1997 FORD AEROSTAR Owners Manual

30 [AS02650(ALL)04/96]NOTE: Once a disc is inserted, the disc
opening is secured to prevent the
accidental insertion of a second disc.
*
[AS02675(ALL)10/95]
NOTE: The CD player has heat protection
circuitry to protect the laser diode. If
the temperature of the player reaches
167ÊF (75ÊC), theheat detection circuit
will shut off the player and ªTOO
HOTº will scroll in the display for
approximately five seconds (radio will
resume playing). When the temperature
returns to normal operating range, the
CD player will again be operational.
*
[AS02700(ALL)10/95]
How to stop and restart the CD player
*
[AS02725(ALL)04/96]
When a disc is loaded, the unit automatically
enters the play mode and the play indicator (
a)
illuminates. To stop temporarily, press the
ªPLAY/STOPº button or the ªAM/FMº button.
The stop indicator (
X) in the display illuminates
and operation returns to the radio mode. To
resume CD play, press the ªPLAY/STOPº
button once again.
*
[AS02750(ALL)10/95]
NOTE: If the ignition key is turned OFF
during play and then is set to the ON
or ACCESSORY position, the CD
player will resume playing in the mode
it was in when ignition was turned off.
*
[AS02775(ALL)08/95]
Using the ªSEEKº feature
*
[AS02800(ALL)05/96]
The ªSEEKº feature allows you to quickly find a
particular selection on the disc.
*
[AS02825(ALL)08/95]
Press the bottom (
b) half of the ªSEEKº button
once to repeat the current playing selection.
Press the top (
a) half of the ªSEEKº button to
advance to the next selection.
File:04cpasa.ex
Update:Fri Jun 7 14:24:14 1996

31
*
[AS02850(ALL)08/95]
Pressing and holding the bottom (
b) or top (
a)
half of the ªSEEKº button will scroll backward
and forward respectively through the tracks.
*
[AS02875(ALL)05/96]
How to fast forward or reverse your CD
player
*
[AS02900(ALL)10/95]
To quickly search for a particular point in a
selection, press the ªFFº button (to fast forward)
or the ªREVº button (to reverse). While either
button is pressed, the disc goes forward or
backward at two different speeds depending on
how long the button is held down. (Pressing
either button for more than three seconds will
speed up the process.) Release the button at the
desired point (found by watching the elapsed
playing time in the display or by listening to the
sound during fast forward or reverse). When
you have reached the beginning of track 1, the
CD player will begin playing.
*
[AS02925(ALL)10/95]
When you have reached the end of the disc by
keeping the fast forward button pressed, the
display will show ªENDº and the player will go
into pause mode. Push the ªPLAY/STOPº
button to begin playing the first track of the
disc, press the ªREVº button to back up from
the end of the disc, or use the ªSEEKº function
to locate a desired track.
*
[AS02950(ALL)10/95]
Using the ªSCANº function
*
[AS02975(ALL)08/95]
Press the ªSCAN/TUNEº button to enter the
scan mode. Once in the scan mode, press the top
(
a) or bottom (
b) half of the ªSEEKº button to
scan forward or reverse, respectively. The CD
player will begin scanning the disc, stopping on
each listenable track for approximately eight
seconds. This continues until you press the
ªSCAN/TUNEº button a second time. While in
the scan mode, the display shows the current
sampled track number.
File:04cpasa.ex
Update:Fri Jun 7 14:24:14 1996

32
*
[AS03000(ALL)10/95]
Special features of your CD player
*
[AS03025(ALL)10/95]
q
Compression
*
[AS03050(ALL)10/95]
The compression feature will bring soft and
loud passages closer together for a more
consistent listening level.
*
[AS03075(ALL)10/95]
To turn the compression on, press the
ªCOMPº button. When on, the compression
indicator (ªCº) will appear in the display.
Press the button again to turn off.
*
[AS03100(ALL)10/95]
q
Automatic Disc Storage
*
[AS03125(ALL)10/95]
If the disc is ejected from the CD player but
is not removed from the disc opening within
approximately 10 seconds, the player will
automatically reload the disc for storage,
unless the disc is automatically ejected due to
a ªfocus errorº (disc inserted upside down).
In this case, the disc will not be automatically
reloaded.
*
[AS03150(ALL)04/96]
How to eject the disc
*
[AS03175(ALL)10/95]
Push the ªEJECTº button to stop play, eject the
disc and resume radio operation of your audio
system.
*
[AS03200(ALL)10/95]
NOTE: You can eject the disc while the radio
power and/or ignition is on or off.
%*
[AS03225(ALL)08/95]
How To Take Care of and Clean Your CD
Player and Discs
*
[AS03250(ALL)08/95]
To ensure the continued performance of your
Ford Compact Disc Player, carefully read the
following precautions:
*
[AS03275(ALL)04/96]
q
Always handle the disc by its edge. Never
touch the playing surface.
File:04cpasa.ex
Update:Fri Jun 7 14:24:14 1996

