Midline Stereo Cassette Radio
File:09unasr.ex
Update:Wed May 1 13:49:43 1996

146
*
[AS29967(R )05/95]
Midline Stereo and Stereo Cassette Radio
*
[AS29970(ALL)08/95]
Using the Controls on Your New Radio
*
[AS29972(ALL)10/95]
How to turn the radio on and off
*
[AS29973(ALL)01/95]
Press the ªVOL/PUSH ONº knob to turn the radio on. Press
again to turn it off.
*
[AS29975(ALL)10/95]
How to adjust the volume
[AS29980(ALL)06/95]
Turn the ªVOL/PUSH ONº knob clockwise to increase the
volume and counterclockwise to decrease the volume. Bars
illuminate in the display to show relative volume level.
*
[AS29985(ALL)10/95]
NOTE: If the volume level is set above a certain listening
level when the ignition switch is turned off, when the
ignition switch is turned back on, the volume will
come back to a ªnominalº listening level. However, if
the radio power is turned off, the volume will remain
in the position it was set at when radio power was
switched off.
*
[AS29990(ALL)10/95]
Selecting the AM or FM frequency band
[AS29995(ALL)10/94]
Push the ªAMº/FMª button to select the desired frequency
band or to stop/store cassette tape (when in cassette mode).
These functions are used with the station memory buttons
described underHow to tune radio stations.
%*
[AS30000(ALL)10/95]
How to tune radio stations
[AS30005(ALL)04/95]
There are four ways for you to tune in a particular station. You
can manually locate the station using the ºTUNEª button,
ºSEEKª button, ºSCANª button, or select the station by using
the memory buttons, which you can set to any desired
frequency. These four methods are described below.
File:09unasr.ex
Update:Wed May 1 13:49:43 1996

Electronic Sound Systems
147
*
[AS30010(ALL)09/95]
n
Using the ºTUNEª function
*
[AS30015(ALL)03/95]
You can change the frequency up or down one increment at
a time by pressing and releasing either the left (
b) or right
(
a) side of the ºTUNEª button.
*
[AS30020(ALL)10/95]
Manual tuning adjusts your radio to any allowable broadcast
frequency, whether or not a station is present on that
frequency. (SeeAll About Radio Frequenciesin this section.)
*
[AS30025(ALL)10/95]
n
Using the ºSEEKª function
*
[AS30030(ALL)09/95]
This feature on your radio allows you to automatically select
listenable stations up or down the frequency band. Press the
right (
a) side of the ºSEEKª button to select the next
listenable station up the frequency band. Press the left (
b)
side of the button to select the next listenable station down
the frequency band. By holding the button down, listenable
stations can be passed over to reach the desired station.
*
[AS30035(ALL)01/95]
n
Using the ºSCANª function
*
[AS30040(ALL)04/95]
Pressing the ºSCANª button will begin the scan mode up
the frequency band, stopping on each listenable station for
approximately five seconds.
*
[AS30045(ALL)02/95]
To stop the scan mode on the presently sampled station,
press the ºSCANª button again.
*
[AS30050(ALL)10/95]
n
Setting the Station Memory Preset buttons
*
[AS30055(ALL)10/95]
Your radio is equipped with 6 station memory buttons.
These buttons can be used to select up to 6 preset AM
stations and 12 FM stations (6 in FM1 and 6 in FM2).
File:09unasr.ex
Update:Wed May 1 13:49:43 1996

