A/C SYSTEM PERFORMANCE PRESSURE SPECIFICATIONS (RAM PICKUP)








\









\









\









\









\









\









\







Ambient Temp. High Side Low SideF (C) psi (kg/cm) psi (kg/cm)
70 (21) .............. 135-145 (9.5-10.2) ........ 35-40 (2.5-2\
.8)
80 (27) .............. 175-215 (12.3-15.1) ....... 40-50 (2.8-3\
.5)
90 (32) .............. 215-270 (15.1-19.0) ....... 50-60 (3.5-4\
.2)
100 (38) ............. 270-330 (19.0-23.2) ....... 60-70 (4.2-4\
.9)
110 (43) ............. 340-370 (23.9-26.0) ....... 70-80 (4.9-5\
.6)
120 (49) ............. 400-430 (28.1-30.2) ....... 85-90 (6.0-6\
.3)









\









\









\









\









\









\









\







BLOWER MOTOR RELAY, HIGH SPEED BLOWER MOTOR RELAY &
COMPRESSOR CLUTCH RELAY
NOTE: Relays appear different, but testing procedures for blower
motor, high speed blower motor, and compressor clutch relays
are identical.
1) Front blower motor relay and compressor clutch relay are
located in Power Distribution Center (PDC). On Durango, high speed
blower motor relay is located in fuse/relay block under left side of
instrument panel.
2) Disconnect negative battery cable. Remove blower motor or
compressor clutch relay. Using an ohmmeter, check for continuity
between terminals No. 87A and 30 of relay. See Fig. 1 or 2. If
continuity does not exist, replace relay. If continuity exists, go to
next step.
3) Using an ohmmeter, check for continuity between terminals
No. 30 and 87 of relay. If continuity exists, replace relay. If
continuity does not exist, go to next step.
4) Measure resistance between terminals No. 85 and 86 of
relay. Reading should be 70-80 ohms. If reading is not as specified,
replace relay. If reading is as specified, go to next step.
5) Using jumper wires, connect battery voltage to terminal
No. 86 and ground terminal No. 85. See Fig. 1 or 2. Check that
continuity exists between terminals No. 30 and 87. Check that
continuity does not exist between terminals No. 87A and 30. If
continuity is not as specified, replace relay. If continuity is as
specified, relay is okay.
Fig. 1: Identifying Blower Motor Relay Terminals (Typical)
Courtesy of Chrysler Corp.

Fig. 2: Identifying Compressor Clutch Relay Terminals (Typical)
Courtesy of Chrysler Corp.
BLOWER MOTOR RESISTOR
1) Disconnect negative battery cable. Disconnect blower motor
resistor harness connector. Using an ohmmeter, check for continuity
between all 4 front blower motor resistor terminals, or 3 rear blower
motor resistor terminals. If continuity exists, go to next step. If
continuity does not exist, replace faulty blower motor resistor.
2) Check for open or short in circuits between blower motor
resistor and A/C-heater control panel. Also check for open or short in
wire between blower motor resistor and blower motor.
BLOWER MOTOR SWITCH
Front
1) Using a voltmeter, check underhood power distribution
center for battery voltage at fuse No. 5 (40-amp) on Dakota and
Durango, or fuse No. 5 (40-amp) on Ram Pickup. If battery voltage
exists, go to next step. If battery voltage does not exist, check for
open in Red wire between battery and underhood power distribution
center. If Red wire is okay, replace underhood power distribution
center.
2) Disconnect negative battery cable. Remove A/C-heater
control panel. See A/C-HEATER CONTROL PANEL R & I . Disconnect A/C-
heater control panel harness connector. Using an ohmmeter, check for
continuity between A/C-heater control panel harness connector terminal
No. 7 (Black wire on Dakota and Durango; Black/Orange on Ram Pickup)
and ground. If continuity exists, go to step 4).
3) If continuity does not exist, repair open in Black or
Black/Orange wire between A/C-heater control panel harness connector
terminal No. 7 and ground connector located at lower right corner of
instrument panel (Dakota and Durango) or behind center of instrument
panel (Ram Pickup).
4) Place mode control knob to any position except OFF. Using
an ohmmeter, check for continuity between A/C-heater control panel
connector terminal No. 7 and terminals No. 3, 4, 5, and 6 while
rotating blower motor switch. See Fig. 3.
5) If continuity does not exist at any terminal, replace
faulty A/C-heater control panel. If continuity exists as specified,
check for open in circuits between A/C-heater control panel and blower
motor resistor. Also check for an open in circuit between A/C-heater