33
*
[AS03281(ALL)08/95]
q
Before playing, inspect the disc for any
contamination. If needed, clean the disc with
an approved disc cleaner, such as the
DiscwasherHCompact Disc Cleaner or the
Allsop 3HCompact Disc Cleaner, by wiping
from the center out to the edges.Do not use
a circular motion to clean.
*
[AS03286(ALL)04/96]
q
Do not clean discs with solvents such as
benzine, thinner, commercially available
cleaners or antistatic spray intended for
analog records.
*
[AS03291(ALL)04/96]
q
Do not expose the disc to direct sunlight or
heat sources such as defroster and floor
heating ducts. Do not leave any discs in a
parked car in direct sunlight where there may
be a considerable rise in temperature or
damage may result.
*
[AS03296(ALL)04/96]
q
After playing, store the disc in its case.
*
[AS03300(ALL)04/96]
q
If a disc has already been inserted, do not try
to insert another disc. Doing so may damage
the disc player.
*
[AS03325(ALL)04/96]
q
Do not insert anything other than a disc into
the disc player.
*
[AS03350(ALL)04/96]
NOTE: The use of optical instruments with
this product will increase eye hazard as
the laser beam used in this compact
disc player is harmful to the eyes. Do
not attempt to disassemble the case.
Refer servicing to qualified personnel
only.
File:04cpasa.ex
Update:Fri Jun 7 14:24:14 1996

34
*
[AS03375(ALL)08/95]
Common Operating Conditions of Your
CD Player
*
[AS03400(ALL)04/96]
The following information is designed to help
you recognize typical situations that could be
mistakenly interpreted as mechanical
malfunctions of the disc player.
*
[AS03425(ALL)04/96]
q
A disc is already loaded.
*
[AS03450(ALL)04/96]
q
The disc is inserted with the label surface
downward.
*
[AS03475(ALL)04/96]
q
The disc is dusty or defective.
*
[AS03500(ALL)08/95]
q
The player's internal temperature is above
140ÊF (60ÊC).Allow the player to cool off
before operating.
*
[AS03525(ALL)08/95]
q
Different manufacturers of compact discs may
produce discs with different dimensions or
tolerances, some of which may not be within
industry standards or in accordance with the
CD format. Because of this, a new disc that is
free of dust and scratches could be defective
and may not play on your Ford Compact
Disc Player.
[AS03550(ALL)09/95]
If play does not begin once the disc has been
inserted:
*
[AS03575(ALL)04/96]
q
The radio is not on.
*
[AS03600(ALL)04/96]
q
The unit is in the stop mode.
*
[AS03625(ALL)04/96]
q
Moisture may have condensed on the lenses
within the unit. If this occurs, remove the
disc and wait approximately an hour until the
moisture evaporates.
*
[AS03650(ALL)04/96]
If the sound skips:
*
[AS03675(ALL)04/96]
q
Badly scratched discs or extremely rough
roads will cause the sound to skip. Skipping
will not damage the disc player or scratch the
discs.
File:04cpasa.ex
Update:Fri Jun 7 14:24:14 1996

35
%*
[AS03700(ALL)08/95]
High-Level Audio System
[AS03725(ALL)04/96]
full page art:0060631-B
High-Level Audio System
File:04cpasa.ex
Update:Fri Jun 7 14:24:14 1996

36
*
[AS03750(ALL)03/96]
Using the Controls on Your New Radio
*
[AS03775(ALL)03/96]
How to turn the radio on and off
*
[AS03800(ALL)10/95]
Press the ªPOWERº button to turn the radio on.
Press it again to turn it off.
*
[AS03825(ALL)03/96]
How to adjust the volume
*
[AS03850(ALL)03/96]
Press the (R/S) side of the ªVOLº button to
increase/decrease the volume. Bars illuminate in
the display to show the relative volume level.
*
[AS03875(ALL)02/96]
NOTE: If the volume level is set above a
certain listening level when the
ignition switch is turned off, when the
ignition switch is turned back on, the
volume will come back to a ªnominalº
listening level. However, if the radio
power is turned off, the volume will
remain in the position it was set at
when radio power was switched off.
*
[AS03900(ALL)03/96]
Selecting the AM or FM frequency band
*
[AS03925(ALL)08/95]
Push the ªAM/FMº button to select the desired
frequency band. When in the radio mode,
pushing the button more than once will alternate
between AM, FM1 and FM2. These functions are
used with the station memory buttons described
underHow to Tune Radio Stations.
File:04cpasa.ex
Update:Fri Jun 7 14:24:14 1996

37 %
*
[AS03950(ALL)03/96]
How to tune radio stations
*
[AS03975(ALL)10/95]
There are four ways for you to tune in a
particular station. You can manually locate the
station using the ªSCAN/TUNEº button,
ªSEEKº the station, ªSCANº to the station or
select the station by using the memory buttons,
which you can set to any desired frequency.
These four methods are described below.
*
[AS04000(ALL)09/95]
q
Using the ªTUNEº function (Stereo Radio)
*
[AS04025(ALL)03/96]
You can change the frequency up or down
one increment at a time (FM changes in
increments of 200 kHz; AM changes in
increments of 10 kHz) by first pressing the
ªSCAN/TUNEº button twice (display shows
ªTUNEº), then Ðwithin approximately five
secondsÐpressing and releasing either the
right
aor left
bside of the ªSEEKº button.
To change frequencies quickly, press and
hold downeither the right or left side of the
ªSEEKº button.
*
[AS04050(ALL)03/96]
Manual tuning adjusts your radio to any
allowable broadcast frequency, whether or
not a station is present on that frequency.
(SeeAll About Radio Frequenciesin this
section.)
*
[AS04075(ALL)04/96]
q
Using the ªSEEKº function
[AS04100(ALL)05/96]
This feature on your radio allows you to
automatically select listenable stations up or
down the frequency band. Press the right
(
a) side of the ªSEEKº button to select the
next listenable station up the frequency band.
Press the left (
b) side of the button to select
the next listenable station down the
frequency band. By holding the button down,
listenable stations can be passed over to reach
the desired station.
File:04cpasa.ex
Update:Fri Jun 7 14:24:14 1996
