P(Floor & Defrost)
[IP03700(R )03/95]
SelectPto get air to the floor and windshield defrosters at the
same time.
%*
[IP03750(R )08/95]
V(Defrost)
[IP03800(R )05/95]
SelectVto obtain maximum air flow to the windshield. Rotate
the temperature knob into the red area for the air temperature
required to defrost. Rotate the
Hknob to increase the air flow.
*
[IP03850(R )04/95]
Operating tips
*
[IP03900(R )02/95]
The following tips will help you to get the most satisfaction
from your heater system.
*
[IP04000(R )02/95]
n
To prevent humidity buildup inside your vehicle, always
drive with the heater system turned on.
*
[IP04050(R )03/95]
n
Do not put objects under the front seats that interfere with
the flow of air to the back seat area.
*
[IP04100(R )02/95]
n
Remove any snow, ice, or leaves from the air intake area at
the bottom of the windshield.
%*
[IP16800(ALL)01/95]
The Interior and Exterior Lights
%*
[IP16900(ALL)01/95]
Turning On the Exterior Lights
*
[IP17000(ALL)09/95]
To turn on your headlamps, parking lamps, marker lamps,
license plate lamps and tail lamps, use the headlamp control
knob to the left of the steering column.
[IP17100(ALL)09/95]1.
Rotate the headlamp control knob to the first position.
Parking lamps, tail lamps, license plate lamps and marker
lamps are now on.
[IP17200(ALL)06/94]2.
Rotate the headlamp control knob to the next position.
Headlamps are now on in addition to the above.
File:06unipr.ex
Update:Wed May 1 13:46:22 1996

Instrument Panel Controls
81
[IP17250(ALL)09/95]3.
Rotate the thumb wheel when the headlamp control knob is
in an ªONº position to brighten or dim the instrument panel
lamps. Rotate fully upward to operate courtesy and cargo
lamps.
[IP17260(ALL)09/95]
17-1/2 pica
art:0090190-A
Headlamp control knob
%*
[IP17715(ALL)04/95]
Fog Lamps (If equipped)
[IP17725(ALL)03/95]
The fog lamps switch is located on the instrument panel to the
right of the radio and climate control.
[IP17730(ALL)05/95]
n
To turn the fog lamps on, turn on the low-beam headlamps,
then push the fog lamp switch. An indicator light will glow
when the lamps are on.
*
[IP17735(ALL)10/94]
n
To turn off, push the switch again.
File:06unipr.ex
Update:Wed May 1 13:46:22 1996

82
[IP17750(ALL)05/95]
7-1/2 pica art:0090191-A
Fog lamp switch
*
[IP17760(ALL)02/93]
The fog lamps act as a supplement to the low beam headlamps
under limited visibility conditions such as rain, snow, dust or
fog and operate only when the low beam headlamps are on.
*
[IP17770(ALL)02/93]
To maximize fog lamp bulb life it is recommended that the fog
lamp switch be turned off after each use prior to turning off the
headlamps.
%*
[IP17780(ALL)08/95]
Cleaning the Exterior Lamps
*
[IP17785(ALL)08/95]
Do not use dry paper towel, chemical solvents or abrasive
cleaners to clean the lamps, as these may cause scratches or
crack the lamps.
%*
[IP17815(ALL)01/95]
Daytime Running Light System
*
[IP17820(ALL)03/95]
(Canadian vehicles only)
*
[IP17830(ALL)03/95]
The Daytime Running Light (DRL) system turns the high beam
headlamps on, with a reduced light output, when:
*
[IP17840(ALL)03/95]
n
The headlamp system is in the OFF position, and
*
[IP17850(ALL)01/95]
n
The vehicle has a fully released parking brake.
*
[IP17860(ALL)05/95]
The high beam indicator light on the instrument cluster will not
be on.
File:06unipr.ex
Update:Wed May 1 13:46:22 1996

