1996 FORD MUSTANG Owners Manual

6
*
[IN07190( ALL)07/95]
Paint damage resulting from fallout is not
related to a defect in paint materials or
workmanship and therefore is not covered by
warranty. Ford, however, believes that continual
improvement in customer satisfaction is a high
priority. For this reason, Ford has authorized its
dealers to repair, at no charge to the owner, the
surfaces of new vehicles damaged by
environmental fallout within 12 months or 12,000
miles (20,000 km) of purchase, whichever comes
first. Customers may be required to bring their
vehicle in for inspection by a Ford
representative.
%*
[IN07200( ALL)04/95]
Washing and Polishing Your Vehicle
*
[IN07300( ALL)04/95]
Wash the outside of your vehicle, including the
underside, with a mild detergent.
*
[IN07400( ALL)06/95]
DO NOT:
*
[IN07500( ALL)04/95]
q
Wash your vehicle with hot water
*
[IN07600( ALL)04/95]
q
Wash your vehicle while it sits in direct
sunlight
*
[IN07700( ALL)04/95]
q
Wash your vehicle while the body is hot
*
[IN08100( ALL)04/95]
Polish your vehicle to remove harmful deposits
and protect the finish.
File:02rcinm.ex
Update:Wed Mar 27 09:22:17 1996

7 %
*
[IN08200( ALL)04/95]
Cleaning Chrome and Aluminum Parts
*
[IN08300( ALL)04/95]
Wash chrome and aluminum parts with a mild
detergent. Do not use steel wool, abrasive
cleaners, fuel, or strong detergents.
%*
[IN08400( ALL)04/95]
Cleaning Plastic Parts
*
[IN08500( ALL)04/95]
Some of your vehicle's exterior trim parts are
plastic. Clean with a tar and road oil remover if
necessary. Use a vinyl cleaner for routine
cleaning.
*
[IN08600( ALL)04/95]
Do not clean plastic parts with thinners, solvents
or petroleum-based cleaners.
%*
[IN08700( ALL)04/95]
If you have your vehicle rustproofed, remove
oversprayed rustproofing with a tar and road oil
remover. If rustproofing is not removed from
plastic and rubber parts, it can cause
deterioration.
File:02rcinm.ex
Update:Wed Mar 27 09:22:17 1996

9
Safety Restraints
%*
[SR00500( ALL)04/95]
Important Safety Belt Information
*
[SR00600( ALL)03/95]
The use of safety belts helps to restrain you and
your passengers in case of a collision. In most
states and in Canada the law requires their use.
*
[SR00800( ALL)08/95]
Safety belts provide best restraint when:
*
[SR00900( ALL)08/95]
q
the seatback is upright
*
[SR01000( ALL)08/95]
q
the occupant is sitting upright (not slouched)
*
[SR01100( ALL)08/95]
q
the lap belt is snug and low on the hips
*
[SR01200( ALL)08/95]
q
the shoulder belt is snug against the chest
*
[SR01300( ALL)08/95]
q
the knees are straight forward
[SR01310(M )06/93]
q
seat belt is placed in guide on top of seat
*
[SR02100( ALL)07/95]
To help you remember to fasten your safety belt,
a warning light may come on and a chime may
sound. SeeSafety Belt Warning Light and Chimein
theWarning Lights and Gaugeschapter.
*
[SR02500( ALL)07/95]
See the following sections in this chapter for
directions on how to properly use these safety
belts. Also seeSafety Restraints for Childrenin this
chapter for special instructions about using
safety belts for children.
%*
[SR02600( ALL)05/95]
RWARNING
Make sure that you and your passengers
wear safety belts. Always drive and ride
with your seatback upright and the lap
belt snug and low across the hips.
File:03rcsrm.ex
Update:Wed Mar 27 09:23:48 1996

10
*
[SR02700( ALL)06/95]
RWARNING
Never wear the shoulder belt under the
arm. Never swing it around the neck over
the inside shoulder. Never use a single
belt for more than one person or across
more than one seating position. Each
seating position in your vehicle has a
specific safety belt assembly which is
made up of one buckle and one tongue
that are designed to be used as a pair.
Failure to follow these precautions could
increase the risk and/or severity of injury
in a collision.
*
[SR02801( ALL)05/95]
RWARNING
Ford recommends that all safety belt
assemblies and attaching hardware should
be inspected by a qualified technician
after any collision. Safety belt assemblies
not in use during a collision should also
be inspected and replaced if either
damage or improper operation is noted.
*
[SR02901( ALL)08/95]
RWARNING
To reduce the risk of serious injury in a
collision, children should always ride with
the seatback upright.
*
[SR03001( ALL)08/95]
RWARNING
Never let a passenger hold a child on his
or her lap while the vehicle is moving.
The passenger cannot protect the child
from injury in a collision.
File:03rcsrm.ex
Update:Wed Mar 27 09:23:48 1996

