display will illuminate for ten seconds then
return to the clock mode.
After clock adjustment, the radio is in the
clock priority mode.
Radio/cassette tape priority mode
In this mode, the radio station will illuminate in
the display during radio operation. During cas-
sette tape operation, ªTAPEº will illuminate in
the display.
Selecting the desired band
Push the band select button (FM/AM) to
change from AM to FM reception.
The stereo indicator illuminates during FM
stereo reception. When the stereo broadcast
signal is weak, the radio will automatically
change from stereo to monaural reception.
Tuning
The radio should not be tuned while
driving in order that full attention may be
given to the driving operation.
Manual tuning
Push either manual tuning button
ª
ºorªº.
SEEK tuning
Push the SEEK/SCAN tuning button
ª
º for less than 1.5 seconds. SEEK tun-
ing begins from low to high frequencies and
stops at the next broadcasting station. Push
the button again for less than 1.5 seconds, and
the next highest broadcasting station is tuned.
Once the highest broadcasting station is
reached, the radio will continue in the ªSEEKº
mode at the lowest broadcast station.
SCAN tuning
Push the SEEK/SCAN tuning button
ª
º for more than 1.5 seconds. ªSCANº will
illuminate in the display window. SCAN tuning
begins from low to high frequencies and stops
at each broadcasting station for five seconds.Pushing the button again during this five sec-
ond period will stop SCAN tuning and the radio
will remain tuned to that station.
3-16
Z01.2.1/R50-DX

Station memory operations
Six stations can be set for each band.
1. Tune to the desired station.
2. Push the desired select button for morethan 2 seconds. (For example, in the dia-
gram ch2 is to be memorized. The radio
stops emitting sounds when the select but-
ton is pushed.)
3. The indicator, ª2chº, will then come on and
the sound will resume. Memorizing is now
complete.
4. Other buttons can be set in the same
manner.
If the battery cable is disconnected, or if the
fuse blows, the radio memory will be
cancelled. In that case, reset the desired sta-
tions.
HA1088
3-17
Z01.2.1/R50-DX

To adjust BASS, TREB (treble), FADER, and
BAL (balance) the control knobs must be re-
leased from their stowed positions. Pushing
the knobs once moves them to the released
position.
In the released position, the knobs control tone
quality. Turn the control knobs to adjust BASS
and TREB to the most pleasing level.
From the released position, the knobs must be
pulled out in order to control FADER and BAL.
FADER adjusts the sound level between the
front and rear speakers, and BAL adjusts the
sound level between the right and left speak-
ers.Once sound quality is set to the desired levels,
return the control knobs to the stowed position
by pushing them in completely and releasing.
Cassette tape operation
Turn the ignition key to ªACCº or ªONº, then
lightly insert the cassette tape into the tape
door.
The cassette tape will automatically pull into
the player. The word ªTAPEº and an arrow
indicating tape side will illuminate in the dis-
play window.
Do not force the cassette tape into the tape
door.Pressing strongly could cause player
damage.
The cassette tape will automatically change
directions to play the other side when the first
side is completed. At this time, the arrow in the
display window will change direction.
ITo maintain good quality sound, NIS-
SAN recommends that you use cassette
tapes of 60 minutes or shorter in length.
ICassette tapes should be removed from
the player when not in use. Store cas-
settes in their protective cases and away
from direct sunlight, heat, moisture and
magnetic sources.
Direct sunlight can cause the cassette to
become deformed. The use of deformed
cassettes may cause the cassette to jam
in the player.
IDo not use cassettes that have labels
which are peeling and loose. If used, the
label could jam in the player.
IIf a cassette has loose tape, insert a
pencil through one of the cassette hubs
and rewind the tape firmly around the
hubs. Loose tape may cause tape jam-
ming and wavering sound quality.
IOver a period of time, the playback
AHA0522
3-18
Z01.2.1/R50-DX

head, capstan and pinch roller may col-
lect a tape coating residue as the tape
passes over the head. This residue ac-
cumulation can cause weak or wavering
sound, and should be removed periodi-
cally with a head cleaning tape. If the
residue is not removed periodically, the
player may need to be disassembled for
cleaning.
Fast forwarding or rewinding the
tape
Push either the FF (forward) or REW (rewind)
button for the desired direction.
The ª
ºorªº symbol will illuminate in
the display. To stop the FF or REW function,
press the ªPLAY/STOPº button.
Automatic Program Search (APS)
fast forwarding or APS rewinding the
tape
Push either the APS FF or APS REW button
while the tape is playing. The tape will run
quickly, and stop and play at the next pro-
gram. The indicator flashes on and off while
searching for the program. The ª
ºor
ªº symbol will illuminate in the display.
This system searches at the blank intervals
between selections. If there is a blank interval
within one program or there is no interval
between programs, the system may not
search correctly.
Changing the direction of tape play
Push the PROG (program) select button. The
ªºorªº symbol will illuminate in the
display to indicate side of program play.
Dolby NR (noise reduction)
Push theªDOLBY NRº button for Dolby
NR encoded tapes to reduce high frequency
tape noise. The indicator will come on.
Dolby NR is manufactured under license from
Dolby Laboratories Licensing Corporation.
ªDOLBY NRº and the double-D symbol aretrademarks of Dolby Laboratories Licensing
Corporation.
If in the clock priority mode when the
but-
ton is pressed,
and ªTAPEº will illuminate
in the display window for about ten seconds.
The clock mode will then return to the display
window.
Metal or chrome tape usage
The cassette player will be automatically set to
high performance play when playing a metal or
chrome cassette tape. The indicator ªMETALº
will come on when playing a metal or chrome
cassette tape.
Stopping and ejecting the cassette
tape
Push the EJECT button.
The cassette tape will automatically come out.
3-19
Z01.2.1/R50-DX

