1999 LAND ROVER DEFENDER Workshop Manual

77PANEL REPAIRS
20
SEALING AND CORROSION PROTECTION Seam sealer on body side assembly
Seam sealer on front door
NOTE: Seam sealer to be wiped after application for cosmetic purposes.
ProCarManuals.com

PANEL REPAIRS
21
SEALING AND CORROSION PROTECTION Seam sealer on rear end assembly
CAUTION: Do not block drain holes when applying seam sealer.
ProCarManuals.com

77PANEL REPAIRS
22
SEALING AND CORROSION PROTECTION Seam sealer on roof assembly
ProCarManuals.com

PANEL REPAIRS
23
SEALING AND CORROSION PROTECTION PUTTY APPLICATION AREAS
The following Illustrations show the treatment areas for Putty application.
All areas symmetrically opposite to those shown are also treated.
Putty location on bulkhead assembly
Putty location on rear end
ProCarManuals.com

77PANEL REPAIRS
24
SEALING AND CORROSION PROTECTION Putty location on underside of vehicle
ProCarManuals.com

PANEL REPAIRS
25
SEALING AND CORROSION PROTECTION Putty location on front door
ProCarManuals.com

77PANEL REPAIRS
26
SEALING AND CORROSION PROTECTION FOAM/RUBBER SEAL APPLICATION AREAS
The following Illustrations show the location of foam/rubber seals. All areas
All areas symmetrically opposite to those shown are also treated.
Body side rear
M77 2093A
A
A
B
B
A - A
B - B
Section A-A shows a rubber seal in position on the body side rear upper assembly.
CAUTION: Ensure rubber seal is correctly seated into channel.
Section B-B shows a foam seal located on the bottom edge of the body side rear upper assembly. It is fixed to the
panel using double sided tape.
ProCarManuals.com

PANEL REPAIRS
27
SEALING AND CORROSION PROTECTION Body side lower
The arrows indicate the positon of two foam seals.
CAUTION: Ensure seals are fitted before refitting assembly.
