1996 FORD RANGER Owners Manual

290
[SV26800(R )04/94]
17-1/2 pica
art:0021191-A
Tire rotation pattern
*
[SV26900(ALL)10/89]
After each rotation, adjust individual tire pressure as specified
on the Safety Compliance Certification Label. Tighten wheel lug
nuts to the required torque specification and retighten again
after 500 miles (800 km).
*
[SV27000(ALL)08/95]
If your vehicle has aluminum wheels, you may demount the full
size, non-temporary spare tire (if so equipped) and remount on
an aluminum wheel to rotate the spare tire into your vehicle's
rotation pattern. Rebalance the wheel.
File:15unsvr.ex
Update:Wed May 1 13:56:18 1996

Servicing Your Ranger
291
%*
[SV27300(ALL)04/95]
Replacing the Tires
*
[SV27400(ALL)05/95]
Replace any tires that show wear bands. When your tire shows
a wear band, it has only 1/16 inch (2 mm) of tread left.
*
[SV27500(ALL)11/93]
7-1/2 pica art:0040200-A
A worn-out tire
*
[SV27600(ALL)01/95]
Because your vehicle's tires may wear unevenly, you may need
to replace them before a wear band appears across the entire
tread. Some spots wear more heavily than others.
*
[SV27700(ALL)03/90]
Your wheels and tires are match-mounted for improved ride.
Before you begin to repair a tire, mark the wheel and tire so
that they are properly aligned when remounted. This will
ensure that the tires will continue to give you the same ride
level.
*
[SV27851(ALL)01/95]
RWARNING
When replacing full size tires, never mix radial,
bias-belted, or bias-type tires. Use only the tire sizes that
are listed on the tire pressure decal. Make sure that all
tires are the same size, speed rating, and load-carrying
capacity. Use only the tire combinations recommended on
the decal. If you do not follow these precautions, your
vehicle may not drive properly and safely.
File:15unsvr.ex
Update:Wed May 1 13:56:18 1996

292
*
[SV27860(ALL)03/90]
RWARNING
Make sure that all replacement tires are of the same size,
type, load-carrying capacity, and tread design (e.g. ªAll
Terrainº, etc.), as originally offered by Ford.
[SV27866(R )06/94]
RWARNING
Do not replace your 4x2 tires with ªhigh performanceº
tires, or larger size tires than approved for your vehicle
by Ford.
[SV27869(R )10/94]
Ranger 4x4 P235/265 Tire and Wheel Usage
[SV27870(R )03/90]
RWARNING
Do not use P235/75R15 ªAll Seasonº tires. For Ranger 4x4
Regular Cab vehicles, P235/75R15 ªAll Terrainº tires are
acceptable only on 15x7 inch wheels.
[SV27872(R )12/91]
RWARNING
Do not use P265/75R15SL tires on the Ranger 4x4 108
inch wheelbase. The P265/75R15SL ªAll Terrainº tires are
acceptable only on the 114 inch and 125 inch wheelbase
Ranger 4x4 models, and only with 15x7 inch wheels.
File:15unsvr.ex
Update:Wed May 1 13:56:18 1996

Servicing Your Ranger
293
[SV27874(R )10/94]
six pica chart:0020904-C*
[SV27895(ALL)05/95]
RWARNING
Failure to follow these precautions may adversely affect
the handling of the vehicle and make it easier to lose
control and roll over.
*
[SV27900(ALL)01/95]
Tires that are larger or smaller than your vehicle's original tires
may also affect the accuracy of your speedometer.
File:15unsvr.ex
Update:Wed May 1 13:56:18 1996

294
[SV28600(R )04/94]
27-1/2 pica art:0020371-F
Tire identification chart
*
[SV28700(ALL)05/95]
RWARNING
Use of aftermarket wheel assemblies may damage your
vehicle or cause accidents resulting in serious injuries.
File:15unsvr.ex
Update:Wed May 1 13:56:18 1996

