WIPERS AND WASHERS
84-22 REPAIRS
Reservoir - washer - from 03MY
$% 84.10.03
Remove
1.Remove the front bumper assembly.

+ EXTERIOR FITTINGS, REPAIRS,
Bumper assembly - front.
2.Disconnect multiplug from the headlamp
washer pump.
3.Place a container beneath vehicle to collect any
spillage.
4.Noting fitted position disconnect multiplugs and
washer hoses from the front and rear
windscreen washer pumps.
5.Remove 2 nuts and 2 bolts securing the washer
reservoir to the body.
6.Release washer reservoir from filler neck.
Remove the washer reservoir.
7.Remove and discard the washer reservoir filler
neck seal.
NOTE: Do not carry out further dismantling if
component is removed for access only.
8.Remove washer pumps from washer reservoir
and discard the seals.Refit
1.Clean washer pump and filler neck seal
recesses.
2.Fit new washer pump and filler neck seals to
the washer reservoir.
3.Fit and secure washer pumps to the washer
reservoir.
4.Fit washer reservoir to the filler neck, fit and
tighten the nuts and bolts.
5.Connect multiplugs and washer hoses to the
windscreen washer pumps.
6.Remove container from beneath the vehicle.
7.Fit the front bumper assembly.

+ EXTERIOR FITTINGS, REPAIRS,
Bumper assembly - front.

WIPERS AND WASHERS
REPAIRS 84-23
Jet - washer - windscreen
$% 84.10.08
Remove
1.Carefully pull the elbow from the washer jet.
2.Place a protective covering around the washer
jet, then release and remove washer jet.
Refit
1.Fit washer jet to its location in the bonnet, and
remove the protective material.
2.Connect the washer tube, ensuring that it is
pushed fully onto the stub pipe.

WIPERS AND WASHERS
84-24 REPAIRS
Pump - washer - screen and headlamp
$% 84.10.21
The following procedure also covers removal of the
rear screen washer pump and the headlamp washer
pump.
Remove
1. Headlamp washer pump: Remove front
bumper.

+ EXTERIOR FITTINGS, REPAIRS,
Bumper assembly - front.
2. Front and rear screen washer pumps:
Remove 7 screws securing LH front wheel arch
liner extension to liner and bumper valance and
remove liner extension.
3.Position container under washer reservoir to
collect fluid spillage. 4.Disconnect multiplug from washer pump.
5.Release clip and disconnect washer hose from
washer pump.
6.Remove washer pump from reservoir and
remove and discard pump seal.
Refit
1.Use a new seal and fit pump to reservoir.
2.Connect hose to pump and secure with clip.
3.Connect multiplug to pump.
4. Front and rear screen washer pumps:Fit
wheel arch liner extension, secure to bumper
valance and liner with screws.
5. Headlamp washer pump:Fit front bumper.

+ EXTERIOR FITTINGS, REPAIRS,
Bumper assembly - front.
6.Fill reservoir with washer fluid.

WIPERS AND WASHERS
REPAIRS 84-25
Motor and linkage - wiper - windscreen
$% 84.15.11
Remove
1.Remove plenum air intake.

+ HEATING AND VENTILATION,
REPAIRS, Plenum Air Intake.
2.Remove 4 nuts and one bolt securing motor
mounting plate to body.
3.Remove nut and bolt securing linkage to body.
4.Release motor and linkage from body and
disconnect multiplug from windscreen wiper
motor.
5.Remove motor and linkage. 6.Remove nut securing linkage connecting rod to
wiper motor spindle.
7.Release link from motor spindle.
8.Remove 3 bolts securing motor to mounting
plate and remove motor.
Refit
1.Fit new wiper motor to mounting plate and
secure with bolts.
2.Connect link to motor spindle and tighten nut to
7 Nm (5.2 lbf.ft).
3.Fit motor and linkage to body, connect
multiplug. Tighten all fixings to 2.5 Nm (1.8
lbf.ft).
4.Fit plenum air intake.

+ HEATING AND VENTILATION,
REPAIRS, Plenum Air Intake.

WIPERS AND WASHERS
84-26 REPAIRS
Switch - wiper and washer - windscreen
$% 84.15.34
WARNING: It is imperative that before any work
is undertaken on the SRS system the appropriate
information is read thoroughly.
Remove
1.Remove rotary coupler.

+ RESTRAINT SYSTEMS, REPAIRS,
Rotary coupler.
2.Release passive coil from steering column lock
and lower the coil without disconnecting the
harness.
3.Release front wiper delay multiplug from
column switch mounting bracket and
disconnect from harness.
4.Disconnect harness multiplug from wiper
switch.
5.Remove 2 screws securing switch, carefully
raise edge of switch bracket to clear location
peg and remove switch. Refit
1.Fit new switch to bracket and secure with
screws.
2.Connect harness multiplug to switch.
3.Connect front wiper delay multiplug and fit
multiplug to switch bracket.
4.Fit passive coil to column lock.
5.Fit rotary coupler.

+ RESTRAINT SYSTEMS, REPAIRS,
Rotary coupler.

WIPERS AND WASHERS
REPAIRS 84-27
Jet - washer - headlamp
$% 84.20.08
The procedure to remove the headlamp washer jet
on 03MY vehicles is detailed in the front bumper
finisher job.

+ EXTERIOR FITTINGS, REPAIRS, Trim
finisher - bumper - front - from 03MY.
Remove
1.Remove retaining screw cover from jet
housing.
2.Remove screw securing jet to bumper.
3.Release jet and withdraw sufficiently to gain
access to washer tube. Disconnect tube from
jet and remove jet.
Refit
1.Connect jet to washer tube, ensuring it is
pushed fully home.
2.Locate jet in bumper, retain with screw and fit
screw cover.
Jet - washer - rear screen
$% 84.30.09
Remove
1.Remove spare wheel.
2.Remove rear screen wiper blade.
3.Release washer jet and washer jet tube from
wiper arm.
4.Release washer jet from washer jet tube and
remove jet.
Refit
1.Fit new washer jet to washer jet tube and fit to
wiper arm.
2.Fit rear screen wiper blade.
3.Fit spare wheel.

WIPERS AND WASHERS
84-28 REPAIRS
Switch - rear wash
$% 84.30.27
Remove
1.Carefully remove switch from instrument cowl.
2.Disconnect multiplug and remove switch. Refit
1.Position new switch and connect multiplug.
2.Carefully push switch into instrument cowl.

WIPERS AND WASHERS
REPAIRS 84-29
Motor - wiper - rear screen
$% 84.35.12
Remove
1.Remove spare wheel from taildoor.
2.Remove tail door trim casing.

+ DOORS, REPAIRS, Trim casing - tail
door.
3.Remove tail door water shedder.
4.Disconnect washer tube
5.Raise nut cover, remove nut and release wiper
arm.
6.Remove spindle nut and flat washer and
discard rubber seal.
7.Disconnect taildoor harness multiplug from
wiper motor.
8.Remove 2 bolts securing wiper motor to tail
door.
9.Remove wiper motor. Refit
1.Position wiper motor to door and secure with
bolts.
2.Connect tail door harness multiplug to wiper
motor.
3.Fit rubber seal, flat washer and spindle nut.
Tighten spindle nut to 3 Nm (2.2 lbf.ft).
4.Position wiper arm to tail door and connect
washer tube.
5.Tighten wiper arm nut to 20 Nm (15 lbf.ft) and
fit nut cover.
6.Fit tail door water shedder.
7.Fit tail door trim casing.

+ DOORS, REPAIRS, Trim casing - tail
door.
8.Fit spare wheel to tail door.