AM-FM RADIO WITH COMPACT
DISC PLAYER
The electronic tuning radio has an FM Diver-
sity reception system, which employs two an-
tennas. One is a rod type antenna; the other is
an antenna printed on the window. This sys-
tem automatically switches to the antenna
which is receiving less noise.
Radio operation
Pushthe FM/AM button to listen to the radio
and tune in the desired station.
Pushing the FM/AM button while the com-pact disc is playing will turn off the com-
pact disc player and turn on the radio.
Turnthe ON.VOL knob to adjust the volume.
Clock set (Adjustment)
Depressing the ªCLOCKº and the ªº but-
tons together will set hours. Depressing the
ªCLOCKº and ª
º buttons together will set
minutes.
Clock operation
By pressing the ªCLOCKº button, you can
alternate the clock and the radio/cassette tape
options in the display.
Clock priority mode
In this mode the clock will be shown in the
display. If any radio or CD functions are acti-
vated, the radio or CD display will illuminate for
ten seconds then return to the clock mode.
After clock adjustment, the radio is in the
clock priority mode.
Selecting the desired band
Push the AM/FM button to change from AM to
FM reception.
The FM stereo indicator ªSTº will glow during
FM stereo reception. When the stereo broad-
cast signal is weak, the radio will automatically
change from stereo to monaural reception.
Tuning
Manual tuning
Push either side of the manual tuning button
ª
º.
SCAN tuning
Push the SEEK/SCAN tuning button ª
º
for more than 1.5 seconds. SCAN tuning be-
gins from low to high frequencies and stops at
each broadcasting station for five seconds.
Pushing the button again during this five sec-
ond period will stop SCAN tuning and the radio
will remain tuned to that station.
SAA0161
3-20
Z01.2.1/R50-DX

SEEK tuning
Push the SEEK/SCAN tuning button ª
º
for less than 1.5 seconds. SEEK tuning begins
from low to high frequencies and stops at the
next broadcasting station.
Station memory operations
Six stations can be set for each band.
1. Tune to the desired station.
2. Push the desired select button for morethan 1.5 seconds. (For example in the
diagram ch2 is to be memorized. The radio
ceases emitting sounds when the select
button is pushed.)
3. The indicator, ªch2º will then come on and
the sound will resume.
Memorization is now complete.
4. Other buttons can be set in the same
manner.
If the battery cable is disconnected, or if the
fuse blows, the radio memory will be canceled.
In that case, reset the desired stations.
SAA0162
3-21
Z01.2.1/R50-DX

Adjusting tone quality
Push then turn the BASS and TREB
(TREBLE) control knobs to obtain the most
pleasant sound.
Adjusting speaker sound balance
Pull then turn the BALANCE (BAL) control
knob to adjust the volume between the right
and left speakers.
FADER volume control
Pull then turn the FADER control knob to
adjust the volume between the front and rear
speakers.
COMPACT DISC PLAYER
OPERATION
CD button
IWhen this button is pushed with the system
off and the compact disc loaded, the sys-
tem will turn on and the compact disc will
start to play.
IWhen this button is pushed with the com-
pact disc loaded but the radio playing, the
radio will automatically be turned off and
the compact disc will start to play.
IWhen this button is pushed while the com-
pact disc is playing, the compact disc will
stop playing. When this button is pushed
with the compact disc stopped, the compact
disc will start to play.Insert the compact disc into the compact disc
player with the label side facing up as illus-
trated. When ejecting the compact disc, press
the EJECT button ª
º.
If the compact disc is left alone for longer than
10 seconds after the EJECT button is pushed,
the compact disc will be automatically inserted
into the player.
FF (fast forward), REW (rewind)
button
When the ªºorªº button is pushed
while the compact disc is being played, the
compact disc will play while fast forwarding or
SAA0054SAA0163
3-22
Z01.2.1/R50-DX

rewinding. When the button is released, the
compact disc will return to normal play speed.
APS FF, APS REW button
When the ªº button is pushed while the
compact disc is being played, the program
next to the present one will start to play from its
beginning. Push several times to skip through
programs. The compact disc will advance the
number of times the button is pushed. (When
the last program on the compact disc is
skipped through, the first program will be
played.) When the ª
º button is pushed,
the program being played returns to its begin-
ning. Push several times to skip back through
programs. The compact disc will go back the
number of times the button is pushed.
PRT (Repeat) button
When this button is pushed while the compact
disc is being played, play pattern will change
as follows:
ALL: All the programs will be played repeat-
edly in sequence.
1: Only one program (the one being played
when the PROG button is pushed) will be
repeated.
RANDOM: Programs will be played at random,not following the sequence on the compact
disc.
l(no mark): All the programs will be played in
sequence and stop when the last program is
finished.
IRANDOM The same program may be re-
peated twice.
IWhen the compact disc is ejected, the play
pattern will automatically change to ALL.
IDuring cold weather or rainy days,
the player may malfunction due to the
humidity. If this occurs, remove the
CD and dehumidify or ventilate the
player completely.
IThe player may skip while driving on
rough roads.
IThe CD player sometimes cannot
function when the compartment tem-
perature is extremely high. Decrease
the temperature before use.
IDo not expose the CD to directsunlight.
3-23
Z01.2.1/R50-DX
