9) Install pitching stopper.
Tightening torque:
T1: 49±5 N⋅m (5.0±0.5 kg-m, 36.2±3.6 ft-lb)
T2: 57±10 N⋅m (5.8±1.0 kg-m, 42±7 ft-lb)
G2M0325
10) Install front drive shafts into transmission.
(1) Lift-up the vehicle.
(2) Install front drive shaft into transmission.
(3) Drive spring pin into chamfered hole of drive shaft.
CAUTION:
Always use a new spring pin.
G2M0324
(4) Install ball joints of lower arm into knuckle arm of
housing, and tighten installing bolts.
Tightening torque:
49±10 N⋅m (5.0±1.0 kg-m, 36±7 ft-lb)
G2M0323
11) Install stabilizer clamps onto front crossmember.
Tightening torque:
25±4 N⋅m (2.5±0.4 kg-m, 18.1±2.9 ft-lb)
G3M0697
12) Install gear shift rod and stay. (MT model)
(1) Install gear shift rod onto transmission.
(2) Install stay onto transmission.
(3) Install spring.
41
2-11SERVICE PROCEDURE
3. Transmission

B2M0033A
13) Install shift selector cable onto selector lever. (AT
model)
(1) Install selector cable into selector lever.
(2) Install cable bracket onto body.
NOTE:
Tighten selector cable adjusting and lock nut after check-
ing selector lever operation.
G2M0317
14) Install ATF level gauge guide, and ATF cooler hoses
onto pipe. (AT model)
G3M0023
15) Install propeller shaft. (AWD model)
(1) Install propeller shaft into transmission.
(2) Tighten bolts which install propeller shaft onto com-
panion flange of rear differential.
Tightening torque:
31±8 N⋅m (3.2±0.8 kg-m, 23.1±5.8 ft-lb)
G3M0024
(3) Install center bearing bracket on body.
Tightening torque:
52±5 N⋅m (5.3±0.5 kg-m, 38.3±3.6 ft-lb)
G2M0830
16) Install exhaust system.
(1) Install heat shield cover. (AWD model)
42
2-11SERVICE PROCEDURE
3. Transmission

G2M0382
(2) Install rear exhaust pipe to muffler. (AWD model)
Tightening torque:
48±9 N⋅m (4.9±0.9 kg-m, 35.4±6.5 ft-lb)
B2M0032
(3) Install hanger bracket on right side of transmission.
(AWD model)
G2M0290
(4) Install front exhaust pipe onto engine.
Tightening torque:
30±5 N⋅m (3.1±0.5 kg-m, 22.4±3.6 ft-lb)
G2M0291
(5) Install center exhaust pipe to rear exhaust pipe.
Tightening torque:
18±5 N⋅m (1.8±0.5 kg-m, 13.0±3.6 ft-lb)
B2M0313
(6) Tighten bolt which installs center exhaust pipe to
hanger bracket.
Tightening torque:
30±5 N⋅m (3.1±0.5 kg-m, 22.4±3.6 ft-lb)
43
2-11SERVICE PROCEDURE
3. Transmission

B2M0335
(7) Connect connector to rear oxygen sensor.
B2M1300A
17) Install clutch damper. (Hydraulic clutch model)
Tightening torque:
25±7 N⋅m (2.5±0.7 kg-m, 18.1±5.1 ft-lb)
G2M0312
18) Install transmission connector holder bracket.
B2M0031
19) Install ATF level gauge. (AT model)
44
2-11SERVICE PROCEDURE
3. Transmission

20) Connect connectors and cables.
(1) Connect the following connectors.
Transmission harness connectors
Transmission ground terminal
Front oxygen sensor connector
Vehicle speed sensor 2
Neutral position switch connector (MT model)
Back-up light switch connector (MT model)
(2) Connect the following cables.
Cruise control cable
(With cruise control model)
Clutch cable
G2M0309
21) Install starter.
(1) Install starter onto transmission case, and connect
connectors and terminals.
(2) Tighten bolt and nut which install starter onto trans-
mission.
Tightening torque:
40±4 N⋅m (4.1±0.4 kg-m, 29.7±2.9 ft-lb)
B2M1170
22) Install air intake duct and chamber.
23) Connect battery ground cable.
24) Fill ATF. (AT model)

25) Check selector lever operation. (AT model)

26) Take off vehicle from lift arms.
27) Check the vehicle on road tester. (AT model)