controls to A/C. Start and operate engine at idle speed.
3) Using an ohmmeter, check for continuity between switch
terminals. Continuity should exist when suction pressure reading is
above 38 psi (2.7 kg/cm
) on Dakota; 43 psi (3.0 kg/cm) on Ram
Pickup. Continuity should not exist when suction pressure reading
drops below 20.5 psi (1.4 kg/cm
) on Dakota; 25 psi (1.8 kg/cm) on
Ram Pickup. If switch is okay, test and repair clutch control circuit
as needed. If switch is not okay, replace faulty clutch cycling
pressure switch.
ELECTRONIC CYCLING CLUTCH SWITCH
Durango
1) Locate electronic cycling clutch switch on thermal
expansion valve in engine compartment. Ensure system pressure is
correct. See A/C SYSTEM PERFORMANCE test. Ensure low pressure cut-out
switch and high pressure cut-out switch are working properly. See
LOW PRESSURE CUT-OUT SWITCH TEST and HIGH PRESSURE CUT-OUT SWITCH
test.
2) Disconnect negative battery cable. Disconnect electronic
cycling clutch switch and high pressure cut-out switch connectors.
Using an ohmmeter, check for continuity in Light Green/White wire
between electronic cycling clutch switch and high pressure cut-out
switch. If continuity exists in Light Green/White wire, go to next
step. If continuity does not exist in Light Green/White wire, repair
wire as necessary.
3) Disconnect low pressure cut-out switch connector. Using an
ohmmeter, check for continuity in Dark Blue/Yellow wire between
electronic cycling clutch switch and low pressure cut-out switch. If
continuity exists in Dark Blue/Yellow wire, go to next step. If
continuity does not exist in Dark Blue/Yellow wire, repair wire as
necessary.
4) Connect low pressure cut-out switch and high pressure cut-
out switch connectors. Connect negative battery cable. Turn ignition
on. Using voltmeter, check for battery voltage at electronic cycling
clutch switch connector terminal No. 2 (White wire). If battery
voltage exists, go to step 6).
5) If battery voltage does not exist, check fuse No. 7 (15-
amp) at junction block located at bottom left of instrument panel. If
fuse is okay, check for short or open in White wire between electronic
cycling clutch switch connector and fuse No. 7 (15-amp) at junction
block.
6) Connect electronic cycling clutch switch connector. Ensure
ambient temperature is between 68-90
F (20-30C). Start engine and
turn A/C on. If compressor clutch cycles 2-3 times per minute, replace
faulty electronic cycling clutch switch. If compressor clutch does not
cycle, check PCM for proper operation. See appropriate G - TESTS
W/CODES article in ENGINE PERFORMANCE section.
HIGH PRESSURE CUT-OUT SWITCH
1) Locate high pressure cut-out switch on compressor
discharge line, near compressor. Ensure system pressure is correct.
See A/C SYSTEM PERFORMANCE test. Disconnect negative battery cable.
Disconnect high pressure cut-off switch connector.
2) Using an ohmmeter, check for continuity between switch
terminals. If continuity exists, test and repair clutch control
circuit as needed. If continuity does not exist, replace faulty
switch.
LOW PRESSURE CUT-OUT SWITCH TEST
Durango
