1996 NISSAN PATHFINDER Owners Manual

The tachometer indicates engine speed in
revolutions per minute (r/min).
When engine speed approaches the red
zone, shift to a higher gear. Operating
the engine in the red zone may cause
serious engine damage.
The gauge indicates the coolant temperature.
The coolant temperature will vary with the
outside air temperature and driving conditions.
If the gauge indicates over the normal
range, stop the vehicle as soon as safely
possible. If the engine is overheated,
continued operation of the vehicle may
seriously damage the engine. See ªIn
case of emergencyº section for immedi-
ate action required.
SIC0588SIC0545
TACHOMETER
ENGINE COOLANT
TEMPERATURE GAUGE
1-4
Z01.2.1/R50-DX

The gauge indicates the APPROXIMATE fuel
level in the tank.
The gauge may move slightly during braking,
turning, acceleration, or going up or down hill.
The gauge needle is designed to remain in
approximately the same position, even when
the ignition key is turned ªOFFº.
Refill the fuel tank before the gauge regis-
ters Empty.This unit is a display unit which possesses the
following functions:
IFunction to measure terrestrial magnetism
and indicate heading direction of vehicle
IFunction to indicate outside air temperature
IFunction to indicate caution for frozen road
surfacesOutside temperature display
Push the switch when the ignition key is in the
ªACCº or ªONº position. The outside tempera-
ture will be displayed in ªÉFº.
ISelecting the indication range
Push the switch to change from ªÉFº to ªÉCº.
IIf the outside temperature drops below the
freezing point, the display indicates
ICE .
SIC0546SIC0590SIC0610
FUEL GAUGECOMPASS AND OUTSIDE
TEMPERATURE DISPLAY
(If so equipped)
1-5
Z01.2.1/R50-DX

IThe outside temperature sensor is
installed in the front of the radiator.
The display may not indicate the cor-
rect temperature due to the heat of
the road and engine depending on
the direction of the wind and driving
conditions, etc.
IUse the ªICEº indication for reference
only. Confirm the traffic information
and road conditions to drive safely.
IWhen the outside temperature is be-
tween 130ÉF (55ÉC) and 158ÉF (70ÉC),
the display shows 130ÉF (55ÉC).
IWhen the outside temperature is
lower than þ20ÉF (þ30ÉC) or higher
than 158ÉF (70ÉC), the display shows
only ª
---º though it is operating. This
is not a problem.
SIC0611
1-6
Z01.2.1/R50-DX

Compass display
Push the switch when the ignition key is in the
ªACCº or ªONº position. The direction will be
displayed.
Zone variation change procedure
The difference between magnetic north and
geographical north is known as variance. In
some areas, this difference can sometimes be
great enough to cause false compass read-
ings. Follow these instructions to set the vari-
ance for your particular location if this hap-
pens:
1. Establish your location on the zone map.
Record your zone number.
2. Push the ªON/OFFº switch in for five sec-
onds until the current zone entry number is
displayed.
3. Press the ªON/OFFº switch repeatedly until
the new zone entry number is displayed.
Once the desired zone number is displayed,
stop pressing the ªON/OFFº switch and the
display will show compass direction within a
few seconds.
IIf a magnet is located near the com-
pass or the vehicle is driven where
the terrestrial magnetism is dis-
turbed, the compass display may not
indicate the correct direction.
IIn places where the terrestrial magne-
tism is disturbed, the correction of
the direction starts automatically, ex-
tinguishing the direction bar. If turn is
made one or two times, the correction
is complete and the direction bar
comes back on.
Correction functions of the direction
meter
The direction display is equipped with auto-
matic correction function. If the direction is not
shown correctly, carry out initial correction.
Manual correction procedure
1. Pushing the switch for about 10 seconds
will enter the initial correction mode. The
direction bar starts blinking.
2. Turn the vehicle slowly in an open, safeplace. The initial correction is completed in
one or two turns.
In places where the terrestrial magne-
tism is extremely disturbed, the initial
correction may start automatically.
1-7
Z01.2.1/R50-DX

The digital clock displays time when the igni-
tion key is in ªACCº or ªONº.
If the power supply is disconnected, the
clock will not indicate the correct time.
Readjust the time.
Clock set (Adjustment)
Depressing the ªCLOCKº and the ªºor
ªº buttons together will set hours. De-
pressing the ªCLOCKº and ªºor
ªº buttons together will set minutes.
Clock operation
By pressing the ªCLOCKº button, you can
alternate the clock and the radio/cassette tape
options in the display.
Clock priority mode
In this mode the clock will be shown in the
display. If any radio or cassette tape functions
are activated, the radio (or cassette tape)
display will illuminate for ten seconds then
return to the clock mode.
After clock adjustment, the radio is in the
clock priority mode.
SIC0591SIC0592
CLOCK
1-8
Z01.2.1/R50-DX

