disarm switch state CLOSED, replace CTM.
23) Turn ignition switch to START position. If horn does not
sound, go to next step. If horn sounds, go to step 24).
24) Locate Central Timer Module (CTM). CTM is located behind\
right kick panel. Disconnect CTM 14-pin connector C1. Using an
external voltmeter, measure voltage between ground and CTM 14-pin
connector C1 terminal No. 8 (Dark Blue/White wire). If voltage is more\
than 10 volts, replace CTM. If voltage is 10 volts or less, repair
open Dark Blue/White wire between CTM and RUN-ACC fuse in junction
block.
WINDSHIELD WIPER SYSTEM
WIPER PARK SWITCH FAILURE
NOTE: For connector terminal identification and wiring diagrams,
see BODY CONTROL COMPUTER - INTRODUCTION article. Perform
VERIFICATION TEST VER-1A after each repair.
CAUTION: Always turn ignition switch to OFF position prior to
disconnecting or connecting any module connector.
NOTE: It takes 8 seconds for wiper park switch failure DTC to set.
1) Using scan tool, clear DTCs. See appropriate SELF-
DIAGNOSTICS article. Operate wipers in low speed, then intermittent
mode. Reread DTCs. If WIPER PARK SWITCH FAILURE is displayed, go to
next step. If WIPER PARK SWITCH FAILURE is not displayed, system is
currently functioning properly.
2) Gain access to wiper motor connector. Using an external
voltmeter, measure voltage between ground and wiper motor terminal No.
2 (Dark Green wire). If voltage is more than 9 volts, go to next step.\
If voltage is 9 volts or less, replace wiper motor.
3) Locate Central Timer Module (CTM). CTM is located under
left side of instrument panel. Using an external voltmeter, measure
voltage between ground and backprobe of CTM 14-pin Green connector C1
terminal No. 11 (Dark Green wire). If voltage is 9 volts or less,
replace CTM. If voltage is more than 9 volts, repair short to voltage
in Dark Green wire between CTM and wiper relay or wiper motor.
INTERMITTENT WIPERS INOPERATIVE
NOTE: For connector terminal identification and wiring diagrams,
see BODY CONTROL COMPUTER - INTRODUCTION article. Perform
VERIFICATION TEST VER-1A after each repair.
CAUTION: Always turn ignition switch to OFF position prior to
disconnecting or connecting any module connector.
1) Using scan tool select CENTRAL TIMER MODULE. If scan tool
displays NO RESPONSE, go to appropriate VEHICLE COMMUNICATIONS
article. If scan tool displays any CCD bus failure message, go to
SYMPTOM IDENTIFICATION. If scan tool does not display NO RESPONSE or
any CCD bus failure message, go to next step.
2) If problem is wipers parking in wrong position, go to next
step. If problem is not wipers parking in wrong position, go to step
5).
3) Gain access to wiper motor connector. Turn wipers on to
low speed. Using an external voltmeter, measure voltage between ground
and wiper motor switch terminal No. 2 (Dark Green wire). If voltage
does not cycle between zero and 12 volts, replace wiper motor. If
voltage cycles between zero and 12 volts, go to next step.

