1996 FORD MUSTANG Owners Manual

15 [SR04695( ALL)09/95]
NOTE: When the combination lap/shoulder
belt is unbuckled and allowed to
retract completely, the retractor will
switch back to the vehicle sensitive
(emergency) locking mode. See the
detailed instructions underSafety Seats
for Childrenin this chapter.
% [SR04696(M )03/95]
Front Passenger Lap Belt Retractor
(Convertible Only)
[SR04697(M )10/95]
Your convertible is equipped with a dual locking
mode retractor on thelap beltpart of the
lap/shoulder belt for the front seat passenger.
[SR04698(M )10/95]
Dual locking mode passenger seat lap belt
retractors operate in two ways:
*
[SR04699(M )08/95]
Vehicle sensitive (emergency) locking mode
[SR04700(M )03/95]
In this operating mode, the lap belt retractor will
allow the occupant freedom of movement,
locking tight only on hard braking, hard
cornering or impacts of approximately 5 mph
(8 km/h) or more. The retractor cannot be made
to lock by pulling on the belt.
%*
[SR04701(M )08/95]
Automatic locking mode
*
[SR04702(M )06/95]
In this operating mode, the lap belt retractor will
remain locked and does not allow the occupant
freedom of movement. This mode provides the
following:
*
[SR04705(M )08/95]
q
A tight lap/shoulder belt on the occupant.
*
[SR04710(M )08/95]
q
Child safety seat installation.
[SR04715(M )03/95]
This modemust be usedwhen installing a
forward facing child safety seat on the front
passenger seat. To switch the retractor from
the vehicle sensitive (emergency) locking
mode to the automatic locking mode,
perform the following steps:
File:03rcsrm.ex
Update:Wed Mar 27 09:23:48 1996

16
*
[SR04720(M )09/95]
RWARNING
Never install a rear-facing child seat or
infant carrier in the right front passenger
seat.
[SR04725(M )03/95]
1. Buckle the lap/shoulder belt.
*
[SR04730(M )06/95]
2. Grasp the lap portion of the belt below the
child seat label. Pull upward until all of the
belt is extracted and a click is heard. At this
time, the lap belt retractor is in the
automatic locking mode (child restraint
mode).
*
[SR04735(M )03/95]
3. Allow the belt to retract. A clicking sound
will be heard as the belt retracts. This
indicates that the retractor is in the
automatic locking mode.
*
[SR04740(M )03/95]
4. Pull down on the belt to remove slack in the
belt.
*
[SR04745(M )08/95]
NOTE: When the combination lap/shoulder
belt is unbuckled and allowed to
retract completely, the retractor will
switch to the vehicle sensitive
(emergency) locking mode. See the
detailed instructions underSafety Seats
for Childrenin this chapter.
File:03rcsrm.ex
Update:Wed Mar 27 09:23:48 1996

17
*
[SR05400( ALL)07/95]
RWARNING
The lap belts should fit snugly and as low
as possible around the hips, not around
the waist.
*
[SR05600( ALL)05/95]
RWARNING
Failure to follow these precautions could
increase the risk and/or severity of injury
in a collision. 1) Use the shoulder belt on
the outside shoulder only. Never wear the
shoulder belt under the arm. 2) Never
swing it around your neck over the inside
shoulder. 3) Never use a single belt for
more than one person.
[SR05800( ALL)05/95]
To unfasten all the belts:
[SR05900(MBC )06/93]
1. Push the release button on the end of the
buckle. This allows the tongue to unlatch
from the buckle.
[SR06400(M )12/93]
quarter page art:0010559-F
Unfastening the front (coupes) and rear outboard
lap/shoulder belts
File:03rcsrm.ex
Update:Wed Mar 27 09:23:48 1996

18 [SR06500(M )08/93]
quarter page art:0010616-BUnfastening the Mustang convertible front outboard
lap/shoulder belts
*
[SR06600( ALL)03/95]
2. While the belt retracts, guide the tongue to
its stowed position. If you do not guide the
tongue, it may strike you or part of the
vehicle.
[SR06800(M )05/94]
3. (Coupe only). Place the belt in the belt
holder at the top of the seatback. The
retracted belt should be stored on this holder
when not in use, except when a passenger is
entering or leaving the rear seat area of the
vehicle.
File:03rcsrm.ex
Update:Wed Mar 27 09:23:48 1996

