3. Pull the belt out of its holder as far as it will
go and untwist the belt or remove the object
that is jamming the belt. Let the belt retract.
*
[SS09985(ALL)01/96]
4. Then, pull the belt out and let it retract
several times to make sure that the belt
works properly.
[SS10000(ALL)01/96]
For Twisted Rear Outboard Combination
Lap and Shoulder Safety Belts Ð
Detachable Anchor
[SS10020(ALL)01/96]
Disengage the detachable anchor tongue from
the detachable anchor, remove the twist and
re-install the detachable anchor tongue end into
the detachable anchor until you hear a snap and
feel the latch engage.
[SS10040(ALL)04/96]
Procedure to Correct a Twisted Safety Belt
at the ªDº Ring (if so equipped) Front
and/or Rear Outboard Seating Positions
[SS10060(ALL)04/96]
NOTE: The restraint system shown in the
following figures may be different than
the restraint system in your vehicle.
However, use these figures and this
procedure to correct a twisted safety
belt at any outboard seating position
that has a ªDº ring.
File:06cpssa.ex
Update:Thu Jun 13 08:56:07 1996

120 [SS10080(ALL)04/96]
half page art:0060598-C
*
[SS10100(ALL)01/96]
1. Grasp the belt webbing at the ªDº ring. See
Figure 2.
File:06cpssa.ex
Update:Thu Jun 13 08:56:07 1996

121 [SS10120(ALL)04/96]
half page art:0060599-D
*
[SS10140(ALL)01/96]
2. Rotate and fold the belt webbing over itself
as required to remove the twist.
*
[SS10160(ALL)01/96]
3. Feed the folded portion of the belt through
the ªDº ring.
*
[SS10180(ALL)01/96]
4. When completed, the safety belt should look
like Figure 3.
File:06cpssa.ex
Update:Thu Jun 13 08:56:07 1996

122 [SS10200(ALL)04/96]
half page art:0060600-D
%*
[SS10300(ALL)05/96]
Air Bag Supplemental Restraint
System (SRS)
*
[SS10600(ALL)05/96]
Important Air Bag Precautions
*
[SS10700(ALL)05/96]
Your vehicle is equipped with a supplemental
restraint system designed to work with the
safety belts to help protect you and your right
front seat passenger in the event of certain
collisions described in the sectionªHow Does
the Air Bag Supplemental Restraint System
Work?º
*
[SS10800(ALL)05/96]
RWARNING
All occupants of the vehicle, including the
driver, should always wear their safety
belts, failure to do so may increase the
risk of personal injury in the event of a
collision.
File:06cpssa.ex
Update:Thu Jun 13 08:56:07 1996

123
*
[SS10900(ALL)05/96]
RWARNING
Do not place objects or mount equipment
on or near the steering wheel or in front
of the passenger dashboard area that may
come into contact with an inflating air
bag. Failure to follow these instructions
may increase the risk of personal injury in
the event of a collision.
*
[SS10950(ALL)05/96]
RWARNING
Do not attempt to service, repair, or
modify the air bag Supplemental Restraint
System or its fuses. See your Ford or
Lincoln-Mercury dealer.
*
[SS11000(ALL)05/96]
RWARNING
If you are close to an inflating air bag, it
could seriously injure you. Sit against the
seatback and position your seat such that
it is as far back from the steering wheel
as possible but still allows you to
properly control the vehicle.
File:06cpssa.ex
Update:Thu Jun 13 08:56:07 1996

124 [SS11100(ALL)05/96]
half page art:0020842-D
*
[SS11300(ALL)05/96]
Children and Air Bags
[SS11400(ALL)06/96]
Children should be placed in the rear in an
appropriate child safety seat that is properly
secured to the vehicle.
*
[SS11500(ALL)05/96]
RWARNING
Children should always wear their safety
belts. Failure to follow these instructions
may increase the risk of personal injury in
the event of a collision.
*
[SS11600(ALL)05/96]
RWARNING
Rear-facing child seats and infant carriers
should never be placed in the front seats.
File:06cpssa.ex
Update:Thu Jun 13 08:56:07 1996

125
*
[SS11650(ALL)05/96]
NOTE: For additional important safety
information on the proper use of seat
belts, child seats, and infant seats,
please read the entire Safety Restraints
chapter in this owner guide.
%*
[SS11700(ALL)05/96]
How Does the Air Bag Supplemental
Restraint System Work?
*
[SS11800(ALL)05/96]
The Air Bag Supplemental Restraint System is
designed to activate when the vehicle sustains
sufficient longitudinal (lengthwise) deceleration
that is equal to or greater than hitting an
immovable barrier head on at a range of about
8-14 mph (13-23 km/h). The fact that the air
bags did not inflate in a collision does not mean
that something is wrong with the system.
Rather, it means the forces were not of the type
sufficient to cause activation.
*
[SS11900(ALL)05/96]
If the vehicle is in a moderate or severe frontal
collision, the system is activated and the air bags
inflate rapidly. After the air bag inflates, it will
quickly deflate. After the air bag deployment,
you may notice a smoke-like, powdery residue
or smell the burnt propellant. This is normal.
The residue may consist of cornstarch or talcum
powder (which is used to lubricate the air bag)
or sodium compounds, such as sodium
carbonates (e.g. baking soda) that result from the
combustion process that inflates the air bag.
Small amounts of sodium hydroxide may be
present which may irritate the skin and eyes, but
none of the residue is toxic. The Air Bag
Supplemental Restraint System will reduce, but
not eliminate all injuries in an accident.
*
[SS12000(ALL)05/96]
RWARNING
Several air bag system components get hot
after inflation. Do not try to touch them
after inflation.
File:06cpssa.ex
Update:Thu Jun 13 08:56:07 1996

126 [SS12100(ALL)05/96]
half page art:0011063-A
*
[SS12200(ALL)05/96]
RWARNING
The air bag will inflate only once. The
system is designed to function on a
one-time-only basis. If the air bag is
inflated, THE AIR BAG WILL NOT
FUNCTION AGAIN AND MUST BE
REPLACED IMMEDIATELY. If the air
bag is not replaced, this will increase the
risk of injury in a subsequent collision.
*
[SS12300(ALL)05/96]
The Air Bag Supplemental Restraint System
consists of:
*
[SS12400(ALL)05/96]
q
driver and passenger air bag modules (which
include the inflators and air bags),
*
[SS12500(ALL)05/96]
q
one or more impact and safing sensors,
*
[SS12600(ALL)05/96]
q
a system diagnostic module,
*
[SS12650(ALL)05/96]
q
a readiness light and tone,