Replacement of the rotor is required because it does not meet
design specifications.
Some conditions indicate that a service or part replacement
is suggested because the part is close to the end of its useful life
or addresses a customer's need, convenience or request. If a
customer's vehicle has one of these conditions, the procedure may be
only to suggest service.
Example:
An exhaust pipe is rusted, corroded or weak, but no leaks are
present. In this case, the exhaust pipe has not failed.
However, there is evidence that the pipe may need replacement
in the near future. Replacement of the pipe may be suggested
for the customer's convenience in avoiding a future problem.
Example:
The customer desires improved ride and/or handling, but the
vehicle's shocks or struts have not failed. In this case,
replacement may be suggested to satisfy the customer's
wishes. In this case, replacement of the shocks or struts may
not be sold as a requirement.
A customer, of course, has the choice of whether or not a
shop will service his or her vehicle. He or she may decide not to
follow some of your suggestions. When a repair is required, a MAP
shop must refuse partial service on that system if, in the judgment of
the service provider, proceeding with the work could create or
continue an unsafe condition. When a procedure states that required
or suggested repair or replacement is recommended, the customer must
be informed of the generally acceptable repair/replacement options
whether or not performed by the shop.
When presenting suggested repairs to the customer, you must
present the facts, allowing the customer to draw their own conclusions
and make an informed decision about how to proceed.
The following reasons may be used for required and suggested
services. These codes are shown in the "Code" column of the MAP
Uniform Inspection & Communications Standards that follow:
Reasons to Require Repair or Replacement
A - Part no longer performs intended purpose
B - Part does not meet a design specification (regardless of
performance)
C - Part is missing
NOTE: When a repair is required, the shop must refuse partial
service to the system in question, if the repair creates
or continues an unsafe condition.
Reasons to Suggest Repair or Replacement
1 - Part is close to the end of its useful life (just above
discard specifications, or weak; failure likely to occur
soon, etc.)
2 - To address a customer need, convenience, or request (to
stiffen ride, enhance performance, eliminate noise, etc.)
3 - To comply with maintenance recommended by the vehicle's
Original Equipment Manufacturer (OEM)
4 - Technician's recommendation based on substantial and
informed experience
NOTE: Suggested services are always optional. When presenting
suggested repairs to the customer, you must present the
facts, allowing the customer to draw their own conclusions

1) Start engine, and check booster vacuum hose connections. A
hissing noise indicates a vacuum leak. Repair any vacuum leaks before
proceeding. Stop engine, and shift transmission into Neutral. Pump
brake pedal until all vacuum reserve in booster is depleted.
2) Hold brake pedal under light pressure. If pedal does not
hold firm and falls away, master cylinder may be faulty. Bleed system
using appropriate method, and repeat step 1). See BLEEDING PROCEDURES
under BLEEDING BRAKE SYSTEM.
3) If pedal still does not hold firm, master cylinder is
faulty. If pedal holds firm, start engine and observe pedal height. If
pedal height change is not apparent, power booster or vacuum check
valve is faulty. Install good check valve, and repeat steps 1) and 2).\
If pedal falls away slightly under light pressure and then holds firm,
go to next step .
4) Start engine. Release brake pedal. Increase engine speed
to 1500 RPM. Close throttle and immediately turn off ignition. Wait at
least 90 seconds, and try brake action again. Booster should provide 2
or more vacuum assisted pedal applications. If vacuum assist is not
provided, perform booster and check valve vacuum tests.
POWER BRAKE BOOSTER VACUUM TEST
Connect vacuum gauge to booster check valve using "T"
fitting. Start engine, and run at idle speed for one minute. Clamp
hose shut between vacuum source and check valve. Stop engine, and
observe vacuum gauge. If vacuum drops more than one in. Hg within 15
seconds, booster diaphragm or check valve is faulty.
POWER BRAKE BOOSTER CHECK VALVE TEST
Disconnect vacuum hose from check valve. Remove check valve
and valve seal from booster. Use a hand-operated vacuum pump for
testing. Apply 15-20 in. Hg at large end of check valve. Vacuum should
hold steady. If gauge on pump indicates vacuum loss, check valve is
faulty and should be replaced.
COMBINATION VALVE METERING VALVE TEST
Metering valve operation can be checked visually with aid of
an assistant. While an assistant applies and releases brake pedal,
observe metering valve stem. If valve is operating correctly, stem
will extend slightly when brakes are applied, and contract when brakes
are released. If valve is faulty, replace combination valve assembly.
COMBINATION VALVE PRESSURE DIFFERENTIAL SWITCH TEST
1) Using an assistant, apply brake pedal. Observe brake
warning light. Raise and support vehicle, and connect a bleed hose to
one rear wheel cylinder. Submerge other end of hose into container
partially filled with brake fluid. Have assistant press and hold brake
pedal down while observing brake warning light. Open bleeder screw. If
warning light glows, switch is operating properly.
2) If warning light fails to glow, check circuit fuse, bulb
and wiring. Repair as necessary. Repeat step 1). If warning light
fails to glow, check brakelight, parking brake switches and related
wiring. Repair as necessary. Repeat step 1). If warning light fails to
glow, pressure differential switch is faulty. Replace combination
valve assembly, and bleed brake system. Verify proper valve operation.
REMOVAL & INSTALLATION

