than 500 miles
A few seconds after the ignition is
switched on, the distance recorder
resumes normal operation and the
spanner remains lit. This indicates
that a service should be carried out
shortly.The service is overdue
Each time the ignition is switched on
and for a few seconds, the symbol
and the excess distance flash.
Note:
with the engine running the
symbol flashes until the service has
been carried out.
PEUGEOT SERVICING
20

09-09-2002
PEUGEOT SERVICING25
A AND C SERVICE LEVELS AND THE INTERMEDIATE VISIT
Level
Operations Description of operation 1st Service
A C Intermediate
DRAIN/REFILL Engine oil Bleed fuel filter (diesel) Oil filter Fuel filter *(petrol)REPLACE Fuel filter element (diesel) Air filter element Spark plugs (petrol) Engine oil (check + topup) Manual gearbox oil (check + topup) Battery (check + topup) if cap is removableLevel Screen wash (check + topup) Coolant (check + topup) Brake fluid (check + topup) Power steering fluid (check + top up according to specification) Operation of lights and indicators Condition of glass, headlamp and light lenses and mirrors Horn Windscreen washer jets Condition of wiper blades Condition and tension of the ancillary drive belts Handbrake Condition of hydraulic circuits (hoses and covers)CHECK Condition of rubber boots and gaiters Brake pads Play in hubs, link rods, ball joints, flexible mountings Shock absorbers Rear drum brake lining wear. Condition and pressure of tyres (including spare wheel) Emission control check as per current legislation (petrol) Smoke opacity (diesel) Pollen filter (according to specification) Visual check of the whole vehicle
SERVICE* Courtesy vehicle
ROAD TEST
: All driving conditions: Arduous conditions * According to country.

09-09-2002
1 Rev counter.
2 Seat belt not fastened warning
light.
3 Engine diagnostics warning
light.
4 Handbrake and low brake fluid
level warning light.
5 Lefthand direction indicator.
6 Coolant temperature indicator. 7
Battery charge warning light.
8 Central (STOP) warning light.
9 Engine oil pressure warning
light.
10 Low fuel level warning light.
11 Righthand direction indicator.
12 Fuel gauge.
13 ABS warning light. 14
Air bag warning light.indicator
light.
16 Speedometer.
17 Service indicator, oil level and
total distance recorder.
18 Trip recorder zero reset.
19 Rear fog lamp indicator light.
20 ESP/ASR warning light
21 Front fog lamps indicator
light.
22 Diesel engine preheating light.
23 Main beam headlamps
indicator light.
24 Low coolant level warning light.
25 Dipped beam headlamps
indicator light.
26 Water in diesel filter warning
light.
27 Lighting rheostat.
INSTRUMENTS AND CONTROLS
28
PETROL / DIESEL INSTRUMENT PANEL DIALS: MANUAL GEARBOX

09-09-2002
INSTRUMENTS AND CONTROLS29
1
Rev counter.
2 Seat belt not fastened warning
light.
3 Engine diagnostics warning
light.
4 Handbrake and low brake fluid
level warning light.
5 Lefthand direction indicator.
6 Coolant temperature indicator. 7
Battery charge warning light.
8 Central (STOP) warning light.
9 Engine oil pressure warning
light.
10 Low fuel level warning light.
11 Righthand direction indicator.
12 Fuel gauge.
13 ABS warning light. 14
Air bag warning light.
15 Passenger air bag disarming
indicator light.
16 Speedometer.
17 Service indicator, oil level and
total distance recorder.
18 Trip recorder zero reset.
19 Rear fog lamp indicator
light.
20 ESP/ASR warning light
21 Front fog lamps indicator light.
22 Main beam headlamps indicator
light.
23 Low coolant level warning light.
24 Dipped beam headlamps
indicator light.
25 Lighting rheostat.
26 Sport programme indicator light.
27 Snow programme indicator
light.
28 Gear lever position indicator.
PETROL INSTRUMENT PANEL DIALS: AUTOMATIC GEARBOX

09-09-2002
Instrument panel display
After switching on the ignition, three functions are shown in succession:
service indicator (see corresponding section),
engine oil level indicator,
total distance recorder (total and trip distances).
Note : the total and trip distances are displayed for 30 seconds wh en the ignition
is switched off, on opening the driver's door, as well as on locking and unlocking
the vehicle.
Engine oil level indicator
When the ignition is switched on, the engine oil level is indicated for approxi
mately 10 seconds, after the servicing information.
Maximum
Check the level using the dipstick to confirm whether the displ ay
is correct; a surplus of oil can cause damage to the engine.
Contact a PEUGEOT dealer without delay.
Minimum
Check the level with the dipstick and top it up. The figu re shown
is only correct if the vehicle has been on stable, level ground , with
the engine stopped, for 10 minutes.
Oil level gauge fault
Flashing of the segments, the square or of "min" and "max" indi
cates a fault in the oil level gauge.
There is a risk the engine will be damaged.
Contact a PEUGEOT dealer. Lighting rheostat
With the lights on,
press the button to
vary the intensity of
the lighting of the
instrument panel and
the multifunction dis
play. When the light
ing reaches the minimum (or maxi
mum) setting, release the button
then press it again to increase (or
reduce) the brightness.
As soon as the lighting is of the
required brightness, release the but
ton.
Trip recorder zero
reset
With the ignition on,
press the button.
