RADIATOR FAN
WARNING: Keep hands away from radiator fan.
STARTING FLUID USE (TURBO DIESEL)
WARNING: DO NOT USE starting fluids (ether) or flammable liquids to
aid the starting of a Cummins Turbo-Diesel. NEVER pour diesel
fuel, flammable liquids or starting fluids into the air
cleaner canister, air intake or turbocharger housing in an
attempt to start the vehicle. A flash fire may result causing
personal injury.
TIRE CHAINS
CAUTION: Do NOT install tire chains or traction devices on front
wheels of 4x4 models with tires larger than P215/75R15. Do
NOT install tire chains or traction devices on rear wheels of
4x4 models with tires larger than P235/75R15. These tires are
too large for sufficient body clearance with chains or other
traction devices. Tire chains are not allowed on 4x2 vehicles
equipped with P235/70R15 tires or 4x4 vehicles equipped with
31 x 10.50R15 tires.
CAUTION: Do NOT drive for a prolonged period of time on dry pavement.
TURBOCHARGED MODELS (TURBO-DIESEL)
CAUTION: Do not race engine immediately after starting. When
stopping engine, allow engine to idle for approximately 60
seconds before shutting it off. Failure to do so may cause
turbocharger damage due to lack of oil flowing to
the turbocharger bearings.
WARRANTY INFORMATION
CAUTION: Due to the different warranties offered in various regions
and the variety of after-market extended warranties
available, please refer to the warranty package that came
with the vehicle to verify all warranty options.
FUSES & CIRCUIT BREAKERS

Fig. 19: Interior Fuse Panel
Courtesy of Chrysler Corp.
Fuse & Circuit Breaker Identification

Fig. 20: Underhood Power Distribution Center
Courtesy of Chrysler Corp.
WARNING: Always disconnect battery ground cable before servicing
"high-current fuses. It is recommended that "high-current"
fuses be replaced by a qualified technician.
Power Distribution Center Relay & Fuse Identification
A - Starter Relay
B - Trailer Lights Relay
C - Auto Transmission Relay
D - Anti-Lock Brake System Relay
E - Auto Shutdown Relay
F - Air Conditioning Clutch Relay
G - Horn Relay
H - Fuel System Relay
J - ABS Warning Light Relay
K - Fog Lamp 2 Relay
L - Fog Lamp 1 Relay
1 - 30 Amp (Pink)
Engine Control
2 - 40 Amp (Green)
Ignition Run/Accessory
3 - 40 Amp (Green)
Ignition Run
4 - 50 Amp (Red)
Instrument Panel, Horn, Parking Lights
5 - 20 Amp (Blue)
Fuel Pump
6 - 30 Amp (Pink)
Trailer Lights
7 - 40 Amp (Green)
Stop/Headlight
8 - 40 Amp (Green)
ABS Pump
9 - 20 Amp (Yellow)
Hazard Lights
10 - 20 Amp (Yellow)
Horn/AC
11 - 15 Amp (Blue)

meter long with force of one Newton applied). Some conversions are:
* A meter kilogram is about 7.2 foot pounds.
* A foot pound is about 1.4 Newton-meters.
* A centimeter kilogram (cmkg) is equal to .9 inch pounds.
PRESSURE
Pressure is another complicated measurement. Pressure is
described as a force or weight applied to a given area. Our common
unit is pounds per square inch. Metric units can be expressed in
several ways. One is the kilogram per square centimeter (kg/cm
).
Another unit of pressure is the Pascal (force of one Newton on an area
of one square meter), which equals about 4 ounces on a square yard.
Since this is a very small amount of pressure, we usually see the
kiloPascal, or kPa (1000 Pascals). Another common automotive term for
pressure is the bar (used by German manufacturers), which equals 10
Pascals. Thoroughly confused? Try the examples below:
* Atmospheric pressure at sea level is about 14.7 psi.
* Atmospheric pressure at sea level is about 1 bar.
* Atmospheric pressure at sea level is about 1 kg/cm
.
* One pound per square inch is about 7 kPa.
CONVERSION FACTORS
CONVERSION FACTORS
\
\
\
\
\
\
\