19 [SR06801(M )08/93]
half page art:0011198-A
Belt holder location Ð coupe only
[SR06805(M )05/94]
4. (Convertible only). Place the shoulder belt in
the belt holder at the top of the seatback and
place the lap belt in the belt guide at the
side of the seat cushion. The retracted belt
should be stored on this holder and in the
belt guide when not in use, except when a
passenger is entering or leaving the rear seat
area of the vehicle.
File:03rcsrm.ex
Update:Wed Mar 27 09:23:48 1996

20 [SR06806(M )08/93]
half page art:0010624-BBelt holder location Ð convertible only
[SR06820(M )08/93]
RWARNING
The shoulder belt must always be in the
belt holder when the belt is in use.
%*
[SR17500( ALL)08/95]
Safety Belt Extension Assembly
*
[SR17600( ALL)07/95]
For some people, the safety belt may be too
short even when it is fully extended. You can
add about eight inches (20 cm) to the belt length
with a safety belt extension assembly (part
number 611C22). Safety belt extensions are
available at no cost from your dealer.
*
[SR17700( ALL)08/95]
RWARNING
Failure to follow these instructions will
affect the performance of the safety belts
and increase the risk of personal injury.
File:03rcsrm.ex
Update:Wed Mar 27 09:23:48 1996

21
*
[SR17705( ALL)08/95]
Use only extensions manufactured by the same
supplier as the safety belt. Manufacturer
identification is located at the end of the
webbing on the label. Also, use the safety belt
extension only if the safety belt is too short for
you when fully extended. Do not use extension
to change the fit of the shoulder belt across the
torso.
%
*
[SR17710( ALL)08/95]
Safety Belt Maintenance
*
[SR17720( ALL)09/95]
Check the safety belt systems periodically to
make sure that they work properly and are not
damaged.
%*
[SR17730( ALL)08/95]
All safety belt assemblies, including retractors,
buckles, front seat belt buckle support assemblies
(slide bar) (if equipped), child safety seat tether
bracket assemblies (if equipped), and attaching
hardware, should be inspected after any
collision. Ford recommends that all safety belt
assemblies used in vehicles involved in a
collision be replaced. However, if the collision
was minor and a qualified technician finds that
the belts do not show damage and continue to
operate properly, they do not need to be
replaced. Safety belt assemblies not in use
during a collision should also be inspected and
replaced if either damage or improper operation
is noted.
%*
[SR17740( ALL)06/95]
Cleaning the Safety Belts
*
[SR17780( ALL)06/95]
Clean the safety belts with any mild soap
solution that is recommended for cleaning
upholstery or carpets. Do not bleach or dye the
belt webbing because this may weaken it.
File:03rcsrm.ex
Update:Wed Mar 27 09:23:48 1996

22
%*
[SR17800( ALL)06/95]
Air Bag Supplemental Restraint
System (SRS)
*
[SR18200( ALL)05/95]
The driver and right front passenger air bags are
Supplemental Restraint Systems (SRS), provided
at these seating positions in addition to the
lap/shoulder belt, and are designed to
supplement the protection provided to properly
belted occupants in moderate to severe frontal
collisions. The supplemental air bag system does
not provide restraint to the lower body.
%*
[SR18400( ALL)05/95]
The Importance of Wearing Safety Belts
*
[SR18425( ALL)06/95]
RWARNING
Safety belts must be worn by all vehicle
occupants to be properly restrained and
help reduce the risk of injury in a
collision.
*
[SR18450( ALL)05/95]
RWARNING
All occupants of the vehicle, including the
driver, should always wear their safety
belts, even when an air bag Supplemental
Restraint System is provided.
*
[SR18500( ALL)01/95]
There are four very important reasons to use
safety belts even with an air bag system. Use
your safety belts to:
*
[SR18600( ALL)01/95]
q
help keep you in the proper position (away
from the air bag) when it inflates
*
[SR18700( ALL)01/95]
q
reduce the risk of harm in rollover, side or
rear impact collisions, because an air bag is
not designed to inflate in such situations
*
[SR18800( ALL)01/95]
q
reduce the risk of harm in frontal collisions
that are not severe enough to activate the
supplemental air bag
*
[SR18900( ALL)01/95]
q
reduce the risk of being thrown from your
vehicle