Instrument Panel Controls
83
*
[IP17890(ALL)05/95]
RWARNING
The Daytime Running Light (DRL) system will not
illuminate the tail lamps and parking lamps. Turn on
your headlamps at dusk. Failure to do so may result in a
collision.
%*
[IP17900(ALL)03/95]
Lighting Up the Instrument Panel and the Interior of
Your Vehicle
[IP18000(ALL)10/94]
The instrument panel lights can be turned on by turning the
headlamp knob toward either the first or second position. You
can brighten or dim the instrument panel lights by rotating the
thumb wheel.
[IP18200(ALL)03/95]
The interior lights will shut off after 25 seconds with all the
doors closed, or immediately when the ignition switch is turned
to the ON position, or if the vehicle speed is above five MPH
(8 km/h). The interior lights will turn off after 40 minutes if
any of the doors are left open. Refer toBattery Saverin the
Featuressection for more details.
[IP18500(R )11/89]
Courtesy and Dome Lamps
[IP19175(R )04/94]
The interior/courtesy lamp is automatically turned on when the
driver or passenger door is opened. Turning the thumb wheel
fully counterclockwise will operate the interior lamp when the
doors are closed.
[IP19185(R )08/94]
7-1/2 pica art:0021156-B
Interior/Courtesy lamp
File:06unipr.ex
Update:Wed May 1 13:46:22 1996

84
%*
[IP19187(ALL)04/95]
Cleaning the Interior Lamps
*
[IP19188(ALL)04/95]
Your interior dome lamps and map lamps are plastic and
should be cleaned with a mild detergent diluted in water. Rinse
them with clear water.
%*
[IP19190(R )08/94]
Combination Cargo and High-Mount Brakelamp
[IP19200(R )08/94]
The combination cargo/high-mount brakelamp is located outside
the vehicle, directly over the rear window. Use the thumb wheel
to turn on the cargo lamp and interior courtesy lights.
[IP19350(R )08/94]
7-1/2 pica art:0021157-B
Cargo/High-mount brakelamp
*
[IP19400(R )05/91]
RWARNING
Do not drive your vehicle with the cargo/courtesy light
on. Showing a white light to the rear while driving on
public roads is illegal in some places.
File:06unipr.ex
Update:Wed May 1 13:46:22 1996

Instrument Panel Controls
85
[IP19700(ALL)04/95]
Dome/Map Lamps (If equipped)
[IP19825(R )08/91]
The map lamps are located on each side of the dome light
assembly. You can turn the individual map lamps on or off by
sliding the switch to the left or right. To turn off, slide the
switch to the middle.
[IP19950(R )04/94]
7-1/2 pica art:0020895-B
Map lamps
*
[IP20300(ALL)04/95]
Clock Controls on Electronic Radios
[IP20400(ALL)10/94]
The electronic radios have a built-in clock. For complete
operating instructions, refer toElectronic Sound Systemsin this
Owner Guide.
File:06unipr.ex
Update:Wed May 1 13:46:22 1996

87
Steering Column Controls
*
[SC00400(ALL)01/95]
The controls on the steering column and wheel are designed to
give you easy access to the controls while you are driving.
%*
[SC00500(ALL)01/95]
The Turn Signal Lever
*
[SC00600(ALL)01/95]
You can use the turn signal lever on the left side of the steering
column to:
*
[SC00700(ALL)03/95]
n
operate the turn signals and cornering lamps
*
[SC00800(ALL)01/95]
n
turn the high beams on/off
*
[SC00900(ALL)05/95]
n
flash the lamps
*
[SC01000(ALL)01/95]
n
turn the windshield wipers and washer on/off
%*
[SC01100(ALL)01/95]
Turn Signals
[SC01600(ALL)07/95]
7-1/2 pica art:0090131-B
Turn signal lever and functions
*
[SC01800(ALL)11/89]
If the turn indicator light in the instrument panel does not
illuminate or remains on (doesn't flash) when you signal a turn,
the turn signaling system is malfunctioning. Have this condition
corrected as soon as possible, but make sure that you use the
accepted hand signals in the meantime.
File:07unscr.ex
Update:Wed May 1 13:46:58 1996

88
%*
[SC03200(ALL)08/95]
High Beams and Flashing the Lamps
[SC03500(ALL)03/95]
7-1/2 pica art:0090130-A
Headlamp high beam switch and turn signal lever on steering column
%*
[SC04400(ALL)08/95]
Windshield Wipers and Washer
*
[SC04500(ALL)03/95]
To turn on the windshield wipers, the ignition key must be
turned to the ON or ACC position.
[SC04900(ALL)08/94]
10-1/2 pica
art:0020084-D
Interval wiper on turn signal lever
*
[SC05000(ALL)02/95]
To set the interval wipers, rotate the knob at the end of the turn
signal lever toward or away from the instrument panel to the
interval operation you desire.
[SC05200(ALL)06/95]
To clean the windshield, push in the end of the wiper knob for
a single wipe. For a constant spray, keep the knob pushed in.
After you release the knob, the wipers operate for two to three
