1999 SUBARU LEGACY sensor

G: REAR WIRING HARNESS
1. LHD MODEL
Connector Connecting to
No. Pole Color Area No. Name
R1 8 * B-2 B97 Bulkhead wiring harness
R224 Black B-2 B98Bulkhead wiring harness
(2200 cc engine AWD except Taiwan model)
20 * B-2 B98 Bulkhead wiring harness (Other models)
R3 24 * B-2 B99 Bulkhead wiring harness
R4 1 Black B-2 Parking brake switch
R5 2 * C-2 Select lever illumination light (AT)
R6 2 Black C-2 Shift lock solenoid (AT)
R7 2 * C-2 P position switch (AT)
R8 2 * C-3 Seat belt switch
R9 1 Brown C-4 Front door switch LH
R10 2 * C-4 D22 Rear door cord LH (Security)
R11 8 * C-4 D21 Rear door cord LH
R12 1 Brown B-2 Front door switch RH
R13 2 * B-2 D28 Rear door cord RH (Security)
R14 8 * B-2 D27 Rear door cord RH
R158 * B-3 R57 Fuel tank cord (Except Taiwan model)
6 Black B-3 R57 Fuel tank cord (Taiwan model)
R16 1 Brown B-3 Rear door switch RH
R29 3 * C-2 Diode (Security)
R30 2 Black C-2 Diode (Rear gate latch switch) (Wagon)
R31 3 * C-2 Diode (Security)
R41 4 Blue B-2 Seat heater (Passenger)
R42 6 * B-3 Seat heater switch (Passenger)
R43 6 Blue B-3 Seat heater switch (Driver)
R44 4 Blue C-3 Seat heater (Driver)
R46 2 * B-3 R67 Fuel tank cord (Except Taiwan model)
R47 3 * B-4 Fuel tank pressure sensor (2200 cc engine AWD model)
R50 4 * B-2 B90 Bulkhead wiring harness
R51 2 * B-2 Vanity mirror illumination light RH
R52 2 * A-3 Room light
R53 4 * C-3 B45 Bulkhead wiring harness
R54 2 * B-3 Vanity mirror illumination light LH
R55 1 * B-3 Sunroof control module (Except OUTBACK)
R56 2 * B-3 Spot light
R578 * B-3 R15 Rear wiring harness (Except Taiwan model)
6 Black B-3 R15 Rear wiring harness (Taiwan model)
R58 6 * B-3 Fuel gauge module & fuel pump
R59 2 * B-4 Fuel gauge sub module (AWD)
R67 2 * B-3 R46 Rear wiring harness (Except Taiwan model)
R68 2 * B-3 Pressure control solenoid valve
R69 2 * B-3 Vent control solenoid valve
R83 4 * B-3 R84 Fuel tank cord (2200 cc engine AWD model)
R84 4 * B-3 R83 Rear wiring harness (2200 cc engine AWD model)
R85 3 * B-2 B178 Bulkhead wiring harness (Wiper deicer)
R86 8 * B-3 Wiper deicer switch
R87 4 Blue C-3 Wiper deicer relay
R88 4 * C-3 Wiper deicer timer
R89 6 Black A-3 Sunroof control module (OUTBACK)
R90 6 Brown A-3 Sunroof switch (OUTBACK)
*: Non-colored
162
6-3[D8G1]WIRING DIAGRAM
8. Electrical Wiring Harness and Ground Point