Servicing Your Ranger
295
%*
[SV28800(ALL)04/95]
Wheel and Tire Matching
*
[SV28950(ALL)03/95]
See an authorized tire dealer for proper servicing procedures.
Wheels and tires must be properly removed, matched and
remounted to maintain the best possible ride.
%*
[SV31100(ALL)04/95]
Snow Tires and Chains
*
[SV31200(ALL)01/95]
The tires on your vehicle have all-weather treads that provide
traction in rain or snow. However, during the winter months in
some climates, you may need to use snow tires and occasionally
chains for your tires.
*
[SV31300(ALL)05/95]
RWARNING
Snow tires must be the same size and grade as the tires
you currently have on your vehicle.
*
[SV31400(ALL)02/95]
Do not use chains when using a temporary spare. For full size
tires, use chains on the tires only in an emergency or if the law
requires them where you live. When you use the tire chains:
*
[SV31500(ALL)01/95]
n
Make sure the chains are the right size for your tires. Use
only SAE Class ªSº chains. Other types may damage your
vehicle.
*
[SV31525(ALL)08/93]
n
Tire chains may scratch or chip aluminum wheels. IT IS
RECOMMENDED THAT TIRE CHAINS ARE INSTALLED
ON STEEL WHEELS ONLY. Be sure to remove wheel
covers (if equipped) from steel rims before using tire chains
to avoid scratches or damage.
[SV31550(ALL)01/95]
n
Install tire chains on rear tires; use of chains on front tires is
not recommended.
[SV31575(ALL)01/95]
n
Local regulations may prohibit or restrict the use of tire
chains. Investigate the laws and regulations in your area
before installing chains.
File:15unsvr.ex
Update:Wed May 1 13:56:18 1996

296
*
[SV31600(ALL)01/95]
n
Put the chains on tightly with the ends held down securely.
Verify that no chain touches any wiring, brake lines, or fuel
lines. Follow the chain manufacturer's instructions.
*
[SV31700(ALL)01/95]
n
Drive slowly. If you can hear the chains rub or bang against
your vehicle, stop the vehicle and tighten the chains. If you
continue to hear the chains rub or bang against your vehicle,
remove the chains to prevent damage to your vehicle.
*
[SV31800(ALL)10/94]
n
Avoid fully loading your vehicle if possible.
*
[SV31850(ALL)11/94]
n
Tire chains may affect vehicle handling. Drive carefully and
avoid hard braking.
[SV31900(ALL)03/95]
Remove tire chains at the first opportunity after using them on
snow and ice. Do not use the chains on dry roads.
*
[SV31950(ALL)05/91]
n
Make sure your suspension insulation and bumpers are not
missing or worn to avoid damage to your vehicle.
%*
[SV31960(ALL)04/95]
Cleaning the Wheels
*
[SV31970(ALL)05/95]
Wash the wheels with the same detergent you use to wash your
vehicle's body. Do not use acid-based wheel cleaners, steel wool,
abrasives, fuel, or strong detergents. These substances will
damage protective coatings. Use tar and road oil remover to
remove grease and tar.
*
[SV31975(ALL)09/95]
NOTE: Before going to a car wash, find out if the brushes are
abrasive.
[SV31980(ALL)03/95]
If you have raised white letter tires that are difficult to clean
with regular detergent, use whitewall tire cleaner. Follow the
directions on the container and rinse the tires with plenty of
clean water.
File:15unsvr.ex
Update:Wed May 1 13:56:18 1996

Servicing Your Ranger
297
%*
[SV32100(ALL)03/95]
Battery
*
[SV32200(ALL)02/95]
Your vehicle may have a Motorcraft maintenance-free battery.
The Motorcraft maintenance-free battery does not require
additional water during its life of service. The vents are part of
the cover and cannot be removed. For longer, trouble-free
operation, keep the top of the battery clean and dry. Also, make
certain the battery cables are tightly fastened to the battery
terminals.
*
[SV32300(ALL)02/95]
If you see any corrosion on the battery cables or terminals,
remove the cables from the terminal and clean them both with a
wire brush. You can neutralize the acid with a solution of
baking soda and water. Reinstall the cables when you are done
cleaning them, and apply a small quantity of grease to the top
of each battery terminal to help prevent corrosion.
*
[SV32400(ALL)07/95]
Battery replacement
*
[SV32500(ALL)02/95]
If your original equipment battery requires replacement (under
warranty), it may in some cases be replaced by a Motorcraft
low-maintenance battery. The low-maintenance battery has
removable vent caps for checking the electrolyte level and for
adding water, if needed.
[SV32550(ALL)05/95]
NOTE: If your battery has a cover/shield, make sure it is
re-installed after the battery is replaced.
*
[SV32600(ALL)07/95]
Check your battery's electrolyte level, at least every 12 months
or 12,000 miles (20,000 km), in temperatures up to90ÊF (32ÊC)
and more often in temperatures above90ÊF (32ÊC).Keep the
electrolyte in each cell up to the ªlevelº indicator. Do not
overfill the battery cell.
*
[SV32700(ALL)02/95]
If the electrolyte level in your battery gets low, you can add
plain tap water to the battery, as long as you don't use hard
water, or water with a high mineral or alkali content. If
possible, however, try to only fill the battery cell with distilled
water. If the battery needs water often, have the charging
system checked.
