1996 FORD MUSTANG Owners Manual

287 %
*
[SV41210( ALL)06/95]
Checking and Replacing Fuses
*
[SV41215( ALL)02/95]
If you need to check a fuse, follow these steps:
[SV41220(M )03/93]
1. Find the fuse panel cover below and to left
of the steering column, in the instrument
panel. Pull outward on the handle below the
word ªfusesº to expose the fuse panel.
Squeeze the two backing tabs and pull to
remove the cover.
[SV41235(M )03/93]
2. On the fuse panel cover, find the number of
the fuse you want to check. The following
fuse panel cover tells you where to locate
the fuse on the panel.
*
[SV41500(M )01/95]
3. Check the fuse to see if it is blown. Look
through the clear side of the fuse to see if
the metal wire inside is separated. If it is,
the fuse should be replaced.
[SV41550( ALL)05/92]
quarter page art:0010416-A
The side view of a fuse
*
[SV41800(M )11/94]
4. Replace the fuse with one that has the right
amperage rating. (See the following chart.)
[SV41900( ALL)07/95]
eight pica chart:0001092-BFile:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996

288 [SV41910(M GV)01/94]
six pica chart:0001093-B
*
[SV42500( ALL)08/95]
RWARNING
Always replace a fuse with one that has
the specified amperage rating. Using a
fuse with a higher amperage rating can
cause severe wire damage and could start
a fire.
*
[SV42650(M )01/95]
5. Replace the cover.
*
[SV42800( ALL)01/95]
Even after you replace a fuse, it will continue to
blow if you do not find what caused the
overload. If the fuse continues to blow, have
your electrical system checked.
%*
[SV42900( ALL)03/95]
Circuit Breakers
*
[SV43000( ALL)01/95]
If you need to check a circuit breaker that is on
the fuse panel, seeChecking and replacing fusesin
this chapter to find out how to locate the fuse
panel.
[SV43200( ALL)12/94]
Circuit breakers will reset themselves and allow
the electrical parts to work again once the
overload on the circuit is removed. If the circuit
breakers continue to cut off electricity, have your
vehicle's electrical system checked.
*
[SV43250( ALL)02/95]
Diagnostic equipment is needed to check circuit
breakers. Refer to the manufacturer's
instructions.
*
[SV43300( ALL)08/95]
If you replace a circuit breaker, use one with the
same amperage rating. To remove a circuit
breaker mounted in the fuse panel, grip it with
your finger and thumb and pull it straight out
of its socket.
File:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996

289
*
[SV43800(M GV)02/95]
Since the circuit breaker for the headlamps is
mounted in the headlamp switch, you must
replace the entire switch to install a new circuit
breaker.
%
*
[SV44400( ALL)03/95]
Lights and Bulb Replacement
*
[SV44500( ALL)01/95]
It is a good idea to check the operation of the
following lights frequently:
*
[SV44600( ALL)01/95]
q
headlamps
*
[SV44700( ALL)01/95]
q
tail lamps
*
[SV44800( ALL)01/95]
q
brakelamps
*
[SV44900( ALL)01/95]
q
hazard flasher
*
[SV44950( ALL)02/95]
q
high-mount brakelamp
*
[SV45000( ALL)01/95]
q
turn signals
*
[SV45200( ALL)01/95]
q
license plate lamp
[SV45400(M )08/93]
q
fog lamps (GT and Cobra models)
%*
[SV45600( ALL)01/95]
The alignment of your headlamps should be
checked if:
*
[SV45700( ALL)01/95]
q
oncoming motorists frequently signal you to
turn off your vehicle's high beams when you
do not have the high beams on
*
[SV45800( ALL)01/95]
q
the headlamps do not seem to give you
enough light to see clearly at night
*
[SV45900( ALL)01/95]
q
the headlamp beams are pointed substantially
away from a position slightly down and to
the right
File:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996

