09-09-2002
3YOUR 307 AT A GLANCE
1 Speaker (tweeter).
2 Side window demisting vent.
3 Windscreen demisting vents.
4 Passenger air bag.
5 Brightness sensor.
6 Multi function display.
7 Alarm button.
8 Central locking button.
9 Hazard warning lights
switch.
10 Lights and direction indica
tors stalk.
11 Instrument dials.
12 Steering wheel adjustment
control.
13 Windscreen wash/wipe
stalk.
Trip computer stalk.
14 Driver's air bag.
Horn. 15
Radio remote control stalk.
16 Headlamp height
adjustment.
17 Electric mirror controls.
Window controls.
Rear window locking
control.
18 Steering lock and ignition.
19 Cruise control switch.
20 12 V accessories socket.
21 Coin storage
Passenger air bag
disarming switch*.
22 Rubbish container.
23 Can holder.
24 Handbrake.
25 Rear footwell heating vent.
26 Gear lever.
27 Front ash tray.
28 Heating/air conditioning
controls. 29
CD changer.
30 RB3, RD3 or RT3
audio equipment.
31 Central adjustable heating/
ventilation vent and air flow
regulation.
32 Side adjustable heating/
ventilation vent and air flow
regulation.
33 Fuse box.
34 Glove box.
35 Bonnet opening control.
* According to destination.
REAR PARKING AID
(ESTATE)
This system, installed in the rear
bumper, detects any obstacle
(person, vehicle, tree, barrier,
kerb...) situated behind the vehi
cle.
Activation
With the engine running, the sys
tem is activated when reverse
gear is engaged. A bleep indi
cates that it is active.
The proximity information is given
by an audible signal, consisting of
bleeps which become faster as
the vehicle approaches the
obstacle.
When the distance between the
rear of the vehicle and the obsta
cle is less than approxi
mately twenty five cen
timetres, the audible sig
nal becomes continuous.
When you switch to neu
tral, the system becomes
inactive again.
Storing a speed
When you reach the required
speed, press button
2or 3. The
speed is stored and will be main
tained automatically.
Note: it is possible to accelerate
temporarily without deactivating
the cruise control.
Deactivating the stored speed
If you wish to deactivate the
stored speed: press button 4or the brake or
clutch pedal.
Recalling the stored speed
Following deactivation, press but
ton 4. Your vehicle will return to
the last speed stored.
Cancelling the stored speed Place knob 1in the OFFposi
tion or switch off the ignition.
Do not use the
cruise control on
slippery roads or
in heavy traffic.
09-09-2002
131130
10YOUR 307 AT A GLANCE
CRUISE CONTROL
The cruise control makes it possi
ble to maintain, at a constant rate,
the vehicle speed programmed by
the driver, irrespective of the pro
file of the road and without any
action on accelerator or brake
pedal.
To be stored, the vehicle speed
must be in excess of approxi
mately 25 mph.
Activation Place knob 1in the ON
position.
You may store a speed. Place knob 1in the OFFposi
tion to deactivate the system.
09-09-2002
CRUISE CONTROL Cruise control berfungsi untuk mem- pertahankan kecepatan kendaraanyang telah diprogram oleh pengemu-di secara stabil dan tidak tergantungpada karakteristik jalan dan penge-mudi tidak perlu menyentuh pedalgas atau pedal rem. Untuk dapat disimpan ke memori, kecepatan kendaraan harus lebihdari 40 km/jam dan gigi 4 atau 5harus dimasukkan.Pengoperasian
Pasang penyetel 1ke posisi ON.
Anda dapat menyimpan satu kece- patan kendaraan. Pasang penyetel 1ke posisi OFF
untuk mematikan sistem.
Menyimpan kecepatan
Jika kecepatan yang Anda inginkan tercapai, tekan tombol 2atau 3.
Kecepatan yang Anda pilih akandisimpan dan akan dipertahankansecara otomatis. Catatan : Anda dapat menginjak
pedal gas sebentar tanpa harus menonaktifkan cruise control terlebihdahulu. Menghapus kecepatan yang disimpan
Jika Anda ingin menghapus kecepa- tan yang disimpan : tekan tombol 4atau pedal rem
atau kopeling. Memanggil kecepatan yang disimpan Setelah menghapus, tekan tombol
4.
Kendaraan Anda akan kembali ke kecepatan terakhir yang disimpan. Mengganti kecepatan yang disimpan Untuk menyimpan kecepatan yang lebih tinggi dari yang sebelumnya : tekan tombol 3;
lepaskan tombol bila kecepatan yang diinginkan tercapai.
Untuk menyimpan kecepatan yanglebih rendah dari kecepatan sebe-lumnya : tekan tombol 2;
lepaskan tombol bila kecepatan yang diinginkan tercapai.
Membatalkan kecepatan yangdisimpan Pasang penyetel 1ke posisi OFF
atau putar kunci kontak ke OFF.
SELENGKAPNYA 307 ANDA
130
Jangan menggunakan cruise control pada jalanyang licin atau di lalu lin-tas yang padat.