TO CONVERT TO  MULTIPLY BY
\b
\
\
\
\
\
 \
\



LENGTH


Millimeters (mm) Inches  .03937

Inches Millimeters  25.4

Meters (M) Feet  3.28084

Feet Meters  .3048

Kilometers(Km) Miles  .62137
\b
\
\
\
\
\
 \
\



AREA


Square Centimeters (cm) Square Inches  .155

Square Inches Square Centimeters  6.45159
\b
\
\
\
\
\
 \
\



VOLUME


Cubic Centimeters Cubic Inches  .06103

Cubic Inches Cubic Centimeters  16.38703

Liters Cubic Inches  61.025

Cubic Inches Liters  .01639

Liters Quarts  1.05672

Quarts Liters  .94633

Liters Pints  2.11344

Pints Liters  .47317

Liters Ounces  33.81497

Ounces Liters  .02957
\b
\
\
\
\
\
 \
\



WEIGHT


Grams Ounces  .03527

Ounces Grams  28.34953

Kilograms Pounds  2.20462

Pounds Kilograms  .45359
\b
\
\
\
\
\
 \
\



WORK


Centimeter Kilograms Inch Pounds  .8676

Pounds/Sq. Inch Kilograms/Sq.Centimeter .07031

Bar Pounds/Sq. Inch  14.504


MIR RO RS - P O W ER

1999 D odge P ic ku p R 1500
1999 ACCESSORIES & EQUIPMENT
CHRY - Power Mirrors
Caravan, Dakota, Durango, Ram Pickup, Ram Van, Ram Wagon,
Town & Country, & Voyager
DESCRIPTION
Outside power rear view mirrors consist of door-mounted
mirrors with internal motor drive and backing plate. On Caravan, Town
& Country, and Voyager, mirrors are controlled by a rocker switch for
left or right mirror selection and a platform button for up, down,
right and left movement. On Dakota, Durango, Ram Pickup, Ram Van and
Ram Wagon, mirrors are controlled by a single, multifunction,
joystick-type switch assembly. On all models, mirror motors are
integral with mirror assemblies and cannot be serviced separately. On
Dakota and Durango, fold-away rear view mirrors are optional.
Dakota, Durango and Ram Pickup are equipped with an automatic
dimming day/night inside mirror. The mirror uses 2 photocell sensors
to monitor ambient and rear facing light levels. The mirror
automatically adjusts its reflectance to reduce headlight glare from
vehicles approaching from the rear. The mirror is controlled by an
off/on switch located on the mirror bottom.
Caravan, Ram Pickup, Town & Country and Voyager have optional
heated outside mirrors. On Caravan, Town & Country and Voyager, heated
mirror is activated whenever the rear defogger is on. On Ram Pickup,
heated mirror is activated by switch in dash. A timer turns off mirror
heater after about 10 minutes.
COMPONENT TESTS
AUTOMATIC DAY/NIGHT INSIDE MIRROR
1) Turn ignition switch to ON position with transmission in
Neutral or Park. Place mirror switch in ON position (switch LED
illuminated). Cover forward facing sensor with a dark cloth or tape to
exclude any ambient light. See Fig. 1.
2) Shine a light into rear-facing sensor. Observe whether or
not mirror darkens. With mirror darkened, place transmission in
Reverse. Mirror should return to normal. If conditions of steps 1) and
2) are met, mirror is operating correctly. If conditions are not met,
go to next step.
3) Turn ignition on. Check for battery voltage at fuse No. 11
in junction block. If battery voltage exists on both sides of fuse, go
to next step. If battery voltage does not exist, repair circuit to
junction block. See WIRING DIAGRAMS. If fuse is blown, repair short
circuit and replace fuse.
4) Check for battery voltage at day/night mirror wire
connector terminal No. 1 (Dark Blue/White wire). If battery voltage
exists, go to next step. If battery voltage does not exist, repair
open circuit between mirror and junction block.
5) Check for continuity between ground and day/night mirror
wire connector terminal No. 2 (Black wire). If continuity exists, go
to next step. If continuity does not exist, repair open ground
circuit.
6) Check for battery voltage at day/night mirror wire
connector terminal No. 3 (Violet/Black wire) with transmission in
Reverse. If battery voltage exists, replace mirror. If battery voltage
does not exist, check back-up light circuit. See WIRING DIAGRAMS.

  Right  2 & 8; 5 & 8; 6 & 7











\









\









\









\









\









\









\





\f
Fig. 4: Identifying Power Mirror Motor Switch Connector Pins
(Dakota, Durango, Ram Pickup, Ram Van & Ram Wagon)
Courtesy of Chrysler Corp.

POWER MIRROR DEFOGGER
NOTE: On Caravan, Town & Country and Voyager, heated mirror is
controlled by rear window defogger switch. Heated mirror is
on whenever rear window defogger is on.
Caravan, Town & Country, & Voyager
1) Mirror should be warm to touch with rear window defogger
activated. If mirror is not warm to touch, check fuse No. 12 (10-amp)
in junction block. Repair short circuit and replace fuse as necessary.
Check for battery voltage at mirror harness connector Light
Blue/Yellow wire with rear window defogger switch on. If battery
voltage does not exist, repair wiring as necessary. See WIRING
DIAGRAMS. If battery voltage exists, go to next step.

