1997 FORD AEROSTAR Owners Manual

201 [ER00418(ALL)05/96]
thirty-six pica chart:0020388-M
File:10cpera.ex
Update:Thu Jun 6 14:45:00 1996

202 [ER00420(ALL)01/96]
fourteen pica chart:0095064-A
File:10cpera.ex
Update:Thu Jun 6 14:45:00 1996

203 [ER00425(ALL)01/96]
full page art:0020516-I
Fuses and their location (under instrument panel on
driver's side)
File:10cpera.ex
Update:Thu Jun 6 14:45:00 1996

204 [ER00430(ALL)05/96]
thirty-two pica chart:0095066-B
File:10cpera.ex
Update:Thu Jun 6 14:45:00 1996

205 [ER00435(ALL)05/96]
thirty-six pica chart:0095067-B
File:10cpera.ex
Update:Thu Jun 6 14:45:00 1996

206 [ER00440(ALL)05/96]
ten pica chart:0095068-B
File:10cpera.ex
Update:Thu Jun 6 14:45:00 1996

207 [ER00445(ALL)05/96]
thirty-six pica chart:0095065-B
File:10cpera.ex
Update:Thu Jun 6 14:45:00 1996

208
*
[ER00450(ALL)01/96]
To remove and replace a fuse, use the fuse
puller provided.
[ER00455(ALL)01/96]
quarter page art:0030248-B
The side view of a fuse
*
[ER00460(ALL)01/96]
RWARNING
Always replace a fuse with one that has
the specified amperage rating. Using a
fuse with a higher amperage rating can
cause severe wire damage and could start
a fire.
[ER00470(ALL)01/96]
Access to the trailer tow fuse is through the rear
most storage compartment in the side trim
panel. This is on the left for all Aerostar models.
[ER00475(ALL)01/96]
1. Remove the screws located inside the
compartment and take off the access hole
cover.
[ER00480(ALL)01/96]
2. Reach in through access hole to remove
fuses. The fuses are located on the side of
the bracket assembly.
[ER00485(ALL)01/96]
3. Replace fuses with standard push-in fuses
(plug type).
[ER00490(ALL)01/96]
4. Reinstall compartment back and screw into
place.
*
[ER00500(ALL)04/96]
Even after you replace a fuse, it may continue to
blow if you do not find what caused the
overload. If the fuse continues to blow, have
your electrical system checked.