2. RHD MODEL
Connector Connecting to
No. Pole Color Area No. Name
R1 56 * B-2 B97 Bulkhead wiring harness (S.M.J.)
R4 1 Black B-2 Parking brake switch
R5 2 * B-2 Select lever illumination light
R6 2 Black B-2 Shift lock solenoid
R7 2 * B-2 P position switch
R8 2 * B-2 Seat belt switch
R9 1 Brown B-3 Front door switch LH
R11 8 * B-4 D21 Rear door cord LH
R12 1 Brown B-2 Front door switch RH
R14 8 * B-2 D27 Rear door cord RH
R15 8 * B-3 R57 Fuel tank cord
R16 1 Brown A-3 Rear door switch RH
R30 2 Black B-2 Diode (Rear gate latch switch)
R46 2 * B-3 R67 Fuel tank cord
R47 3 * B-4 Fuel tank pressure sensor
R50 2 Green B-2 B90 Bulkhead wiring harness
R52 2 * A-3 Room light
R57 8 * B-3 R15 Rear wiring harness
R58 6 * A-3 Fuel gauge module & fuel pump
R59 2 * B-4 Fuel gauge sub module
R67 2 * B-3 R46 Rear wiring harness
R68 2 * B-3 Pressure control solenoid valve
R69 2 * A-3 Vent control solenoid valve
R83 4 * B-3 R84 Fuel tank cord
R84 4 * B-3 R83 Rear wiring harness
*: Non-colored
164
6-3[D8G2]WIRING DIAGRAM
8. Electrical Wiring Harness and Ground Point

H: FLOOR WIRING HARNESS AND DOOR CORD
1. LHD MODEL
Connector Connecting to
No. Pole Color Area No. Name
P120 Blue B-1 F1Front wiring harness
(With TCS model)
8 * B-1 F1Front wiring harness
(With ABS model)
P2 2 Black C-2 Diode (TCS)
P4 6 * B-3
ABS/TCS control
module P5 8 * B-3
P6 16 * B-3
P7 20 * B-3
P82 Gray B-3Rear ABS sensor
RH
2 * B-3Rear ABS sensor
RH (Outback with
step roof)
P92 Gray B-4 Rear ABS sensor LH
2 * B-4Rear ABS sensor LH
(Outback with step
roof)
P10 40 Gray B-2 B63Bulkhead wiring har-
ness (With TCS
model)
P11 3 * B-2 ABS G sensor
*: Non-colored
Connector Connecting to
No. Pole Color Area No. Name
D1 24 * C-3 B30Bulkhead wiring har-
ness
D2 2 * C-3Front door speaker
LH
D3 2 Green C-3Front power window
motor LH
D4 2 Black B-3 Front tweeter LH
D5 6 * B-3Remote control rear-
view mirror LH
D6 2 * B-3 Mirror heater LH
D7 14 * B-3Power window main
switch
D84 * B-3Front door lock
actuator LH
4 Gray B-3Front door lock
actuator LH (With
security system)
D9 4 Gray B-3Front door key
switch LH (Security)
D10 2 Black C-3 Step light LH
D11 24 * B-2 B101Bulkhead wiring har-
ness
D12 2 * B-2Front door speaker
RH
Connector Connecting to
No. Pole Color Area No. Name
D13 2 Green B-2Front power window
motor RH
D14 2 Black B-2 Front tweeter RH
D15 6 * B-2Remote control rear-
view mirror RH
D16 2 * B-2 Mirror heater RH
D17 5 * B-2Front power window
sub switch RH
D184 * B-2Front door lock
actuator RH
4 Gray B-2Front door lock
actuator RH (With
security system)
D19 4 Gray B-2Front door key
switch RH (Security)
D20 2 Black B-2 Step light RH
D21 8 * B-3 R11 Rear wiring harness
D22 2 * B-3 R10Rear wiring harness
(Security)
D23 2 Black B-4Rear door speaker
LH
D24 2 Green B-4Rear power window
motor LH
D25 5 * B-4Rear power window
sub switch LH
D264 * B-4Rear door lock
actuator LH
4 Gray B-4Rear door lock
actuator LH (With
security system)
D27 8 * B-2 R14 Rear wiring harness
D28 2 * B-2 R13Rear wiring harness
(Security)
D29 2 Black B-2Rear door speaker
RH
D30 2 Green B-3Rear power window
motor RH
D31 5 * A-2Rear power window
sub switch RH
D324 * A-3Rear door lock
actuator RH
4 Gray A-3Rear door lock
actuator RH (With
security system)
D50 2 * C-2 B113Bulkhead wiring har-
ness
D51 5 * B-3Front door lock
switch LH
D52 5 * B-2Front door lock
switch RH
*: Non-colored
166
6-3[D8H1]WIRING DIAGRAM
8. Electrical Wiring Harness and Ground Point