148
*
[AS30060(ALL)10/95]
Follow the easy steps below to set these buttons to the desired
frequencies:
*
[AS30065(ALL)10/95]1.
Select a band, then select a frequency.
*
[AS30075(ALL)10/95]2.
Press one of the memory preset buttons and hold the button
until the sound returns. That station is now held in memory
on that button.
*
[AS30080(ALL)10/95]3.
Follow the two steps above for each station memory preset
button you want to set.
*
[AS30085(ALL)10/95]
Adjusting the tone balance and speaker output of your
radio
*
[AS30090(ALL)10/95]
n
Increasing or decreasing bass response
*
[AS30095(ALL)03/95]
Press the top (
c) of the ºBASSª button to increase bass;
press the bottom (
d) of the ºBASSª button to decrease bass.
*
[AS30100(ALL)10/95]
n
Increasing or decreasing treble response
*
[AS30105(ALL)03/95]
Press the top (
c) of the ºTREBLEª button to increase treble;
press the bottom (
d) of the treble button to decrease treble.
*
[AS30110(ALL)10/95]
n
Adjusting speaker balance
*
[AS30115(ALL)03/95]
Balance control allows you to adjust the sound distribution
between the right and left speakers. Press the top (
c) of the
ºBALª button to shift the sound to the right speakers, and
press the bottom (
d) of the ºBALª button to shift the sound
to the left speakers.
*
[AS30120(ALL)10/95]
n
Adjusting speaker fader
*
[AS30125(ALL)03/95]
Fade control allows you to adjust the sound distribution
between the front and rear speakers. Press the top (
c)of
the ºFADEª button to shift the sound to the front speakers,
and press the bottom (
d) of the ºFADEª button to shift the
sound to the back speakers.
File:09unasr.ex
Update:Wed May 1 13:49:43 1996

Electronic Sound Systems
149
*
[AS30130(ALL)10/95]
NOTE: Illuminated bars in the display show relative levels of
bass and treble, and positions of speaker balance and
fader functions (left to right, front to rear).
%*
[AS30135(R )08/95]
Using the Controls of Your Cassette Tape Player
*
[AS30140(R )09/95]
NOTE: Radio power must be on to use the cassette tape
player or eject a tape.
*
[AS30145(R )08/95]
How to insert a tape
*
[AS30150(R )09/94]
Your cassette tape player is equipped with power loading. Once
you insert a tape and push slightly (with theopen edge to the
right), the loading mechanism draws the tape the rest of the
way in and play will begin after a momentary tape tightening
process.
*
[AS30155(R )09/95]
NOTE: A cassette tape can be loaded and stored with the
ignition and radio power off.
*
[AS30165(R )08/95]
How to locate a desired track on the tape
*
[AS30170(R )09/94]
There are four ways to quickly locate a desired selection on the
tape. You can use the fast forward, rewind, ºSEEKª, or ºSCANª
function. Following are brief descriptions of each.
*
[AS30175(R )09/95]
n
Fast forwarding the tape
*
[AS30180(R )01/95]
To fast forward the tape, press the ºFFª button. The radio
will begin playing until fast forward is manually stopped (by
pushing the ºTAPEª button) or the end of the tape is
reached.
*
[AS30185(R )01/95]
At the end of the tape, the direction automatically reverses
and plays the other side of the tape.
*
[AS30190(R )08/95]
n
Rewinding the tape
*
[AS30195(R )01/95]
To rewind the tape, press the ºREWª button. The radio will
begin playing until rewind is manually stopped (by pushing
the ºTAPEª button) or the beginning of the tape is reached.
File:09unasr.ex
Update:Wed May 1 13:49:43 1996

150
*
[AS30200(R )08/95]
n
Using the ºSEEKª function with your cassette tape player
*
[AS30205(R )08/95]
While in the tape mode, push the right (
a) side of the
ºSEEKª button to seek forward to the next selection on the
tape. Push the left (
b) side to seek the previous tape
selection.
*
[AS30210(R )08/95]
n
Using the ºSCANª function with your cassette tape player
*
[AS30215(R )01/95]
Press the ºSCANª button to begin the forward scan mode on
the tape currently playing, stopping on each tape selection
for approximately an eight-second sampling (display
indicates ºSCª).
*
[AS30220(R )01/95]
To stop the scan mode on the presently sampled tape
selection, press ºSCANª a second time.
*
[AS30225(R )08/95]
n
How to change the side of the tape being played
*
[AS30230(R )01/95]
The alternate side of the tape can be selected by pressing the
ºSIDE 1-2ª button.
*
[AS30235(R )08/95]
How to eject the tape
*
[AS30240(R )01/95]
To stop the tape and eject the cassette, press the ºEJª button.
The radio will resume playing if the radio power is on. The
tape cartridge can be ejected with radio power (and/or ignition)
on or off.
[AS30245(R )06/95]
HowtoswitchfromtapetoAM/FMmode
*
[AS30247(R )01/95]
Press the ºAM/FMª button to stop the tape player and resume
radio play.
*
[AS30250(R )08/95]
Using the DolbyHB noise reduction feature
*
[AS30255(R )08/95]
NOTE: Noise reduction system manufactured under license
from Dolby Labs Licensing Corporation. ºDolbyª and
double-D symbol are trademarks of Dolby
Laboratories Licensing Corporation.
File:09unasr.ex
Update:Wed May 1 13:49:43 1996

