1996 NISSAN PATHFINDER Owners Manual

ENGINE OIL AND OIL FILTER
RECOMMENDATION
Selecting the correct oil
It is essential to chose the correct quality, and
viscosity oil to ensure satisfactory engine life
and performance. Nissan recommends the
use of a low friction oil (energy conserving oil)
in order to improve fuel economy and con-
serve energy. Oils which do not have the
specified quality label should not be used as
they could cause engine damage.
Only those engine oils with the American Pe-
troleum Institute (API) CERTIFICATIONMARK on the front of the container should be
used. This type of oil supersedes the existing
API SG or SH and Energy Conserving II
categories.
If you cannot find engine oil with the CERTI-
FICATION MARK, an API SG or SH and
Energy Conserving II oil with API Service
Symbol may be used. An oil with a single
designation ªSGº or ªSHº, or in combination
with other categories (for example, ªSG/CCº or
ªSG/CDº) may also be used if one with the API
CERTIFICATION MARK cannot be found.
Mineral based or synthetic type oils may be
used in your NISSAN vehicle. These oils musthowever, meet the API quality and SAE vis-
cosity ratings specified for your vehicle. Do not
mix mineral based and synthetic type oils in
the engine at the same time.
Oil additives
NISSAN does not recommend the use of oil
additives. The use of an oil additive is not
necessary when the proper oil type is used
and maintenance intervals are followed.
Oil which may contain foreign matter or has
been previously used should not be used.
Oil viscosity
The engine oil viscosity or thickness changes
with temperature. Because of this, it is impor-
tant that the engine oil viscosity be selected
based on the temperatures at which the ve-
hicle will be operated before the next oil
change. The chart ªRecommended SAE vis-
cosity numberº shows the recommended oil
viscosities for the expected ambient tempera-
tures. Choosing an oil viscosity other than that
recommended could cause serious engine
damage.STI0077
9-6
Z01.2.1/R50-DX

Selecting the correct oil filter
Your new vehicle is equipped with a high-
quality genuine Nissan oil filter. When replac-
ing, use the genuine oil filter or its equivalent
for the reason described in ªchange intervalsº.
Change intervals
The oil and oil filter change intervals for your
engine are based on the use of the specified
quality oils and filters. Oil and filter other than
the specified quality, or oil and filter change
intervals longer than recommended could re-
duce engine life. Damage to engines caused
by improper maintenance or use of incorrect
oil and filter quality and/or viscosity is not
covered by the new Nissan vehicle warranties.
Your engine was filled with a high quality
engine oil when it was built. You do not have to
change the oil before the first recommended
change interval. Oil and filter change intervals
depend upon how you use your vehicle. Op-
eration under the following conditions may
require more frequent oil and filter changes.
Ð repeated short distance driving at cold out-
side temperatures,
Ð driving in dusty conditions,
Ð extensive idling,Ð towing a trailer.
9-7
Z01.2.1/R50-DX

RECOMMENDED SAE VISCOSITY
NUMBERISAE 5W-30 viscosity oil is preferred for
all ambient temperatures. SAE 10W-30
viscosity oil may be used if the ambient
temperature is above 0ÉF (þ18ÉC).
I75W-90 for transmission and 80W-90 for
differential are preferable if the ambient
temperature is below 104ÉF (40ÉC).
TI0008-ATI0003
9-8
Z01.2.1/R50-DX

AIR CONDITIONING SYSTEM
REFRIGERANT AND LUBRICANT
RECOMMENDATIONS
The air conditioning system in this NISSAN
vehicle must be charged with the refriger-
ant HFC-134a (R-134a) and the lubricant,
Nissan A/C System Oil Type S or the exact
equivalents.Use of any other refrigerants or
lubricants will cause severe damage and you
will need to replace your vehicle's entire air
conditioning system.
The new refrigerant HFC-134a (R-134a) in
your NISSAN vehicle will not harm the earth's
ozone layer. Although this refrigerant does not
affect the earth's atmosphere, certain govern-
mental regulations require the recovery and
recycling of any refrigerant during automotive
air conditioning system service. Your NISSAN
dealer has the trained technicians and equip-
ment needed to recover and recycle your air
conditioning system refrigerant.
Contact your NISSAN dealer when servicing
your air conditioning system.
9-9
Z01.2.1/R50-DX

