1996 FORD RANGER Owners Manual

Steering Column Controls
97
*
[SC10250(ALL)10/94]
n
TAP-UP Ð This allows you to increase your current speed in
increments of 1 mph (1.6 km/h) by a momentary tap of the
SET-ACCEL switch. Multiple taps of the SET-ACCEL switch
will increase your vehicle speed 1 mph (1.6 km/h) for each
tap. For example, if you are currently set at 60 mph
(96 km/h) and tap the SET-ACCEL switch 5 times your
vehicle speed will increase and set at 65 mph (104 km/h).
*
[SC10300(ALL)06/95]
Turning the Speed Control Off
*
[SC10400(ALL)06/95]
You can cancel the speed control while you are driving.
[SC10550(ALL)08/94]
n
Press the OFF switch. The speed control is off. If you want
to resume speed control, press the ON switch and reset the
speed control by pressing the SET ACCEL switch.
[SC10600(ALL)06/94]
n
Press the brake or clutch pedal slightly. The speed control is
suspended, but you can reset it by pressing SET ACCEL or
return to the previous set speed with the RSM switch.
*
[SC10800(ALL)10/95]
In addition, the speed control is turned off each time you turn
the vehicle ignition off.
*
[SC11100(ALL)11/89]
Driving uphill or on a steep grade
*
[SC11200(ALL)05/95]
When the speed control is on, your vehicle may significantly
drop speed when driving uphill, especially with a heavy load. If
the speed drops more than 8 to 14 mph (15 - 25 km/h) the
automatic speed control will, by design, be canceled. You may
have to temporarily resume manual speed control while driving
up a steep grade in order to maintain the speed you desire.
[SC11300(ALL)05/95]
If the speed control ªdropped outº after your climb is
completed, the speed of your light truck can be reset with the
SET ACCEL switch, or returned to the previous set speed with
the RSM switch, as long as you are driving over 30 mph
(50 km/h).
File:07unscr.ex
Update:Wed May 1 13:46:58 1996

98
%*
[SC11500(ALL)08/95]
Resuming a Set Speed
*
[SC11600(ALL)06/95]
If you press the brake pedal, the speed control is cancelled. You
can return to the speed you set by using the RSM switch, as
long as you did not press the OFF switch.
*
[SC11700(ALL)08/95]
To resume the speed you had before, you must be driving at
least 30 mph (50 km/h).
*
[SC11800(ALL)05/93]
Press and release the RSM switch. Your vehicle gradually
returns to the previously set speed and then maintains it.
*
[SC11850(ALL)03/95]
RWARNING
If your vehicle has speed control, do not use it on
slippery roads. You could lose control of your vehicle
and could injure someone.
File:07unscr.ex
Update:Wed May 1 13:46:58 1996

99
Features
*
[FV00350(ALL)02/95]
Your vehicle has a variety of features designed for your
comfort, convenience and safety. Read this chapter to find out
about standard and optional features.
%*
[FV00601(ALL)01/95]
Doors
*
[FV00701(ALL)06/95]
Door Handles and Locks
[FV00800(R )08/94]
17-1/2 pica
art:0020177-D
Inside handles
File:08unfvr.ex
Update:Wed May 1 13:48:36 1996

100
[FV01501(R )10/94]
10-1/2 pica
art:0020181-C
Outside handles and locks
%*
[FV01801(ALL)03/95]
Anti-theft front door lock knobs
*
[FV01901(ALL)10/89]
Anti-theft lock knobs are designed to preclude unlocking the
door by pulling up on the bullet type lock knob. To unlock and
open the front door from the inside of the vehicle, pull on the
inside door handle.
%*
[FV06001(R )05/90]
Tailgate
[FV06501(R )04/94]
7-1/2 pica art:0020192-D
Tailgate operation
*
[FV06601(R )09/95]
When open, the tailgate load should not exceed 500 lbs
(227 kgs). If you want to load heavy items onto your vehicle,
Ford recommends that you load them one at a time, directly on
the bed floor to avoid damage to the tailgate or its supports.
File:08unfvr.ex
Update:Wed May 1 13:48:36 1996