Electronic Sound Systems
151
*
[AS30260(R )04/95]
Push thekbutton to activate Dolby B Noise Reduction. Push
again to deactivate.
*
[AS30345(R )08/95]
Tips on Caring for the Cassette Player and Tapes
*
[AS30350(R )08/95]
In order to keep your cassette tape player performing the way it
was meant to, read and follow these simple precautions:
*
[AS30355(R )08/95]
n
Using a Ford Cassette Cleaning Cartridge to clean the tape
player head after 10-12 hours of play will help maintain the
best playback sound and proper tape operation.
*
[AS30360(R )08/95]
n
Only cassettes that are 90 minutes long or less should be
used. Tapes longer than 90 minutes are thinner and subject
to breakage or may jam the tape player mechanism.
*
[AS30365(R )08/95]
n
Protect cassettes from exposure to direct sunlight, high
humidity and extreme heat or cold. If they are exposed to
extreme conditions, allow them to reach a moderate
temperature before playing.
*
[AS30370(R )08/95]
n
If a tape is loose inside the cassette, tighten it before playing
by putting your finger or a pencil into one of the holes and
turning the hub until the tape is tight.
*
[AS30375(R )08/95]
n
Loose labels on cassette tapes can become lodged in the
mechanism. Remove any loose label material before inserting
cassette.
*
[AS30380(R )08/95]
n
Do not leave a tape in the cassette tape player. High heat in
the vehicle can cause the cassette to warp.
%*
[AS30401(ALL)08/95]
Clock Operation
*
[AS30411(ALL)08/95]
How to view the clock mode
[AS30421(ALL)09/94]
Press the ºCLKª button to display time. The time will continue
to be displayed until a radio or tape function is chosen. After
approximately 10 seconds, the time will again appear in the
display. To display radio or tape information only, press the
ºCLKª button a second time.
File:09unasr.ex
Update:Wed May 1 13:49:43 1996

152
[AS30431(ALL)09/95]
NOTE: The clock can be displayed or set whether the ignition
is on or off.
*
[AS30441(ALL)08/95]
How to set the clock
*
[AS30451(ALL)08/95]1.
Turn the radio on.
[AS30461(ALL)04/95]2.
Press and hold the ºCLKª button, press the right (
a) side of
the ºSEEKª button to increase hours. Press the left (
b) side
of the button to decrease hours. Press the right (
a) side of
the ºTUNEª button to increase minutes. Press the left (
b)
side of the button to decrease minutes.
*
[AS30471(ALL)09/95]
NOTE: The clock displays 12-hour time with no AM/PM
indications.
%*
[AS35200(ALL)08/95]
Common Radio Reception Conditions
*
[AS35300(ALL)08/95]
Several conditions prevent FM reception from being completely
clear and noise-free, such as the following:
*
[AS35400(ALL)08/95]1.
Distance/Strength
*
[AS35500(ALL)08/95]
The strength of the FM signal is directly related to the distance
the signal must travel. The listenable range of an average FM
signal is approximately 25 miles (40 kilometers). Beyond this
distance, the radio is operating in a fringe area and the signal
becomes weaker.
*
[AS35600(ALL)08/95]2.
Terrain
*
[AS35700(ALL)08/95]
The terrain (hilly, mountainous, tall buildings) of the area over
which the signal travels may prevent the FM signal from being
noise-free.
*
[AS35900(ALL)08/95]
If there is a building or large structure between the antenna and
station, some of the signal ºbendsª around the building, but
certain spots receive almost no signal. Moving out of the
ºshadowª of the structure will allow the station to return to
normal.
File:09unasr.ex
Update:Wed May 1 13:49:43 1996