made.
* When using a jumper wire, ensure either jumper wire or
circuit is fuse-protected.
* Before disconnecting connector from any control module,
ensure ignition is off before removing connector.
* When checking voltage or continuity at any control module,
probe connector for control module from pin side. DO NOT
backprobe connector or probe wires through insulation.
* DO NOT cause short circuits when performing electrical tests.
This will set additional Diagnostic Trouble Codes (DTCs),
making diagnosis of original problem more difficult.
* Use specified test equipment when performing electrical
tests.
RETRIEVING DIAGNOSTIC TROUBLE CODES
NOTE: Self-diagnostic tests are written specifically for Chrysler's
Diagnostic Readout Box (DRB). If using a generic scan tool,
ensure it is OBD-II certified. A generic scan tool may not be
capable of performing all necessary test functions.
Ensure battery is fully charged. Turn ignition off. Connect
scan tool to Data Link Connector (DLC). DLC is located under left side\
of instrument panel. Turn ignition on. Using scan tool manufacturer's
instructions, record all DTCs displayed on scan tool. If ant DTCs are
retrieved, perform appropriate test under DIAGNOSTIC TESTS. Once all
repairs are made, clear DTCs. See CLEARING DIAGNOSTIC TROUBLE CODES.
If no DTCs are retrieved and fault still exists, go to CHECKING SPEED
CONTROL OPERATION under SYSTEM TESTS.
CLEARING DIAGNOSTIC TROUBLE CODES
Ensure ignition is off. Connect scan tool to DLC. Turn
ignition on. Using screen prompts on scan tool, erase DTCs from PCM.
DIAGNOSTIC TESTS
FTC P0720: LOW OUTPUT SPEED SENSOR (OSS) RPM MORE THAN 15 MPH
FTC P0720 will set if output shaft speed is less than 60 RPM
for 2.6 seconds when vehicle speed is more than 15 MPH.
Possible Causes:
* Defective Output Speed Sensor (OSS).
* OSS signal circuit open or shorted.
* OSS ground circuit open or shorted.
* Park/Neutral Position (PNP) switch FTC present.
* Defective PNP switch.
* Defective PCM.
1) Turn ignition on. Using scan tool, read DTCs. If FTC
specific good trip is displayed and equal to zero, go to next step. If
FTC specific good trip is equal to more than zero, go to step 13).
2) If there are any Park/Neutral Position (PNP) switch DTCs,\
repair PNP switch FTC first. Perform TEST VER-5A under VERIFICATION
TESTS. If there are no PNP switch DTCs, go to next step.
3) Using scan tool, read PNP switch state. While observing
scan tool, shift transmission through all positions. If scan tool did
not display P/N and D/R in correct positions, repair PNP switch or
circuit as necessary. Perform TEST VER-5A under VERIFICATION TESTS. If