Turn signal/hazard indicator lightsLow washer fluid warning light
(For Canada)Automatic transmission oil temperature
warning light
orBrake warning light4-wheel drive indicator lightMalfunction indicator light
High beam indicator light (Blue)CRUISE indicator lightDoor open warning light
Seat belt reminder light and buzzerAnti-lock brake warning light
(Except for Canada)Tire carrier open warning light
Engine oil pressure warning lightAnti-lock brake warning light
(For Canada)Supplemental air bag warning light
Charge warning lightOverdrive off indicator light
Low fuel warning lightAutomatic transmission park warning light
Checking bulbs
Turn the ignition key to ªONº without starting
the engine. The following lights will come on:
,,,or,
The following lights come on briefly and then
go off:
or,,
If any light fails to come on, it may indicate a
burned-out bulb or an open circuit in the elec-
trical system. Have the system repaired
promptly.
Turn signal/hazard indicator
lights
The light flashes when the turn signal switch
lever or hazard switch is turned on.
orBrake warning light
This light functions for both the parking brake
and the foot brake systems.Parking brake indicator
The light comes on when the parking brake is
applied.
Low brake fluid warning
The light warns of a low brake fluid level. If the
light comes on while the engine is running,
stop the vehicle and perform the following:
1. Check the brake fluid level. Add brake fluid
as necessary. See ªBrake and clutch fluidº
in the ªDo-it-yourself operationsº section.
WARNING/INDICATOR LIGHT
AND BUZZER
1-9
Z01.2.1/R50-DX

If the level is below the MINIMUM mark
on the brake fluid reservoir, do not drive
until the brake system has been
checked at a NISSAN dealer.
2. If the brake fluid level is correct:
Have the warning system checked by a NIS-
SAN dealer.
IEven if you judge it to be safe, have
your vehicle towed because driving it
could be dangerous.
IPressing the brake pedal with the
engine stopped could increase your
stopping distance and require greater
pedal effort as well as pedal travel.
High beam indicator light
(Blue)
This light comes on when the headlight high
beam is on, and goes out when the low beams
are selected.
Seat belt reminder light
The light and buzzer remind you to fasten seat
belts. The light illuminates whenever the igni-
tion key is turned to ªONº, and will remain
illuminated until the driver's seat belt is fas-
tened. At the same time, the buzzer will sound
for about six seconds unless the driver's seat
belt is securely fastened.
Refer to ªSeat beltsº in the ªPre-driving checks
and adjustmentsº section for precautions on
seat belt usage.
Engine oil pressure warning
light
This light warns of low engine oil pressure. If
the light flickers or comes on during normal
driving, pull off the road in a safe area, stop the
engineimmediatelyand call a NISSAN dealer
or other authorized repair shop.
The oil pressure warning light is not de-
signed to indicate a low oil level. Use the
dipstick to check the oil level.See ªEngine
oilº in the ªDo-it-yourself operationsº section.
Running the engine with the oil pressure
warning light on could cause seriousdamage to the engine.
Charge warning light
If the light comes on while the engine is
running, it may indicate that there is something
wrong with the charging system. Turn the
engine off and check the alternator belt. If the
belt is loose, broken, missing or if the light
remains on, see your NISSAN dealer immedi-
ately.
Do not continue driving if the belt is
loose, broken or missing.
Low fuel warning light
This light comes on when the fuel in the tank is
getting low. Refuel as soon as it is convenient,
preferably before the fuel gauge reaches ªEº.
There should be a small reserve of fuel
remaining in the tank when the fuel gauge
needle reaches ªEº.
1-10
Z01.2.1/R50-DX

Low washer fluid warning
light (For Canada)
This light comes on when the washer fluid in
the washer tank is at a low level. Add washer
fluid as necessary. See the ªDo-it- yourself
operationsº section.
4-wheel drive indicator light
This light comes on when the transfer shift
control lever is in the ª4Hº or ª4Lº position.
CRUISE indicator light
The light comes on while the vehicle speed is
controlled by the cruise control system.
If the light flickers while the engine is running,
it may indicate there is something wrong with
the cruise control system. Have the system
checked by your NISSAN dealer.
orAnti-lock
brake warning
light
If the light comes on while the engine is
running, it may indicate there is something
wrong with the anti-lock brake system. Have
the system checked by your NISSAN dealer.
If an abnormality occurs in the system, the
anti-lock function will cease but the ordinarybrakes will continue to operate normally.
If the light comes on while you are driving,
contact your NISSAN dealer for repair.
Overdrive off indicator light
This light comes on when the overdrive switch
is pushed in the ªOFFº position.
Automatic transmission park
warning light (
model)
This light indicates that the automatic trans-
mission parking function is not engaged. If the
transfer control is not secured in any drive
position while the automatic transmission se-
lector lever is in the ªPº position, the transmis-
sion will disengage and the wheel will not lock.
Shift the transfer control lever into the ª2Hº or
ª4Lº position when the warning light comes on.
Automatic transmission oil
temperature warning light
(
model)
This light comes on when the automatic trans-
mission oil temperature is too high. If the light
comes on while driving, reduce the vehicle
speed as soon as safely possible until the light
turns off.
Continued vehicle operation when the A/Toil temperature warning light is on may
damage the automatic transmission.
Malfunction indicator light
(MIL)
If the Malfunction indicator light comes on
steady or blinks while the engine is running, it
may indicate a potential emission control prob-
lem.
The Malfunction indicator light will come on in
one of two ways:
IMalfunction indicator light comes on steady
Ð An emission control system malfunction
has been detected. Have the vehicle in-
spected by an authorized
NISSAN dealer. You do not need to have
your vehicle towed in.
IMalfunction indicator light blinking Ð An
engine misfire has been detected which
may damage the emission control system.
To reduce or avoid emission control system
damage:
* do not drive at speeds above 45 MPH (72
km/h).
* avoid hard acceleration or deceleration.
* avoid steep uphill grades.
* if possible, reduce the load being carried
or towed.
1-11
Z01.2.1/R50-DX