45
2-11SERVICE PROCEDURE
3. Transmission

5. SHIFTER FORK AND ROD
Select suitable shifter forks so that both coupling sleeve and
reverse driven gear are positioned in the center of their synchro-
mesh mechanisms.
1st-2nd shifter fork
Part No. Mark Remarks
32804AA060 1Approach to 1st gear by
0.2 mm (0.008 in)
32804AA070 No mark Standard
32804AA080 3Approach to 2nd gear by
0.2 mm (0.008 in)
3rd-4th shifter fork
Part No. Mark Remarks
32810AA060 1Approach to 4th gear by
0.2 mm (0.008 in)
32810AA070 No mark Standard
32810AA100 3Approach to 3rd gear by
0.2 mm (0.008 in)
5th shifter fork
Part No. Mark Remarks
32812AA200 4Approach to 5th gear by
0.2 mm (0.008 in)
32812AA210 No mark Standard
32812AA220 6Become distant from 5th
gear by 0.2 mm (0.008 in)
Rod end clearance
A: 1st-2nd—3rd-4th
0.5—1.5 mm (0.020—0.059 in)
B: 3rd-4th—5th
0.6—1.4 mm (0.024—0.055 in)
6. TRANSMISSION CASE ASSEMBLY
Drive pinion shim adjustment
Drive pinion shim
Part No.Thickness
mm (in)Part No.Thickness
mm (in)
32295AA0310.150
(0.0059)32295AA0710.250
(0.0098)
32295AA0410.175
(0.0069)32295AA0810.275
(0.0108)
32295AA0510.200
(0.0079)32295AA0910.300
(0.0118)
32295AA0610.225
(0.0089)32295AA1010.500
(0.0197)
Hypoid gear backlash
0.13—0.18 mm (0.0051—0.0071 in)Selection of main shaft rear plate
Main shaft rear plate
Dimension“A”mm (in) Part No. Mark
4.00—4.13 (0.1575—0.1626) 32294AA041 1
3.87—3.99 (0.1524—0.1571) 32294AA051 2
7. DRIVE PINION ASSEMBLY
Preload adjustment of thrust bearing
Starting torque
0.3—0.8 N⋅m(3—8 kg-cm, 2.6—6.9 in-lb)
Adjusting washer No. 1
Part No. Thickness mm (in)
803025051 3.925 (0.1545)
803025052 3.950 (0.1555)
803025053 3.975 (0.1565)
803025054 4.000 (0.1575)
803025055 4.025 (0.1585)
803025056 4.050 (0.1594)
803025057 4.075 (0.1604)
Adjusting washer No. 2
Part No. Thickness mm (in)
803025059 3.850 (0.1516)
803025054 4.000 (0.1575)
803025058 4.150 (0.1634)
Assemble a driven shaft and 1st driven gear that are selected for
the proper radial clearance adjustment.
Driven shaft 1st driven gear
Part No.Diameter A
mm (in)Part No.
32229AA15049.959—49.966
(1.9669—
1.9672)32231AA290
32229AA14049.967—49.975
(1.9672—
1.9675)32231AA280
8. DRIVE PINION ASSEMBLY (FWD Model)
Selection of 1st driven gear:
1st driven gear
Outer diameter of bushing mm (in) Part No.
41.983—41.996 (1.6529—1.6534) 32231AA320
41.968—41.982 (1.6523—1.6528) 32231AA330
41.954—41.967 (1.6517—1.6522) 32231AA340
4
3-1SPECIFICATIONS AND SERVICE DATA
1. Manual Transmission and Differential

1. Transfer Case and Extension (AWD
Model)
B3M0326A

1Transfer cover


2Cover gasket


3Oil seal


4Gasket


5Neutral switch


6Back-up light switch


7Transfer case


8Gasket


9Oil guide


10Ball


11Reverse accent spring


12Gasket


13Plug


14Snap ring (Inner)


15Reverse check plate

16Reverse check spring


17Reverse return spring


18Reverse check cam


19Reverse accent shaft


20O-ring


21Adjusting select shim


22Reverse check sleeve


23Adjusting washer


24Ball bearing


25Transfer driven gear


26Ball bearing


27Oil seal


28Shift bracket


29Extension cover


30Gasket

31Snap ring (Outer-30)


32Gasket


33Ball bearing


34Snap ring (Inner-72)


35Transfer drive gear


36Extension
Tightening torque: N⋅m (kg-m, ft-lb)
T1: 5±1 (0.5±0.1, 3.6±0.7)
T2: 10±1 (1.0±0.1, 7.2±0.7)
T3: 15.7±1.5
(1.6±0.15, 11.6±1.1)
T4: 25±2 (2.5±0.2, 18.1±1.4)
T5: 37±3 (3.8±0.3, 27.5±2.2)
6
3-1COMPONENT PARTS
1. Transfer Case and Extension (AWD Model)

2. Rear Case (FWD Model)
G3M0265

1Rear case


2Case gasket


3Back-up light switch


4Neutral switch


5Reverse check sleeve ASSY


6Gasket


7Adjusting shim

8O-ring


9Oil seal
Tightening torque: N⋅m (kg-m, ft-lb)
T1: 6.4±0.5 (0.65±0.05, 4.7±0.4)
T2: 25±2 (2.5±0.2, 18.1±1.4)
7
3-1COMPONENT PARTS
2. Rear Case (FWD Model)