Example:
An exhaust pipe is rusted, corroded or weak, but no leaks are
present. In this case, the exhaust pipe has not failed.
However, there is evidence that the pipe may need replacement
in the near future. Replacement of the pipe may be suggested
for the customer's convenience in avoiding a future problem.
Example:
The customer desires improved ride and/or handling, but the
vehicle's shocks or struts have not failed. In this case,
replacement may be suggested to satisfy the customer's
wishes. In this case, replacement of the shocks or struts may
not be sold as a requirement.
A customer, of course, has the choice of whether or not a
shop will service his or her vehicle. He or she may decide not to
follow some of your suggestions. When a repair is required, a MAP shop
must refuse partial service on that system if, in the judgment of the
service provider, proceeding with the work could create or continue an
unsafe condition. When a procedure states that required or suggested
repair or replacement is recommended, the customer must be informed of
the generally acceptable repair/replacement options whether or not
performed by the shop.
When presenting suggested repairs to the customer, you must
present the facts, allowing the customer to draw their own conclusions
and make an informed decision about how to proceed.
The following reasons may be used for required and suggested
services. These codes are shown in the "Code" column of the MAP
Uniform Inspection & Communications Standards that follow:
Reasons to Require Repair or Replacement
A - Part no longer performs intended purpose
B - Part does not meet a design specification (regardless of
performance)
C - Part is missing
NOTE: When a repair is required, the shop must refuse partial
service to the system in question, if the repair creates
or continues an unsafe condition.
Reasons to Suggest Repair or Replacement
1 - Part is close to the end of its useful life (just above
discard specifications, or weak; failure likely to occur
soon, etc.)
2 - To address a customer need, convenience, or request (to
stiffen ride, enhance performance, eliminate noise, etc.)
3 - To comply with maintenance recommended by the vehicle's
Original Equipment Manufacturer (OEM)
4 - Technician's recommendation based on substantial and
informed experience
NOTE: Suggested services are always optional. When presenting
suggested repairs to the customer, you must present the
facts, allowing the customer to draw their own conclusions
and make an informed decision about how to proceed.
DRIVE/POWER TRAIN ASSEMBLIES
SERVICE PROCEDURES REQUIRED AND SUGGESTED FOR PROPER
VEHICLE OPERATION


* E LE C TR IC AL S YSTE M U NIF O RM IN SPEC TIO N G UID ELIN ES *

1 999 D odge P ic ku p R 1500
GENERAL INFORMATION
Electrical System Motorist Assurance Program
Standards For Automotive Repair
All Makes and Models
INTRODUCTION TO MOTORIST ASSURANCE PROGRAM (MAP)
CONTENTS
OVERVIEW OF MOTORIST ASSURANCE PROGRAM
OVERVIEW OF SERVICE REQUIREMENTS & SUGGESTIONS
ACTUATOR MOTORS (SOLENOIDS) (ELECTRIC)
ACTUATOR MOTORS (VACUUM)
AIR BAGS
ALTERNATORS AND GENERATORS
AMPLIFIERS
ANTENNAS
BATTERIES
BATTERY CABLES
BATTERY CABLES
BATTERY HOLD DOWN HARDWARE
BATTERY TRAYS AND HOLD DOWN HARDWARE
BATTERY WIRES
BELTS
BULB SOCKETS
BULBS, SEALED BEAMS AND LEDS
CD PLAYERS
CIGARETTE LIGHTER ASSEMBLIES
CIRCUIT BREAKERS
CLUTCH SWITCHES
CONNECTORS
CONTROL MODULES
CRUISE CONTROL BRAKE SWITCHES
CRUISE CONTROL CABLES
CRUISE CONTROL CLUTCH SWITCHES
CRUISE CONTROL LINKAGES AND CABLES
CRUISE CONTROL RESERVOIRS
CRUISE CONTROL TUBES
CRUISE CONTROL VACUUM DUMP RELEASE VALVES
CRUISE CONTROL VACUUM HOSES, TUBES AND RESERVOIRS
CRUISE CONTROL VEHICLE SPEED SENSORS
DEFOGGERS
DEFROSTERS
DELAYS
DIMMERS
ELECTRIC HEATERS
EQUALIZERS
FUSE BLOCKS
FUSE BOXES AND BLOCKS
FUSES, FUSIBLE LINKS AND CIRCUIT BREAKERS
FUSIBLE LINKS
GAUGES
GENERATORS
GROUND CABLES AND STRAPS
GROUND STRAPS
HEADLIGHT ADJUSTERS
HEATING ELEMENTS (DEFROSTERS, DEFOGGERS, ELECTRIC HEATERS AND SEATS)
HORNS AND SIRENS