I: REAR END WIRING HARNESS (SEDAN)
Connector Connecting to
No. Pole Color Area No. Name
R17 1 Black A-3 Rear defogger (Power)
R18 2 Black B-3 Rear speaker RH
R19 2 * B-3 High-mounted stop light
R20 2 Blue B-2 Trunk room light
R21 2 Black B-2 Rear speaker LH
R22 1 Brown B-1 Rear door switch LH
R23 3 * B-2 Power antenna
R246 * B-3 R60 Trunk lid cord (Without security system)
8 * B-3 R60 Trunk lid cord (With security system)
R25 2 Black B-4 Rear defogger condenser
R26 4 * B-4 Rear combination light RH
R27 2 * B-4 Trunk room light switch
R28 4 * B-3 Rear combination light LH
R45 6 * B-4 Trailer connector
R47 3 * B-3Fuel tank pressure sensor
(2200 cc engine FWD and 2500 cc engine model)
R606 * B-4 R24 Rear wiring harness (Without security system)
8 * B-4 R24 Rear wiring harness (With security system)
R61 3 * B-4 Key switch (Security)
R62 4 * B-4 Rear finisher light RH
R63 2 * B-3 License plate light
R64 4 * B-3 Rear finisher light LH
R65 1 Black A-2 Rear defogger (Ground)
R66 2 Black B-4 High-mounted stop light (Rear spoiler)
*: Non-colored
170
6-3[D8I0]WIRING DIAGRAM
8. Electrical Wiring Harness and Ground Point

J: REAR END WIRING HARNESS (WAGON)
1. LHD MODEL
Connector Connecting to
No. Pole Color Area No. Name
R22 1 Brown C-1 Rear door switch LH
R23 6 * C-2 Power antenna
R25 2 Black C-3 Rear defogger condenser
R26 4 Black D-4 Rear combination light RH
R28 4 Black C-2 Rear combination light LH
R32 2 * C-2 Rear accessory power supply
R36 5 Black C-3 Rear wiper relay
R37 2 * C-3 D33
Rear gate cord R38 4 * C-3 D34
R39 8 * C-4 D35
R40 4 Black C-3 D36 Rear gate cord (With security)
R45 6 * C-2 Trailer connector (Outback with step roof)
R47 3 * D-3Fuel tank pressure sensor
(2200 cc engine FWD and 2500 cc engine model)
R89 8 * D-2 Joint connector (Rear speaker)
R90 8 * D-2 Joint connector (Rear speaker)
R91 4 Black C-4 D65 Rear gate cord (With rear tweeter)
Connector Connecting to
No. Pole Color Area No. Name
D33 2 * C-3 R37
Rear wiring harness D34 4 * C-3 R38
D35 8 * C-4 R39
D36 4 Black C-3 R40 Rear wiring harness (With security)
D37 1 Black B-3
Luggage room light
D38 1 * B-3
D39 2 * B-3 High-mounted stop light
D40 1 Black B-4 Rear defogger (Power)
D41 4 Gray B-4 Key switch (Security)
D42 4 * B-4 Rear finisher light RH
D43 4 * B-3 Rear wiper motor
D44 2 * B-4 License plate light RH
D45 2 * A-3 License plate light LH
D46 2 Black A-4 Rear gate latch switch
D474 * A-4 Rear gate lock actuator (Without security system)
4 Gray A-4 Rear gate lock actuator (With security system)
D48 1 Black B-3 Rear defogger (Ground)
D49 4 * A-3 Rear finisher light LH
D65 4 Black C-4 R91 Rear wiring harness (With rear tweeter)
D66 2 Black C-3 Rear tweeter RH
D67 2 Black B-2 Rear tweeter LH
*: Non-colored
172
6-3[D8J1]WIRING DIAGRAM
8. Electrical Wiring Harness and Ground Point