290 %
*
[SV46000( ALL)03/95]
Headlamp Bulb
*
[SV46100( ALL)01/95]
The headlamps on your vehicle use replaceable
bulbs. When the lamp burns out, simply replace
the bulb, rather than the whole lamp.
*
[SV46200( ALL)05/95]
RWARNING
Handle a halogen headlamp bulb carefully
and keep out of children's reach. Grasp
the bulb only by its plastic base and do
not touch the glass. The oil from your
hand could cause the bulb to break the
next time the headlamps are operated.
*
[SV46300( ALL)01/95]
Do not remove the burned-out bulb unless you
can immediately replace it with a new one. If a
bulb is removed for an extended period of time,
contaminants may enter the headlamp housing
and affect its performance.
[SV46450(M )03/90]
quarter page art:0010536-A
Parts of a headlamp
*
[SV46600( ALL)03/95]
Removing the headlamp bulb
*
[SV46700( ALL)01/95]
1. Make sure that the headlamp switch is in
the OFF position.
[SV46705(M )05/95]
2. Open the hood and locate the headlamp
access cover. Remove the plastic pushpin.
File:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996

291 [SV46710(M )05/95]
quarter page art:0011232-B
Headlamp access covers
[SV46875(M )08/93]
3. Lift the cover and find the bulb in the
headlamp socket.
[SV47125(M )06/93]
4. Remove the electrical connector from the
bulb by lifting the connector clip upward
while pulling the connector rearward.
[SV47250(M )08/93]
5. Remove the retaining ring by turning
counterclockwise 1/8 of a turn to free it
from the socket. Then slide the ring off the
plastic base.Keep the ring.You must use it
again to hold the new bulb in place.
[SV47300(M )11/92]
6. Carefully remove the bulb assembly from its
socket by gently pulling it rearward without
turning.
File:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996

292
*
[SV47400( ALL)03/95]
Installing the headlamp bulb
*
[SV47600(MBC )02/95]
1. With the flat side of the bulb's plastic base
facing upward, insert the glass end of the
bulb into the socket. You may need to turn
the bulb left or right to line up the grooves
in the plastic base with the tabs in the
socket. When the grooves are aligned, push
the bulb into the socket until the plastic base
contacts the rear of the socket.
*
[SV47800(MBC )08/95]
2. Slip the bulb retaining ring over the plastic
base until it contacts the rear of the socket.
Lock the ring into the socket by rotating it
clockwise until you feel a ªstop.º
*
[SV47900( ALL)02/95]
3. Push the electrical connector into the rear of
the plastic base until it snaps, locking it into
position.
*
[SV48000(MBC )02/95]
4. Turn the headlamps on and make sure that
they work properly. If the headlamp was
correctly aligned before you changed the
bulb, you should not need to align it again.
[SV48075(M )05/95]
5. Reinstall the headlamp cover pushpin and
tighten until snug.
File:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996

293 %
*
[SV51600( ALL)10/92]
Using the Right Bulbs
[SV51700(M )05/95]
thirty-six pica chart:0010438-GFile:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996

294
%*
[SV52400( ALL)03/95]
Emission Control System
*
[SV52500( ALL)05/95]
Your vehicle is equipped with a catalytic
converter which enables your vehicle to comply
with applicable exhaust emission requirements.
*
[SV52550( ALL)06/95]
RWARNING
Exhaust leaks may result in the entry of
harmful and potentially lethal fumes into
the passenger compartment. Under
extreme conditions excessive exhaust
temperatures could damage the fuel
system, the interior floor covering, or
other vehicle components, possibly
causing a fire.
*
[SV52600( ALL)05/95]
To make sure that the catalytic converter and the
other emission control parts continue to work
properly:
*
[SV52700( ALL)01/95]
q
Use only unleaded fuel.
*
[SV52800( ALL)01/95]
q
Avoid running out of fuel.
*
[SV52900( ALL)01/95]
q
Do not turn off the ignition while your
vehicle is moving, especially at high speeds.
*
[SV52950( ALL)01/95]
q
Do not push start your vehicle.
*
[SV53000( ALL)03/95]
q
Have the services listed in theMaintenance
Schedule and Recordbooklet performed
according to the specified schedule. The
scheduled maintenance services are required
because they are considered essential to the
life and performance of your vehicle and to
its emissions system.
*
[SV53075( ALL)03/95]
In general, maintenance, replacement, or service
of the emissions control devices or systems in
your new Ford Motor Company vehicle or
engine may be performed at your expense by
any automotive repair establishment or
individual using automotive parts equivalent to
File:15rcsvm.ex