Before any service is performed on a vehicle, an inspection
of the appropriate system must be performed. The results of this
inspection must be explained to the customer and documented on an
inspection form. The condition of the vehicle and its components will
indicate what services/part replacements may be "Required" or
"Suggested". In addition, suggestions may be made to satisfy the
requests expressed by the customer.
When a component is suggested or required to be repaired or
replaced, the decision to repair or replace must be made in the
customer's best interest, and at his or her choice given the options
available.
This section lists the various parts and conditions that
indicate a required or suggested service or part replacement. Although
this list is extensive, it is not fully inclusive. In addition to this
list, a technician may make a suggestion. However, any suggestions
must be based on substantial and informed experience, or the vehicle
manufacturer's recommended service interval and must be documented.
Some conditions indicate that service or part replacement is
required because the part in question is no longer providing the
function for which it is intended, does not meet a vehicle
manufacturer's design specification or is missing.
Example:
An exhaust pipe has corroded severely and has a hole
in it through which exhaust gases are leaking. Replacement of
the exhaust pipe in this case is required due to functional
failure.
Example:
A brake rotor has been worn to the point where it measures
less than the vehicle manufacturer's discard specifications.
Replacement of the rotor is required because it does not meet
design specifications.
Some conditions indicate that a service or part replacement
is suggested because the part is close to the end of its useful life
or addresses a customer's need, convenience or request. If a
customer's vehicle has one of these conditions, the procedure may be
only to suggest service.
Example:
An exhaust pipe is rusted, corroded or weak, but no leaks are
present. In this case, the exhaust pipe has not failed.
However, there is evidence that the pipe may need replacement
in the near future. Replacement of the pipe may be suggested
for the customer's convenience in avoiding a future problem.
Example:
The customer desires improved ride and/or handling, but the
vehicle's shocks or struts have not failed. In this case,
replacement may be suggested to satisfy the customer's
wishes. In this case, replacement of the shocks or struts may
not be sold as a requirement.
A customer, of course, has the choice of whether or not a
shop will service his or her vehicle. He or she may decide not to
follow some of your suggestions. When a repair is required, a MAP shop
must refuse partial service on that system if, in the judgment of the
service provider, proceeding with the work could create or continue an
unsafe condition. When a procedure states that required or suggested
repair or replacement is recommended, the customer must be informed of
the generally acceptable repair/replacement options whether or not
performed by the shop.

When presenting suggested repairs to the customer, you must
present the facts, allowing the customer to draw their own conclusions
and make an informed decision about how to proceed.
The following reasons may be used for required and suggested
services. These codes are shown in the "Code" column of the MAP
Uniform Inspection & Communications Standards that follow:
Reasons to Require Repair or Replacement
A - Part no longer performs intended purpose
B - Part does not meet a design specification (regardless of
performance)
C - Part is missing
NOTE: When a repair is required, the shop must refuse partial
service to the system in question, if the repair creates
or continues an unsafe condition.
Reasons to Suggest Repair or Replacement
1 - Part is close to the end of its useful life (just above
discard specifications, or weak; failure likely to occur
soon, etc.)
2 - To address a customer need, convenience, or request (to
stiffen ride, enhance performance, eliminate noise,
etc.)
3 - To comply with maintenance recommended by the vehicle's
Original Equipment Manufacturer (OEM)
4 - Technician's recommendation based on substantial and
informed experience
NOTE: Suggested services are always optional. When presenting
suggested repairs to the customer, you must present the
facts, allowing the customer to draw their own conclusions
and make an informed decision about how to proceed.
ELECTRICAL SYSTEMS
SERVICE PROCEDURES REQUIRED AND SUGGESTED FOR PROPER
VEHICLE OPERATION
NOTE: When working on electrical systems, if a potentially
hazardous condition is observed, require repair or
replacement of affected components prior to performing
further work.
ACTUATOR MOTORS (SOLENOIDS) (ELECTRIC)
ACTUATOR MOTOR (SOLENOIDS) (ELECTRIC) INSPECTION








\









\









\









\









\









\









\


Condition Code Procedure
Attaching hardware
broken ................. A ... Require repair or replacement
of hardware.
Attaching hardware
missing ................ C .......... Require replacement of
hardware.
Attaching hardware not
functioning ............ A ... Require repair or replacement
of hardware.
Connector broken ........ A .. Require repair or replacement.
Connector (Weatherpack
type) leaking .......... A .. Require repair or replacement.