Features
101
*
[FV07601(R )01/93]
To release the tailgate:
*
[FV07701(R )10/90]
Open the tailgate as directed above, but support it to allow for
slack in the cables at both sides. Use a coin or similar object to
pry the spring clip (on each upper cable connector) past the
head of the support screw. Doing so will allow you to center
the wider opening in the connector over the screw head and
disconnect it.
*
[FV07801(R )05/90]
If you disconnect the upper end of each cable, you can lower
the tailgate completely.
*
[FV07901(R )05/91]
NOTE: Step bumpers or hitches may damage the tailgate if it
is lowered completely.
[FV08001(R )04/94]
7-1/2 pica art:0020194-C
Releasing the tailgate
*
[FV08201(R )05/90]
Tailgate removal
*
[FV08301(R )07/92]
First release the tailgate as described above. Be sure to support
the left side to prevent it from falling. Then raise the tailgate to
a 45 degree angle (see the following illustration) and lift the
right side of the tailgate off its hinge. You can now pull the left
side of the tailgate away from the left hinge.
File:08unfvr.ex
Update:Wed May 1 13:48:36 1996

102
[FV08401(R )04/94]
10-1/2 pica
art:0020196-C
Tailgate removal
*
[FV08601(R )05/95]
RWARNING
Do not drive your vehicle with the tailgate open unless
there is a load holding it in place.
%*
[FV14100(ALL)04/95]
Power Door Locks (If equipped)
[FV14550(R )05/95]
The power door lock switches are located in the front doors. To
lock all doors push the switch markeds. To unlock all doors
push the switch markeds.
*
[FV14701(ALL)03/91]
The manual door locks will override the power door lock
controls.
[FV15101(R )06/94]
7-1/2 pica art:0020204-F
Power door lock controls
File:08unfvr.ex
Update:Wed May 1 13:48:36 1996

Features
103
%*
[FV15425(ALL)05/95]
Remote Entry System (If equipped)
[FV15450(R )06/95]
If your vehicle has the remote entry system, you can lock or
unlock the vehicle doors without using a key. The remote also
has a personal alarm feature. The buttons for the system are
located on the hand held transmitter that came with your
vehicle.
[FV15650(R )06/95]
The system will work with up to four transmitters. Your vehicle
came with one transmitter. Additional transmitters can be
ordered from your dealer.
*
[FV15700(ALL)02/95]
The remote entry features only operate with the ignition in the
OFF position.
[FV15800(ALL)04/94]
7-1/2 pica art:0021159-A
The remote entry transmitter
%*
[FV15901(ALL)02/95]
Unlocking the doors with the remote entry system
*
[FV16001(ALL)02/95]
To unlock the driver's door, press the UNLOCK button.
[FV16230(R )08/94]
To unlock the other door, press the UNLOCK button a second
time, within five seconds after the first UNLOCK.
*
[FV16300(ALL)02/95]
Locking the doors with the remote entry system
[FV16425(R )03/95]
To lock both doors, press the LOCK button. This will also arm
the factory installed Anti-Theft system.
[FV16475(R )08/94]
If you would like a signal that the doors are being locked, press
the LOCK button again within five seconds. If all doors are
completely closed, the doors will lock again, the horn will chirp,
File:08unfvr.ex
Update:Wed May 1 13:48:36 1996

104and the parking lamps will flash. If a door is open or ajar, the
horn will give two short chirps warning you that a door is
open.
%*
[FV16800(ALL)02/95]
Remote entry personal alarm
*
[FV16900(ALL)02/95]
If you wish to activate the remote entry system personal alarm,
press the PANIC button. This will honk the horn and flash the
lights for approximately 2 minutes 45 seconds. You can turn it
off by pressing the PANIC button again from the transmitter or
by turning the ignition to the ON or ACCESSORY position.
*
[FV17000(ALL)02/95]
When you use the remote entry UNLOCK or PANIC buttons,
the illuminated entry system turns on the vehicle's interior
lights for 25 seconds. You can turn these lights off with the
remote entry LOCK button or by turning the ignition to the ON
or ACCESSORY position.
[FV17100(ALL)03/95]
7-1/2 pica art:0021160-A%*
[FV17200(ALL)04/95]
Arming and Disarming the Alarm System with Remote
Entry
*
[FV17350(ALL)04/95]
Your Remote Entry System will automatically arm the factory
installed Anti-Theft System when the doors are locked, and
automatically disarm it when the doors are unlocked. The
remote will also reset the anti-theft alarm (when the driver's
door is unlocked or the PANIC button is pressed on a
programmed remote entry transmitter) if it was triggered.