Model VG33E
Type Gasoline, 4-cycle
Cylinder arrangement 6-cylinder, V-slanted at 60É
Bore´Stroke in (mm) 3.602´3.268 (91.5´83.0)
Displacement
cu in (cm
3)199.84 (3,275)
Firing order 1-2-3-4-5-6*1
Idle speed rpm
See the ªEmission Control
Labelº on the underside of the
hood. Ignition timing (BTDC)
degree/rpm
CO percentage at idle speed
[No air] %
Spark plug BKR4ES-11 (Hot)
BKR5ES-11 (Standard)
BKR6ES-11 (Cold)
Spark plug gap in (mm) 0.039 to 0.043 (1.0 to 1.1)
Camshaft operation Timing belt*2
Alternator belt size
Width´Length
in (mm)0.8409´41.93 (21.36´1,065)
*2: Periodic maintenance is necessary. Refer to the appropriate maintenance
schedule in chapter 8.
The spark ignition system of this vehicle meets all requirements of
the Canadian Interference-Causing Equipment Regulations.
TI0001-A
ENGINE
9-10
Z01.2.1/R50-DX

FOR U.S.A.
Grade Road wheel/
offset in (mm)Tire Spare tire size
4x2 PATH-
FINDERXE
LE15x6-1/2JJ/1.97
(50)
15x6-1/2JJ
Aluminum/1.97
(50)P235/75R15
102SP235/75R15
102S
4x4 PATH-
FINDERXE
LE15x6-1/2JJ/1.97
(50)
15x6-1/2JJ
Aluminum/1.97
(50)P235/75R15
102SP235/75R15
102S
SE 15x7JJ/1.57 (40)
15x7JJ
Aluminum/1.57
(40)P265/70R15
110SP265/70R15
110S
FOR CANADA
Grade Road
wheel/offset in
(mm)Tire Spare tire size
4x4 PATH-
FINDERXE
LE15x6-1/2JJ/1.97
(50)
15x6-1/2JJ
Aluminum/1.97
(50)P235/75R15
102SP235/75R15
102S
SE 15x7JJ/1.57 (40)
15x7JJ
Aluminum/1.57
(40)P265/70R15
110SP265/70R15
110S
WHEELS & TIRES
9-11
Z01.2.1/R50-DX

Unit: in (mm)
PATHFINDER
Overall length*1 178.3 (4,530)
Overall width 68.7 (1,745)
72.4 (1,840)*2*3
Overall height 67.1 (1,705)
67.9 (1,725)*2
Front tread 58.3 (1,480)
59.1 (1,500)*2
Rear tread 58.5 (1,485)
59.3 (1,505)*2
Wheelbase 106.3 (2,700)
Gross vehicle weight rating
lb (kg)See the ªF.M.V.S.S. certification
labelº on the driver's side lock
pillar.
Gross axle weight rating
Front lb (kg)
Rear lb (kg)
*1: On spare tire carrier equipped models, the spare tire carrier adds 9.45 in (240
mm) to the overall length.
*2: SE models
*3: XE models with overfender
When planning to travel in another country,
you should first find out if the fuel available is
suitable for your vehicle's engine.
Using fuel with too low an octane rating
may cause engine damage. All gasoline
vehicles can be operated with unleaded
gasoline. Therefore, avoid taking your ve-
hicle to areas where appropriate fuel is not
available.
When transferring the registration of your
vehicle to another country, state, province
or district,it may be necessary to modify the
vehicle to meet local laws and regulations.
The laws and regulations for motor vehicle
emission control and safety standards vary
according to the country, state, province or
district; therefore, vehicle specifications may
differ.
When any vehicle is to be taken into an-
other country, state, province or district
and registered, its modifications, transpor-
tation and registration are the responsibil-
ity of the user. NISSAN is not responsible
for any inconvenience that may result.
DIMENSIONS AND WEIGHTSWHEN TRAVELING OR
REGISTERING YOUR VEHICLE IN
ANOTHER COUNTRY
9-12
Z01.2.1/R50-DX

VEHICLE IDENTIFICATION
NUMBER PLATE
The vehicle identification number plate is at-
tached as shown. This number is the identifi-
cation for your vehicle and is used in the
vehicle registration.
VEHICLE IDENTIFICATION
NUMBER (Chassis number)ENGINE SERIAL NUMBER
The number is stamped on the engine as
shown.
STI0095STI0089STI0094
VEHICLE IDENTIFICATION
9-13