11
*
[SR03200( ALL)09/95]
RWARNING
Lock the doors of your vehicle before
driving to lessen the risk of the door
coming open in a collision.
%
*
[SR03700( ALL)05/95]
Combination Lap and Shoulder
Belts
*
[SR03800( ALL)01/95]
While your vehicle is in motion, the combination
lap and shoulder belt adjusts to your movement.
However, if you brake hard, corner hard or if
your vehicle receives an impact of 5 mph
(8 km/h) or more, the lap and shoulder belt
locks and helps reduce your forward movement.
*
[SR04100( ALL)05/95]
After you get into your vehicle, close the door
and lock it. Then adjust the seat to the position
that suits you best.
[SR04300(M )06/93]
Before fastening the front seat belt, make sure
the shoulder belt passes through the belt holder
on the top of the seatback.
[SR04400( ALL)06/93]
To fasten the belt,pull the lap/shoulder belt
from the retractor so that the shoulder portion of
the belt crosses your shoulder and chest. Be sure
the belt is not twisted. If it is, remove the twist.
Insert the belt tongue into the proper buckle
until you hear a snap and feel it latch. Make
sure the tongue is securely fastened in the
buckle.
File:03rcsrm.ex
Update:Wed Mar 27 09:23:48 1996

12 [SR04555(M )03/95]
one third page art:0011200-BFastening the front seat combination lap and shoulder belt
(coupe models)
[SR04557(M )03/95]
one third page art:0011225-B
Fastening the front seat combination lap and shoulder belt
(convertible models)
File:03rcsrm.ex
Update:Wed Mar 27 09:23:48 1996

13 [SR04650(M )03/95]
one third page art:0010502-A
Fastening the rear seat combination lap and shoulder belt
coupe and convertible
*
[SR04675( ALL)07/95]
NOTE: Be sure to read and understand
Important Safety Belt Informationat
the beginning of this chapter.
% [SR04678(M )03/95]
Safety Belts for Front Passenger (Coupe
Only) and Rear (Coupe and Convertible)
Outboard Seating Positions
[SR04681(M )03/95]
Your vehicle is equipped with a dual locking
mode retractor on the shoulder belt portion of
the combination lap/shoulder safety belt for
front seat passengers (coupe) and rear outboard
passenger seats (coupe and convertible).
*
[SR04682( ALL)08/95]
Dual locking mode retractors operate in two
ways:
*
[SR04683( ALL)08/95]
Vehicle sensitive (emergency) locking mode
[SR04684( ALL)03/95]
In this operating mode, the shoulder belt
retractor will allow the occupant freedom of
movement, locking tight only on hard braking,
hard cornering or impacts of approximately
5 mph (8 km/h) or more. The retractor can also
be made to lock by pulling/jerking on the belt.
File:03rcsrm.ex
Update:Wed Mar 27 09:23:48 1996

14 %
*
[SR04685( ALL)08/95]
Automatic locking mode
*
[SR04686( ALL)03/95]
In this operating mode, the shoulder belt
retractor will be automatically locked and remain
locked when the combination lap/shoulder
safety belt is buckled, and does not allow the
occupant freedom of movement. This mode
provides the following:
*
[SR04687( ALL)08/95]
q
A tight lap/shoulder belt fit on the occupant.
*
[SR04688( ALL)08/95]
q
Child seat or infant carrier installation
restraint.
*
[SR04689( ALL)09/95]
RWARNING
Never install a rear-facing child seat or
infant carrier in the right front passenger
seat.
*
[SR04690( ALL)09/95]
This modemust be usedwhen installing a child
safety seat on the front passenger seat and rear
outboard seats where dual locking retractors are
provided.
*
[SR04691( ALL)08/95]
To switch the retractor from the emergency
locking mode to the automatic locking mode,
perform the following steps:
*
[SR04692( ALL)08/95]
1. Buckle the lap/shoulder combination belt.
*
[SR04693( ALL)09/95]
2. Grasp the shoulder portion of the belt and
pull downward until all of the belt is
extracted and, when allowed to retract, a
clicking sound is heard. At this time, the belt
retractor is in the automatic locking mode
(child restraint mode).
*
[SR04694( ALL)10/95]
3. A clicking sound will continue to be heard
as the belt is allowed to retract.
File:03rcsrm.ex
Update:Wed Mar 27 09:23:48 1996