2) Apply voltage to Light Blue/Yellow wire at heated mirror
and ground Black wire at heated mirror. Mirror should become warm to
touch. If mirror is not warm to touch, remove mirror and test wires
for continuity. If no continuity exists, repair wires. If wires are
okay, replace mirror. To test defogger switch, see appropriate wiring
diagram in REAR WINDOW DEFOGGERS article.
NOTE: On Ram Pickup, heated mirror is controlled by mirror defogger
switch.
Ram Pickup
1) Turn ignition on. While watching instrument panel
voltmeter, turn heated mirror switch on. Voltmeter needle should
deflect. With heated mirror on, mirror should be warm to touch after
3-4 minutes. If system operates as described, system is okay at this
time.
2) If system does not operate as described, go to next step.
Illuminated indicator light means only that voltage exists at heated
mirror relay.
3) Ensure ignition is on. Check fuses in Power Distribution
Center (PDC) and junction block. Ensure fuses are fully seated and
connections are secure. If mirrors are still inoperative, problem is
in heated mirror control, mirror heating grid and/or heated mirror
harness or connectors. If turning switch on causes a large deflection
in instrument panel voltmeter, check for a short circuit in system.
Repair as necessary.
REMOVAL & INSTALLATION
CAUTION: When battery is disconnected, vehicle computer and memory
systems may lose memory data. Driveability problems may exist
until computer systems have completed a relearn cycle. See
COMPUTER RELEARN PROCEDURES article in GENERAL INFORMATION
before disconnecting battery.
HEATED MIRROR SWITCH
Removal & Installation (Ram Pickup)
Heated mirror switch is part of HVAC control unit. See
appropriate AUTOMATIC A/C-HEATER SYSTEMS article in appropriate AIR
CONDITIONING & HEATING SERVICE & REPAIR section.
POWER MIRROR SWITCH
Removal & Installation (Caravan, Town & Country, & Voyager)
1) Remove cover from over steering column. Remove screws
holding instrument cluster bezel to dash (above cluster lens). Remove
screws holding instrument cluster bezel to dash from each side of
steering column. Disconnect clip holding instrument cluster bezel to
dash from above right vent louver.
2) Separate instrument cluster bezel from dash. Disconnect
wires from back of bezel. Disengage lock tabs above and below mirror
switch. Pull mirror switch from headlight switch bezel. To install,
reverse removal procedure.
Removal & Installation (Dakota & Durango)
1) Pull power mirror switch control knob rearward to remove
it from switch body. Remove nut securing switch to door trim panel.
Pull door latch handle to open position and remove screw securing trim
panel to door. Remove manual window crank handle, if equipped. Release
locking tab on power window/lock switch, if equipped. Remove power
window/lock switch and unplug connector.

PA R ASIT IC L O AD E XPLA N ATIO N & T E ST P R O CED URES

1999 D odge P ic ku p R 1500
GENERAL INFORMATION
Parasitic Load Explanation & Test Procedures
* PLEASE READ THIS FIRST *
This article is provided for general information only. Not
all procedures apply to all makes and models.
GENERAL INFORMATION
The term Parasitic Load refers to electrical devices that
continue to use or draw current after the ignition switch is turned to
OFF position. This small amount of continuous battery draw is
expressed in milliamps (mA). On Ford Motor Co. and General Motors
vehicles produced after 1980, a typical Parasitic Load should be no
more than 50 milliamps (0.050 amps).
Vehicles produced since 1980 have memory devices that draw
current with ignition off for as long as 20 minutes before shutting
down the Parasitic Drain. When Parasitic Load exceeds normal
specifications, the vehicle may exhibit dead battery and no-start
condition.
Follow test procedure for checking Parasitic Loads to
completion. A brief overview of a suggested test procedure is included
along with some typical Parasitic Load specifications. Refer to the
GENERAL MOTORS PARASITIC LOAD TABLE chart.
TESTING FOR PARASITIC LOAD
INTRODUCTION
CAUTION: Always turn ignition off when connecting or disconnecting
battery cables, battery chargers or jumper cables. DO NOT
turn test switch to OFF position (which causes current to run
through ammeter or vehicle electrical system).
NOTE: Memory functions of various accessories must be reset after
the battery is reconnected.
The battery circuit must be opened to connect test switch
(shunt) and ammeter into the circuit. When a battery cable is removed,\
timer circuits within the vehicle computer are interrupted and
immediately begin to discharge. If in doubt about the condition of the
ammeter fuse, test it with an ohmmeter prior to beginning test. An
open fuse will show the same reading (00.00) as no parasitic drain.
Begin test sequence with the meter installed and on the 10-amp scale.
Select lower scale to read parasitic draw.
TEST PROCEDURE USING TEST SWITCH
1) Turn ignition off. Remove negative battery terminal cable.
Install Disconnect Tool (J-38758) test switch male end to negative
battery cable. Turn test switch knob to OFF position (current through
meter). Install negative battery cable to the female end of test
switch.
2) Turn test switch knob to ON position (current through
switch). Road test vehicle with vehicle accessories on (radio, air
conditioner, etc.). After road test, turn ignition switch to LOCKED
position and remove key. Connect ammeter terminals to test switch
